TRACK LIGHTING SYSTEM

JANUARY 2015

TRACK LIGHTING SYSTEM

Four Lengths (L):

• 1000 mm
• 3000 mm
• 2000 mm
• 4000 mm

Two versions:

• standard
• recessed(R)

9000

• 1 (1000 mm)

/

W (white)

• ST (standard)

2 (2000 mm) B (black) R (recessed) 3 (3000 mm) G (grey) 4 (4000 mm)

BLACK (RAL 9005) WHITE (RAL 9010) ANODIZED (EN 5) Order Codes: The system is tested and certified in accordance with the technical standards IEC60570 and IEC60598.

Tracks

Electrical Data

Technical Data

To ensure the creepage and clearance distances, all the copper conductors are recessed in the extruded plastic. The rail can be easily cut to any length in the field with a tool provide by A.A.G. Stucchi.

Dimensions in mm

Voltage 440 V Current 16 A Frequency 50 Hz Phase power 3,6 kVA / 10,8 kVA Protection degree IP 20 (IP40 with additional cover) Protection Class Class I

Current “Euro standard” tracks on the market

3 Phase 3 Phase+DALI 1 Phase+DALI

Top state of the art Platform

“EURO STANDARD PLUS” track

“EUROSTANDARD PLUS” track combines the functionality of all 3 tracks systems currently available in the market in one unique product.

“EURO STANDARD PLUS” tracks: advantages

“EURO STANDARD PLUS” track provides a unique “state of the art” solution incorporating all the functionality now available only by using 3 different types of “EURO STANDARD” tracks. This provides great advantages for both the lighting OEM using it as a platform and the end user of the lighting system. For the lighting OEM:

• Same product range with 1/3 of the product codes (tracks, connections)
• Drastic reduction of inventory levels
• Increased sales of controllable lighting systems

For the final user:

• The “future proof” platform allows the lighting system to be upgraded to a controllable system at

any time. As lighting controls evolve continuously, thanks to the LEDs technology, this gives the system flexibility to work with new protocols.

• Better ROI (Return of Investment)

In retail and architectural applications, track lighting is an important part of the overall design and often represents an important architectural element. With this in mind we designed all our “EURO STANDARD PLUS” components with a compact size and clean form factor.

Attention to details

The complete platform is manufactured so that it can meet different private labeling needs:

• Packaging
• Labeling
• Special packaging
• Instruction sheet
• Track
• Adapter
• Connections

Make it your own branded platform

Electro-mechanical connection accessories

• CONNECTORS
• LIVE-END
• ADAPTORS

Electro-mechanical connection accessories

Positioning Tab: The end feed is keyed which guarantees correct assembly of the accessories. Once installed in the track a locking screw is tighten to secure the assembly.

The accessories are made of self-extinguishing polycarbonate (class V2 - glow wire 960C)

Art. Code Description Position of the locking screw Dimensions

End feed 9001/W (R) 9001/B (R) 9001/G (R) 9002/W (R) 9002/B (R) 9002/G (R) White left end feed Black left end feed Grey left end feed White right end feed Black right end feed Grey right end feed

Art. Code Description Position of the locking screw Dimensions

Middle Feed 9010/W (R) 9010/B (R) 9010/G (R) White middle feed Black middle feed Grey middle feed L-feed 9011/W (R) 9011/B (R) 9011/G (R) 9012/W (R) 9012/B (R) 9012/G (R) White internal L-feed Black internal L-feed Grey internal L-feed White external L-feed Black external L-feed Grey external L-feed

Electro-mechanical connection accessories

The accessories are made of self-extinguishing polycarbonate (class V2 - glow wire 960C)

Art. Code Description Position of the locking screw Dimensions

9013/W (R) 9013/B (R) 9013/G (R) 9014/W (R) 9014/B (R) 9014/G (R) 9015/W (R) 9015/B (R) 9015/G (R) 9016/W (R) 9016/B (R) 9016/G (R) White external-right T-feed Black external-right T-feed Grey external-right T-feed White external-left T-feed Black external-left T-feed Grey external-left T-feed White internal-right T-feed Black internal-right T-feed Grey internal-right -feed White internal-left T-feed Black internal-left T-feed Grey internal-left T-feed

Electro-mechanical connection accessories

The accessories are made of self-extinguishing polycarbonate (class V2 - glow wire 960C)

Art. Code Description Position of the locking screw Dimensions

X-feed

9017/W (R) 9017/B (R) 9017/G (R) White X-feed Black X-feed Grey X-feed

Adjustable corner

9018/W 9018/B 9018/G White adjustable corner Black adjustable corner Grey adjustable corner

Jointing connector

9003/W 9003/B 9003/G White jointing connector Black jointing connector Grey jointing connector

End cap

9004/W 9004/B 9004/G White end cap Black end cap Grey end cap

Electro-mechanical connection accessories

The accessories are made of self-extinguishing polycarbonate (class V2 - glow wire 960C)

6 conductor adapter

3 PHASE+DALI

Track adapter types

4 conductor adapter

3 PHASE

Available in 3 different colors

Compatibility:

6 conductor adapter is compatible with Nordic Pulse products. 4 conductor 3-phase adapter is compatible with the majority of the tracks available on the market.

