UK Biomethane Market Update 50 Plants Injecting Gas by End 2015 15th June 2015 John Baldwin Managing Director CNG Services Ltd john.baldwin@cngservices.co.uk www.cngservices.co.uk 07831 241217 UK Biomethane Market Update w e have

slide-1
SLIDE 1

UK Biomethane Market Update 50 Plants Injecting Gas by End 2015

15th June 2015

John Baldwin Managing Director CNG Services Ltd

john.baldwin@cngservices.co.uk www.cngservices.co.uk 07831 241217

slide-2
SLIDE 2

UK Biomethane Market Update

“we have scratched the surface”

  • 1. Biomethane Journey
  • 2006 – 2010
  • 2011 - 2015
  • 2. 2013 – 15 Market Statistics
  • 3. Selected projects
  • 4. Benefits and Market Forecast
  • 5. Conclusions

The fastest growing renewable technology?

slide-3
SLIDE 3

BIOMETHANE JOURNEY REMINDER FROM UK BIOMETHANE DAY 26 JUNE 2012

slide-4
SLIDE 4

Why Biomethane Injection?

1

  • In 2007 we said:
  • Biogas CHP often cannot use its waste heat
  • UK has invested around £30 billion in its gas grid and even

more in appliances and central heating

  • To meet EU Renewable Energy targets, we need to use

resources efficiently

  • So, take the renewable methane to where it can be used

efficiently…..using the gas grid

slide-5
SLIDE 5

2006 - 2008

  • December 2006 – WRG – Wakefield

– Proved that vehicles could run on biomethane but this was not practical due to vehicle fill patterns and far too much gas – needed gas grid injection

  • REA’s initial concept was for “equivalence”

– Otherwise no point injecting biomethane – Gaynor thought it seemed a good idea!

  • Nov 2007 – Feb 2008 – United Utilities

– Feasibility Study for Grid Injection – National Grid strongly in favour

slide-6
SLIDE 6

2008 - 2010

  • Renewable Heat Incentive in Energy Act:

– In November 2008, REA concept of a premium for biomethane injected into grid accepted by DECC

  • April 2009:

– Proposal to Thames Water and SGN re Didcot flared gas project

  • October 2010:

– First biomethane injection from Thames Water’s Didcot plant

  • REA work with DECC on RHI tariff levels to be set to give

equivalent returns to those from electricity generation

  • Visits to other EU countries, especially Germany and Sweden

– Sweden has not much gas grid and lots of hydro so misleading – Germany has ‘expensive and slow’ regulations Didcot proved it could be done

slide-7
SLIDE 7

2011 - 2012

  • Not for Profit REAL Green Gas Certificate Scheme launched:

– April 2011

  • Poundbury BtG Project identified:

– Start in June 2011 – Biomethane injection by Oct 2012

  • Renewable Heat Incentive introduced:

– November 2011 tariff of 6.7 p/kWh

  • EMIB review to bring down costs of entry and simplify processes:

– Sept 2011 – May 2012

  • HSE Gas Quality:

– Agreed change in Oxygen limit to 1%, in place in Q2 2012 Poundbury 2012 was a key milestone

slide-8
SLIDE 8

2006 – 2012 Conclusions

  • In 2012, we said
  • It has taken 6 years but we have:

– Attractive RHI tariff for projects starting in 2012 – Good regime that reduces costs, saves time and supports innovation – ‘Not for profit’ Green Gas Certificate Scheme that facilitates biomethane sales – Competitive supply chains starting to develop

This is the growth in Germany from start in 2006...we can follow this path

So what has happened since 2012?

slide-9
SLIDE 9

BIOMETHANE JOURNEY HOW HAVE WE PROGRESSED SINCE 2012? END 2015 STATS

slide-10
SLIDE 10

Biomethane projects per year 2010-2015

1 in 2012, 2 in 2013, total of 50 projects injecting gas by end 2015

slide-11
SLIDE 11

Proportion of Projects in Each Feedstock Category

GGG Feedstock Category Number projects in Category % Sewage Sludge 5 10% Agricultural 29 58% Food Waste 11 22% Food Processing 4 8% Biodegradable 1 2% Unknown 0% Total Projects 50

slide-12
SLIDE 12

GDN Number of Projects % NG 17 34% SGN 16 32% WWU 12 24% NGN 5 10% Total Projects 50

