slide-1
SLIDE 1

Parsing transcripts of speech

Andrew Caines1, Michael McCarthy2 & Paula Buttery1

1University of Cambridge 2University of Nottingham

Speech-Centric NLP, 7 September 2017

slide-2
SLIDE 2

Background

◮ Speech (can be) very different from writing ◮ Put phonetics & prosody aside for now ◮ Focus on the transcribed form: lexis, morphology, syntax ◮ Most NLP tools trained on (newswire) written language ◮ How well do they cope with spoken data?

2/17

slide-3
SLIDE 3

Background

◮ Speech (can be) very different from writing ◮ Put phonetics & prosody aside for now ◮ Focus on the transcribed form: lexis, morphology, syntax ◮ Most NLP tools trained on (newswire) written language ◮ How well do they cope with spoken data?

2/17

slide-4
SLIDE 4

Background

◮ Speech (can be) very different from writing ◮ Put phonetics & prosody aside for now ◮ Focus on the transcribed form: lexis, morphology, syntax ◮ Most NLP tools trained on (newswire) written language ◮ How well do they cope with spoken data?

2/17

slide-5
SLIDE 5

Background

◮ Speech (can be) very different from writing ◮ Put phonetics & prosody aside for now ◮ Focus on the transcribed form: lexis, morphology, syntax ◮ Most NLP tools trained on (newswire) written language ◮ How well do they cope with spoken data?

2/17

slide-6
SLIDE 6

Background

◮ Speech (can be) very different from writing ◮ Put phonetics & prosody aside for now ◮ Focus on the transcribed form: lexis, morphology, syntax ◮ Most NLP tools trained on (newswire) written language ◮ How well do they cope with spoken data?

2/17

slide-7
SLIDE 7

Speech versus Writing

◮ Fundamental difference: lack of sentence unit as used in

writing; instead speech-units (SUs) (Moore et al. 2016 COLING)

◮ And disfluencies –

◮ filled pauses: um he’s a closet yuppie is what he is ◮ repetitions: I played, I played against um ◮ false starts: You’re happy to – welcome to include it

(Moore et al. 2015 TSD)

◮ Features of conversation: turn-taking, overlap,

co-construction, etc

3/17

slide-8
SLIDE 8

Speech versus Writing

◮ Fundamental difference: lack of sentence unit as used in

writing; instead speech-units (SUs) (Moore et al. 2016 COLING)

◮ And disfluencies –

◮ filled pauses: um he’s a closet yuppie is what he is ◮ repetitions: I played, I played against um ◮ false starts: You’re happy to – welcome to include it

(Moore et al. 2015 TSD)

◮ Features of conversation: turn-taking, overlap,

co-construction, etc

3/17

slide-9
SLIDE 9

Speech versus Writing

◮ Fundamental difference: lack of sentence unit as used in

writing; instead speech-units (SUs) (Moore et al. 2016 COLING)

◮ And disfluencies –

◮ filled pauses: um he’s a closet yuppie is what he is ◮ repetitions: I played, I played against um ◮ false starts: You’re happy to – welcome to include it

(Moore et al. 2015 TSD)

◮ Features of conversation: turn-taking, overlap,

co-construction, etc

3/17

slide-10
SLIDE 10

Speech versus Writing

◮ Fundamental difference: lack of sentence unit as used in

writing; instead speech-units (SUs) (Moore et al. 2016 COLING)

◮ And disfluencies –

◮ filled pauses: um he’s a closet yuppie is what he is ◮ repetitions: I played, I played against um ◮ false starts: You’re happy to – welcome to include it

(Moore et al. 2015 TSD)

◮ Features of conversation: turn-taking, overlap,

co-construction, etc

3/17

slide-11
SLIDE 11

Speech versus Writing

◮ Fundamental difference: lack of sentence unit as used in

writing; instead speech-units (SUs) (Moore et al. 2016 COLING)

◮ And disfluencies –

◮ filled pauses: um he’s a closet yuppie is what he is ◮ repetitions: I played, I played against um ◮ false starts: You’re happy to – welcome to include it

(Moore et al. 2015 TSD)

◮ Features of conversation: turn-taking, overlap,

co-construction, etc

3/17

slide-12
SLIDE 12

Speech versus Writing

◮ Fundamental difference: lack of sentence unit as used in

writing; instead speech-units (SUs) (Moore et al. 2016 COLING)