Track adapter

Symmetrical adapter for spotlights is equipped with a phase selector, making installation and configuration a breeze. Two locking mechanisms fix the adapter securely to the track. The wires are connected with IDC contacts (insulation displacement connector).

Locking for mechanical fixing. Phase selector. IDC connection of the cables.

Track adapter: security elements

Security element 2: To avoid that the 4 conductor (3 phase 1 neutral) adapter is inserted in the incorrect 4 conductor track (1 phase + DALI)

Security element 1: To avoid the insertion of the 6 conductor adapter in a 4 conductor track. Security element 3: Locking mechanism will not engage unless the adapter has been correctly inserted into the track.

Technical specifications

3 2 90 47, 5 8 1 3

Voltage 250 V Current 10 A Wire section (solid and stranded) 0.5 mm2 for 6 A max 1 mm2 for 10 A max Maximum pull strenght 100 N Degree of protection IP 20 (IP40 with special cover) Class of protection Class I Plastic material Self-extinguishing polycarbonate (class V2-960°C)

Adapter accessories

Knock-out wall Space for the interface with the luminaire

Available accessories

S-9009/10-W S-9009/10-B S-9009/10-G S-9009/M10 S-9009/M13

The interface with the luminaire is provided by a series of accessories.

Available accessories

S-9009/BC-W S-9009/BC-B S-9009/BC-G S-9009/51

Adapter accessories

• 1. Internal Cord Grip in plastic for cables

with outside diameters of 6 to 9 mm.

• 2. External Cord Grip in plastic for cable having an outside diameter of 6 to 9 mm. When using this

cord grip the adapter is an electrical interface only to the lighting fixture. (no mechanical interface).

Article code: S-9009/10-W S-9009/10-B S-9009/10-G

Adapter accessories

• 3. Aluminum Ring with a locking screw to stop the rotation
• f the spotlight joint.
• 4. Threaded Nipple available in M10 and M13 thread.

If the pin of threaded nipple is positioned as in figure 1 the luminaire can be rotated approximately 360° and then locked into the desired position with the use of a locking screw as in figure 3. If the pin of the nipple is positioned as in figure 2 (pin inside in the plastic cavity) the luminaire will be in a fixed position with no additional hardware needed.

Figure1 Figure 2 Figure 3

Adapter accessories

Mechanical adapter

• 5. For heavy loads (up to 100N) a mechanical adapter, made of metal and self-extinguishing

polycarbonate (class V2-960°C) is available. Compatible with all electrical-mechanical adapter accessories.

Mechnical and seperate electrical adapter in use.

Adaptors and accessories

Article Code Description

9009/W 9009/B 9009/G White 6 conductors adapter Black 6 conductors adapter Grey 6 conductors adapter 9009-4/W 9009-4/B 9009-4/G

White 4 conductors adapter Black 4 conductors adapter Grey 4 conductors adapter

S-9000/M-W S-9000/M-B S-9000/M-G White mechanical adapter Black mechanical adapter Grey mechanical adapter S-9009/10-W S-9009/10-B S-9009/10-G White internal cord grip Black internal cord grip Grey internal cord grip S-9009/51 Aluminum ring with a locking screw S-9009/M10 S-9009/M13 Aluminum nipple M10 x 1 Aluminum nipple M13 x 1 S-9009/D-M10 S-9009/D-M13 Nut M10 Nut M13 S-9009/BC-W S-9009/BC-B S-9009/BC-G White external cord grip with plastic screw Black external cord grip with plastic screw Grey external cord grip with plastic screw

Articolo Codice Descrizione

S-9009/IP40-W S-9009/IP40-B S-9009/IP40-G White IP40 carter for the adapter Black IP40 carter for the adapter Grey IP40 carter for the adapter S-9000-T/IP40-G Grey IP40 closure cap S-9000/IP40-W S-9000/IP40-B S-9000/IP40-G White IP40 cover strip for the track Black IP40 cover strip for the track Grey IP40 cover strip for the track S-9009/T Installation tool for the adapter S-9000/T Cutting tool for track wires S-9000/H-W S-9000/H-B S-9000/H-G White suspension hook Black suspension hook Grey suspension hook

Altri accessori disponibili

Articolo Codice Descrizione

S-9000/211 Steel cable (diameter 1,5 mm – lenght 2 m) S-9000/211-S Steel cable (diameter 1,5 mm – lenght 2 m) with a spherical end S-9000/212 Automatic M5 gripper with integrated balancing cylinder and side hole S-9000/213 Automatic gripper with hook S-9000/214 Automatic Lock S-9000/215 Screw Lock S-9000/216 Round head ceiling attachment with hole

Accessori per sospensioni

Articolo Codice Descrizione

S-9000/111 Ceiling bracket S-9000/112-LA Short pendant linear bracket with countersunk hole for suspensions (to be used with S-9000/212) S-9000/112-SV Short flaring pendant bracket for suspensions (use with steel cable with spherical ens) S-9000/122-LA Long pendant linear bracket with countersunk hole for suspensions to be used when tracks are connected with a 9003 joint (use with S-9000/212) S-9000/122-SV Long flaring pendant bracket for suspensions to be used when tracks are connected with a 9003 joint (use with steel cable with spherical end) S-9000/113 Short “T” pendant bracket for suspensions (use with S-9000/213) S-9000/123 Long “T” pendant bracket for suspensions (use with S-9000/213)
