TOWARDS AN OPERATIONAL MODEL OF SCHEDULES IN TENSOR EXPRESSION Yuan Lin and Yongfeng Gu 2019-12-05 Q Question: is this a legal schedule? Q Illegal, but why? TVMError: Check failed: found_attach || stage_attach.size() == 0: Invalid
SLIDE 2
SLIDE 3
Q
Illegal, but why?
TVMError: Check failed: found_attach || stage_attach.size() == 0: Invalid Schedule, cannot find the producer compute(B, 0x2851e60) along the loop nest specified by compute_at of consumer compute(B.local, 0x2b83b00)
SLIDE 4
Show the Schedule Tree
SLIDE 5
LCA(B, C) LCA(BL, C)
Illegal
Violation of Legality
SLIDE 6
LCA(B, C) LCA(BL, C)
Legal
A Possible Fix
SLIDE 7
Background
- Describe schedule primitives and transformations in a more elaborate way
- Provide guidance to new TE users
- Help debugging tricky TE programs
- Provide a framework to discuss bugs (is this a bug or feature?)
- Ensure conherent development of new features
Motivations
SLIDE 8
Dataflow Graph
The Operational Model
IterVar-relation DAG Tensor Expression Schedule Tree
SLIDE 9
The Document
SLIDE 10
Example pages
SLIDE 11
- We would like to contribute the document to the TVM community.
- We are also working on a visualization tool, Tensor Expression Debug Display (TEDD).
- Questions/Survey:
- Is this model helpful?
- Is this or similar model well understood?
- Will you use it for future discussion?
- Let's work together to
- improve the model
- complete the document
Help Needed!