◮ And disfluencies –

◮ filled pauses: um he’s a closet yuppie is what he is ◮ repetitions: I played, I played against um ◮ false starts: You’re happy to – welcome to include it

(Moore et al. 2015 TSD)

◮ Features of conversation: turn-taking, overlap,

co-construction, etc

3/17

slide-13
SLIDE 13

Speech versus Writing

◮ In this work we compare 4 English corpora from Universal

Dependencies 2.0 and Penn Treebank 3

◮ PTB Switchboard Corpus of transcribed telephone

conversations (SWB)

◮ UD English Web Treebank (EWT) ◮ UD English LinES (LinES), parallel corpus of English novels

and Swedish translations

◮ UD Treebank of Learner English (TLE), subset of CLC-FCE 4/17

slide-14
SLIDE 14

Speech versus Writing

◮ In this work we compare 4 English corpora from Universal

Dependencies 2.0 and Penn Treebank 3

◮ PTB Switchboard Corpus of transcribed telephone

conversations (SWB)

◮ UD English Web Treebank (EWT) ◮ UD English LinES (LinES), parallel corpus of English novels

and Swedish translations

◮ UD Treebank of Learner English (TLE), subset of CLC-FCE 4/17

slide-15
SLIDE 15

Speech versus Writing

◮ In this work we compare 4 English corpora from Universal

Dependencies 2.0 and Penn Treebank 3

◮ PTB Switchboard Corpus of transcribed telephone

conversations (SWB)

◮ UD English Web Treebank (EWT) ◮ UD English LinES (LinES), parallel corpus of English novels

and Swedish translations

◮ UD Treebank of Learner English (TLE), subset of CLC-FCE 4/17

slide-16
SLIDE 16

Speech versus Writing

◮ In this work we compare 4 English corpora from Universal

Dependencies 2.0 and Penn Treebank 3

◮ PTB Switchboard Corpus of transcribed telephone

conversations (SWB)

◮ UD English Web Treebank (EWT) ◮ UD English LinES (LinES), parallel corpus of English novels

and Swedish translations

◮ UD Treebank of Learner English (TLE), subset of CLC-FCE 4/17

slide-17
SLIDE 17

Speech versus Writing

◮ In this work we compare 4 English corpora from Universal

Dependencies 2.0 and Penn Treebank 3

◮ PTB Switchboard Corpus of transcribed telephone

conversations (SWB)

◮ UD English Web Treebank (EWT) ◮ UD English LinES (LinES), parallel corpus of English novels

and Swedish translations

◮ UD Treebank of Learner English (TLE), subset of CLC-FCE 4/17

slide-18
SLIDE 18

Speech versus Writing

Medium Tokens Types speech 394,611* 11,326** writing 394,611 27,126 *sampled from 766,650 total **mean of 100 samples (st.dev=45.5)

5/17

slide-19
SLIDE 19

Speech versus Writing

Speech Freq. Rank Writing Freq. I 46,382 1 the 41,423 and 33,080 2 to 26,459 the 29,870 3 and 22,977 you 27,142 4 I 20,048 that 27,038 5 a 18,289 it 26,600 6

  • f

18,112 to 22,666 7 in 14,490 a 22,513 8 is 10,020 uh 20,695 9 you 10,002 ’s 20,494 10 that 9952

  • f

17,112 11 for 8578 yeah 14,805 12 it 8238 know 14,723 13 was 8195 they 13,147 14 have 6604 in 12,548 15

  • n

5821

6/17

slide-20
SLIDE 20

Speech versus Writing

Speech Freq. Rank Writing Freq. you know 11,165 1

  • f the

4313 it’s 8531 2 in the 3702 that’s 6708 3 to the 2352 don’t 5680 4 I have 1655 I do 4390 5

  • n the

1607 I think 4142 6 I am 1500 and I 3790 7 for the 1475 I’m 3716 8 I would 1427 I I 3000 9 and the 1389 in the 2972 10 and I 1361 and uh 2780 11 to be 1318 a lot 2714 12 I was 1140

