Tools for effortless reverse engineering of MikroTik routers https://github.com/0ki/mikrotik-tools v3 http ://kirils.org/ Legal disclaimer Goal of this presentation is to allow the members of the research community to assess security and

slide-1
SLIDE 1

Tools for effortless reverse engineering of MikroTik routers

v3

https://github.com/0ki/mikrotik-tools http ://kirils.org/

slide-2
SLIDE 2

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 2 / 47

Legal disclaimer

Goal of this presentation is to allow the members of the research community to assess security and achieve the interoperability of computer programs

slide-3
SLIDE 3

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 3 / 47

MikroTik? Anyone even uses it?

slide-4
SLIDE 4

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 4 / 47

RouterOS is …

  • Linux!

– old Linux!

  • Startup scripts
  • Nova binaries
  • Config
slide-5
SLIDE 5

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 5 / 47

And it’s also closed source & closed ecosystem

slide-6
SLIDE 6

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 6 / 47

A jailbreak is needed...

slide-7
SLIDE 7

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 7 / 47

A built-in backdoor. How nice.

  • RouterOS 2.9.8 delivered on

15 Nov 2005

– a wild “/nova/etc/devel-login”

appears in /nova/bin/login

– [ -f /nova/etc/devel-login &&

username == devel && password == admin.password ] && /bin/ash

slide-8
SLIDE 8

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 8 / 47

All we gotta do is ...

slide-9
SLIDE 9

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 9 / 47

All we gotta do is ...

1) Create /nova/etc/devel-login 2) telnet to 192.168.88.1 as devel

slide-10
SLIDE 10

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 10 / 47

[TAB] to the rescue

  • No ls? No problem!

– cat, space, tab, tab

  • Or, you know, do it properly, and upload busybox

– statically linked, for the right architecture

  • uname -m

– this might be of interest:

  • https://busybox.net/downloads/binaries/1.21.1/
slide-11
SLIDE 11

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 11 / 47

But how… ?

slide-12
SLIDE 12

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 12 / 47

The old way

  • A VirtualBox appliance!
  • DEMO
slide-13
SLIDE 13

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 13 / 47

The old way

  • A VirtualBox appliance!
  • Works only if

– If your CPU is AR9344 and device has at least two ethernet ports

  • RB951G-2HnD, RB951Ui-2HnD <== tested
  • CRS109-8G-1S-2HnD-IN, CRS125-24G-1S-IN, CRS125-24G-1S-2HnD-IN
  • RB2011L, RB2011LS, RB2011iLS-IN, RB2011iL-IN, RB2011UiAS-IN

RB2011UiAS-RM, RB2011UiAS-2HnD-IN

  • OmniTIK 5, OmniTIK 5 PoE
slide-14
SLIDE 14

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 14 / 47

The new way

  • A bash/python script
  • Works regardless of architecture
  • Very fast
  • Can do remote jailbreaks
  • Will not help you recover lost passwords
  • Will probably get patched soon after this presentation
  • DEMO
slide-15
SLIDE 15

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 15 / 47

  • Now. The tools.
slide-16
SLIDE 16

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 16 / 47

NPK file sourcing

  • getnpk.sh

– deps: wget

  • reversenpk.sh

– deps: unsquashfs, unnpk

– https://github.com/rsa9000/npk-tools

slide-17
SLIDE 17

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 17 / 47

https://github.com/wsxarcher/routeros-linux-patch

Kernel patches

slide-18
SLIDE 18

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 18 / 47

RouterOS boot process

slide-19
SLIDE 19

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 19 / 47

Where do we put custom binaries?

slide-20
SLIDE 20

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 20 / 47

Anywhere!

