Transcatheter Aortic Replacement: Advances in Technology, Procedure and Patient Selection Alexander (Sandy) Dick, MD ACC Rockies, 2015 Disclosures None Smoothing out bumps Learning Objectives Understand current risk predictor

slide-1
SLIDE 1

Transcatheter Aortic Replacement: Advances in Technology, Procedure and Patient Selection

Alexander (Sandy) Dick, MD ACC Rockies, 2015

slide-2
SLIDE 2

Disclosures

  • ‰ None
slide-3
SLIDE 3

Smoothing out bumps

slide-4
SLIDE 4

Learning Objectives

  • ‰ Understand current risk predictor scores

and limitations in prediction of outcomes

  • ‰ Importance of Quality of Life measures
  • ‰ Appreciate the crucial role of CT for

patient selection, valve selection, access site and outcomes

  • ‰ Emphasize the future of the minimalist

approach

slide-5
SLIDE 5

Partner 2 yr Follow-up

NEJM, 2012

slide-6
SLIDE 6

CoreValve US Pivotal Trial

Adams et al NEJM 2014

slide-7
SLIDE 7
slide-8
SLIDE 8

Risk Score

  • ‰ Society of Thoracic Surgeons-Predicted

Risk of Mortality score (STS-PROM) and the European System for Cardiac Operative Risk Evaluation (EuroSCORE)

– ‰riskcalc.sts.org

  • ‰ STS-PROMscore exceeds 10% or when

the logistic EuroSCORE is ≥20%, referral for TAVI should be considered

Vahanian, et al Eur Hrt J 2012 Nishimura, et al Circulation 2014

slide-9
SLIDE 9

Risk Score Performance

  • ‰ Specific risk factors for TAVI are not

included, such as frailty, porcelain aorta, vessel tortuosity, chest wall malformation,

  • r chest radiation
  • ‰ Improved prediction with EuroSCORE II

for 30 day mortality but still AOC 0.70

  • ‰ Heart Team Approach

Stahli, et al Cardiology 2013

slide-10
SLIDE 10

CoreValve US Pivotal Trial Intermediate Risk ~80%

TAVR Group (N = 394) SAVR Group (N = 401)

Adams et al NEJM 2014

slide-11
SLIDE 11
slide-12
SLIDE 12
slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17
slide-18
SLIDE 18

CorValve - Medtronic

slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21

CT

slide-22
SLIDE 22

Crucial role preprocedural CT

  • ‰ Reduce peripheral vascular complications

– ‰Determination of access

  • ‰ Anatomic assessment of valvular

apparatus

  • ‰ Annular sizing and device selection

– ‰Avoid complications over and undersizing

  • ‰ Prediction fluoroscopic angles
slide-23
SLIDE 23
slide-24
SLIDE 24

Low lying coronary arteries

slide-25
SLIDE 25
slide-26
SLIDE 26
slide-27
SLIDE 27
slide-28
SLIDE 28
slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31

UK TAVR Registry

slide-32
SLIDE 32

Imaging to guide prosthesis sizing

slide-33
SLIDE 33
slide-34
SLIDE 34

Impact CT sizing on TAVR outcomes

  • ‰ 133 patients underwent TAVR with MDCT

sizing algorithm and 133 without

  • ‰ PVL > mild

– ‰5.3% MDCT and 12.8% control (p=0.32)

  • ‰ Composite in-hospital death, aortic

annulus rupture and PVL > moderate

– ‰3.8% MDCT and 11.3% control (p=0.020)

Leipsic, et al JACC 2013

slide-35
SLIDE 35
slide-36
SLIDE 36
slide-37
SLIDE 37
slide-38
SLIDE 38
slide-39
SLIDE 39

Bax et al Eur Hrt J 2014

slide-40
SLIDE 40

Clavel et al JACC 2013 Cueff et al Heart 2011

slide-41
SLIDE 41

Minimalist Approach

slide-42
SLIDE 42

9:12

slide-43
SLIDE 43

9:44

slide-44
SLIDE 44
slide-45
SLIDE 45

9:56

slide-46
SLIDE 46

10:11

slide-47
SLIDE 47

“Minimalist” Approach

slide-48
SLIDE 48
slide-49
SLIDE 49

Methods ¡

  • ‰ From ¡a ¡poten0al ¡pool ¡of ¡385 ¡pa0ents ¡considered ¡

high ¡risk ¡for ¡surgery, ¡85 ¡(22%) ¡were ¡selected ¡for ¡ the ¡3M ¡protocol ¡and ¡underwent ¡SAPIEN ¡XT ¡ (Edwards ¡Lifesciences ¡Inc.) ¡valve ¡implanta0on ¡

  • ‰ The ¡Vancouver ¡3M ¡Clinical ¡Pathway ¡was ¡

prospec0vely ¡u0lized ¡for ¡objec0ve ¡anatomical ¡and ¡ func0onal ¡screening, ¡peri-­‑procedural ¡ management, ¡and ¡to ¡determine ¡if ¡next ¡day ¡ discharge ¡home ¡was ¡appropriate ¡ ¡

