Traditional Technologies Can Be a Drag- Rev Up Your Brownfield By Incorporating Sustainable Landscape and Stormwater Practices Nadia Locke, PE, LEED AP October 2, 2018 Stormwater Challenges at Brownfields Cannot discharge stormwater into

slide-1
SLIDE 1

Traditional Technologies Can Be a Drag- Rev Up Your Brownfield By Incorporating Sustainable Landscape and Stormwater Practices

Nadia Locke, PE, LEED AP October 2, 2018

slide-2
SLIDE 2

Stormwater Challenges at Brownfields

  • Cannot discharge stormwater into contaminated areas
  • Dewatering can spread contamination
  • Engineering controls can increase impervious area
  • Increases runoff volume
  • Increases size of stormwater management system
slide-3
SLIDE 3

Site Planning Strategies to Avoid Contamination Conflicts

  • Consultant/Designer Partnership
  • Maximize placement of impervious site features
  • Strategically place buildings/parking over

contamination

  • Move or remove contaminated soils
  • Divert runoff from contaminated area
  • Consider alternative technologies
slide-4
SLIDE 4

Site Planning Strategies to Reduce Stormwater Management Features

  • Reduce impervious areas
  • Minimize compaction to increase infiltration and storage
  • Use draught tolerant vegetation
  • Redirect stormwater runoff
  • Re-use
slide-5
SLIDE 5

Sustainable Stormwater Management

  • Permeable Pavement
  • Underground storage (open trenches, cisterns)
  • Aboveground storage (tanks, cisterns)
  • Draught tolerant landscaping
  • Green Roofs
  • Rain gardens/Flow-through planters
  • Bioswales
  • Injection wells
  • Regional stormwater management
slide-6
SLIDE 6

Permeable Pavement

slide-7
SLIDE 7

Underground Modular Storage

Rainstorm 3

slide-8
SLIDE 8

8

Undergound Storage- Modular Vault Chamber

Low impact development exfiltration system that facilitates the infiltration of stormwater into the soil for natural treatment and to replenish local aquifers. StormCapture

slide-9
SLIDE 9

Underground Storage- Modular Vault Chambers

Designed to minimize the development footprint and reduce project costs. Modular design allows for maximum storage volume and the precast base allows for discharge of stormwater to the soil, reducing stormwater runoff and recharging the groundwater table.

slide-10
SLIDE 10

Underground Storage- Arch Chambers

10

Contech ChamberMaxx Terre Arch

slide-11
SLIDE 11

11

Rainwater Harvesting Systems-Re-use

slide-12
SLIDE 12

Drought Tolerant Landscaping, Green Roofs, Living Walls Increase Canopy Cover

  • Reduce irrigation requirements
  • Improve evapotranspiration
  • Increase soil storage capacity
  • Reduce roof runoff
  • Improve heat island effect
slide-13
SLIDE 13

Rain Gardens/Flow Through Planters

  • Reduce irrigation requirements
  • Improve evapotranspiration
  • Reduce runoff from roof
  • Provide pretreatment
  • Provide storage capacity
  • Improve heat island effect
slide-14
SLIDE 14

Drainage Wells

  • Class V injection wells
  • Stormwater discharges below

contaminated media

slide-15
SLIDE 15

Combining Technologies

slide-16
SLIDE 16

Regional Approach to Stormwater Management

slide-17
SLIDE 17

Beneficial Stormwater Opportunities at Brownfields

  • Overcome fatal flaws for previously undevelopable sites
  • May reduce construction costs
  • Increased area for development
  • Increased area for open space
  • Up to four LEED Points
  • Community Amenities
  • Sustainable
slide-18
SLIDE 18

Funding Sources

  • Clean Water RLF
  • Section 319 Grants
  • EPA Urban Small Waters Grant
  • TMDL Water Quality Restoration Grants
  • Helpful links

https://floridadep.gov/wra/wra/highlights/water-project-funding-sources https://www.epa.gov/green-infrastructure/green-infrastructure-funding-tools- documents

slide-19
SLIDE 19

More Stormwater Challenges at Brownfields Coming our Way

slide-20
SLIDE 20

Tides and Groundwater are Linked

slide-21
SLIDE 21

Soil Storage Capacity

slide-22
SLIDE 22
slide-23
SLIDE 23

Stormwater Challenges at Brownfields

  • Climate change causing rising tides
slide-24
SLIDE 24

Rising Tides

slide-25
SLIDE 25

Rising Tides

slide-26
SLIDE 26

Climate Change-Effects of Rising Tides and Groundwater

  • Reduced soil storage capacity (vadose zone)
  • Smear zone is rising
  • Contaminated groundwater rising
  • Regulatory agencies establishing new average wet season water levels

for design and permitting

  • Flooding from outfalls backing onto land
  • Backflow prevention valves
  • Pumping systems
  • Raising ground elevations
  • Again, reduce runoff-be creative!
slide-27
SLIDE 27

Thank you!

Nadia Locke, PE, LEED AP E Sciences, Incorporated 224 SE 9th Street Fort Lauderdale, Florida 33316 954-484-8500 nlocke@esciencesinc.com www.esciencesinc.com
