Typing Rank Polymorphism Justin Slepak In collaboration with Olin Shivers and Panagiotis Manolios 100 175 0.6 ( [(lo 0) (hi 0) ( 0)] (+ (* hi ) (* lo (- 1 )))) 100 175 0.6 (( [(lo 0) (hi 0) ( 0)] (+ (* hi ) (* lo (- 1

slide-1

SLIDE 1

Typing Rank Polymorphism

Justin Slepak In collaboration with Olin Shivers and Panagiotis Manolios

slide-2

SLIDE 2

100 175 0.6 (λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α))))

slide-3

SLIDE 3

100 175 0.6 ((λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α)))) 100 175 0.6)

slide-4

SLIDE 4

RGB RGB

(λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α))))

slide-5

SLIDE 5

RGB RGB

((λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α)))) rgb1 ; 3 channels rgb2 ; 3 channels 0.6) ; scalar

slide-6

SLIDE 6

Credit: Wikimedia user Sadalsuud

(λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α))))

slide-7

SLIDE 7

Credit: Wikimedia user Sadalsuud

((λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α)))) sky ; row × col × chan labels ; row × col × chan img-mask) ; row × col × chan

slide-8

SLIDE 8

(λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α))))

slide-9

SLIDE 9

((λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α)))) film ; time × row × col × chan audience ; time × row × col × chan vid-mask) ; time × row × col × chan

slide-10

SLIDE 10

Credit: Wikimedia user Thetawave

(λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α))))

slide-11

SLIDE 11

Credit: Wikimedia user Thetawave

((λ [(lo 0) (hi 0) (α 0)] (+ (* hi α) (* lo (- 1 α)))) scene1 ; time × row × col × chan scene2 ; time × row × col × chan [0.0 ... 1.0]) ; time

slide-12

SLIDE 12

slide-13

SLIDE 13

(lerp dragonfly ; row × col × chan tint-color ; chan 0.6) ; scalar

slide-14

SLIDE 14

(~[1 1 0]lerp dragonfly ; row × col × chan tint-color ; chan 0.6) ; scalar

slide-15

SLIDE 15

(~[1 1 0]lerp dragonfly ; row × col × chan tint-color ; chan 0.6) ; scalar

slide-16

SLIDE 16

(~[1 1 0]lerp dragonfly ; row × col × chan tint-color ; chan 0.6) ; scalar

slide-17

SLIDE 17

(~[1 1 0]lerp dragonfly ; row × col × chan tint-color ; chan 0.6) ; scalar

slide-18

SLIDE 18

(~[1 1 0]lerp dragonfly ; row × col × chan tint-color ; chan 0.6) ; scalar

slide-19

SLIDE 19

(~[1 1 0]lerp dragonfly ; row × col × chan tint-color ; chan 0.6) ; scalar

slide-20

SLIDE 20

(~[1 1 0]lerp dragonfly ; row × col × chan tint-color ; chan 0.6) ; scalar

slide-21

SLIDE 21

(~[1 1 0]lerp dragonfly ; row × col × chan tint-color ; chan 0.6) ; scalar

slide-22

SLIDE 22

Rank manipulation

slide-23

SLIDE 23

(~[0 1]* [1 2 3] [10 20])

slide-24

SLIDE 24

(~[0 1]* [1 2 3] [10 20]) Cells:

slide-25

SLIDE 25

(~[0 1]* [1 2 3] [10 20]) Cells: ~[0 1]*

slide-26

SLIDE 26

(~[0 1]* [1 2 3] [10 20]) Cells: ~[0 1]* 1 2 3

slide-27

SLIDE 27

(~[0 1]* [1 2 3] [10 20]) Cells: ~[0 1]* 1 [10 20] 2 3

slide-28

SLIDE 28

(~[0 1]* [1 2 3] [10 20]) Cells: ~[0 1]* 1 [10 20] 2 3 Frame: [] [3] []