Proportion of Projects in Each GDN area

slide-13
SLIDE 13

Biogas Ncmh Number of Projects % 0 - 400 3 6% 400 - 800 8 16% 800 - 1200 29 58% 1200 + 10 20% Total Projects 50

Proportion of Projects by Biogas Flow-rate

slide-14
SLIDE 14

Technology Number of Projects % Water Wash 13 26% Membrane 34 68% Chemical Wash 3 6% TBC 0% Total Projects 50

Proportion of Projects by CO2 Removal Technology

slide-15
SLIDE 15

Annual Biomethane to Grid and RHI for 2012-2015

Note – RHI commitment is max based on capacity, actual lower in 2015 due to project build up

Biomethane to grid is RHI technology with highest kWh

slide-16
SLIDE 16

BIOMETHANE JOURNEY SELECTED PROJECTS

slide-17
SLIDE 17

Poundbury

UK’s first commercial project

slide-18
SLIDE 18

Vale Green

Tomatoes just love CO2

slide-19
SLIDE 19

Saria Widnes

Is this the largest food waste to biomethane plant on earth???

slide-20
SLIDE 20

Severn Trent Water Minworth

Inject to LTS, no propane needed……and highly energy efficient solution

slide-21
SLIDE 21

Greener for Life Fraddon

Most westerly food waste to biomethane plant in EU!

slide-22
SLIDE 22

Wyke Farms

Most sustainable cheese in the UK….

slide-23
SLIDE 23

Welsh Water Five Fords

Launched project May 2014, injecting gas April 2015

slide-24
SLIDE 24

Geneco Avonmouth

Is this the best PR ever for a biomethane project in UK?

slide-25
SLIDE 25

Raynham

National Grid – 19 bar Hexel One (Plastic) pipe

slide-26
SLIDE 26

Euston

Remote compression into 42 bar LTS

slide-27
SLIDE 27

BIOMETHANE JOURNEY BENEFITS AND MARKET FORECASTS

slide-28
SLIDE 28

Benefits – Using the Gas Grid

  • UK has great gas grid

– 85% of domestic market connected to grid – 95% of industry – Power generation back up to wind

  • To build gas grid and central heating etc would

cost around £60 - 100 billion

  • All our Grid Owners are very supportive and

have created an attractive regime to allow projects to go ahead at lower cost/quicker

slide-29
SLIDE 29

Benefits - CO2 Impact

  • Forecast 2 TWh injected into gas grid in 2016
  • 140,000 tonnes of gas
  • 140 x (44/16) = 385,000 tonnes of CO2 saved at the burner tip
  • Marginal gas to UK is Qatar LNG
  • The 140,000 tonnes of biomethane displaces 140,000 tonnes of LNG

– 15% higher CO2 than UKCS gas on a “Well to Tank” basis – 7% CO2 vented in Qatar – So around 50,000 tonnes on top

  • So, around 430,000 tonnes/annum benefit
  • Material contribution towards 2020 renewable energy targets
  • And we have only scratched the surface….
slide-30
SLIDE 30

Benefits – Investment and Jobs

  • 50 projects by end 2015
  • Capex £6 - £20 Million
  • Estimated total capex of around £500 Million
  • Increasing % of UK supply chain – estimated 70%
  • Job Survey needed to support continuing DECC investment
slide-31
SLIDE 31

Biomethane Market Forecast

  • UK total gas demand now is around 750 TWh/annum
  • Around 50% domestic heating, 25% power gen and 25% industry
  • Biomethane by 2030 is around 20 TWh, though we have only scratched the

surface…..

  • For heat in cities there are few practical/economic alternatives
  • Biomass (air quality), heat pumps (do not work in very cold weather), district

heating (too late to dig up cities)

slide-32
SLIDE 32

Biomethane to Grid Conclusions

  • Over 50 projects by end 2015, further 100 by end 2020 if tariffs OK
  • 46 projects completed in period 1 June 2014 to 31 Dec 2015
  • Around 2 TWh by end 2015
  • UK total gas demand 750 TWh
  • 140,000 tonnes of LNG not imported
  • Focus on reducing capital and operating costs
  • No Letter of Direction
  • Tariff fixed
  • Competition as established supply chains
  • Lower cost of finance?
  • To be discussed tomorrow…..

UK biomethane market growing fast, delivering significant benefits and helping meet 2020 renewable energy targets