7/17

slide-21
SLIDE 21

Speech versus Writing

Speech Freq. Rank Writing Freq. VBP_PRP 51,845 1 NN_DT 48,846 NN_DT 47,469 2 NN_IN 36,274 ROOT_UH 39,067 3 NN_NN 27,490 IN_NN 26,868 4 NN_JJ 21,566 VB_PRP 24,321 5 VB_NN 19,584 ROOT_VBP 24,156 6 VB_PRP 16,320

8/17

slide-22
SLIDE 22

Parsing experiments

◮ Used Stanford CoreNLP toolkit to parse CoNLL format

treebanks

◮ PTB Switchboard Corpus of transcribed telephone

conversations (SWB)

◮ UD English Web Treebank (EWT) ◮ UD English LinES (LinES), parallel corpus of English novels

and Swedish translations

◮ UD Treebank of Learner English (TLE), subset of CLC-FCE

◮ We report unlabelled attachment scores (% tokens with

correct heads)

9/17

slide-23
SLIDE 23

Parsing experiments

◮ Used Stanford CoreNLP toolkit to parse CoNLL format

treebanks

◮ PTB Switchboard Corpus of transcribed telephone

conversations (SWB)

◮ UD English Web Treebank (EWT) ◮ UD English LinES (LinES), parallel corpus of English novels

and Swedish translations

◮ UD Treebank of Learner English (TLE), subset of CLC-FCE

◮ We report unlabelled attachment scores (% tokens with

correct heads)

9/17

slide-24
SLIDE 24

Parsing experiments

◮ Used Stanford CoreNLP toolkit to parse CoNLL format

treebanks

◮ PTB Switchboard Corpus of transcribed telephone

conversations (SWB)

◮ UD English Web Treebank (EWT) ◮ UD English LinES (LinES), parallel corpus of English novels

and Swedish translations

◮ UD Treebank of Learner English (TLE), subset of CLC-FCE

◮ We report unlabelled attachment scores (% tokens with

correct heads)

9/17

slide-25
SLIDE 25

Parsing experiments

Corpus Medium Units Tokens UAS SWB speech 102,900 766,560 .540 EWT writing 14,545 218,159 .744 LinES writing 3650 64,188 .758 TLE writing 5124 96,180 .845

10/17

slide-26
SLIDE 26

Parsing experiments

SWB EWT LinES TLE 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

unit length (tokens) unlabelled attachment score

11/17

slide-27
SLIDE 27

Parsing experiments

◮ What if we train instead on the Wall Street Journal +

Switchboard?

◮ We used Stanford Parser to train PCFGs with max.40 and

80 token SUs

◮ And make these models available (future baselines?)

12/17

slide-28
SLIDE 28

Parsing experiments

◮ What if we train instead on the Wall Street Journal +

Switchboard?

◮ We used Stanford Parser to train PCFGs with max.40 and

80 token SUs

◮ And make these models available (future baselines?)

12/17

slide-29
SLIDE 29

Parsing experiments

◮ What if we train instead on the Wall Street Journal +

Switchboard?

◮ We used Stanford Parser to train PCFGs with max.40 and

80 token SUs

◮ And make these models available (future baselines?)

12/17

slide-30
SLIDE 30

Parsing experiments

Model SWB EWT LinES TLE CoreNLP .540 .744 .758 .845 PCFG_WSJ_SWB_40 .624 .748 .760 .847 PCFG_WSJ_SWB_80 .624 .748 .760 .847

13/17

slide-31
SLIDE 31

Parsing experiments

SWB EWT LinES TLE 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80 1-10 11-20 21-30 31-40 41-50 51-60 61-70 71-80

  • 1.0
  • 0.9
  • 0.8
  • 0.7
  • 0.6
  • 0.5
  • 0.4
  • 0.3
  • 0.2
  • 0.1

0.0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1.0

unit length (tokens) UAS Δ(PCFG_WSJ_SWB_40, CoreNLP)

14/17

slide-32
SLIDE 32

Conclusions

◮ Characterised speech vs writing differences ◮ Showed how unit length affects parsing of speech more than

writing

◮ Demonstrated how much improvement can be made with a

domain-appropriate parsing model

◮ +Speech parsing models available for other researchers:

https://goo.gl/iQMu9w

◮ Call for more development of speech transcript treebanks.

