URANIS URANIS COMPANY PRESENTATION COMPANY PRESENTATION INTRODUCTION INTRODUCTION URANIS (Ukrainian RAdio & Navigation Service) was founded in 2001. The Company based on many years' experience of operation at maritime electronics market

slide-1
SLIDE 1

URANIS URANIS

COMPANY PRESENTATION COMPANY PRESENTATION

slide-2
SLIDE 2

INTRODUCTION INTRODUCTION

URANIS (Ukrainian RAdio & Navigation Service) was founded in 2001. The Company based on many years' experience of operation at maritime electronics market gained by the founders. The Company’s philosophy is based upon fast and flexible approach to the customers’ needs, high responsibility and professionalism in projects making. Due to its convenient geographical location in Sevastopol, a key point of shipping at the Black Sea, URANIS provides fast and efficient service in all main ports of Ukraine and Russia. Today URANIS is rapidly developing company aiming to become a leader at Ukrainian radio and navigation market as well as abroad due to its highly professional and skilled staff of managers, engineers and technicians using their more than 30 years experience. The Company's activity covers the following directions:

  • development and manufacturing of new types of radio, navigation and marine safety

equipment

  • supply and service of radio and navigation electronic equipment for all types of vessels
  • warranty and A/S service and shore base maintenance
  • installation projects for retrofit and new shipbuilding

Due to close cooperation with our partners worldwide and permanent attention to our customers' demands we create a new style of relations in maritime business. We make sea safer!

slide-3
SLIDE 3

COMPANY STRUCTURE COMPANY STRUCTURE

Director-General Technical Director

Deputy Director-General, Purchasing and Supply

Deputy Director-General, Manufacturing Deputy Director-General, R&D HF Equipment Divn. COSPAS-SARSAT Divn. RFID Divn. Manufacturing PCBs, Mechanical, Packing QA Purchasing & Supply Dept. Chief Financial Officer Office Clerk Mechanical and PCB Artwork Divn. Service Division Satcom Division

slide-4
SLIDE 4

ANNUAL TURNOVER, US$ ANNUAL TURNOVER, US$

500000 1000000 1500000 2000000 2500000

2002 2003 2004 2005 2006 2007 2008 2009 (plan)

slide-5
SLIDE 5

PRODUCTION PRODUCTION

  • HF RADIO EQUIPMENT
  • HF Power Amplifiers
  • HF Antenna Tuning Units
  • HF Automatic Tuning

Antenna

  • F antennas
  • HF/VHF digital tunable filters
  • Lithium Batteries
  • Li Batteries Chargers
  • Marine UPS & Chargers
  • COSPAS-SARSAT EPIRB tester
  • COSPAS-SARSAT EPIRB
slide-6
SLIDE 6

HF Amplifiers HF Amplifiers

  • PA500 - 1.5...30MHz

500W Solid State Power Amplifier

slide-7
SLIDE 7

HF Amplifiers (Cont.) HF Amplifiers (Cont.)

  • PA500C -

1.5...30MHz 500W Solid State Power Amplifier

slide-8
SLIDE 8

HF Amplifiers (Cont.) HF Amplifiers (Cont.)

  • PA400 - 1.5...30MHz

400W Solid State Power Amplifier

slide-9
SLIDE 9

HF Amplifiers (Cont.) HF Amplifiers (Cont.)

  • PA1000 -

1.5...30MHz 1000W Solid State Power Amplifier

slide-10
SLIDE 10

HF transceivers HF transceivers

1 kW HF SSB 500 W HF SSB A Family of HF transceivers provides:

  • High reliability
  • digital voice
  • High speed data

(up to 19200 bps)

  • Email exchange
slide-11
SLIDE 11

HF Amplifiers (Cont.) HF Amplifiers (Cont.)

  • PA4K - 1.5...30MHz

4000W Solid State Power Amplifier

slide-12
SLIDE 12

ATU’s & ATA ATU’s & ATA

  • ATA125 - 1.5...30 MHz

125W Automatic Tuning Antenna

  • ATA125B - 1.5...30 MHz

125W Automatic Tuning Antenna

slide-13
SLIDE 13

ATU’s & ATA (Cont.) ATU’s & ATA (Cont.)

  • ATU500 - 1.5...30MHz 500W

Antenna Tuning Unit

  • ATU1000 - 1.5...30MHz

1000W Antenna Tuning Unit

slide-14
SLIDE 14

ATU’s & ATA (Cont.) ATU’s & ATA (Cont.)

