Suffix Trees

Construction and Applications

João Carreira 2008

Outline

• Why Suffix Trees?
• Definition
• Ukkonen's Algorithm (construction)
• Applications

Why Suffix Trees?

Why Suffix Trees?

• Asymptotically fast.

Why Suffix Trees?

• Asymptotically fast.
• The basis of state of the art data structures.

Why Suffix Trees?

• Asymptotically fast.
• The basis of state of the art data structures.
• You don't need a Phd to use them.

Why Suffix Trees?

• Asymptotically fast.
• The basis of state of the art data structures.
• You don't need a Phd to use them.
• Challenging.

Why Suffix Trees?

• Asymptotically fast.
• The basis of state of the art data structures.
• You don't need a Phd to use them.
• Challenging.
• Expose interesting algorithmic ideas.

Definition

• m leaves numbered 1 to m

Suffix Tree for an m-character string:

Definition

• m leaves numbered 1 to m
• edge-label vs node-label

Suffix Tree for an m-character string:

Definition

• m leaves numbered 1 to m
• edge-label vs node-label
• each internal node has at least two children

Suffix Tree for an m-character string:

Definition

• m leaves numbered 1 to m
• edge-label vs node-label
• each internal node has at least two children
• the label of the leaf j is S[ j..m ]

Suffix Tree for an m-character string:

Definition

• m leaves numbered 1 to m
• edge-label vs node-label
• each internal node has at least two children
• the label of the leaf j is S[ j..m ]
• no two edges out of the same node can have edge-labels

beginning with the same character Suffix Tree for an m-character string:

Definition Example

String: xabxac Length (m): 6 characters Number of Leaves: 6 Node 5 label: ac

Implicit vs Explicit

• What if we have “axabx” ?

Ukkonen's Algorithm

suffix tree construction

Ukkonen's Algorithm

• Text: S[ 1..m ]
• m phases
• phase j is divided into j extensions:

In extension j of phase i + 1:

• find the end of the path from the root labeled with substring S[ j..i ]
• extend the substring by adding the character S(i + 1) to its end

suffix tree construction

Extension Rules

• Rule 1: Path β ends at a leaf. S(i + 1) is added to the end of the label on that leaf edge.

Extension Rules

• Rule 2: No path from the end of β starts with S(i + 1), but at least one labeled path

continues from the end of β.

Extension Rules

• Rule 3: Some path from the end of β starts with S(i + 1), so we do nothing.

Ukkonen's Algorithm

Complexity:

suffix tree construction

Ukkonen's Algorithm

Complexity:

• m phases

suffix tree construction

Ukkonen's Algorithm

Complexity:

• m phases
• phase j -> j extensions

suffix tree construction

Ukkonen's Algorithm

Complexity:

• m phases
• phase j -> j extensions
• find the end of the path of substring β: O(|β|) = O(m)

suffix tree construction

Ukkonen's Algorithm

Complexity:

• m phases
• phase j -> j extensions
• find the end of the path of substring β: O(|β|) = O(m)
• each extension: O(1)

suffix tree construction

Ukkonen's Algorithm

Complexity:

• m phases
• phase j -> j extensions
• find the end of the path of substring β: O(|β|) = O(m)
• each extension: O(1)

O(m3)

suffix tree construction

“First make it run, then make it run fast.”

Brian Kernighan

Suffix Links

Definition:

• For an internal node v with path-label xα, if there is another node s(v), with

path-label α, then a pointer from v to s(v) is called a suffix link.

Suffix Links

Lemma:

• If a new internal node v with path label xα is added to the current tree in extension

j of some phase, then either the path labeled α already ends at an internal node

• r an internal at the end of the string α will be created in the next extension
• f the same phase.

If Rule 2 applies:

Suffix Links

Lemma:

• If a new internal node v with path label xα is added to the current tree in extension

j of some phase, then either the path labeled α already ends at an internal node

• r an internal at the end of the string α will be created in the next extension
• f the same phase.

If Rule 2 applies:

• S[ j..i ] continues with c ≠ S(i + 1)

Suffix Links

Lemma:

• If a new internal node v with path label xα is added to the current tree in extension

j of some phase, then either the path labeled α already ends at an internal node

• r an internal at the end of the string α will be created in the next extension
• f the same phase.

