NFS Tricks and Benchmarking Traps Daniel Ellard and Margo Seltzer FREENIX 2003 - June 12, 2003 Outline Motivation Research questions Benchmarking traps New NFS Read-Ahead Heuristics Optimize sequential reads Improve

slide-1
SLIDE 1

NFS Tricks and Benchmarking Traps

Daniel Ellard and Margo Seltzer FREENIX 2003 - June 12, 2003

slide-2
SLIDE 2

June 12, 2003 2 Daniel Ellard - Freenix 2003

Outline

  • Motivation

– Research questions – Benchmarking traps

  • New NFS Read-Ahead Heuristics

– Optimize sequential reads – Improve non-sequential reads

  • Results
  • Conclusions
slide-3
SLIDE 3

June 12, 2003 3 Daniel Ellard - Freenix 2003

Goal - Improve NFS Read Throughput

  • We are interested in improving the throughput
  • f data accessed from disk via NFS.

– Example: email workload

  • Our approach: improve the heuristics that

control the amount of read-ahead done by the server.

slide-4
SLIDE 4

June 12, 2003 4 Daniel Ellard - Freenix 2003

Why Improve Read-Ahead Heuristics?

  • With busy NFS clients, 5-10% of NFS

requests arrive at the server out-of-order.

  • nfsiods are the primary source of reordering.

– nfsiod is a client daemon that marshals and schedules NFS requests. – Many implementations use multiple nfsiods. – Contention for resources and process scheduling effects can cause reordering.

slide-5
SLIDE 5

June 12, 2003 5 Daniel Ellard - Freenix 2003

Why Improve Read-Ahead Heuristics?

  • Sequential access patterns may appear non-

sequential if requests are reordered.

  • Servers do less (or no) read-ahead for non-

sequential access patterns.

  • Read-ahead is necessary for good

performance.

slide-6
SLIDE 6

June 12, 2003 6 Daniel Ellard - Freenix 2003

Research Questions

  • Can we improve performance for sequential

reads by improving the way the NFS sequentiality-detection heuristic handles “slightly” out-of-order requests?

  • Can we detect non-sequential access

patterns that have sequential components and therefore can benefit from read-ahead?

slide-7
SLIDE 7

June 12, 2003 7 Daniel Ellard - Freenix 2003

A Micro-Benchmark for NFS Reads

  • Long sequential reads
  • Many concurrent readers
  • Inspired by observed email workloads
  • All tests begin with a cold cache on client and

server.

– All data is brought from disk during the benchmark.

slide-8
SLIDE 8

June 12, 2003 8 Daniel Ellard - Freenix 2003

The Testbed

  • FreeBSD 4.6.2
  • Commodity PCs

– Note: PCI bus transfer speed of 54 MB/s

  • Intel PRO/1000 TX gigabit Ethernet

– em device driver – MTU=1500 – Raw TCP transfer rate of 49 MB/s

  • IDE and SCSI drives

– Paper discusses SCSI, this talk focuses on IDE

slide-9
SLIDE 9

June 12, 2003 9 Daniel Ellard - Freenix 2003

Preliminary Results

  • Before measuring the effect of our changes to

the NFS server, we must understand the default system.

  • Results of our benchmarks were frustrating:

– Large variance – Strange effects

  • We decided to investigate these effects

before proceeding.

slide-10
SLIDE 10

June 12, 2003 10 Daniel Ellard - Freenix 2003

Benchmarking Traps

  • Properties of disks and their drivers:

– ZCAV/disk geometry effects – Disk scheduling algorithms – Tagged command queues

  • Arbitrary limits in the NFS implementation
  • Network issues

– TCP vs UDP for RPC

slide-11
SLIDE 11

June 12, 2003 11 Daniel Ellard - Freenix 2003

ZCAV Effects

  • ZCAV - “Zoned Constant Angular Velocity”

– Disk tracks are grouped into zones. – Within each zone, each track has the same number of sectors. – The number of sectors is roughly proportional to the length of the track.

  • Tracks in the outer zones hold 1.2 - 2 times

more data

– Outer zone has a higher transfer rate – Outer zone requires fewer seeks

slide-12
SLIDE 12

June 12, 2003 12 Daniel Ellard - Freenix 2003

The ZCAV Effect - Local IDE Disk

5 10 15 20 25 30 35 40 45 50 1 2 4 8 16 32

Number of Concurrent Readers MB/s Outermost Zones Inner Zones

slide-13
SLIDE 13

June 12, 2003 13 Daniel Ellard - Freenix 2003

Controlling for ZCAV Effects

  • To minimize the ZCAV effect, minimize the

difference between the innermost and

  • utermost zones you use.

– Use a large disk. – Run your benchmark in a small partition.

  • To measure the effect, create several

partitions and repeat your benchmark in each.

slide-14
SLIDE 14

June 12, 2003 14 Daniel Ellard - Freenix 2003

Disk Scheduler Issues

  • BSD systems use the CSCAN scheduler.
  • CSCAN trades fairness for disk utilitization.

– Some requests are serviced much sooner than

  • thers.

– It is not hard to create request streams that starve

  • ther requests for the disk.

