Variant Path Types for Scalable Extensibility

Atsushi Igarashi (Kyoto Univ.) joint work with Mirko Viroli (Univ. Bologna)

Background: Scalable Extensibility

• Language support

– for extending program components – which can be uniformly applied to

components of different scales:

• classes, groups of classes, groups of

groups, and so on

• Lot of work on this issue has emerged recently

(gbeta, Scala, Concord, CaesarJ, JX, J&)

Extending a Group of Classes

• Inheritance of hierarchies of nested classes

– a.k.a higher-order hierarchies [Ernst03]

class AST { } class Exp { } class Plus ext Exp{ } class Eval extends AST { } class Exp { } class Plus ext Exp{ }

Implicit extension

How “Nested” Inheritance Works

[Ernst99][JX] Complete definition of a class is obtained by

• combining bodies of superclasses with possible

method overriding

• propagating combination down recursively

class Eval { // extends AST // defs inherited from AST // Eval's own defs (with overriding) } class Exp {

// from AST.Exp

class Plus ext Exp{ // from AST.Plus

// from Eval.Exp

} // from Eval.Plus }

Two Styles of Semantics

• Nested classes as (dynamic) attributes of objects

[gbeta,Scala]

– Run-time type = instance id (a) + class (Plus) – Naturally lead to a dependent type system

• Nested classes as (static) attributes of

classes/groups [JX, Concord, Bruce03WOOD]

– Run-time type = fully qualified name of class

var a = new AST(); var p = new a.Plus(); var p = new AST.Plus();

This Paper

• Addresses typing issues for the second semantics

– Without using dependent types

• Less complication
• Less interaction with side effects

– With rich subtyping by variant path types

• Formalizes the type system as a core language

FJpath

• States a type safety theorem

– Hand-written proofs finished

Outline of the Talk

• Preliminary Syntax
• Variant Path Types
• Related Work
• Conclusion

Syntax of FJpath (ver. 0.1)

Looks like FJ + (static) nested classes T ::= (to be filled) L ::= class C extends C { ~T ~f; ~L ~M } M ::= T m(~T ~x){ return e; } e ::= x | this | e.f | e.m(~e) | new T(~e)

Example

class AST { class Exp { method print() { ... } } class Const extends Exp { field v; method print() { ... } } class Plus extends Exp { field right, left; method print() { ... } } }

class Eval extends AST { class Exp { method eval() {...} } class Const extends Exp { method eval() { return this.v; } } class Plus extends Exp { method eval() { return right.eval()+left.eval(); } } }

Outline of the Talk

• Preliminary Syntax
• Variant Path Types

– Relative and absolute path types – Exact types for safety – Exact and inexact qualifications – Parametric methods

• Related Work
• Conclusion

Requirements for a Type System

It should

• be able to express intra-relationship of classes

– l“m takes an expression of the same group”

• Preserved by group extension
• achieve type safety (of course!)

Relative Path Types for Intragroup Reference

• This always refers to the current class
• ^This to refer to the enclosing class

– ^This.C for a sibling

• ^^This for the further enclosing class, and so on

class AST { class Exp { bool eq1( This exp) {...} bool eq2( ^This.Exp exp) {...} } class Plus extends Exp { ^This.Exp left,right; ... } }

Resolution of Relative Path Types

• The signature of a method (or a field type) is

computed by substituting

– the (static) type of the receiver for This – a prefix of the receiver type for ^...^This

• left of AST.Plus is AST.Exp
• left of Eval.Plus is Eval.Exp
• AST.Exp.eq1() takes AST.Exp
• AST.Exp.eq2() takes AST.Exp
• AST.Const.eq1() takes AST.Const
• AST.Const.eq2() takes AST.Exp

eq1(This e); eq2(^This.Exp e);

Exact Types for Safety

• Assuming AST.Plus being a subtype of AST.Exp

can break the type system (as usual)

• Exact types [Bruce] solve the problem

– Exact type @(AST.Plus) (subtype of AST.Plus)

includes only instances of class AST.Plus

– Invocation of method taking This (with ^) must be

• n an exact type

AST.Exp e1 = new AST.Plus(); AST.Exp e2 = new AST.Const(); bool b = e1.eq(e2);

Making Subtying Finer-Grained ...

• AST.Exp for all expressions of all ATSs
• @(AST.Exp) for the Exp of the ATS
• Any way to specify e.g., classes of a certain

group?

class Exp { } class Plus ext Exp{ } class Exp { } class Plus ext Exp{ } @(AST.Exp) @(Eval.Exp) @(AST.Plus) AST.Exp

... By Generalizing @ as Qualification

• It's natural to view @ as qualification!

