TRUCK Wi-Fi

POWERED BY

Eagle Automation and Andium

The automation specialists at Eagle Automation have partnered with technology developer Andium to create new industry-ready products, giving users the ability to improve their operations without hassle. It’s our goal to help our customers efficiently and effectively manage their business with turn-key solutions to their everyday problems.

Overview

• Product Overview/Features
• What is Truck Wi-Fi?
• Key Features
• System Options
• Andium C-Suite Integration
• What is C-Suite?
• C-Suite and Truck Wi-Fi
• Case Study

Product Overview/Features

What is Truck Wi-Fi? Key Features System Options

What is Truck Wi-Fi?

Eagle Automation Truck Wi-Fi devices powered by Andium provide a turn-key solution for ensuring robust in-vehicle cellular and Wi-Fi connectivity at speeds sufficient to support remote office

• functions. Associated antenna sets are

able to boost the same signal well beyond the confines of the vehicle for dismounted use. The Interactive Vehicle Telematics Analysis package joins key data provided by Truck Wi-Fi devices with industry-leading business analytics tools and Andium’s user-friendly dashboarding software, providing unique operational insights.

Key Features

• Reliable 2G/3G/4G/LTE cellular coverage, even in remote areas
• Demonstrated superior to Verizon Jetpack in poor-service areas
• Boosted cellular and Wi-Fi signal from installed vehicle
• 50ft – 100ft radius
• Simple installation
• Both permanent and temporary options
• Remote, over-the-air configuration of devices
• High-speed data
• Flexible data plans
• Multiple cellular carrier support
• AT&T and Verizon
• Two available antenna upgrade packages

Key Features

Device Photos

System Options

• Cellular Carrier
• AT&T
• Verizon
• Both (Dual SIM Cards)
• Data Package
• Unlimited data and 10GB of 4G LTE per month (throttled to 3G after 10GB usage)
• Unlimited data with increased 4G LTE data (additional cost)
• Antenna Configuration
• Standard
• Low-profile cellular MiMo antenna
• GPS puck antenna
• SMA Wi-Fi antenna
• (2) SMA cellular antennas
• Antenna Upgrade 1
• GPSD multifunction MiMo antenna (Cell/Wi-Fi/GPS/GNSS)
• Standard antennas included
• Antenna Upgrade 2
• Improved low-profile MiMo antenna (Cell/Wi-Fi/GPS/GNSS)
• Standard antennas included

System Options

Antenna Upgrade 1

For clients who desire improved performance from their Truck Wi-Fi system while simplifying their vehicle antenna configuration into one low-profile “shark fin” design, Antenna Upgrade 1 is the perfect choice. This antenna is designed around the rugged Panorama low-profile MiMo cellular antenna with included GPS/GNSS. The package includes all of the ultra-low- loss cabling necessary to extend the two cellular antenna cables, one Wi-Fi antenna cable, and one GPS antenna cable from antenna to router.

Included Accessories

(1) Black GPSD Multifunction MiMo Antenna (GPS/GNSS, 4G/3G/2G, 2.4/4.9-6GHz) (2) CS29 5mm ultra-low-loss double shielded cable extension for cellular antenna (1) CS32 5mm ultra-low-loss double shielded cable extension for Wi-Fi antenna (1) RG174 2.8mm ultra-low-loss performance cable extension for GPS antenna

System Options

Antenna Upgrade 2

For the highest level of coverage when operating in especially remote areas, Antenna Upgrade 2 includes the award-winning Panorama “Great White” low profile MiMo antenna. Recognized as a 2014 FCS Gerald David CBE Innovation in Business Radio Award winner and a 2015 International TETRA Awards finalist, this rugged, low-profile antenna was designed to provide optimal support to high- performing vehicle LTE routers even in the most-remote

• areas. Also included is the same set of ultra-low-loss

antenna cable extensions as Antenna Upgrade 1.