  • “path” looks for specified path in prefixed directories

– Used throughout their scripts – Makes using custom scripts easier

slide-21
SLIDE 21

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 21 / 47

High level overview of RouterOS

slide-22
SLIDE 22

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 22 / 47

NPK format

slide-23
SLIDE 23

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 23 / 47

NPK format

  • Numeric values are unsigned little endian
  • File consists of header, file size, parts and footer.
  • File size is 8b less
  • Each part consist of:

– part type (short) – payload size (long) – payload

slide-24
SLIDE 24

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 24 / 47

NPK format

  • At least two types of current NPKs:

– package

  • 0..3 header 1E F1 D0 BA
  • footer 10 00 01 00 00 00 49

– footer since 3.22

– restriction (invisible package)

  • 0..3 header FB 0F 10 A1
  • footer 03 00 00 00 00 00
slide-25
SLIDE 25

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 25 / 47

Part types

slide-26
SLIDE 26

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 26 / 47

supout.rif

slide-27
SLIDE 27

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 27 / 47

What is supout.rif?

  • Support output

– ridiculously intricate format – or RouterOS information file, maybe, idk ¯\_( ツ )_/¯

slide-28
SLIDE 28

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 28 / 47

supout.rif from outside

slide-29
SLIDE 29

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 29 / 47

supout.rif section decoding

  • swap bits around

– per three bytes

  • base64
  • section decodes to:

– name + ‘\0’ +

zlib_compressed_content

slide-30
SLIDE 30

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 30 / 47

supout.rif section decoding

slide-31
SLIDE 31

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 31 / 47

supout.rif from inside

  • What does it contain?

– your whole

configuration

– /proc/ folder – memory addresses – your log – and more

slide-32
SLIDE 32

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 32 / 47

DEMO

Demo: mikrotik.com xss Demo: decode_supout.py

slide-33
SLIDE 33

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 33 / 47

Config files

slide-34
SLIDE 34

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 34 / 47

Configuration

  • Config is stored in /rw/store as pairs of files

– IDX = index – DAT = data

slide-35
SLIDE 35

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 35 / 47

IDX format

  • Record ID (long)

– if ID is 0xFFFFFFFF, field has no content – used for offsetting

  • length (long)
  • separator (long)

– usually 0x05000000

slide-36
SLIDE 36

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 36 / 47

DAT format

  • LENGTH (short)
  • M2 RECORD of length

– Config ID (3 bytes) – type (1 byte)

  • content depends on to type
slide-37
SLIDE 37

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 37 / 47

Peculiarities / features

  • Field IDs shared with web
  • Winbox protocol derived from DAT format

– Working directly with files? – Dangerous!

slide-38
SLIDE 38

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 38 / 47

mt_dat_decoder.py module

  • DEMO
slide-39
SLIDE 39

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 39 / 47

Where’s my password?

  • Calm down! It’s encrypted!
slide-40
SLIDE 40

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 40 / 47

The password is

  • hashed
  • salted
  • md5
  • Oh, wait, no. That’s the key.
slide-41
SLIDE 41

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 41 / 47

The password

key = md5(username + "283i4jfkai3389") password = user["password"] xor key

slide-42
SLIDE 42

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 42 / 47

The password tool

  • DEMO
slide-43
SLIDE 43

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 43 / 47

Backup files

slide-44
SLIDE 44

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 44 / 47

Backup file layout

  • Header (long)

– 0x88ACA1B1 – backup – 0xEFA89172 – encrypted backup

  • Length of backup file (long)
  • Records of:

– Path name, idx contents, dat contents

  • Each record consists of length (long) and binary data
slide-45
SLIDE 45

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 45 / 47

The bug

  • mkdir -p pathname(“/flash/rw/store/”+filename)
  • write idx to “/flash/rw/store/”+filename+“.idx”
  • write dat to “/flash/rw/store/”+filename+“.dat”
slide-46
SLIDE 46

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 46 / 47

decode_backup.py

  • DEMO
slide-47
SLIDE 47

Oct 21, 2017, Hacktivity, Budapest @KirilsSolovjovs 47 / 47

The end.

  • Tools & jailbreak available

https://github.com/0ki/mikrotik-tools

  • Latest appliance:

http://02.lv/f/2017/09/15/MT_JB_0.89.ova
