Towards a better understanding of the Southern Ocean overturning circulation Steve Rintoul, J. B. Salle and Serguei Sokolov CSIRO Marine and Atmospheric Research Antarctic Climate and Ecosystems CRC Wealth from Oceans National Research
SLIDE 2
SLIDE 3
Role of the Southern Ocean in the Earth system
The Southern Ocean: acts as a valve controlling exchange between the surface and the deep ocean. plays roughly equal role with North Atlantic in ventilating the deep ocean. stores more heat and anthropogenic carbon than any other latitude band. is the primary return path for nutrients and carbon exported to the deep sea. influences the rate of mass loss by the Antarctic ice sheet and therefore sea-level rise.
SLIDE 4
How is water transferred from the surface layer to the ocean interior (ie subducted)?
Sallée et al, JPO, 2010
SLIDE 5
Subduction hot-spots
SLIDE 6
Inferred subduction hot-spots consistent with interior PV distribution γn = 26.9 γn = 27.1
Sallee, Speer, Rintoul + Wijffels, JPO, 2010
SLIDE 7
… and interior distribution of anthropogenic carbon dioxide
Sallée, Matear, Lenton and Rintoul, submitted
SLIDE 8
Can the Gent-McWilliams (GM) parameterisation represent eddy contribution to subduction?
Sallée and Rintoul, Ocean Modelling, submitted
Eddy subduction Eddy + Ekman
SLIDE 9
Eddy subduction: dependence on diffusivity
SLIDE 10
Large, regionally-varying κ required
SLIDE 11
The deep limb of the SO overturning
Orsi et al., 1999
SLIDE 12
Kerguelen Deep Western Boundary Current Experiment
12 Sv ± 1.2 Sv of AABW (<0°C) to north. Net AABW transport across array is 6.8 Sv. 2-yr mean speeds > 20 cm s-1 at 4000 m. Fukamachi et al., Nature Geoscience, 2010.
SLIDE 13
Freshening of RSBW at 150E
SLIDE 14
AABW freshening
SLIDE 15
SLIDE 16
Summary and conclusions
Eddies largely compensate Ekman contribution to
- subduction. Regional pattern set by lateral induction.
Subduction pattern consistent with interior distribution
- f PV and anthropogenic CO2.
Must get eddies, mixed layer depth and surface currents right to get heat and carbon storage right. Need to use a large, spatially-varying diffusivity in GM to parameterise eddy contribution to subduction. Antarctic Bottom Water continues to freshen. Calving
- f Mertz glacier contributed.
SLIDE 17
Mertz Polynya region, summer 2008
SLIDE 18
Mertz Polynya region, 2011 (red), 2008 (blue)
SLIDE 19
Less dense water formed after calving
0.041
SLIDE 20
SLIDE 21
Freshening of Ross Sea shelf waters
Jacobs +Giulivi, JCLIM, 2010
Trend of 0.03 / decade, 1958 – 2008 (r = -0.90)
Whitworth, 2002, GRL Jacobs et al., 2002 Jacobs 2004, 2006
SLIDE 22
Water mass changes: freshening of Antarctic Bottom Water
neutral density salinity
SLIDE 23
Water mass changes: freshening of Antarctic Bottom Water
neutral density salinity
SLIDE 24
SLIDE 25
CAML photo
Martin Riddle and Aaron Spurr
SLIDE 26
Regulation of chemical exposure by the
- verturning circulation
SLIDE 27
dissolved oxygen
Cossa et al., 2010, submitted
a b
Elevated methyl mercury in the Southern Ocean
methyl mercury reactive mercury
SLIDE 28
Ocean, ice and atmosphere combine to produce elevated methyl mercury at high latitude
- 1. Bacteria consume
- xygen and methylate
mercury in deep water
- 2. Upwelling of low oxygen
deep water increases methylmercury concentrations in surface water.
- 3. Mercury in atmosphere
reacts with bromine released during sea ice formation and is deposited
- n ice-ocean surface.
- 4. Mercury is scavenged
by sinking organic particles in productive sea ice zone. Bacteria consume organic matter and methylate mercury.
SLIDE 29
Ocean currents protecting ecosystems from exposure to contaminants (eg PFCs).
Bengtson-Nash et al., 2010
SLIDE 30
Open questions
Future of Southern Ocean overturning Likelihood and magnitude of climate feedbacks
Overturning Carbon cycle Sea ice
Ocean impact on Antarctic ice sheet mass balance Ecosystem response to global change
SLIDE 31
A Southern Ocean Observing System: www.scar.org/soos
SLIDE 32
Conclusions
The Southern Ocean has a profound influence on the earth system. Changes in the Southern Ocean will affect climate, sea level, biogeochemical cycles and biological productivity. Recent progress:
mechanism of subduction & heat/carbon uptake role of eddies physical controls on biological productivity pathways of overturning circulation nature and causes of Southern Ocean change