  • ATU60 - 1.5...30MHz

60W Antenna Tuning Unit

slide-15
SLIDE 15

HF antennae HF antennae

Horizontal Tunable Dipole Antenna HTDA - 7125 Half Loop Antenna HLA-6125

NVIS solution for Naval applications and limited area base installations 0-1000km continuous operation, without “skip zone

slide-16
SLIDE 16

2m HLA vs. 5m Whip 2m HLA vs. 5m Whip

2m Half-loop Antenna 5m Whip Antenna

2m Loop - 5m Whip @100km

0.0 2.0 4.0 6.0 8.0 10.0 2.0 3.0 4.0 5.0 6.0 7.0 Mhz db Avg Min

slide-17
SLIDE 17

Digital Tunable RF Filters Digital Tunable RF Filters

PRESELECTOR PS-UHF (digital tunable RF filter) 225 – 450 MHz

140 x 107 x 60 mm Dimensions

  • 40 to + 65°C

Operating Temperature Range: +5 VDC @ 500 mA DC Power: 55dB 20% adjustment frequency off-tuning ≥ 26dB 5% adjustment frequency off-tuning ≥ 45dB 10% adjustment frequency off-tuning ≤ -10dB IN band loss 80 PPM/°C Center Frequency Drift: 20 W CW

  • stop-band, at ±10% or greater of tune

frequency 5W CW

  • in band, at ±0.5% of tune frequency

RF Power Handling Capability ≤ 50 µsec Tuning time 8 bit parallel Tuning Control: ≥+100 dBm (input) In-band Second Order Intercept Point: ≥+50 dBm (input) In-band Third Order Intercept Point: (2.0 ± 0.5) %

  • 3dB Bandwidth

50 Ω; VSWR ≤ 2:1 Input/Output Impedance: 225 MHz to 450 MHz Frequency Coverage:

slide-18
SLIDE 18

Digital Tunable RF Filters Digital Tunable RF Filters

PRESELECTOR PS-HF (digital tunable RF filter) 1.5 - 30 MHz

≥ 15dB 5% adjustment frequency off-tuning 146 8638 mm Dimensions

  • 40 to + 85°C

Operating Temperature Range: +5 VDC @ 500 mA DC Power: 40dB 20% adjustment frequency off-tuning ≥ 30dB 10% adjustment frequency off-tuning Selectivity : 80 PPM/°C Center Frequency Drift: 20 W CW

  • stop-band, at ±10% or greater of tune

frequency 5W CW

  • in band, at ±3% of tune frequency

RF Power Handling Capability ≤ 150 µsec Tuning time ≥+33dBm

  • for 4 - 30

≥+27dBm

  • for 1.5 - 3.99

In-band Third Order Intercept Point: (2,5 ± 0,5) %

  • 3dB Bandwidth

50 Ω; VSWR ≤ 2:1 Input/Output Impedance: 1,5 – 30 MHz Frequency Coverage:

slide-19
SLIDE 19

Li Li-

  • Ion Batteries & Chargers

Ion Batteries & Chargers

FTN-6066 16 AH 14.8V Li-ion battery, 1.7 kgs FLN-9541 Desk-top Battery Charger for FTN-6066 FDN-6151 Carry Power Supply

slide-20
SLIDE 20

Marine PS & Charger Marine PS & Charger

  • Combined Switch-mode Power

Supply and Battery Charger 220 VAC / 24 VDC 9A Charging current 3 outputs

slide-21
SLIDE 21

C/S EPIRB Tester C/S EPIRB Tester

  • BT611 Cospas-Sarsat Beacon Tester

The BT611 is easy-to-use unique COSPAS/SARSAT beacon tester designed for high accuracy and resolution measurement of the full set of beacon signal parameters to check its compliance with the

  • nes, specified in C/S doc. T.001, T.007.

The BT611 is the most advanced Cospas-Sarsat beacon tester recognized by many beacon manufacturers and service stations worldwide.

slide-22
SLIDE 22

NEW 406 MHz EPIRB NEW 406 MHz EPIRB

PRO-5 Emergency Position Indicating Radio Beacon (EPIRB) is designed for

  • peration within the COSPAS-

SARSAT international satellite

  • system. It fully meets the

COSPAS-SARSAT technical specification latest issues and IMO recommendations.

Model: PRO-5

slide-23
SLIDE 23

R & D R & D

  • New HF equipment
  • Digital Signal Processing Technique
  • Voice Digital Coding/Decoding
  • New C/S EPIRBs
  • RFID technology
  • Testing
slide-24
SLIDE 24

MARITIME ELECTRONICS MARITIME ELECTRONICS

Brands represented

ACR Electronics -AIS EQUIPMENT SEVENSTAR ELECTRONICS – SART SATAMATICS – SSAS/LRIT EQUIPMENT FURUNO -NAVIGATION AND RADIO EQUIPMENT Pole Star – SATELLITE SERVICES MVS Global Communications – SATELLITE SERVICES Netwave Systems – VDR/sVDR equipment

slide-25
SLIDE 25

MARITIME ELECTRONICS MARITIME ELECTRONICS

Technical Support for Brands

  • FURUNO
  • KELVIN HUGHES
  • THRANE & THRANE
  • ICOM
  • AVECS
  • NETWAVE
  • SAMYUNG
  • SEVENSTAR ELECTRONICS
  • ACR ELECTRONICS
  • ENTEL UK
slide-26
SLIDE 26

MARITIME ELECTRONICS MARITIME ELECTRONICS

Area of Service

  • All ports of Ukraine
  • Ports of Russia at Black Sea
  • All ports of Turkey (through URANIS’ office in Istanbul)
  • Greece (through partners in Piraeus)
  • UAE and the Gulf (through partners in UAE)
