Tolerating Latency in Replicated State Machines through Client Speculation April 22, 2009 Benjamin Wester 1 , James Cowling 2 , Edmund B. Nightingale 3 , Peter M. Chen 1 , Jason Flinn 1 , Barbara Liskov 2 University of Michigan 1 , MIT CSAIL 2 ,

SLIDE 1

Tolerating Latency in Replicated State Machines through Client Speculation

April 22, 2009

Benjamin Wester1, James Cowling2, Edmund B. Nightingale3, Peter M. Chen1, Jason Flinn1, Barbara Liskov2 University of Michigan1, MIT CSAIL2, Microsoft Research3

SLIDE 2

Simple Service Configuration

NSDI'09 Benjamin Wester University of Michigan CSE 2

1 ++x x=1

SLIDE 3

Replicated State Machines (RSM)

x=1 x=1 x=1 ++x 2 2 2 2 x=1 x=2 x=2 x=2 x=2 ++x ++x ++x

Agree on request
All non-faulty replies are

identical

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 4

RSMs have high latency

2 2 2

1. Need many replies
2. Agreement
3. Geographic Distribution

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 5

Hide the Latency

Use speculative execution inside RSM
Speculate before consensus is reached

– Without faults, any reply predicts consensus value – Let client continue after receiving one reply

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 6

Overview

Introduction
Improving RSMs with speculation
Application to PBFT
Performance
Conclusion

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 7

Speculative Execution in RSM

Continue processing while waiting

Blocked Take Checkpoint x=1 Predict: 1 Speculate! Commit x=1

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 8

Critical path: first reply

Completion latency less relevant
First reply latency sets critical path

– Speed – Accuracy

Other desirable properties

– Throughput – Stability under contention – Smaller number of replicas

1 1

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 9

Requests while speculative

1. Hold request

– Bad performance

2. Distributed commit/rollback

– State tracking complex

while !check_lottery(): submit_tps() buy_corvette()

win?

yes

Predict win? = yes buy

What do we do with this?

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 10

Resolve speculations on the replicas

Explicitly encode dependencies as predicates
No special request handling needed
Replicas need to log past replies
Local decision at replicas matches client

yes

if win?=yes: buy

yes

NSDI'09 Benjamin Wester University of Michigan CSE

while !check_lottery(): submit_tps() buy_corvette()

win?

win? = yes

Predict win? = yes

SLIDE 11

Overview

Introduction
Improving RSMs with speculation
Application to PBFT
Performance
Conclusion

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 12

Practical BFT

f=1

primary client

[Castro and Liskov 1999]

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 13

Additional Details

Tentative execution

– PBFT/PBFT-CS complete in 4 phases

Read-only optimization

– Accurate answer from backup replica

Failure threshold

– Bound worst-case failure

Correctness

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 14

Overview

Introduction
Improving RSMs with speculation
Application to PBFT
Performance
Conclusion

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 15

Benchmarks

Shared counter

– Simple checkpoint – No computation

NFS: Apache httpd build

– Complex checkpoint – Significant computation

15 NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 16

Topology

2.5 or 15 ms Primary 1. Primary-local 2. Primary-remote 3. Uniform

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 17

Base case: no replication

2.5 or 15 ms 1. Primary-local 2. Primary-remote 3. Uniform

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 18

Shared Counter

20 40 60 80 100 120 5 10 15 Run Time (sec) Network Delay (ms) PBFT PBFT-CS No replication

Primary-local topology

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 19

Shared Counter

20 40 60 80 100 120 5 10 15 Run Time (sec) Network Delay (ms) PBFT PBFT-CS No replication Zyzzyva

Primary-local topology

[Kotla et al. 07]

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 20

Shared Counter

20 40 60 80 100 120 5 10 15 Run Time (sec) Network Delay (ms) PBFT PBFT-CS No replication

Uniform & Primary-remote topology

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 21

Shared Counter

20 40 60 80 100 120 5 10 15 Run Time (sec) Network Delay (ms) PBFT PBFT-CS No replication Zyzzyva

NSDI'09 Benjamin Wester University of Michigan CSE

Uniform & Primary-remote topology

SLIDE 22

NFS: Apache build

5 10 15 20 25 30 35 5 10 15 Run Time (min) Network Delay (ms) PBFT PBFT-CS No replication

Primary-local topology

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 23

NFS: Apache build

Uniform topology

5 10 15 20 25 30 35 5 10 15 Run Time (min) Network Delay (ms) PBFT PBFT-CS No replication

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 24

NFS: Apache build

Primary-remote topology

5 10 15 20 25 30 35 5 10 15 Run Time (min) Network Delay (ms) PBFT PBFT-CS No replication

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 25

NFS: With Failure

5 10 15 20 25 30 35 5 10 15 Run Time (min) Network Delay (ms) PBFT PBFT-CS No replication PBFT-CS (1% fail)

Primary-local topology

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 26

Throughput (Shared Counter)

10 20 30 40 50 60 70 1 10 100 KOps/sec Number of Clients PBFT PBFT-CS Zyzzyva

LAN topology

NSDI'09 Benjamin Wester University of Michigan CSE

SLIDE 27

Conclusion

Integrate client speculation within RSMs
Predicated requests: performance without complexity
Clients less sensitive to latency between replicas
5x speedup over non-speculative protocol

Makes WAN deployments more practical

NSDI'09 Benjamin Wester University of Michigan CSE
