Tries and Suffix Trees

Inge Li Gørtz

• String matching problem. Given strings T (text) and P (pattern) over an alphabet Σ,

report starting positions of all occurrences of P in T.

• Finite automaton: O(mΣ + n) time and space
• KMP: O(m+n) time and space
• String indexing problem. Given a string S of characters from an alphabet Σ.

Preprocess S into a data structure to support

• Search(P): Return starting position of all occurrences of P in S.
• Today: Data structure using O(n) space and supporting Search(P) in O(m) time.
• Applications:
• Search engines, e.g. prefix searches.
• Finding common substrings of many biological strings
• Finding repeating substructures in biological strings
• Detecting DNA contamination

String indexing problem

• Tries
• Compressed tries
• Suffix trees
• Applications of suffix trees

Outline

Tries

• Text retrieval
• Trie over the strings: sells, by, the, sea, shells, tea.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

• Text retrieval
• Prefix-free?
• Trie over the strings: sells, by, the, sea, shells, tea, she.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

• Text retrieval
• Prefix-free?
• Trie over the strings: sells, by, the, sea, shells, tea, she.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “sea”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

S4

Tries

b y

S2 S1

s s s

S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “short”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “short”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “short”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “short”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Text retrieval
• Search for “short”
• Trie over the strings: sells$, by$, the$, sea$, shells$, tea$, she$.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Build a trie over the strings: by$, sells$, sea$.

Tries

b y

S2 S1

s s

S4

e a l l $ $ $

• Properties of the trie. A trie T storing a collection S of s strings of total length n from

an alphabet of size d has the following properties:

• How many children can a node have?
• How many leaves does T have?
• What is the height of T?
• What is the number of nodes in T?

Trie

• Search time: O(d) in each node => O(dm).
• O(m) if d constant.
• d not constant: use dictionary
• Hashing O(1)
• Balanced BST: O(log d)
• Time and space for a trie (for small/constant d):
• O(m) for searching for a string of length m.
• O(n) space.
• Preprocessing: O(n)

Trie

• Prefix search: return all words in the trie starting with “se”

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Prefix search: return all words in the trie starting with “se”

• Prefix search: return all words in the trie starting with “se”

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Time for prefix search: O(m) + time to report all occurrences.
• Solution: compact tries.

Trie

Could be large!!

Compact tries

• Compact trie: Chains of nodes with a single child is merged into a single node.

Tries

b y

S2 S1

s s s

S4 S6 S3

e e e e a a l l l l h h t

S5

$ $ $ $ $ $

S7

$

• Compact trie: Chains of nodes with a single child is merged into a single node.

Tries

b t y a s

e

l l e s a h e h e l l s $ $ $ $ $ $ $

b y $ S2 s e a $ S4 l l s $ S1 he l l s $ S6 S3 S5 S7 $ t e a $ h e $

• Properties of the compact trie. A compact trie T storing a collection S of s strings of

total length n from an alphabet of size d has the following properties:

• Every internal node of T has at least 2 and at most d children.
• T has s leaves
• The number of nodes in T is < 2s.
• Time and space for a compact trie (constant d):
• O(m) for searching for a string of length m.
• O(m + occ) for prefix search, where occ = #occurrences
• O(s) space.
• Preprocessing: O(n)

Trie

Suffix trees

• String indexing problem. Given a string S of characters from an alphabet Σ.

Preprocess S into a data structure to support

• Search(P): Return starting position of all occurrences of P in S.
• Build a compressed trie over all suffixes of S (suffix tree). Label leaves with

index of suffix.

• Observation: An occurrence of P is a prefix of a suffix of S.

Suffix tree

• ccurrence of P

Suffix of S

• String indexing problem. Given a string S of characters from an alphabet Σ.

Preprocess S into a data structure to support

• Search(P): Return starting position of all occurrences of P in S.
• Build a compressed trie over all suffixes of S (suffix tree). Label leaves with

index of suffix.

• Observation: An occurrence of P is a prefix of a suffix of S.
• Example: P = ana.

Suffix tree

• ccurrence of P

Suffix of S b a n a n a s t r i n g s s a l a d s Suffix of S Suffix of S

• Suffix tree: over the string banana$

Suffix Tree

$

b

1

a n a a n a

$ 6

n a

$ 4

n a

$ 2

n a n a

$ 3 5 $ $ 7

• Suffix tree: over the string banana$

Suffix Tree

$

b

1

a n a a n a

$ 6

n a

$ 4

n a

$ 2

n a n a

$ 3 5 $ $ 7

• Search for P

.

• Report labels of all leaves

below final node

• Suffix tree: over the string banana$
• Find all occurrences of P=“an”

Suffix Tree

$

b

1

a n a a n a

$ 6

n a

$ 4

n a

$ 2

n a n a

$ 3 5 $ $ 7

• Search for P

.