If Rule 2 applies:

• S[ j..i ] continues with c ≠ S(i + 1)
• S[ j + 1..i ] continues with c.

Single Extension Algorithm

Extension j of phase i + 1:

• 1. Find the first node v at or above the end of S[ j - 1..i ] that either has a suffix link

from it or is the root. Let λ denote the string between v and the end of S[ j – 1..i ].

Single Extension Algorithm

Extension j of phase i + 1:

• 1. Find the first node v at or above the end of S[ j - 1..i ] that either has a suffix link

from it or is the root. Let λ denote the string between v and the end of S[ j – 1..i ].

• 2. If v is the root, follow the path for S[ j..i ] (as in the naive algorithm). Else traverse the

suffix link and walk down from s(v) following the path for string λ.

Single Extension Algorithm

Extension j of phase i + 1:

• 1. Find the first node v at or above the end of S[ j - 1..i ] that either has a suffix link

from it or is the root. Let λ denote the string between v and the end of S[ j – 1..i ].

• 2. If v is the root, follow the path for S[ j..i ] (as in the naive algorithm). Else traverse the

suffix link and walk down from s(v) following the path for string λ.

• 3. Using the extension rules, ensure that the string S[ j..i ] S(i+1) is in the tree.

Single Extension Algorithm

Extension j of phase i + 1:

• 1. Find the first node v at or above the end of S[ j - 1..i ] that either has a suffix link

from it or is the root. Let λ denote the string between v and the end of S[ j – 1..i ].

• 2. If v is the root, follow the path for S[ j..i ] (as in the naive algorithm). Else traverse the

suffix link and walk down from s(v) following the path for string λ.

• 3. Using the extension rules, ensure that the string S[ j..i ] S(i+1) is in the tree.
• 4. If a new internal w was created in extension j – 1 (by rule 2), then string α must

end at node s(w), the end node for the suffix link from w. Create the suffix link (w, s(w)) from w to s(w).

Node Depth

The node-depth of v is at most one greater than the node depth of s(v).

α ß xß xα xλ λ xß xα xλ ß α λ equal node-depth: 3 Node depth: 4 Node depth: 3

• γ number of characters in an edge
• “Directly implemented” edge traversal: O(|γ|)

Skip/count Trick

Skip/count Trick

• “Jump” from node to node.
• K = number of nodes in a path
• Time to traverse a path: O(|K|)
• γ number of characters in an edge
• “Directly implemented” edge traversal: O(|γ|)

Ukkonen's Algorithm

Using the skip/count trick:

• any phase of Ukkonen's algorithm takes O(m) time.

Proof:

Ukkonen's Algorithm

Using the skip/count trick:

• any phase of Ukkonen's algorithm takes O(m) time.

Proof:

• There are i + 1 ≤ m extensions in phase i + 1

Ukkonen's Algorithm

Using the skip/count trick:

• any phase of Ukkonen's algorithm takes O(m) time.

Proof:

• There are i + 1 ≤ m extensions in phase i + 1
• In a single extension, the algorithm walks up at most one edge, traverses one suffix link,

walks down some number of nodes, applies the extension rules and may add a suffix link.

Ukkonen's Algorithm

Using the skip/count trick:

• any phase of Ukkonen's algorithm takes O(m) time.

Proof:

• There are i + 1 ≤ m extensions in phase i + 1
• In a single extension, the algorithm walks up at most one edge, traverses one suffix link,

walks down some number of nodes, applies the extension rules and may add a suffix link.

• The up-walk decreases the current node-depth by at most one.

Ukkonen's Algorithm

Using the skip/count trick:

• any phase of Ukkonen's algorithm takes O(m) time.

Proof:

• There are i + 1 ≤ m extensions in phase i + 1
• In a single extension, the algorithm walks up at most one edge, traverses one suffix link,

walks down some number of nodes, applies the extension rules and may add a suffix link.

• The up-walk decreases the current node-depth by at most one.
• Each suffix link traversal decreases the node-depth by at most another one.

Ukkonen's Algorithm

Using the skip/count trick:

• any phase of Ukkonen's algorithm takes O(m) time.