slide-29

SLIDE 29

(~[0 1]* [1 2 3] [10 20]) Cells: ~[0 1]* 1 [10 20] 2 3 Frame: [] [3] [] [(* 1 [10 20]) (* 2 [10 20]) (* 3 [10 20])]

slide-30

SLIDE 30

(~[0 1]* [1 2 3] [10 20]) Cells: ~[0 1]* 1 [10 20] 2 3 Frame: [] [3] [] [(* 1 [10 20]) (* 2 [10 20]) (* 3 [10 20])] [[10 20] [20 40] [30 60]]

slide-31

SLIDE 31

; M×N array for M points in N-space > (define points ...)

slide-32

SLIDE 32

; M×N array for M points in N-space > (define points ...) > (define (dist^2 (a 1) (b 1)) (reduce + 0 (sqr (- a b))))

slide-33

SLIDE 33

; M×N array for M points in N-space > (define points ...) > (define (dist^2 (a 1) (b 1)) (reduce + 0 (sqr (- a b)))) ; points[x,newDim,y] and points[newDim,x,y]?

slide-34

SLIDE 34

; M×N array for M points in N-space > (define points ...) > (define (dist^2 (a 1) (b 1)) (reduce + 0 (sqr (- a b)))) ; points[x,newDim,y] and points[newDim,x,y]? > (~[1 2]dist^2 points points) [[some ...] [symmetric ...] [matrix ...] ...]

slide-35

SLIDE 35

Non-rectangular data

slide-36

SLIDE 36

> (define ragged [(box [1]) (box [4 2 5]) (box [8 7 2 4 3]) (box [9 0])])

slide-37

SLIDE 37

> (define ragged [(box [1]) (box [4 2 5]) (box [8 7 2 4 3]) (box [9 0])]) > (shape-of ragged)

slide-38

SLIDE 38

> (define ragged [(box [1]) (box [4 2 5]) (box [8 7 2 4 3]) (box [9 0])]) > (shape-of ragged) [4]

slide-39

SLIDE 39

> (define ragged [(box [1]) (box [4 2 5]) (box [8 7 2 4 3]) (box [9 0])]) > (shape-of ragged) [4] > ((λ (b 0) (unbox contents b (shape-of contents))) ragged)

slide-40

SLIDE 40

> (define ragged [(box [1]) (box [4 2 5]) (box [8 7 2 4 3]) (box [9 0])]) > (shape-of ragged) [4] > ((λ (b 0) (unbox contents b (shape-of contents))) ragged) [[1] [3] [5] [2]]

slide-41

SLIDE 41

> (take 3 [1 2 3 4 5])

slide-42

SLIDE 42

> (take 3 [1 2 3 4 5]) [1 2 3]

slide-43

SLIDE 43

> (take 3 [1 2 3 4 5]) [1 2 3] > (take 2 [1 2 3 4 5])

slide-44

SLIDE 44

> (take 3 [1 2 3 4 5]) [1 2 3] > (take 2 [1 2 3 4 5]) [1 2]

slide-45

SLIDE 45

> (take 3 [1 2 3 4 5]) [1 2 3] > (take 2 [1 2 3 4 5]) [1 2] > (take [2 3] [1 2 3 4 5])

slide-46

SLIDE 46

> (take 3 [1 2 3 4 5]) [1 2 3] > (take 2 [1 2 3 4 5]) [1 2] > (take [2 3] [1 2 3 4 5]) Error: Result cells have mismatched shapes

slide-47

SLIDE 47

> (take 3 [1 2 3 4 5]) [1 2 3] > (take 2 [1 2 3 4 5]) [1 2] > (take [2 3] [1 2 3 4 5]) Error: Result cells have mismatched shapes Ragged results can arise from lifting non-ragged ops

slide-48

SLIDE 48

> (take* 3 [1 2 3 4 5])

slide-49

SLIDE 49

> (take* 3 [1 2 3 4 5]) (box [1 2 3])

