USING HIGH–THROUGHPUT COMPUTING FOR DYNAMIC SIMULATION OF BIPEDAL WALKING

Mohammadhossein Saadatzi, Anne K. Silverman, Ozkan Celik

slide-2
SLIDE 2

1  Simulation framework for combined human bipedal

walking and wearable robots

 Introduction  Problem definition  Using HTC to solve the problem

 Applications of the prepared framework

 A passive hip exoskeleton  Walking energetics at different speeds

Outline

slide-3
SLIDE 3

2

Introduction

 Previously, high-throughput computing (HTC) was used

for stochastic simulation and analysis of human movements [1,2].

 By considering parametric uncertainty in musculoskeletal model,

HTC was used to investigate cartilage loading in the knee during movement.

 Simulations of movement are traditionally performed

using generic models with assumed parameters and geometries.

 Population variability and parametric uncertainty become

critically important to consider when interpreting model predictions [1,2].

[1] Smith CR, et al. J Knee Surg, 29 (2), 99-106, 2016. [2] Smith CR, et al. J Biomech Eng, 138 (2), 021017, 2016.

slide-4
SLIDE 4

3

Introduction

 Simulations and dynamic optimization for investigation

human biomechanics and human-robot interaction.

 We have developed a

framework for combined simulation of human bipedal walking and exoskeletons [1].

 Simulation of human bipedal walking through muscle

actuation presents an optimization problem with a substantial number of parameters [2,3].

[1] Saadatzi M, et al. Proceedings of 41st ASB, 451–452, 2017. [2] Miller RH. J Biomech, 47 (6), 373–1381, 2014. [3] Umberger BR, J. Royal Soc. Interface, 7 (50), 1329-1340, 2010.

slide-5
SLIDE 5

4

Introduction

 Calculation of the cost function for this optimization

problem, necessitates significant computational power [1].

 Because of the redundant nature

  • f the human musculoskeletal system,

the problem is highly prone to getting stuck in local minima.

 Researchers have chosen to solve the

problem several times [2-5].

 Miller [2], single step, 4 times, 2.5 days using HPC.  Umberger [3], single step, 10 times.  Ong et al. [4], 10 seconds, 20 times.

 They used the best solution to seed another round of 20 optimizations.  This process was repeated until the change was less than 5%.

[1] Ackermann M, van den Bogert AJ, J Biomech, 43 (6), 1055–1060, 2010. [2] Miller RH. J Biomech, 47 (6), 373–1381, 2014. [3] Umberger BR, J. Royal Soc. Interface, 7 (50), 1329-1340, 2010. [4] Ong CF, et al. IEEE Trans Biomed Eng, 63 (5), 894–903, 2016. [5] Ong CF, et al. Proceedings of ISB-TGCS, 19–20, 2017.

slide-6
SLIDE 6

5

Introduction

We use HTC as a tool to perform computations related to predictive simulation of human bipedal walking through muscle actuation.

slide-7
SLIDE 7

6

Problem definition

[1] Farris RJ, et al. IEEE Trans Neural Syst Rehabil Eng, 19(6), 652-659, 2011. [2] Delp SL, et al. IEEE Trans Biomed Eng, 54 (11), 1940-1950, 2007.

Exoskeleton structure and control parameters

Human-exoskeleton kinematic and dynamic data

Optimization Algorithm Objective function Forward dynamic simulation Actuation profile Human-exoskeleton combined model

slide-8
SLIDE 8

7

Problem definition:

Human-exoskeleton model

The musculoskeletal model has 9 sagittal degrees of freedom and 18 muscle groups (24 muscles):

 DOFs: pelvis tilt, two planar pelvis translations,

hip and knee flexion/extension, ankle plantar/dorsiflexion

 Muscle groups: soleus, vasti,

gastrocnemius, tibialis anterior, bicep femoris short head, hamstring, rectus femoris, gluteus maximus, and iliopsoas.

slide-9
SLIDE 9

8

Human-exoskeleton combined model

Problem definition

[1] Farris RJ, et al. IEEE Trans Neural Syst Rehabil Eng, 19(6), 652-659, 2011. [2] Delp SL, et al. IEEE Trans Biomed Eng, 54 (11), 1940-1950, 2007.

Exoskeleton structure and control parameters

Human-exoskeleton kinematic and dynamic data

Optimization Algorithm Objective function Actuation profile Forward dynamic simulation

slide-10
SLIDE 10

9

Problem definition:

Forward dynamic simulation

Two controller states are considered, corresponding to stance and swing phases.

Swing

Heel strike

Stance

Toe off Heel strike

slide-11
SLIDE 11

10

Human-exoskeleton combined model

Problem definition

[1] Farris RJ, et al. IEEE Trans Neural Syst Rehabil Eng, 19(6), 652-659, 2011. [2] Delp SL, et al. IEEE Trans Biomed Eng, 54 (11), 1940-1950, 2007.