• Report labels of all leaves

below final node

• Suffix tree: over the string banana$

Suffix Tree

$

b

1

a n a a n a

$ 6

n a

$ 4

n a

$ 2

n a n a

$ 3 5 $ $ 7

1 2 3 4 5 6 7 b a n a n a $

• Store S and store node labels by reference to S.

• Suffix tree: over the string banana$

Suffix Tree

1

[2,2]

6 4 2 3 5 7

1 2 3 4 5 6 7 b a n a n a $

• Store S and store node labels by reference to S.

[3,4] [7,7] [5,7] [7,7] [7,7] [7,7] [1,7] [3,4] [5,7]

Suffix trees and common substrings

9 18 15 12 7 16 3 6 14 11 2 10 13 5 1 17 8 4

$2 $1 $2 $2 $2 $1 $1 $2 $2 $1 $1 $2 $2 $1 $1 $2 $1 $1

• Suffix tree of a string S: Compact trie over all suffixes of S.
• Space and time:
• Space: O(n)
• Search time: O(m) + time to report all occurrences = O(m+occ)
• Preprocessing: Can be done in O(sort(n,|Σ|)) time, where sort(n,|Σ|) is the time it

takes to sort n characters from an alphabet Σ.

• Suffix trees can be used to solve the String indexing problem in:
• Space: O(n)
• Search time: O(m+occ)
• Preprocessing: O(sort(n,|Σ|)) time

Suffix tree

Applications of suffix trees

• Find longest common substring of strings S1 and S2.
• Construct the suffix tree over S1$1S2$2.
• Example: Find longest common substring of piespies and piepiees:
• Construct suffix tree of piespies$1piepiees$2.

Longest common substring

• Suffix tree of piespies$1piepiees$2.

Generalized suffix tree

$1

9 18 15 12 7 16 3 6 14 11 2 10 13 5 1 17 8 4

$2 $1 $1 $1 $2 $2 $2 $2 $2 p p p p p i i i e e e e e e e e s s s s s s i i i s s $1 $2 $2 $2 s s e e . . . . . . . . . . . . . . . e e $2 $2 $2 $2 $1 $2 . . . e $2 s p s i e $1 $2 . . . p s i $1 $2 e . . . p s i $1 $2 e . . .

• Suffix tree of piespies$1piepiees$2.
• Mark leaf with if $1 suffix starts in S1.

Generalized suffix tree

9 18 15 12 7 16 3 6 14 11 2 10 13 5 1 17 8 4

$2 $1 $2 $2 $2 $1 $1 $2 $2 $1 $1 $2 $2 $1 $1 $2 $1 $1

• Suffix tree of piespies$1piepiees$2.
• Mark leaf with if $1 suffix starts in S1.

Generalized suffix tree

9 18 15 12 7 16 3 6 14 11 2 10 13 5 1 17 8 4

$2 $1 $2 $2 $2 $1 $1 $2 $2 $1 $1 $2 $2 $1 $1 $2 $1 $1

• Suffix tree of piespies$1piepiees$2.
• Mark leaf with if $1 suffix starts in S1.
• Add string-depth.

15 11 1

Generalized suffix tree

9 18 15 12 7 16 3 6 14 11 2 10 13 5 1 17 8 4

$2 $1 $2 $2 $2 $1 $1 $2 $2 $1 $1 $2 $2 $1 $1 $2 $1 $1

[18,18] [9,18] [15,15] [16,18] [13,18] [17,17] [18,18] [9,18] [5,18] [14,15] [16,18] [13,18] [8,8] [9,18] [5,18] [13,15] [16,18] [13,18] [8,8] [9,18] [5,18] [18,18] [17,17] [9,18] [5,18] 1 10 1 4 7 2 3 12 16 2 5 8 3 13 17 3 6 9 4 14 18

13 3

• Suffix tree of piespies$1piepiees$2.
• Mark leaf with if $1 suffix starts in S1.
• Add string-depth.

15 11 1

Generalized suffix tree

9 18 15 12 7 16 3 6 14 11 2 10 13 5 1 17 8 4

$2 $1 $2 $2 $2 $1 $1 $2 $2 $1 $1 $2 $2 $1 $1 $2 $1 $1

[18,18] [9,18] [15,15] [16,18] [13,18] [17,17] [18,18] [9,18] [5,18] [14,15] [16,18] [13,18] [8,8] [9,18] [5,18] [13,15] [16,18] [13,18] [8,8] [9,18] [5,18] [18,18] [17,17] [9,18] [5,18] 1 11 1 4 7 2 3 12 16 2 5 8 3 17 6 9 4 14 18

S[13,15] = “pie” is the longest common substring.

• Using a suffix tree we can solve the longest common substring problem in linear

time (for a constant size alphabet).

Longest common substring
