SLIDE 1
Introduction
Discrepancy main CPU and main memory speed
- Intel lists for Pentium M nowadays:
– ~240 cycles to access main memory
- The gap is widening
- Faster memory is too expensive
Understanding CPU Caches Ulrich Drepper Introduction Discrepancy - - PowerPoint PPT Presentation
Understanding CPU Caches Ulrich Drepper Introduction Discrepancy - - PowerPoint PPT Presentation
Understanding CPU Caches Ulrich Drepper Introduction Discrepancy main CPU and main memory speed Intel lists for Pentium M nowadays: ~240 cycles to access main memory The gap is widening Faster memory is too expensive The Solution
SLIDE 2
SLIDE 3
The Solution for Now
CPU caches: additional set(s) of memory added between CPU and main memory
- Designed to not change the programs' semantics
- Controlled by the CPU/chipset
- Can have multiple layers with different speed
(i.e., cost) and size
SLIDE 4
How Does It Look Like
Main Memory 3rd Level Cache 2nd Level Cache System Bus 1st Level Data Cache 1st Level Instruction Cache Execution Unit
≤1 cycle ~3 cycles ~3 cycles ~14 cycles ~240 cycles
SLIDE 5
Cache Usage Factors
Numerous factors decide cache performance:
- Cache size
- Cacheline handling
– associativity
- Replacement strategy
- Automatic prefetching
SLIDE 6
Cache Addressing
Address (32/64 Bits) M Bits Cacheline Size H Bits Hash Bucket Address Aliases ! N-way Buckets
SLIDE 7
Observing the Effects
Test Program to see the effects:
- Walks single linked list
– Sequential in memory – Randomly distributed
- Write to list elements
struct l { struct l *n; long pad[NPAD]; };
SLIDE 8
2^10 2^12 2^14 2^16 2^18 2^20 2^22 2^24 2^26 2^28 4 4.5 5 5.5 6 6.5 7 7.5 8 8.5 9 9.5
Sequential Access (NPAD=0)
Working Set Size (Bytes) Cycles / List Element
SLIDE 9
2^10 2^12 2^14 2^16 2^18 2^20 2^22 2^24 2^26 2^28 25 50 75 100 125 150 175 200 225 250 275 300 325
Sequential List Access
Size=8 Size=64 Size=128 Size=256
Working Set Size (Bytes) Cycles / List Element
SLIDE 10
2^10 2^12 2^14 2^16 2^18 2^20 2^22 2^24 2^26 2^28 50 100 150 200 250 300 350 400 450 500
Sequential vs Random Access (NPAD=0)
Sequential Random
Working Set Size (in bytes) Cycles / List Element
SLIDE 11
2^10 2^12 2^14 2^16 2^18 2^20 2^22 2^24 2^26 2^28 3 5 8 10 13 15 18 20 23 25 28 30
Sequential Access (NPAD=1)
Follow Inc Addnext0
Working Set Size (Bytes) Cycles / List Element
SLIDE 12
Optimizing for Caches I
- Use memory sequentially
– For data, use arrays instead of lists – For instructions, avoid indirect calls
- Chose data structures as small as possible
- Prefetch memory
SLIDE 13
2^10 2^12 2^14 2^16 2^18 2^20 2^22 2^24 2^26 2^28 50 100 150 200 250 300 350 400 450 500
Sequential Access w/ vs w/out L3
P4/64/16k/1M-128b P4/64/16k/1M-256b P4/32/?/512k/2M- 128b P4/32/?/512k/2M- 256b
Working Set Size (Bytes) Cycles / List Element
SLIDE 14
More Fun: Multithreading
- 1. CPU Core #1 and #3 read from a memory location; L2 the
relevant L1 contain the data
- 2. CPU Core #2 writes to the memory location
a)Notify L1 of core #1 that content is obsolete b)Notify L2 and L1 of second proc that content is obsolete
CPU Core #2 L1 L2 L1 CPU Core #1 CPU Core #4 L1 L2 L1 CPU Core #3
Main Memory
SLIDE 15
More Fun: Multithreading
- 3. Core #4 writes to the memory location
a)Wait for core #2's cache content to land in main memory b)Notify core #2's L1 and L2 that content is obsolete
CPU Core #2 L1 L2 L1 CPU Core #1 CPU Core #4 L1 L2 L1 CPU Core #3
Main Memory
SLIDE 16
2^10 2^12 2^14 2^16 2^18 2^20 2^22 2^24 2^26 2^28 1 10 100 1000
Sequential Increment 128 Byte Elements
Nthreads=1 Nthreads=2 Nthreads=4
Working Set Size (Bytes) Cycles / List Element
SLIDE 17
Optimizing for Caches II
Cacheline ping-pong is deadly for performance
- If possible, write always on the same CPU
- Use per-CPU memory; lock thread to specific
CPU
- Avoid placing often independently read and
written-to data in the same cacheline