Human-exoskeleton kinematic and dynamic data

Optimization Algorithm Objective function Forward dynamic simulation Actuation profile Exoskeleton structure and control parameters

slide-12
SLIDE 12

11

Problem definition:

Actuation/exoskeleton parameters

Actuation profile of each muscle is defined as two piecewise linear functions

 One with 6 parameters for stance phase,

and

 One with 4 parameters for swing phase.

The values of signals at discretized points constitute the optimization parameters.

Exoskeleton structure and control parameters

slide-13
SLIDE 13

12

Human-exoskeleton combined model

Problem definition

[1] Farris RJ, et al. IEEE Trans Neural Syst Rehabil Eng, 19(6), 652-659, 2011. [2] Delp SL, et al. IEEE Trans Biomed Eng, 54 (11), 1940-1950, 2007.

Exoskeleton structure and control parameters Optimization Algorithm Forward dynamic simulation Actuation profile Objective function

Human-exoskeleton kinematic and dynamic data

slide-14
SLIDE 14

13

Problem definition:

Objective function

 A weighted combination of several cost

functions constitutes our optimization goal:

 Duration of walking  Target velocity error  Excessive alternating motion of the upper body  Metabolic expenditure of muscles

Objective function

slide-15
SLIDE 15

14

Human-exoskeleton combined model

Problem definition

[1] Farris RJ, et al. IEEE Trans Neural Syst Rehabil Eng, 19(6), 652-659, 2011. [2] Delp SL, et al. IEEE Trans Biomed Eng, 54 (11), 1940-1950, 2007.

Exoskeleton structure and control parameters

Human-exoskeleton kinematic and dynamic data

Objective function Forward dynamic simulation Actuation profile Optimization Algorithm

slide-16
SLIDE 16

15

Problem definition:

Optimization Algorithm

 Covariance Matrix Adaptation (CMA) [1].

 Previously has successfully been used for

simulation of bipedal walking [2-4].

 Available with OpenSim API.

 We use the computed muscle control

(CMC) method to generate favorable initial optimization parameters,

 which reduces convergence time and

probability of getting stuck in local minima.

[1] Hansen N, et al. Evol Comput, 11(1), 1–18, 2003. [2] Wang JM, et al. ACM Trans Graph, 31(4), 2012. [3] Dorn TW, et al. PLOS ONE, 10 (4), 1-16, 2015. [4] Ong CF, et al. Proceedings of ISB-TGCS, 19–20, 2017.

Optimization Algorithm

slide-17
SLIDE 17

16  HTC enables the use of many computers and cores

simultaneously

 Ideally, we would like to combine the results from several

computers to reduce

 necessary time for the convergence of our optimization  probability of getting stuck in local minima

Methods

[1] Sfiligoi I, et al. IEEE-CSIE, 428–432, 2009. Pordes, R et al. J Phys Conf Ser 78 (1), 012057, 2007. [2]

HTC

slide-18
SLIDE 18

17

Methods:

High-level algorithm

 We run several instances of our optimization, and combine

their results periodically to generate a more efficient

  • ptimization algorithm.

 We seed a round of optimization on remote computers with different

sets of initial optimization parameters.

 We compare and combine their results to generate initial

  • ptimization parameters for subsequent optimizations.

Initialization Compare & combination Optimization Optimization Optimization Convergence Detection Submit server Remote computers

slide-19
SLIDE 19

18  Directed Acyclic Graph Manager (DAGMan): a meta-

scheduler for the execution of programs (computations)

 DAG file is used by DAGMan when submitting programs.

Methods:

High-level algorithm

PS.dag # Predictive Simulation DAG Job PSitr PSitr.sub SCRIPT PRE PSitr initPop.sh SCRIPT POST PSitr nextItrPrep.sh RETRY PSitr 10 InitPop.sh Prescript Postscript Job

J1 J2 J3 Jn J4

PSitr: PSitr.sub Retry NextItrPrep.sh

slide-20
SLIDE 20

19

Methods:

High-level algorithm

 Prescript bash “initPop.sh”

generates the initial population.

 Postscript bash

“nextItrPrep.sh” generates the population for the next iterations.

 We used the best results to

seed the following iterations of

  • ptimizations.

 Job “PSitr”, runs the sub-

jobs, which consist of the

  • ptimizations of each round.

