TROPHY CLUB MUNICIPAL UTILITY DISTRICT WASTEWATER TREATMENT PLANT PROBLEMS & POSSIBLE SOLUTIONS Presented by: 1825 Market Center Blvd Dallas, Texas 75207 Work Completed Performed elevation survey of key components of the WWTP

SLIDE 1

TROPHY CLUB MUNICIPAL UTILITY DISTRICT WASTEWATER TREATMENT PLANT PROBLEMS & POSSIBLE SOLUTIONS Presented by: 1825 Market Center Blvd Dallas, Texas 75207

SLIDE 2

Work Completed

Performed elevation survey of key components of the

WWTP equipment in order to study the hydraulic profile

f the plant.
Performed calculations for the sizing of various units and

pipe sizing per flow requirements and loading parameters.

Reviewed previous permitting and design documents as

well as past and existing permits.

Conducted meetings with Jennifer McKnight and Karl

Schlielig in order to assess how the plant is currently being operated and what problems they observe from

perations and managements spectrums.

SLIDE 3

TCMUD WWTP Original Design vs Current Conditions

Original Design

Population* – 10,000
BOD – 10mg/l
TSS – 15mg/l
Raw – 180mg/l
Q = 1.75 MGD

Current Conditions

Population* – 13,000 -14,000
BOD – 5 mg/l
TSS – 10mg/l
Raw – 200-240mg/l
Q = 1.90 MGD

*Town of Trophy Club Only

SLIDE 4

Aeration Basins

Aeration Basins Issues

Limited Capacity & Number
Wall Elevations Too Low
Splitter Box Too High

SLIDE 5

Tertiary Filters

Filter Issues

Limited Hydraulically
No Redundancy

SLIDE 6

RAS/WAS Pump Station

Pump Issues

RAS and WAS Pump Limitations
Capacity and Operating Flexibility

SLIDE 7

Effluent Lift Station

Effluent Lift Station Issues

Insufficient Pump Capacity
UV Channel/Weirs Surcharging

SLIDE 8

Recommendations

Complete detailed Preliminary Engineering

Report (PER) to consider options, sizes, locations and cost estimates:

– Detailed Unit Process Assessment – Submit PER to TCEQ – Construct Third Treatment Basin & Modify Existing Basins – Construct Third Tertiary Filter Basin – Upgrade Pump Stations – RAS/WAS and Effluent – Biosolids/Sludge Operations Enhancements

Investigate Funding Options

SLIDE 9

Funding Options

TYPE DURATION RATE Open Market 3 months 3.75 – 4.25% TWDBD Development Fund 8 months 4.1% TWDBD Clean Water Supply Revolving Fund 2 years 3.1%