Included Accessories

(1) Black GPSD Multifunction MiMo Antenna (GPS/GNSS, 4G/3G/2G, 2.4/4.9-6GHz) (2) CS29 5mm ultra-low-loss double shielded cable extension for cellular antenna (1) CS32 5mm ultra-low-loss double shielded cable extension for Wi-Fi antenna (1) RG174 2.8mm ultra-low-loss performance cable extension for GPS antenna

System Options

IVTA (included with all Eagle Automation Truck Wi-Fi packages) allows clients to view device-specific data related to GPS location, vehicle speed, device signal strength, and time spent at each location. This data,

• rganized by device serial number or user-defined alias,

is analyzed using the powerful, industry-leading Microsoft Power Business Intelligence (Power BI) toolset, then visualized for Truck Wi-Fi customers with the IVTA packages in a custom-designed, interactive reporting format.

Interactive Vehicle Telematics Analysis (IVTA)

Use Cases for IVTA

• Optimizing fleet routing from vehicle GPS/GNSS data
• Ensuring driver speed restriction compliance
• Monitoring time-on-location
• Tracking/mapping cellular signal strength across operating areas

Andium C-Suite Integration

What is C-Suite? C-Suite and Truck Wi-Fi

What Is C-Suite?

• Central: Main portal and admin hub for Andium C-Suite
• Overall system health monitoring (device, data stream, etc.)
• Remote, over-the-air configuration of devices
• Made up of widgets and dashboards for system management
• Curate: Data visualization dashboard
• Used for real-time data visualization (charting)
• Allows for set-up of event driven notification
• Tools for data exporting
• Collaborate: Tool for third-party software integrations
• Data analysis and reporting using embedded business analytics tools (ex. Microsoft

Power BI)

• Tailored integration of other third party tools as requested

The Andium C-Suite is a robust set of web-based, user friendly cloud dashboarding tools to ensure maximum value for customers interacting with their data.

C-Suite and Truck Wi-Fi

Collaborate is the primary tool for clients to utilize the IVTA package to interact with their data. The data is processed using industry-leading Microsoft Power BI tools. IVTA can be used to view a client’s selected Truck Wi-Fi devices on a mapping tool, which includes filtering for a selected date range for data analysis. Groups of devices can be selected by location, while individual devices (or groups of individual devices) can be selected by serial number or user-defined alias.

Collaborate will allow clients to access the following data:

• Vehicle speed (can be visualized by color to identify high rates of speed)
• Time spent at each location (visualized by size of point marker)
• Vehicle route (visualized by the collection of individual points)
• Device signal strength (rated from 1-5, represented by color)

C-Suite and Truck Wi-Fi

Shown:

• Vehicle route (visualized by the collection of individual points)
• Device signal strength (rated from 1-5, represented by color)

Shown:

• Time spent at each location (visualized by size of point marker)
• Device signal strength (rated from 1-5, represented by color)

C-Suite and Truck Wi-Fi

Case Study

Case Study

• BP Lower 48 Onshore conducted a

pilot test of Truck Wi-Fi in West Texas

• Previously, technicians servicing

wells located at the bottom of 400+ foot canyons were unable to maintain cellular connectivity

• Use of Truck Wi-Fi allowed these

technicians to not only establish cellular signal, but to sustain a useable internet connection during

• perations

Case Study

• Communication at well sites improved from 40% of

locations to 90% with the implementation of the Truck Wi-Fi units

• Nearly 300 units have since been successfully

employed throughout Colorado, New Mexico, Texas, and Oklahoma

40% 90%

The number of internet-capable well sites more than doubled.

Summary

• Eagle Automation’s Truck Wi-Fi brings reliable cellular

coverage and internet to even the most remote areas, providing field operators with the ability to perform

• ffice functions while on the go
• C-Suite, powered by Andium, combines key data with

industry-leading business analytics tools to create unique operational insights for fleet management

• This turn-key solution allows customers to act efficiently

and effectively when executing their day-to-day functions

For all inquiries, please contact sales@eagleautomation.com
