SLIDE 1
Considerations
▪ Evacuation conditions ▪ Validation of software ▪ Simulex algorithm ▪ Selection of occupants ▪ Construction of geometry ▪ In practice
2
Validating a Simulex Model Brian Thompson, P.E. AEGIS Engineering - - PowerPoint PPT Presentation
Validating a Simulex Model Brian Thompson, P.E. AEGIS Engineering - - PowerPoint PPT Presentation
Validating a Simulex Model Brian Thompson, P.E. AEGIS Engineering Considerations Evacuation conditions Validation of software Simulex algorithm Selection of occupants Construction of geometry In practice 2 Evacuation
SLIDE 2
SLIDE 3
3
Evacuation Conditions
SLIDE 4
Simulation Parameters
▪ Occupants accounted for ▪ Environmental conditions ▪ Movement characteristics
4
SLIDE 5
Occupant Accounting
▪ Partial Evacuation ▪ Full Evacuation
5
SLIDE 6
Model Environment
▪ Smoke-free ▪ Accumulating smoke layer ▪ Near tenability threshold
6
SLIDE 7
State-of-Mind
▪ Laissez-faire/flippant ▪ Intentional/reasoned ▪ Frightened/panicked
7
SLIDE 8
8
Validation of Software
SLIDE 9
Partial Behavioral
▪ Rates of body twist ▪ Acceleration/deceleration ▪ Speed fluctuations ▪ Inter-person distance
9
SLIDE 10
Validation Tests
▪ Department stores ▪ Office buildings ▪ Lecture theatres ▪ Sports stadia egress areas ▪ University buildings ▪ Mock-up building geometries
10
SLIDE 11
Lecture Theatre
▪ 1-story + intermediate floor ▪ 278 occupants ▪ Simulex travel time: 93 sec. ▪ Actual travel time: 90 sec. ▪ IBC (93 x 1.5) = 140 sec.
11
SLIDE 12
Law School
▪ 5-story ▪ 494 occupants ▪ Simulex travel time: 161 sec. ▪ Actual travel time: 170 sec. ▪ IBC (161 x 1.5) = 242 sec.
12
SLIDE 13
Business School
▪ 8-story ▪ 716 occupants ▪ Simulex travel time: 178 sec. ▪ Actual travel time: 220 sec. ▪ IBC (178 x 1.5) = 267 sec.
13
SLIDE 14
14
Simulex Algorithm
SLIDE 15
Operations
▪ Evaluates building geometry ▪ Creates “distance map” ▪ Preset occupant population ▪ Occupants follow shortest path
15
SLIDE 16
Distance Map
▪ Travel distance isolines ▪ Geometry gaps
16
SLIDE 17
Occupant Travel
▪ Aligned with distance map ▪ Perpendicular to isolines ▪ Inability to get unstuck
17
SLIDE 18
18
Occupant Population
SLIDE 19
Population Group
▪ Body size variable ▪ Speed 0.8 - 1.7 m/s
19
SLIDE 20
Location
▪ Boundary-free ▪ Distance map
20
SLIDE 21
21
Construction
- f Geometry
SLIDE 22
Building Geometry
▪ Refinement ▪ Alterations ▪ Iterative modifications
22
SLIDE 23
Refinement
▪ Automatic ▪ Manual
23
SLIDE 24
Alterations
▪ Aisle width ▪ Narrow gaps
24
SLIDE 25
Iterative Modifications
▪ Remove impediments ▪ Modify distance map
25
SLIDE 26
26
Case Studies
SLIDE 27
Sample Projects
▪ Multi-purpose arena ▪ Theatre
27
SLIDE 28
Multi-Use Arena
▪ Trade shows ▪ Sporting events ▪ Concerts
28
SLIDE 29
Trade Show
SLIDE 30
Observations
▪ Distributed population ▪ Generally free movement
30
SLIDE 31
31
Sporting Event
SLIDE 32
Observations
▪ Concentrated population ▪ Restricted movement
32
SLIDE 33
33
Grandstands
SLIDE 34
34
Divide Rows
SLIDE 35
35
Eliminate Gap
SLIDE 36
36
Exit Distribution
SLIDE 37
37
Engineering Judgment
▪ Reduce bleacher depth ▪ Limit travel in seating row ▪ Invert exit access
SLIDE 38
38
Concert
SLIDE 39
Time 0:15
SLIDE 40
Time 0:30
SLIDE 41
Time 0:45
SLIDE 42
Time 1:45
SLIDE 43
Time 2:45
SLIDE 44
Time 3:30
SLIDE 45
Time 4:30
SLIDE 46
Time 6:00
SLIDE 47
Engineering Judgment
▪ Limit travel within row ▪ Forced exit distribution ▪ Queuing vs. available exits
SLIDE 48
Tiered Theatre Seating
SLIDE 49
Time 1:00
SLIDE 50
Time 3:30
SLIDE 51
Time 5:00
SLIDE 52
Time 6:00
SLIDE 53
Time 8:00
SLIDE 54
Time 9:30
SLIDE 55
Time 11:00
SLIDE 56
Engineering Judgment
▪ Deleted seat obstructions ▪ Limited travel within row ▪ Forced exit distribution ▪ Queuing vs. available exits ▪ Account for jams
56
SLIDE 57
Validation Factors
▪ Comparable to test data ▪ Absence of panic ▪ Aisles equalize rows ▪ Queuing vs. exit availability ▪ Rational manipulations
57
SLIDE 58
Potential Refinement
▪ Multi-story stairs ▪ Effects of pillar at exit ▪ Alter movement speed
58