slide-50

SLIDE 50

> (take* 3 [1 2 3 4 5]) (box [1 2 3]) > (take* [2 4] [1 2 3 4 5])

slide-51

SLIDE 51

> (take* 3 [1 2 3 4 5]) (box [1 2 3]) > (take* [2 4] [1 2 3 4 5]) [(box [1 2]) (box [1 2 3 4])]

slide-52

SLIDE 52

> (take* 3 [1 2 3 4 5]) (box [1 2 3]) > (take* [2 4] [1 2 3 4 5]) [(box [1 2]) (box [1 2 3 4])] > (take* (add1 (iota [5])) [1 2 3 4 5])

slide-53

SLIDE 53

> (take* 3 [1 2 3 4 5]) (box [1 2 3]) > (take* [2 4] [1 2 3 4 5]) [(box [1 2]) (box [1 2 3 4])] > (take* (add1 (iota [5])) [1 2 3 4 5]) [(box [1]) (box [1 2]) (box [1 2 3]) (box [1 2 3 4]) (box [1 2 3 4 5])]

slide-54

SLIDE 54

> (define (prefixes (v all)) ; Expect arg with at least one dimension (take* (add1 (iota [(length v)])) v))

slide-55

SLIDE 55

> (define (prefixes (v all)) ; Expect arg with at least one dimension (take* (add1 (iota [(length v)])) v)) > (define (multi-dist^2 (src 1) (dst-box 0)) (unbox dsts dst-box (box (dist^2 src dsts))))

slide-56

SLIDE 56

> (define (prefixes (v all)) ; Expect arg with at least one dimension (take* (add1 (iota [(length v)])) v)) > (define (multi-dist^2 (src 1) (dst-box 0)) (unbox dsts dst-box (box (dist^2 src dsts)))) > (multi-dist^2 points (prefixes points))

slide-57

SLIDE 57

> (define (prefixes (v all)) ; Expect arg with at least one dimension (take* (add1 (iota [(length v)])) v)) > (define (multi-dist^2 (src 1) (dst-box 0)) (unbox dsts dst-box (box (dist^2 src dsts)))) > (multi-dist^2 points (prefixes points)) [(box [p1->p1]) (box [p2->p1 p2->p2]) (box [p3->p1 p3->p2 p3->p3]) ...]

slide-58

SLIDE 58

Heterogeneous records

slide-59

SLIDE 59

> (define (champion (y 0) (c 0) (n 0)) {(year y) (city c) (name n)})

slide-60

SLIDE 60

> (define (champion (y 0) (c 0) (n 0)) {(year y) (city c) (name n)}) > (champion 2018 "Washington" "Capitals")

slide-61

SLIDE 61

> (define (champion (y 0) (c 0) (n 0)) {(year y) (city c) (name n)}) > (champion 2018 "Washington" "Capitals") {(year 2018) (city "Washington") (name "Capitals")}

slide-62

SLIDE 62

> (define (champion (y 0) (c 0) (n 0)) {(year y) (city c) (name n)}) > (champion 2018 "Washington" "Capitals") {(year 2018) (city "Washington") (name "Capitals")} > (define last-four (champion [2015 2016 2017 2018] ["Chicago" "Pittsburgh" "Pittsburgh" "Washington"] ["Blackhawks" "Penguins" "Penguins" "Capitals"]))

slide-63

SLIDE 63

> last-four

slide-64

SLIDE 64

> last-four [{(year 2015) (city "Chicago") (name "Blackhawks")} {(year 2016) (city "Pittsburgh") (name "Penguins")} {(year 2017) (city "Pittsburgh") (name "Penguins")} {(year 2018) (city "Washington") (name "Capitals")}]

slide-65

SLIDE 65

> last-four [{(year 2015) (city "Chicago") (name "Blackhawks")} {(year 2016) (city "Pittsburgh") (name "Penguins")} {(year 2017) (city "Pittsburgh") (name "Penguins")} {(year 2018) (city "Washington") (name "Capitals")}] > (shape-of last-four)