  • ‰ Thirty ¡day ¡and ¡one ¡year ¡outcomes ¡were ¡reported ¡

according ¡to ¡VARC-­‑2 ¡guidelines ¡ ¡

Wood DA et al. JACC 2014 (under review)

slide-50
SLIDE 50

Baseline Characteristics

Characteristic All N= 85 GA /TEE N=35 Awake N=50 P value Age – year 82.7+/-6.9 82.0+/-7.8 83.1+/-6.2 0.45 Male sex, n (%) 42 (50) 17 (49) 25 (50) 0.73 STS Score — % 7.9+/-3.5 8.4+/-3.4 7.5+/-3.5 0.23 NYHA III/IV – n (%) 78 (92) 31 (89) 47(95) 0.23 CCS III/IV 7 (8) 4 (11) 3 (6) 0.608 Clinical characteristics, n (%) Prior MI 18 (21) 5 (14) 13 (26) 0.19 Prior PCI 17 (20) 6 (17) 11 (22) 0.58 Prior CABG 14 (17) 6 (17) 8 (16) 0.89 Prior CVA 29 (34) 11 (31) 18 (36) 0.45 Hypertension 69 (81) 27 (77) 42 (84) 0.42 Peripheral Vascular disease 18 (21) 5 (14) 13 (26) 0.19 Diabetes 22 (26) 11 (31) 11 (22) 0.33 Severe Lung disease 23 (27) 12 (34) 11 (22) 0.21 Chronic kidney disease 51 (64) 20 (57) 31 (62) 0.44 Porcelain aorta 15 (18) 5(14) 10 (20) 0.49 Prior Pacemaker 12 (14) 4 (11) 8 (16) 0.55 Echocardiographic findings Aortic Valve Area, cm2 0.6+/-0.1 0.7 +/- 0.1 0.6 +/- 0.1 0.86 Mean aortic valve gradient, mmHg 42 +/- 17 42 +/-15 42 +/- 18 0.99 Left ventricular ejection fraction, % 56 +/- 11 55 +/- 12 57 +/- 10 0.84 Mod/Severe Mitral Regurgitation, n % 5 (6) 4 (11) 1 (2) 0.25

slide-51
SLIDE 51

Clinical Outcomes

Procedural Outcomes All N= 85 GA /TEE N=35 Awake N=50 P value Procedural Success, n (%) 82 (96.4) 33 (94.3) 49 (98.0) 0.51 Mean Hospital length of stay, days 1.6+/-1.5 2.1+/-2 1.2+/-1 <0.01 Hospital Readmission prior to 30 days 2 (2.4) 2 (5.7) 0 (0%) 0.19 Death at 30 days, n (%) 1 (1.2) 0 (0) 1 (2.0) 0.40 Death at one year 4/55 (7.3) 2/35 (5.7) 2/20(10.0) 0.24 Implantation of two valves 2 (2.4) 2 (5.7) 0 (0) 0.16 Periprosthetic regurgitation at 30 days N, (%)* Grade 0 42/82 (51) 20/35 (57) 22/47 (47) 0.03 Grade 1 37/82 (45) 14/35 (40) 23/47 (49) Grade 2 3/82 (4) 1/35 (3) 2/47 (4) Grade 3 0 (0) 0 (0) 0 (0) Complications at 30 days Stroke 1 (1.2) 0 (0) 1 (2.0) 0.40 Myocardial infarction 1 (1.2) 0 (0) 1 (2.0) 0.40 Bleeding Life threatening 1 (1.2) 0 (0) 1 (2.0) 0.40 Major 1 (1.2) 0 (0) 1 (2.0) 0.40 Minor 2 (2.4) 1 (2.9) 1 (2.0) 0.34 Vascular complication Major 2 (2.4) 0 (0) 2 (4.0) 0.23 Minor 4 (4.7) 1 (2.9) 3 (6.0) 0.55 New pacemaker 2 (2.4) 2 (5.7) 1 (2.0) 0.37 Early combined 30 Day VARC safety endpoint 4 (5.3) 2 (5.7) 2 (4.0) 0.89

slide-52
SLIDE 52

¡3M ¡TAVR ¡Trial

¡

  • ‰ Evaluate ¡the ¡efficacy, ¡feasibility ¡and ¡safety ¡of ¡next ¡day ¡ ¡

¡ ¡ ¡discharge ¡home ¡in ¡high ¡risk ¡pa0ents ¡undergoing ¡TF ¡TAVR ¡ ¡ ¡ ¡ ¡u0lizing ¡Vancouver ¡3M ¡Clinical ¡Pathway ¡& ¡SAPIEN ¡XT ¡