– fully exact type: @AST@Plus – partially exact type: @AST.Exp, AST@Plus

• Inclusion gives rise to subtyping

class Exp { } class Plus ext Exp{ } class Exp { } class Plus ext Exp{ } @AST@Exp @Eval.Exp AST@Plus AST.Exp

Restriction on Method Invocations

• All occurrences of ^...^This in argument types

have to be replaced with fully exact types

– It doesn't necessarily mean the receiver type

must be (fully) exact!

@AST@Exp e1; e1.eq1(...); // @AST@Exp -> bool e1.eq2(...); // @AST.Exp -> bool AST.Exp e2; e2.eq1(...); // not allowed e2.eq2(...); // not allowed @AST.Exp e3; e3.eq1(...); // not allowed e3.eq2(...); // @AST.Exp -> bool

eq1(This e); eq2(^This.Exp e);

Revised Syntax

A ::= C | A@C absolute path types E ::= ^...^This | @C | E@C exact types T ::= ^...^This | C | @C | T.C | T@C types L ::= class C extends C { ~T ~f; ~L ~M } M ::= T m(~T ~x){ return e; } e ::= x | this | e.f | e.m(~e) | new A(~e)

Outline of the Talk

• Preliminary Syntax
• Variant Path Types

– Relative and absolute path types – Exact types for safety – Exact and inexact qualifications – Parametric methods

• Related Work
• Conclusion

Exact Type Parameters for “Group-Polymorphic” Methods

Consider a method to replace both operands of Plus with a given expression

• Such a group-polymorphic method can be

described by a parametric method as in Java 5.0

[Igarashi-Saito-Viroli05]

– X must range only over exact types – Otherwise, the caller could pass nodes from

different kinds of expressions

<exact X extends AST> void repl_left(X@Plus p, X.Exp e){ p.left = e; p.right = e; }

Revised^2, Final Syntax

A ::= @C | A@C absolute path types E ::= ^...^This | ^...^X | @C | E@C exact types T ::= ^...^This | ^...^X | @C | C | T.C | T@C types L ::= class C extends C { ~T ~f; ~L ~M } M ::= <~X extends ~T> T m(~T ~x){ return e; } e ::= x | this | e.f | e.m<~T>(~e) | new A(~e)

Variant Path Types: Summary

• Relative Path Types

– for describing intragroup relationship

• Exact/inexact qualifications

– for fine-grained control over exactness and

subtyping

• Parametric methods w/ exact type variables
• FJpath = FJ + nested inheritance + variant path

types + parametric methods

– Formalization and Type Soundness Theorem

(See the paper!)

Outline of the Talk

• Informal Semantics of Inheritance
• Variant Path Types

– Relative and absolute path types – Exact types for safety – Exact and inexact qualifications – Parametric methods

• Related Work
• Conclusion

Related Work

• gbeta, Caesar/J
• Scala
• Nested Inheritance/Intersection (JX) [Nystrom et al.]
• Concord [Jolly-Drossopoulou-Anderson-Ostermann]
• Lightweight family polymorphism [Igarashi-Saito-

Viroli05]

• Bruce's series of work on binary methods,

matching, statically type safe virtual types, and LOOJ

• Variant parametric types (Java wildcards)

Comparison with Variant Parametric Types (Java wildcards)

Variant parametric types

• Invariant types C<T>

– C<S> <: C<T> if S = T

• Covariant types C<+T>

(C<? extends T>)

– C<+S> <: C<+T> if S <: T – C<T> <: C<+T> – restricted method access

List<+Num> List<Int> List<Dbl> MyList<+Num> Basic.Exp Basic@Var Basic@Plus Eval.Exp MyList<Int> @Eval@Var

Variant path types

• Invariant qualification “@”

– T@C <: T@D if C = D

• Covariant qualification “.”

– T.C <: T.D if C extends D – T@C <: T.C – restricted method access

Types in JX [Nystrom et al.]

• Dependent classes: x.class, x.f.class
• Prefix types: C[T]

– The innermost enclosing class of T that is a

subclass of C

– AST[this.class].Exp ≈ ^This.Exp

• Inheritance is subtyping

void repl_left(AST.Plus p, AST[p.class].Exp e){ p.left = e; }

Conclusion

Variant path types as an alternative to dependent types in the context of nested inheritance

• Clear separation of types and values possible
• Fine-grained control over subtyping by two kinds
• f qualification

Ongoing/future work:

• Mechanism to locally “exactize” .C types?
• Type inference for parametric methods

– Preliminary results in a simpler setting [Igarashi-

Saito-Viroli05]

• Metatheory for typechecking
