Trustworthy Technologies for Local Area Management, Monitoring, and Control

Tom Overbye

Number of Activities: 5 2012 Industry Workshop October 30, 2012

| 2

TCIPG Technical Clusters and Threads

Trustworthy Technologies for Wide Area Monitoring and Control

Communication and Data Delivery (4 activities) Applications (2 activities) Component Technologies (3 activities)

Trustworthy Technologies for Local Area Management, Monitoring, and Control

Active Demand Management (3 activities) Distribution Networks (2 activities)

Responding To and Managing Cyber Events

Design of Semi-automated Intrusion Detection and Response Techniques (6 activities)

Trust Assessment

Model-based Assessment (6 activities) Experiment-based Assessment (5 activities)

| 3

Cluster Overview

• Cluster focuses on the distribution system and the end load
• Adding more renewable, but less

controllable generation, will require more participation by the electric load – Distributed generation may be embedded in “demand” – Demand could drastically change with new loads – New loads can have unexpected societal impacts

• New distribution technologies promise better reliability

– Cyber security of distributed devices is a growing concern

| 4

Cluster Problem Areas

• Focus on issues associated with making the distribution

system and load more known and/or controllable

• Directly addresses many of the core issues associated with

the “smart grid” – Traditionally, distribution and load have been viewed as relatively passive – Key smart grid premise is to make customers participants, providing information to help them optimize their electricity usage – Making the distribution and demand more “active” adds cyber security issues

138 kV 13.8 kV

1.00 pu 2 3 3.2 M W

• 2.0 M

var tap 1.050 3.3 M W

• 1.6 M

var

A MVA A MVA

1.063 pu 1.060 pu tap 1.050

1.060 pu 1.062 pu 1.062 pu 1.064 pu 1.064 pu

1.064 pu 1.067 pu 1.069 pu 1.067 pu 1.070 pu

1 Transm issionBus

| 5

Cluster Approach

• Objective of the cluster is to better determine and solve the

cyber security issues related to making for a more active distribution system and demand

• Distribution Network Thread

– Growing number of cyber enabled distribution system devices makes password management problematic

• Active Demand Management Thread

– As the load becomes more active, and potentially mobile, new opportunities and challenges are emerging

| 6

Activity Highlights

• Password Changing Protocol
• Large number of distributed devices make

password management difficult; activity is investigating the use of authenticated hand held devices that then communicate securely to the pole mounted devices

• Development of the Information Layer for

the V2G Framework Implementation

• Loss of fuel tax revenue is a key concern with a transition

to electric vehicles (EVs); looking at security aspects of mileage-based tax collection using GPS systems

| 7

Activity Highlights

• Trustworthy Framework for Mobile Smart Meters
• Idea is meter is on EV with reporting to utility of amount

charged, and utility providing the EV with pricing options; work is progressing on development of a basic obstacle- aware routing protocol

• Control of distributed reactive resources
• Distributed devices like EVs and PVs

can provide reactive power; algorithms needed to determine the amount of information necessary to determine the appropriate power factor

| 8

Cluster Impact

• Demonstration of the password changing framework

between a laptop and an android phone to test performance

• Specification of a basic reliable

routing protocol titled Obstacle- Aware Cyber-Physical Routing for Vehicle-to-Infrastructure Communication

• Assessment of past mileage-based data usage projects
• Development of a localized control scheme to achieve a

target household power factor using smart meters and a home monitoring and control system

| 9

Planned Research for Coming Year

• Explore camera based authentication protocols.
• Continue the assessment of previous EV studies, and

develop a set of key requirements for the architecture and the data collection/processing aspects

• Study the issues of reliable and secure communication and

routing over heterogeneous networks (WiFi/cellular/ZigBee)

• Move towards validation on distributed reactive resource

control algorithms on the UIUC distribution network

| 10

Questions?