15/17

slide-33
SLIDE 33

Conclusions

◮ Characterised speech vs writing differences ◮ Showed how unit length affects parsing of speech more than

writing

◮ Demonstrated how much improvement can be made with a

domain-appropriate parsing model

◮ +Speech parsing models available for other researchers:

https://goo.gl/iQMu9w

◮ Call for more development of speech transcript treebanks.

15/17

slide-34
SLIDE 34

Conclusions

◮ Characterised speech vs writing differences ◮ Showed how unit length affects parsing of speech more than

writing

◮ Demonstrated how much improvement can be made with a

domain-appropriate parsing model

◮ +Speech parsing models available for other researchers:

https://goo.gl/iQMu9w

◮ Call for more development of speech transcript treebanks.

15/17

slide-35
SLIDE 35

Conclusions

◮ Characterised speech vs writing differences ◮ Showed how unit length affects parsing of speech more than

writing

◮ Demonstrated how much improvement can be made with a

domain-appropriate parsing model

◮ +Speech parsing models available for other researchers:

https://goo.gl/iQMu9w

◮ Call for more development of speech transcript treebanks.

15/17

slide-36
SLIDE 36

Conclusions

◮ Characterised speech vs writing differences ◮ Showed how unit length affects parsing of speech more than

writing

◮ Demonstrated how much improvement can be made with a

domain-appropriate parsing model

◮ +Speech parsing models available for other researchers:

https://goo.gl/iQMu9w

◮ Call for more development of speech transcript treebanks.

15/17

slide-37
SLIDE 37

Future work

◮ Analyse SUs with low UAS: what are the causes? ◮ Redefine grammar and grammaticality? ◮ Extra pre-processing: e.g. semantic chunking (Muszynska

2016 ACL)

◮ Or joint SU delimitation, disfluency detection, parsing (e.g.

Honnibal & Johnson 2014 TACL; Yoshikawa et al 2016 EMNLP)

◮ Other metrics: e.g. SParseval (Roark et al 2006 LREC)

16/17

slide-38
SLIDE 38

Future work

◮ Analyse SUs with low UAS: what are the causes? ◮ Redefine grammar and grammaticality? ◮ Extra pre-processing: e.g. semantic chunking (Muszynska

2016 ACL)

◮ Or joint SU delimitation, disfluency detection, parsing (e.g.

Honnibal & Johnson 2014 TACL; Yoshikawa et al 2016 EMNLP)

◮ Other metrics: e.g. SParseval (Roark et al 2006 LREC)

16/17

slide-39
SLIDE 39

Future work

◮ Analyse SUs with low UAS: what are the causes? ◮ Redefine grammar and grammaticality? ◮ Extra pre-processing: e.g. semantic chunking (Muszynska

2016 ACL)

◮ Or joint SU delimitation, disfluency detection, parsing (e.g.

Honnibal & Johnson 2014 TACL; Yoshikawa et al 2016 EMNLP)

◮ Other metrics: e.g. SParseval (Roark et al 2006 LREC)

16/17

slide-40
SLIDE 40

Future work

◮ Analyse SUs with low UAS: what are the causes? ◮ Redefine grammar and grammaticality? ◮ Extra pre-processing: e.g. semantic chunking (Muszynska

2016 ACL)

◮ Or joint SU delimitation, disfluency detection, parsing (e.g.

Honnibal & Johnson 2014 TACL; Yoshikawa et al 2016 EMNLP)

◮ Other metrics: e.g. SParseval (Roark et al 2006 LREC)

16/17

slide-41
SLIDE 41

Future work

◮ Analyse SUs with low UAS: what are the causes? ◮ Redefine grammar and grammaticality? ◮ Extra pre-processing: e.g. semantic chunking (Muszynska

2016 ACL)

◮ Or joint SU delimitation, disfluency detection, parsing (e.g.

Honnibal & Johnson 2014 TACL; Yoshikawa et al 2016 EMNLP)

◮ Other metrics: e.g. SParseval (Roark et al 2006 LREC)

16/17

slide-42
SLIDE 42

The End

◮ Acknowledgements:

◮ Cambridge English Language Assessment ◮ Sebastian Schuster & Chris Manning re UD corpora ◮ SCNLP organisers ◮ 3 anonymous reviewers

◮ Thank you! apc38@cam.ac.uk

17/17
