THE EVOLUTION IN BIOMASS PRETREATMENT

Why the pretreatment is important?

• a) Substrate without pretreatment
• b) Speed in biomethane production
• c) Amount of biomethane produced
• d) Speed and quantity of biomethane

produced

Graphic 1: Montgomery et al. (2014) IEA Task 37 Technical Brochure.

Source: Applied research in the waste enhancement field and integrated management system . Ecomondo, Rimini, 5 Novembre 2015.

• Dott. Mirco Garuti (CRPA)
• pretreatment techniques

increasing the speed and quantity of biomethane produced from biomass.

• Pretreatment is important

to improve the plant efficiency

How is BioBANG

BioBANG is the innovative, effective and efficient cavitator that transfers 100% of the energy to the fluid. Cavitation breaks up and permanently liquefies all types of biomass, even low-cost types, resulting in its immediate digestion in biogas and biomethane systems. BioBANG is the future standard to the biomass treatment and pretreatment for any plant.

How BioBANG Cavitator works

BioBANG in Europe

• More than 90 installations:

 Italy  Germany  United kingdom  France  Switzerland  Denmark

Benefits for the end customers:

INCREASE PLANT’S YELD BioBANG increases the production of Biogas and Biomethane, reducing the amount of biomass that must be loaded every day. IMPROVE THE MIXING BioBANG improves energy conservation offered by the mix because it drastically reduces the viscosity of biomass. BIOMASS SAVING BioBANG increases the digestibility of fibres, even low-cost types, and reduces the retention of biomass.

Picture 1: Untreated straw Picture 2: Straw treated with BioBANG

USE OF CHEAPER BIOMASS (for example, STRAW)

• Physical break up
• Increased contact surface
• Increased fiber’s digestibility

Biomass instant breakdown

Retention time

Untreaed straw

Straw treated with BioBANG

Graphic 2. CH4 production and degradability for untreated straw Graphic 3. CH4 production and degradability for treated straw

• Increase in methane yield
• Increase in methane speed production
• Increase dry matter content

UNTREATED STRAW STRAW TREATED WITH BioBANG + 21%

BMP

without increasing diluitions!! and without increasing plant’s retention times!!

Viscosity

No BioBANG No BioBANG BioBANG BioBANG

Graphic 4. Normalized and apparent digestate’s viscosity taken from the last digester.

• Viscosity reduced up to 50%
• Increased energy savings by mixers
• Reduction of liquid-solid separation in the digester

• Best Mixing
• Best Homogenization
• Surface crust elimination
• Plant’s volume optimization

BETTER PLANT’S HYDRAULIC MANAGEMENT! Cattle manure and straw Triticale Grape marcs OFMSW BioBANG BioBANG BioBANG BioBANG Original Original Original Original

Visual effect

Installation method

Applied research in the field of waste enhancement and integrated management systems

• Dott. Mirco Garuti (CRPA)
• bypass connection on first digester
• It take the product from the top of the

digester

• It treats only the 20-30% of of fiber that is

not easily digested by bacteria

• Direct recirculation of treated biomass in the

lower part of the digester

• It doesn’t compete with the bacteria
• MAXIMUM EFFICIENCY !!

Loaded biomass cavitation Inlet line Outlet line BioBANG

Recirculation on the first digester

how improve plant’s efficiency with BioBANG

1) Gradually reduce the use of the mixers in the system:

The viscosity of cavitated products is distinctly lower. The mixers will consume a lot less.

2) Reduce the ratio of liquid to solid:

Once product viscosity has reduced, less dilution is required. Retention time will increase considerably, to the advantage of the yeld.

3) Gradually reduce the amount of feed and use low-cost waste fibers to feed the plant:

The guaranteed breakdown offered by BioBANG makes it possible to digest even the cheapest, most difficult products, so make good use of them!

Meet BioBANG

• You can find us at the stand 23.

Discover the potential of BioBANG on your plant:

• At our stand you can booking a free

test with our mobile unit directly in your plant!

BioBANG

THANKS FOR THE ATTENTION