slide-66

SLIDE 66

> last-four [{(year 2015) (city "Chicago") (name "Blackhawks")} {(year 2016) (city "Pittsburgh") (name "Penguins")} {(year 2017) (city "Pittsburgh") (name "Penguins")} {(year 2018) (city "Washington") (name "Capitals")}] > (shape-of last-four) [4]

slide-67

SLIDE 67

> last-four [{(year 2015) (city "Chicago") (name "Blackhawks")} {(year 2016) (city "Pittsburgh") (name "Penguins")} {(year 2017) (city "Pittsburgh") (name "Penguins")} {(year 2018) (city "Washington") (name "Capitals")}] > (shape-of last-four) [4] > (head last-four)

slide-68

SLIDE 68

> last-four [{(year 2015) (city "Chicago") (name "Blackhawks")} {(year 2016) (city "Pittsburgh") (name "Penguins")} {(year 2017) (city "Pittsburgh") (name "Penguins")} {(year 2018) (city "Washington") (name "Capitals")}] > (shape-of last-four) [4] > (head last-four) {(year 2015) (city "Chicago") (name "Blackhawks")}

slide-69

SLIDE 69

> last-four [{(year 2015) (city "Chicago") (name "Blackhawks")} {(year 2016) (city "Pittsburgh") (name "Penguins")} {(year 2017) (city "Pittsburgh") (name "Penguins")} {(year 2018) (city "Washington") (name "Capitals")}] > (shape-of last-four) [4] > (head last-four) {(year 2015) (city "Chicago") (name "Blackhawks")} > (get city last-four)

slide-70

SLIDE 70

> last-four [{(year 2015) (city "Chicago") (name "Blackhawks")} {(year 2016) (city "Pittsburgh") (name "Penguins")} {(year 2017) (city "Pittsburgh") (name "Penguins")} {(year 2018) (city "Washington") (name "Capitals")}] > (shape-of last-four) [4] > (head last-four) {(year 2015) (city "Chicago") (name "Blackhawks")} > (get city last-four) ["Chicago" "Pittsburgh" "Pittsburgh" "Washington"]

slide-71

SLIDE 71

> last-four [{(year 2015) (city "Chicago") (name "Blackhawks")} {(year 2016) (city "Pittsburgh") (name "Penguins")} {(year 2017) (city "Pittsburgh") (name "Penguins")} {(year 2018) (city "Washington") (name "Capitals")}] > (shape-of last-four) [4] > (head last-four) {(year 2015) (city "Chicago") (name "Blackhawks")} > (get city last-four) ["Chicago" "Pittsburgh" "Pittsburgh" "Washington"] > (string=? "Pittsburgh" (get city last-four))

slide-72

SLIDE 72

> last-four [{(year 2015) (city "Chicago") (name "Blackhawks")} {(year 2016) (city "Pittsburgh") (name "Penguins")} {(year 2017) (city "Pittsburgh") (name "Penguins")} {(year 2018) (city "Washington") (name "Capitals")}] > (shape-of last-four) [4] > (head last-four) {(year 2015) (city "Chicago") (name "Blackhawks")} > (get city last-four) ["Chicago" "Pittsburgh" "Pittsburgh" "Washington"] > (string=? "Pittsburgh" (get city last-four)) [#f #t #t #f]

slide-73

SLIDE 73

Formalism

slide-74

SLIDE 74

slide-75

SLIDE 75

slide-76

SLIDE 76

Machine-friendly, fully-annotated syntax

slide-77

SLIDE 77

Machine-friendly, fully-annotated syntax Human-friendly shorthand (+ [1 2 3] [[10 20] [30 40] [50 60]])

slide-78

SLIDE 78

slide-79

SLIDE 79

slide-80

SLIDE 80

slide-81

SLIDE 81

slide-82

SLIDE 82

(+ [1 2 3] [[10 20] [30 40] [50 60]])

slide-83

SLIDE 83

(+ [1 2 3] [[10 20] [30 40] [50 60]])