Proof:

• There are i + 1 ≤ m extensions in phase i + 1
• In a single extension, the algorithm walks up at most one edge, traverses one suffix link,

walks down some number of nodes, applies the extension rules and may add a suffix link.

• The up-walk decreases the current node-depth by at most one.
• Each suffix link traversal decreases the node-depth by at most another one.
• Each down-walk moves to a node of greater depth.

Ukkonen's Algorithm

Using the skip/count trick:

• any phase of Ukkonen's algorithm takes O(m) time.

Proof:

• There are i + 1 ≤ m extensions in phase i + 1
• In a single extension, the algorithm walks up at most one edge, traverses one suffix link,

walks down some number of nodes, applies the extension rules and may add a suffix link.

• The up-walk decreases the current node-depth by at most one.
• Each suffix link traversal decreases the node-depth by at most another one.
• Each down-walk moves to a node of greater depth.
• Over the entire phase the node-depth is decremented at most 2m times.

Ukkonen's Algorithm

Using the skip/count trick:

• any phase of Ukkonen's algorithm takes O(m) time.

Proof:

• There are i + 1 ≤ m extensions in phase i + 1
• In a single extension, the algorithm walks up at most one edge, traverses one suffix link,

walks down some number of nodes, applies the extension rules and may add a suffix link.

• The up-walk decreases the current node-depth by at most one.
• Each suffix link traversal decreases the node-depth by at most another one.
• Each down-walk moves to a node of greater depth.
• Over the entire phase the node-depth is decremented at most 2m times.
• No node can have depth greater than m, so the total increment to current node-depth

(down walks) is bounded by 3m over the entire phase.

Ukkonen's Algorithm

• m phases
• 1 phase: O(m)

Ukkonen's Algorithm

• m phases
• 1 phase: O(m)

O(m2)

“First make it run fast, then make it run faster.”

João Carreira

Edge-Label Compression

• A string with m characters has m suffixes.
• If edge labels are represented with characters, O(m2) space is needed.

Edge-Label Compression

• A string with m characters has m suffixes.
• If edge labels are represented with characters, O(m2) space is needed.

To achieve O(m) space, each edge-label:

(p, q)

Two more tricks...

Rule 3 is a show stopper

If rule 3 applies in extension j, it will also apply in all further extensions until the end of the phase. Why?

Rule 3 is a show stopper

If rule 3 applies in extension j, it will also apply in all further extensions until the end of the phase. Why?

• When rule 3 applies, the path labeled S[ j..i ] must continue with character S(i + 1), and

so the path labeled S[ j + 1..i ] does also, and rule 3 again applies in extensions j+1...i+1.

Rule 3 is a show stopper

• End any phase i +1 the first time rule 3 applies.
• The remaining extensions are said to be done implicitly.

Once a leaf always a leaf

• Leaf created => always a leaf in all successive trees.
• No mechanism for extending a leaf edge beyond its current leaf.
• Once there is a leaf labeled j, extension rule 1 will always apply to extension j

in any sucessive phase.

Once a leaf always a leaf

• Leaf created => always a leaf in all successive trees.
• No mechanism for extending a leaf edge beyond its current leaf.
• Once there is a leaf labeled j, extension rule 1 will always apply to extension j

in any sucessive phase.

Leaf Edge Label:

(p, e)

Single Phase Algorithm

In each phase i:

Single Phase Algorithm

During construction:

Implicit to Explicit

One last phase to add character $: O(m)

Suffix Trees are a Swiss Knife

Applications

Exact String Matching:

Applications

Exact String Matching:

Three ocurrences of string aw. Preprocessing: O(m) Search: O(n + k)

Applications

And much more..

• Longest common substring

O(n)

• Longest repeated substring

O(n)

• Longest palindrome

O(n)

• Most frequently occurring substrings of a minimum length

O(n)

• Shortest substrings occurring only once

O(n)

• Lempel-Ziv decomposition

O(n)

• .....

“Biology easily has 500 years of exciting problems to work on.”

Donald Knuth

web.ist.utl.pt/joao.carreira

web.ist.utl.pt/joao.carreira

Questions?
