REFERENCE - FOTO PRESENTATION PROJECT: Construction of K7 and TG3 unit in Plzesk teplrensk, a.s. GREEN UNIT INVELT HOLDING Project management, interdisciplinary coordination and completion INVELT INVELT INVELT SERVIS
SLIDE 2
SLIDE 3
INVELT ELEKTRO INVELT ENERGO INVELT SERVIS INVELT HOLDING
Project, manufacture, supply and commissioning
- DCS (Honeywell)
- TG3 turbine control system
- Excitation system with ABB
UNITROL
- Electrical protections,
measurement and synchronization (ABB) Project, manufacture, supply and commissioning
- Output and neutral cubicle of
the TG3 11.5MWe generator
- Generator breaker
- MCC 400VAC, 220VDC
Project, manufacture, supply and commissioning
- Technological equipment of
K7 biomass boiler
- Field instrumentation
Project management, interdisciplinary coordination and completion
SLIDE 4
Manufacture and installation of the boiler technological equipment
SLIDE 5
K7 boiler, drum, wood chips combustion
SLIDE 6
Field instrumentation – conductivity measurement, emission monitoring etc.
SLIDE 7
Unit DCS system (Honeywell) - boiler house, machine room etc.
SLIDE 8
TG3 turbine control system, Siemens Simatic S7 400
SLIDE 9
Electrical room under TG3 – generator output and neutral cubicle (MTB), generator breaker, ABB excitation system, ABB electrical protections, measurement and synchronization
