USC Stadium PV Team Football Sun-days Team Members: Connor Charney, Dylan Humenik, Evelyn Bateman, and Howard Holmes Contents Client and Location Technology Review Technological Constraints Socioeconomic Constraints


slide-1
SLIDE 1

USC Stadium PV

Team Football Sun-days

Team Members: Connor Charney, Dylan Humenik, Evelyn Bateman, and Howard Holmes

slide-2
SLIDE 2

Contents

  • Client and Location
  • Technology Review
  • Technological Constraints
  • Socioeconomic Constraints
  • Design Criteria
  • Results/Comments
  • Conclusion
slide-3
SLIDE 3

Location and Client

Url: http://www.nytimes.com/2012/06/03/us/new-plan-yields-hint-of-hope-for-aging-la-coliseum.html?_r=0

slide-4
SLIDE 4

Location

Los Angeles Memorial Coliseum

  • Home of Rose Bowl

Renovating:

  • $70 million across 10 years

Url: http://football.ballparks.com/NCAA/Pac12/USC/aerial.jpg

slide-5
SLIDE 5

Client

Url: http://culturela.org/musicla/

City of Los Angeles

  • Owns the stadium/parking lots
  • Some municipal buildings already

have solar panels

slide-6
SLIDE 6

Technology Review

  • Related Projects

○ FedEx Field

  • Proposed Technology

○ Solaire Generation

  • The Solar Carport Market
slide-7
SLIDE 7

Related Projects

FedEx Field

  • 79,000 people
  • Cost: $12,700,000
  • 2 MW peak load
  • 100% of energy on off days
  • 20% on game days

Url: https://www.clarkconstruction.com/our- work/projects/fedexfield-solar-panel-installation

slide-8
SLIDE 8

Proposed Technology

Solaire Generation

Existing Projects

  • Rutgers

○ 8 MW ○ Yingli 206 W panel

  • J&J ITS Headquarters

○ 2.1 MW ○ Sunpower 305 W Panel

Url: http://solairegeneration.com/our-vision/stadium/

slide-9
SLIDE 9

Carport Market

Benefits

  • Minimizes heat island effect
  • Increased car efficiency
  • Less physical/regulatory barriers
  • Prices for carport PV declining

Challenges

  • Higher average per kWh cost

○ Less competitive

Url: http://www.washingtonpost.com/news/energy-environment/wp/2015/01/28/the-best-idea-in- a-long-time-covering-parking-lots-with-solar-panels/

slide-10
SLIDE 10

Technological Constraints

  • Assess solar

resource

  • Shading
  • Fixed vs. Tracking
  • Competitive fuels
slide-11
SLIDE 11

Solar Resource

slide-12
SLIDE 12

Shading

slide-13
SLIDE 13

Fixed vs. Tracking

slide-14
SLIDE 14

Competitive Fuels

slide-15
SLIDE 15

Socioeconomic Constraints

  • Client Demands and Loading Estimates
  • Electricity Rate Structure
  • Federal and State Incentives
  • Financial Model
slide-16
SLIDE 16

Client Demands

  • Irregular Loading
  • Beaver Stadium as an estimate

○ larger size ○ higher energy demand

Url: http://www.raystownlakehotel.com/raystown-lake-events/beaver-stadium-psu/

slide-17
SLIDE 17

Loading Estimate

slide-18
SLIDE 18

Electricity Rate Structure

slide-19
SLIDE 19

Federal and State Incentives

  • Solar Investment Tax Credit 30%
  • California Solar Initiative Calculator

○ %0.025/kWh State production Tax ○ Over 5 years

  • Database of State Incentives for Renewables

○ $0.00039 / W capacity incentive

slide-20
SLIDE 20

Financial Model

  • Financial Modeling Performed in SAM

○ Loan of $5,086,154.00 ■ 100% debt for 25 years ■ rate of 7.5% per year ○ Inflation rate = 2.5% ○ Real discount rate = 5.5% ○ Taxes ■ Federal/State income tax = 28%/7% ■ Sales Tax = 5% ○ Insurance rate = 0.5% of installed cost

slide-21
SLIDE 21

Design Criteria

  • Inverter
  • Modules

○ Yingli Energy (China) YL260P-35B ○ Sunpower SPR-305E-WHT-D

  • Tilt
  • Shadowing Effects
slide-22
SLIDE 22

Inverter

Eaton Xpert 1670 357V

  • 1.671 MW
  • One inverter required

http://www.eaton.com/ecm/groups/public/@pub/@electrical/documents/content/pa08303003e.pdf

slide-23
SLIDE 23

Modules

  • Yingli Energy (China)

YL260P-35B

  • Sunpower SPR-305E-

WHT-D

slide-24
SLIDE 24

Yingli Energy (China) YL260P-35B

slide-25
SLIDE 25

Sunpower SPR-305E-WHT-D

slide-26
SLIDE 26

Tilt

Source: Department

  • f Mechanical and

Aerospace Engineering, University of California, San Diego

slide-27
SLIDE 27

Shadowing Effects

  • 3D SAM Model

LA Memorial Coliseum LA Memorial Sports Arena Row of apartment buildings Solar Array

slide-28
SLIDE 28

Shadowing Effects

SAM shading percentage table

slide-29
SLIDE 29

Technology Summary

slide-30
SLIDE 30

Comments

http://www.wsj.com/articles/SB10000872396390444914904577619821383361402

slide-31
SLIDE 31

Conclusion

http://www.wildnatureimages.com/Los_Angeles_Memorial_Coliseum_Photos.htm