– Overall throughput is very good.

  • Many scheduling algorithms are unfair.
slide-15
SLIDE 15

June 12, 2003 15 Daniel Ellard - Freenix 2003

Controlling for Scheduler Effects

  • Application specific!
  • For our purposes:

– Total throughput for concurrent readers – Measure the total time it takes for all the concurrent readers to finish their tasks, instead of the time of each individual reader.

  • There is large variation in the time each

reader takes, but the time required by the slowest reader is reasonably consistent.

slide-16
SLIDE 16

June 12, 2003 16 Daniel Ellard - Freenix 2003

Tagged Command Queues

  • SCSI drives have tagged command queues.

– Disk requests are sent to the drive as soon as they reach the front of the scheduler queue. – The drive schedules the requests according to its

  • wn scheduling algorithm.
  • For our benchmarks and hardware:

– Tagged command queues increase fairness. – Unfortunately, throughput is reduced (almost 50% in the worst case).

slide-17
SLIDE 17

June 12, 2003 17 Daniel Ellard - Freenix 2003

Back to the Experiments…

Q: What is the potential for improvement in the read-ahead algorithm?

– Compare the default system to AlwaysReadAhead, a system that aggressively always does as much read-ahead as it can.

A: There is benefit when the degree of concurrency is high and requests arrive out-

  • f-order.
slide-18
SLIDE 18

June 12, 2003 18 Daniel Ellard - Freenix 2003

NFS Read Throughput (Busy Clients)

5 10 15 20 1 2 4 8 16 32 Number of Concurrent Readers MB/s AlwaysReadAhead Default

slide-19
SLIDE 19

June 12, 2003 19 Daniel Ellard - Freenix 2003

The SlowDown Heuristic

Default Heuristic

If the access is sequential relative to the previous access: seqCount++ else seqCount = small const

SlowDown Heuristic

If the access is sequential relative to the previous access: seqCount++ else if the access is “close” to the previous access: seqCount is unchanged else seqCount = seqCount / 2

slide-20
SLIDE 20

June 12, 2003 20 Daniel Ellard - Freenix 2003

The Effect of SlowDown

5 10 15 20 1 2 4 8 16 32

Number of Concurrent Readers MB/s AlwaysReadAhead Default SlowDown

slide-21
SLIDE 21

June 12, 2003 21 Daniel Ellard - Freenix 2003

Why Doesn’t SlowDown Help?

The problem is not SlowDown.

  • In FreeBSD, the sequentiality scores are

stored in a fixed-size hash table.

  • When the table is full, adding a new entry

forces the ejection of another.

  • The hash table is too small to support more

than a few readers.

slide-22
SLIDE 22

June 12, 2003 22 Daniel Ellard - Freenix 2003

SlowDown with the Larger Table

5 10 15 20 1 2 4 8 16 32

Number of Concurrent Readers MB/s AlwaysReadAhead Default SlowDown + New Table

slide-23
SLIDE 23

June 12, 2003 23 Daniel Ellard - Freenix 2003

The Effect of Increasing the Table Size

  • Increasing the hash table size makes

SlowDown as fast as AlwaysReadAhead.

  • Fixing the table also makes the default

algorithm as fast as AlwaysReadAhead.

– For our current testbed, it is enough simply to have a reasonable value for seqCount. – Perhaps in the future having a more accurate value will become important.

slide-24
SLIDE 24

June 12, 2003 24 Daniel Ellard - Freenix 2003

Improving Non-Sequential Reads

  • Some read patterns are non-sequential, but

do contain sequential components.

  • One example is two threads reading

sequentially from the same file:

– Thread 1 reads blocks 0, 1, 2, 3, 4 … – Thread 2 reads blocks 1000, 1001, 1002, 1003 … – Server sees 0, 1000, 1, 1001, 2, 1002, 3, 1003 …

  • This pattern is not sequential according to the

default or SlowDown read-ahead heuristics.

slide-25
SLIDE 25

June 12, 2003 25 Daniel Ellard - Freenix 2003

Using Cursors to Find Components

  • For each active file, maintain a set of cursors.

– Each cursor is a position and sequentiality score.

  • For each read access to the file, choose the

cursor with the closest position:

– If there is no “close” cursor, create one. – If there are already too many cursors for this file, eject the least recently used. – Update the sequentiality score for the cursor.

slide-26
SLIDE 26

June 12, 2003 26 Daniel Ellard - Freenix 2003

The Effect of Cursors

2 4 6 8 10 12 14 16 2 4 8

Number of Concurrent Threads MB/s Using Cursors Default Read-Ahead

slide-27
SLIDE 27

June 12, 2003 27 Daniel Ellard - Freenix 2003

Conclusions

  • The SlowDown heuristic does not help much,

at least not for our system.

– Fixing the hash table does help

  • Cursors work well for access patterns that are

the composition of sequential access patterns.

  • Benchmarking is hard, even for simple

changes.

slide-28
SLIDE 28

June 12, 2003 28 Daniel Ellard - Freenix 2003

Obtaining Our Code

Daniel Ellard ellard@eecs.harvard.edu http://www.eecs.harvard.edu/~ellard/NFS