: (Arr (-> ((Arr (Shp) Int) (Arr (Shp) Int)) (Arr (Shp) Int)) (Shp))

slide-84

SLIDE 84

(+ [1 2 3] [[10 20] [30 40] [50 60]])

: (Arr (-> ((Arr (Shp) Int) (Arr (Shp) Int)) (Arr (Shp) Int)) (Shp)) : (Arr (Shp 3) Int) : (Arr (Shp 3 2) Int)

slide-85

SLIDE 85

(+ [1 2 3] [[10 20] [30 40] [50 60]])

: (Arr (-> ((Arr (Shp) Int) (Arr (Shp) Int)) (Arr (Shp) Int)) (Shp)) : (Arr (Shp 3) Int) : (Arr (Shp 3 2) Int)

(Shp 3 2)

slide-86

SLIDE 86

(+ [1 2 3] [[10 20] [30 40] [50 60]]) : (Arr (Shp 3 2) Int)

: (Arr (-> ((Arr (Shp) Int) (Arr (Shp) Int)) (Arr (Shp) Int)) (Shp)) : (Arr (Shp 3) Int) : (Arr (Shp 3 2) Int)

(Shp 3 2)

slide-87

SLIDE 87

slide-88

SLIDE 88

Ensure ragged result data typed appropriately

slide-89

SLIDE 89

slide-90

SLIDE 90

slide-91

SLIDE 91

Canonicalize: fat append of bags-of-summands

slide-92

SLIDE 92

Cell-type polymorphism

slide-93

SLIDE 93

vec-norm : (-> ((Arr [3] Float)) Float)

slide-94

SLIDE 94

vec-norm : (-> ((Arr [2] Float)) Float)

slide-95

SLIDE 95

vec-norm : (-> ((Arr [L] Float)) Float)

slide-96

SLIDE 96

vec-norm : (Pi ((L Dim)) (-> ((Arr [L] Float)) Float))

slide-97

SLIDE 97

vec-norm : (Pi ((L Dim)) (-> ((Arr [L] Float)) Float)) n.b., shorthand for (Arr [] (Pi ((L Dim)) (Arr [] (-> ((Arr [L] Float)) (Arr [] Float)))))

slide-98

SLIDE 98

m*

slide-99

SLIDE 99

m* (Pi ((L Dim) (M Dim) (N Dim)) (-> ((Arr [L M] Float) (Arr [M N] Float)) (Arr [L N] Float)))

slide-100

SLIDE 100

m* (Pi ((L Dim) (M Dim) (N Dim)) (-> ((Arr [L M] Float) (Arr [M N] Float)) (Arr [L N] Float))) head

slide-101

SLIDE 101

m* (Pi ((L Dim) (M Dim) (N Dim)) (-> ((Arr [L M] Float) (Arr [M N] Float)) (Arr [L N] Float))) head (Pi ((L Dim)) (∀ ((T Atom)) (-> ((Arr [(+ L 1)] T)) (Arr [] T))))

slide-102

SLIDE 102

m* (Pi ((L Dim) (M Dim) (N Dim)) (-> ((Arr [L M] Float) (Arr [M N] Float)) (Arr [L N] Float))) head (Pi ((L Dim)) (∀ ((T Atom)) (-> ((Arr [(+ L 1)] T)) (Arr [] T)))) append

slide-103

SLIDE 103

m* (Pi ((L Dim) (M Dim) (N Dim)) (-> ((Arr [L M] Float) (Arr [M N] Float)) (Arr [L N] Float))) head (Pi ((L Dim)) (∀ ((T Atom)) (-> ((Arr [(+ L 1)] T)) (Arr [] T)))) append (Pi ((L1 Dim) (L2 Dim) (C Shape)) (∀ ((T Atom)) (-> ((Array (++ [L1] C) T) (Array (++ [L2] C) T)) (Array (++ [(+ L1 L2)] C) T))))