valve ¡ ¡ ¡

  • ‰ Prospec0ve ¡mul0centre ¡case ¡series ¡(10 ¡North ¡American ¡

sites) ¡ ¡

  • ‰

Vancouver ¡(VGH ¡and ¡SPH) ¡

  • ‰

Edmonton ¡(Dr. ¡R. ¡Welsh) ¡

  • ‰

Calgary ¡(Dr. ¡F. ¡Al-­‑Qoofi) ¡

  • ‰

Hamilton ¡(Dr. ¡J. ¡Velianou) ¡

  • ‰

Sunnybrook ¡(Dr. ¡H. ¡Wijeysundera/Dr. ¡S. ¡Radhakrishnan) ¡

  • ‰

Hôpital ¡du ¡Sacré-­‑Coeur ¡de ¡Montréal ¡(Dr. ¡JB ¡Masson) ¡

  • ‰

Centre ¡Hospitalier ¡de ¡L’Universite ¡de ¡Montreal ¡(Dr. ¡P. ¡Genereux) ¡

  • ‰

Cedars-­‑Sinai ¡Medical ¡Center ¡(Dr. ¡R. ¡Makkar) ¡

  • ‰

Columbia ¡University ¡Medical ¡Center ¡(Dr. ¡M. ¡Leon/Dr. ¡S. ¡Kodali) ¡

slide-53
SLIDE 53
slide-54
SLIDE 54
slide-55
SLIDE 55

Summary

  • ‰ Inclusion of Quality of Life measures in
  • utcomes
  • ‰ Crucial role of CT for patient selection,

valve selection, access site and outcomes

  • ‰ Minimalist approach
slide-56
SLIDE 56

Questions?

slide-57
SLIDE 57
slide-58
SLIDE 58
slide-59
SLIDE 59
slide-60
SLIDE 60
slide-61
SLIDE 61
slide-62
SLIDE 62
slide-63
SLIDE 63
slide-64
SLIDE 64
slide-65
SLIDE 65
slide-66
SLIDE 66
slide-67
SLIDE 67
slide-68
SLIDE 68
slide-69
SLIDE 69
slide-70
SLIDE 70
slide-71
SLIDE 71
slide-72
SLIDE 72
slide-73
SLIDE 73
slide-74
SLIDE 74

Unger et al Heart 2010

slide-75
SLIDE 75

Concomitant MR

  • ‰ Variable correlation to morbidity and

mortality

  • ‰ Independent predictors of improvement

MR at 1yr

– ‰Baseline mean gradient ≥40 mmHg – ‰Functional MR – ‰Absence of pulmonary hypertension – ‰Absence of atrial fibrillation

Toggweller et al JACC 2012

slide-76
SLIDE 76

Role of TAVI in Bicuspid Aortic Valve

  • ‰ BAV in 1% general population

– ‰20% elderly critical AS patients

  • ‰ MRI and CT improve accuracy detect BAV
  • ‰ BAV excluded TAVR trials
  • ‰ Challenge of aortopathy, coronary ostia

location, elliptical implantation

  • ‰ Transcather Valve Therapy registry US

– ‰2% BAV, similar outcomes

slide-77
SLIDE 77

Piazzo et al JACC 2014

≥2+ AR 28.4% MDCT sizing ~17%

slide-78
SLIDE 78
slide-79
SLIDE 79
slide-80
SLIDE 80
slide-81
SLIDE 81
slide-82
SLIDE 82

Home? ¡

slide-83
SLIDE 83
slide-84
SLIDE 84

Utilizing the Vancouver 3M Clinical Pathway, in objectively screened patients with a mean age of 83±7 years and a mean STS score of 7.9±3.5%, 46 of the last 50 (24 of the last 25) have been safely discharged home on Day 1 with no 30 day readmissions…

slide-85
SLIDE 85

To achieve the above results…

  • ‰ Safe
  • ‰ Reproducible (general anesthetic or

awake)

  • ‰ Reduced LOS to not only improve cost

effectiveness but also clinical outcomes

  • ‰ Glimpse of the future (for both individual

Heart Teams and regional Health Authorities)…

slide-86
SLIDE 86
slide-87
SLIDE 87
slide-88
SLIDE 88
slide-89
SLIDE 89

PARTNER 2yr Follow-up

NEJM, 2012

slide-90
SLIDE 90

PARTNER 2yr Follow-up

NEJM, 2012

slide-91
SLIDE 91
slide-92
SLIDE 92
slide-93
SLIDE 93
slide-94
SLIDE 94
slide-95
SLIDE 95
slide-96
SLIDE 96
slide-97
SLIDE 97

TAVR Bus

slide-98
SLIDE 98

3M Approach All N = 85 3M Approach Awake N=50 Partner TF High risk N = 244 TVT Registry TF High Risk N =1687 Corevalv e USA N = 390 FRANCE 2 TF N = 2361 Source XT TF N=2688 Choice N=241 STS Score 7.9+/-3.5 7.5+/-3.5 11.8+/-3. 3 7 (5-11) 7.3+/-3.0 14.5+/-11 .9 7.9+/-6.6 5.6 +/-2.9 Length of hospital stay 1.6+/-1.5 1.2+/-1 8 5 (4-9) NA 10.5+/-8. 1 11.1+/-9. 2 NA 30-day mortality 1.4% 2.6% 3.4% 4.6% 3.3% 8.5% 4.2% 4.6% 30-day stroke 0% 0% 4.7% 3.2% 3.9% 3.7% 3.6% 4.1%

STS Score, length of hospital stay, and 30-day mortality and stroke utilizing the Vancouver 3M Clinical Pathway compared with contemporary randomized transfemoral TAVR trials and registries