InitPop.sh Prescript Postscript Job

J1 J2 J3 Jn J4

PSitr: PSitr.sub Retry NextItrPrep.sh

slide-21
SLIDE 21

20

Methods:

Individual jobs

PSitr.sub # Jobs submit file

executable = myExe.sh arguments = $(Process) transfer_input_files = bipedWalkingOptFiles.tar.gz, pop/bestParametersBinary.$(Process) transfer_output_files = bestSoFarLog_$(Process).txt, bestParametersBinary_$(Process) periodic_remove = (CurrentTime - QDate) > 4200 queue 100

slide-22
SLIDE 22

21

Results & discussion

 We tested different intervals of running individual jobs, and explored fixed

and adaptive initial step-size of the CMA algorithm

 OSG 8-core computers (3.89) and AWS 36-core instance (3.86). Doesn’t walk the entire duration Walks the entire duration, when gets smaller becomes more realistic OSG 8-core computers, and AWS 36-core computer

slide-23
SLIDE 23

22

Conclusion & future work

 Our results suggest that HTC is a promising tool for

solving computationally expensive optimization problems, which arise during forward dynamic simulation of human movement

 Using conventional algorithms for combining the results of

remote computers

 In [1], a HTC based distributed genetic algorithm is presented for

solving building energy optimization problem.

 In [2], a pattern search optimization method is used for combination

  • f HTC resources to maximize capacity of electrical transmission

lines.

[1] Yang C, et al. Energ Buildings, Anderson EJ, Linderoth J, IEEE Trans. Smart Grid, 8 (3), 1427–1435, 2017. 76, 92–101, 2014. [2]

slide-24
SLIDE 24

23  Simulation framework for combined human bipedal

walking and wearable robots

 Introduction  Problem definition  Using HTC to solve the problem

 Applications of the prepared framework

 A passive hip exoskeleton  Walking energetics at different speeds

Outline

slide-25
SLIDE 25

24

 Iliopsoas performs negative work in the first half of the gait cycle.

 Could potentially be replaced by a torsional spring.

 Energy stored in the spring during the first half of the stride can be used during

the rest of the stride to fulfill the positive work normally done by Iliopsoas.

[1] S. H. Collins et al., Nature, vol. 522, no. 7555, pp. 212–215, Jun. 2015.

10 20 30 40 50 60 70 80 90 100

Hip (Deg)

  • 40
  • 20

20

Joint Kinematics Stride Phase (%)

10 20 30 40 50 60 70 80 90 100

Muscle Force (BW)

1 2

ILPSO

Estimated from Experimental Data Simulated

Negative work Positive work

Example: A Passive Hip Exoskeleton

slide-26
SLIDE 26

25

 Based on our framework, an optimal spring is predicted to decrease the metabolic

cost of walking by 10.3%.

Stiffness of 0.99 (Nm/deg)

Equilibrium angle of 10.04 (deg) flexion  The hip exoskeleton replaces majority of the work done by the Iliopsoas muscle.

[1] Uchida TK ,et al. PLOS ONE 11(9), 1-16, 2016.

Example: A Passive Hip Exoskeleton

Normal With Exo Average metabolic power (W/kg) 1 2 3 4 5 6 7 ILPSO GMAX Other Muscles

slide-27
SLIDE 27

26

 Our simulation framework captured a realistic parabolic trend

across speed

 Among the seven simulated speeds, the minimum cost of

transport took place at speed 1.25 m/s (within the range reported in experimental studies).

New simulations: Walking energetics at

different speeds

Speed (m/s)

0.4 0.6 0.8 1 1.2 1.4 1.6 1.8 2 2.2 2.4

Cost of Transport (J/kg.m)

2.5 3 3.5 4 4.5 5 5.5 6 6.5

Ralston 1958 (experimental) Martin 1992 (experimental) Browning 2006 (experimental) Simulation results

  • 10. Martin PE, et al. J Appl Physiol 73: 200-206,1992.
  • 11. Browning RC, et al. J Appl Physiol 100: 390-398, 2006.
  • 12. Ralston HJ, Int Z Angew Physiol 17: 277-283,1958.
slide-28
SLIDE 28

27

V = 1.25 m/s T = 0.52 s Distance = 0.65 m V = 0.5 m/s T = 0.74 s Distance = 0.38 m V = 2 m/s T = 0.37 s Distance = 0.73 m

slide-29
SLIDE 29

28

Thank You

slide-30
SLIDE 30

USING HIGH–THROUGHPUT COMPUTING FOR DYNAMIC SIMULATION OF BIPEDAL WALKING

Mohammadhossein Saadatzi,

Mechanical Engineering Department, Colorado School of Mines

Problem:

  • Simulation of human bipedal walking through muscle

actuation presents an optimization problem with a substantial number of parameters.

  • Because of the redundant nature of the human

musculoskeletal system, the problem is highly prone to getting stuck in local minima. Solution: We use HTC for robust and efficient computations of predictive simulation of human bipedal walking through muscle actuation.