slide-104

SLIDE 104

Typing ragged data

slide-105

SLIDE 105

(box [1 2 3 4])

slide-106

SLIDE 106

(box [1 2 3 4]) (box 4 [1 2 3 4] (Sigma ((N Dim)) (Arr [N] Int)))

slide-107

SLIDE 107

(box [1 2 3 4]) (box 4 [1 2 3 4] (Sigma ((N Dim)) (Arr [N] Int))) (box 3 [1 2 3 4] (Sigma ((N Dim)) (Arr [(+ 1 N)] Int)))

slide-108

SLIDE 108

(box [1 2 3 4]) (box 4 [1 2 3 4] (Sigma ((N Dim)) (Arr [N] Int))) (box 3 [1 2 3 4] (Sigma ((N Dim)) (Arr [(+ 1 N)] Int))) (box [4] [1 2 3 4] (Sigma ((S Shape)) (Arr S Int)))

slide-109

SLIDE 109

(Sigma ((N Dim)) (Arr [N] Int))

slide-110

SLIDE 110

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length

slide-111

SLIDE 111

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length (Sigma ((N Dim)) (Arr [(+ 1 N)] Int))

slide-112

SLIDE 112

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length (Sigma ((N Dim)) (Arr [(+ 1 N)] Int)) Vector, nonempty

slide-113

SLIDE 113

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length (Sigma ((N Dim)) (Arr [(+ 1 N)] Int)) Vector, nonempty (Sigma ((M Dim) (N Dim)) (Arr [M N] Int))

slide-114

SLIDE 114

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length (Sigma ((N Dim)) (Arr [(+ 1 N)] Int)) Vector, nonempty (Sigma ((M Dim) (N Dim)) (Arr [M N] Int)) Matrix, unknown dimensions

slide-115

SLIDE 115

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length (Sigma ((N Dim)) (Arr [(+ 1 N)] Int)) Vector, nonempty (Sigma ((M Dim) (N Dim)) (Arr [M N] Int)) Matrix, unknown dimensions (Sigma ((S Shape)) (Arr S Int))

slide-116

SLIDE 116

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length (Sigma ((N Dim)) (Arr [(+ 1 N)] Int)) Vector, nonempty (Sigma ((M Dim) (N Dim)) (Arr [M N] Int)) Matrix, unknown dimensions (Sigma ((S Shape)) (Arr S Int)) Completely unknown shape

slide-117

SLIDE 117

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length (Sigma ((N Dim)) (Arr [(+ 1 N)] Int)) Vector, nonempty (Sigma ((M Dim) (N Dim)) (Arr [M N] Int)) Matrix, unknown dimensions (Sigma ((S Shape)) (Arr S Int)) Completely unknown shape (Sigma ((N Dim) (S Shape)) (Arr (++ [N] S) Int))

slide-118

SLIDE 118

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length (Sigma ((N Dim)) (Arr [(+ 1 N)] Int)) Vector, nonempty (Sigma ((M Dim) (N Dim)) (Arr [M N] Int)) Matrix, unknown dimensions (Sigma ((S Shape)) (Arr S Int)) Completely unknown shape (Sigma ((N Dim) (S Shape)) (Arr (++ [N] S) Int)) Rank at least one

slide-119

SLIDE 119

(Sigma ((N Dim)) (Arr [N] Int)) Vector, unknown length (Sigma ((N Dim)) (Arr [(+ 1 N)] Int)) Vector, nonempty (Sigma ((M Dim) (N Dim)) (Arr [M N] Int)) Matrix, unknown dimensions (Sigma ((S Shape)) (Arr S Int)) Completely unknown shape (Sigma ((N Dim) (S Shape)) (Arr (++ [N] S) Int)) Rank at least one But still all regular

slide-120

SLIDE 120

(Arr [4] (Sigma ((N Dim)) (Arr [N] Int)))

slide-121

SLIDE 121

(Arr [4] (Sigma ((N Dim)) (Arr [N] Int))) Four vectors, may vary in length

slide-122

SLIDE 122

(Arr [4] (Sigma ((N Dim)) (Arr [N] Int))) Four vectors, may vary in length (Sigma ((N Dim)) (Arr [4 N] Int))

slide-123

SLIDE 123

(Arr [4] (Sigma ((N Dim)) (Arr [N] Int))) Four vectors, may vary in length (Sigma ((N Dim)) (Arr [4 N] Int)) Four vectors, same unknown length

slide-124

SLIDE 124

(Arr [4] (Sigma ((N Dim)) (Arr [N] Int))) Four vectors, may vary in length (Sigma ((N Dim)) (Arr [4 N] Int)) Four vectors, same unknown length (Arr [4] (Sigma ((S Shape)) (Arr S Int)))

slide-125

SLIDE 125

(Arr [4] (Sigma ((N Dim)) (Arr [N] Int))) Four vectors, may vary in length (Sigma ((N Dim)) (Arr [4 N] Int)) Four vectors, same unknown length (Arr [4] (Sigma ((S Shape)) (Arr S Int))) Four arrays which may even differ in rank

slide-126

SLIDE 126

(Arr [4] (Sigma ((N Dim)) (Arr [N] Int))) Four vectors, may vary in length (Sigma ((N Dim)) (Arr [4 N] Int)) Four vectors, same unknown length (Arr [4] (Sigma ((S Shape)) (Arr S Int))) Four arrays which may even differ in rank (Sigma ((S Shape)) (Arr (++ [4] S) Int))

slide-127

SLIDE 127

(Arr [4] (Sigma ((N Dim)) (Arr [N] Int))) Four vectors, may vary in length (Sigma ((N Dim)) (Arr [4 N] Int)) Four vectors, same unknown length (Arr [4] (Sigma ((S Shape)) (Arr S Int))) Four arrays which may even differ in rank (Sigma ((S Shape)) (Arr (++ [4] S) Int)) Four arrays with same unknown shape

slide-128

SLIDE 128

(Arr [4] (Sigma ((N Dim)) (Arr [N] Int))) Four vectors, may vary in length (Sigma ((N Dim)) (Arr [4 N] Int)) Four vectors, same unknown length (Arr [4] (Sigma ((S Shape)) (Arr S Int))) Four arrays which may even differ in rank (Sigma ((S Shape)) (Arr (++ [4] S) Int)) Four arrays with same unknown shape Raggedness is frame structure around shape uncertainty

slide-129

SLIDE 129

filter : (Pi ((L Dim) (C Shape)) (∀ ((T Atom)) (-> ((Arr [L] Bool) (Arr (++ [L] C) T)) (Sigma ((N Dim)) (++ [N] C) T))))

slide-130

SLIDE 130

filter : (Pi ((L Dim) (C Shape)) (∀ ((T Atom)) (-> ((Arr [L] Bool) (Arr (++ [L] C) T)) (Sigma ((N Dim)) (++ [N] C) T)))) filter/p : (Pi ((L Dim) (C Shape)) (∀ ((T Atom)) (-> ((-> ((Arr C T)) Bool) (Arr (++ [L] C) T)) (Sigma ((N Dim)) (++ [N] C) T))))

slide-131

SLIDE 131

; Build a predicate to check ; membership in [lo,hi) in-range? : (-> (Int Int) (-> Int Bool))

slide-132

SLIDE 132

; Build a predicate to check ; membership in [lo,hi) in-range? : (-> (Int Int) (-> Int Bool)) (define binned-grades (filter/p (in-range? [ 0 60 70 80 90] [60 70 80 90 101]) grades))

slide-133

SLIDE 133

; Build a predicate to check ; membership in [lo,hi) in-range? : (-> (Int Int) (-> Int Bool)) (define binned-grades (filter/p (in-range? [ 0 60 70 80 90] [60 70 80 90 101]) grades)) binned-grades : (Arr [5] (Sigma ((N Dim)) (Arr [N] Int)))

slide-134

SLIDE 134

Type inference:

Identify index arguments elided by programmer

slide-135

SLIDE 135

Type inference:

Identify index arguments elided by programmer Function type (Pi (e ...) (-> ((Arr ι σ) ...) τ))

slide-136

SLIDE 136

Type inference:

Identify index arguments elided by programmer Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

slide-137

SLIDE 137

Type inference:

Identify index arguments elided by programmer Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

quantifiers for bound index vars

slide-138

SLIDE 138

Type inference:

Identify index arguments elided by programmer Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

quantifiers for bound index vars
quantifiers for frames

slide-139

SLIDE 139

Type inference:

Identify index arguments elided by programmer Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

quantifiers for bound index vars
quantifiers for frames
quantifiers for index arguments

slide-140

SLIDE 140

Type inference:

Identify index arguments elided by programmer Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

quantifiers for bound index vars
quantifiers for frames (eliminated before)
quantifiers for index arguments

slide-141

SLIDE 141

Type inference:

Identify index arguments elided by programmer Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

quantifiers for bound index vars
quantifiers for frames (eliminated before)
quantifiers for index arguments (solving for these)

slide-142

SLIDE 142

Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

slide-143

SLIDE 143

Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

slide-144

SLIDE 144

Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

slide-145

SLIDE 145

Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ...

slide-146

SLIDE 146

Function type Argument types (Pi (e ...) (-> ((Arr ι σ) ...) τ)) (Arr κ σ) ... Pretend are additional generators

slide-147

SLIDE 147

Why can we treat like additional generators?

slide-148

SLIDE 148

Why can we treat like additional generators? Algorithm for existential fragment (Makanin, 1977)

slide-149

SLIDE 149

Why can we treat like additional generators? Algorithm for existential fragment (Makanin, 1977) "How might subsequences align with each other?"

slide-150

SLIDE 150

Why can we treat like additional generators? Algorithm for existential fragment (Makanin, 1977) "How might subsequences align with each other?" Equations about smaller sequences

slide-151

SLIDE 151

Why can we treat like additional generators? Algorithm for existential fragment (Makanin, 1977) "How might subsequences align with each other?" Equations about smaller sequences No boundaries inside a generator

slide-152

SLIDE 152

Why can we treat like additional generators? Algorithm for existential fragment (Makanin, 1977) "How might subsequences align with each other?" Equations about smaller sequences No boundaries inside a generator ... or a universal variable

slide-153

SLIDE 153

Why can we treat like additional generators? Algorithm for existential fragment (Makanin, 1977) "How might subsequences align with each other?" Equations about smaller sequences No boundaries inside a generator ... or a universal variable Caveat: only works in conjunctive fragment

slide-154

SLIDE 154

slide-155

SLIDE 155

Type inference

slide-156

SLIDE 156

Type inference Compilation

slide-157

SLIDE 157

Type inference

Implement sketched algorithm

Compilation

slide-158

SLIDE 158

Type inference

Implement sketched algorithm Codebase for evaluating inference

Compilation

slide-159

SLIDE 159

Type inference

Implement sketched algorithm Codebase for evaluating inference

Compilation

Possible targets?

slide-160

SLIDE 160

Type inference

Implement sketched algorithm Codebase for evaluating inference

Compilation

Possible targets? IRs for array manipulation

slide-161

SLIDE 161

Type inference

Implement sketched algorithm Codebase for evaluating inference

Compilation

Possible targets? IRs for array manipulation

Broad goal

How much can we accomplish by combining a few powerful features instead of building lots of purpose-specifc machinery?
