Titans Methane Weather Thank you. We started the week hearing about cosmology, large scale structure, & galaxy formation. Today we zoomed in to extrasolar planets. So, lets zoom in from thinking about planets around other stars to

slide-1
SLIDE 1

Titan’s Methane Weather

Henry Roe (Lowell Observatory) Emily Schaller (IfA, University of Hawaii) Michael Brown (Caltech) Chadwick Trujillo (Gemini Observatory)

20 May 2009 - Joint Subaru/Gemini Science Meeting Thank you. We started the week hearing about cosmology, large scale structure, & galaxy formation. Today we zoomed in to extrasolar planets. So, let’s zoom in from thinking about planet’s around other stars to an object in our own solar system Today I would like to talk about a project we have been working on using Gemini and other telescopes to study weather and climate on Saturn’s largest moon Titan. Acknowledge collaborators. I would like to spend the first few minutes giving a brief introduction to Titan.

slide-2
SLIDE 2

Titan’s Methane Weather

Henry Roe (Lowell Observatory) Emily Schaller (IfA, University of Hawaii) Michael Brown (Caltech) Chadwick Trujillo (Gemini Observatory)

20 May 2009 - Joint Subaru/Gemini Science Meeting Thank you. We started the week hearing about cosmology, large scale structure, & galaxy formation. Today we zoomed in to extrasolar planets. So, let’s zoom in from thinking about planet’s around other stars to an object in our own solar system Today I would like to talk about a project we have been working on using Gemini and other telescopes to study weather and climate on Saturn’s largest moon Titan. Acknowledge collaborators. I would like to spend the first few minutes giving a brief introduction to Titan.

slide-3
SLIDE 3

When we look at the surfaces of Titan & Earth we see some remarkable similarities. If you had never seen any of these images before, you would probably have a hard time identifying which were from Titan and which were from Earth. The materials are very different on Titan (water ice instead of rock, liquid methane instead of water, etc, but the processes on the surface and in the atmosphere are familiar.

slide-4
SLIDE 4

Titan Earth

When we look at the surfaces of Titan & Earth we see some remarkable similarities. If you had never seen any of these images before, you would probably have a hard time identifying which were from Titan and which were from Earth. The materials are very different on Titan (water ice instead of rock, liquid methane instead of water, etc, but the processes on the surface and in the atmosphere are familiar.

slide-5
SLIDE 5

30-year Seasonal Cycle

slide-6
SLIDE 6

Mean daily insolation on Titan

30-year Seasonal Cycle

slide-7
SLIDE 7

~80% N2 ~90% N2

slide-8
SLIDE 8

~80% N2 ~90% N2

Thick vs. thin Trace species: Oxygen (we all like) Water - condensible, triple point, phase transitions On Titan - water = rock, but near triple point of methane and few percent methane

slide-9
SLIDE 9

Methane Water

~80% N2 ~90% N2

Thick vs. thin Trace species: Oxygen (we all like) Water - condensible, triple point, phase transitions On Titan - water = rock, but near triple point of methane and few percent methane

slide-10
SLIDE 10

Thin shell even though surface area much less: Titan/Earth atmos mass = 2x Titan: 4m/10cm Earth: 1

  • 10cm/1

m With that much condensible in the atmosphere, where’s liquid on surface? How to look for it?

slide-11
SLIDE 11

Titan’s Surface Mapped by Cassini

Cassini map of Titan’s surface. No liquids at low latitudes, but evidence of fluid flow

  • everywhere. Lots of lakes in North, a few in south.
  • pportunity to discuss, temporal coverage of Cassini
  • vs. ground-based

90°N 0° 90°S

slide-12
SLIDE 12

Titan

Methane in atmosphere Irreversible loss of methane at top of atmosphere All methane gone in 10myr

Methane

slide-13
SLIDE 13

Titan

Methane in atmosphere Irreversible loss of methane at top of atmosphere All methane gone in 10myr

Methane

slide-14
SLIDE 14

Titan

Methane in atmosphere Irreversible loss of methane at top of atmosphere All methane gone in 10myr

Methane

slide-15
SLIDE 15

Some Questions

  • Methane weather? Where? When? How?
  • Source of methane?
  • Hydrology/Meteorology: Where? When? How?
  • Seasonal climate change; Massive monsoon?
slide-16
SLIDE 16

Methane transmission

slide-17
SLIDE 17

Methane transmission

slide-18
SLIDE 18

Methane transmission

slide-19
SLIDE 19

Small angular size As Joe Jensen discussed on Monday: Flexibility of Gemini Operations are key Importance of Queue! Snapshot needs only 15- 20 minutes Maximize efficient use of Gemini with small telescopes to trigger ToO’s and fill-in temporal record.

slide-20
SLIDE 20

Small angular size As Joe Jensen discussed on Monday: Flexibility of Gemini Operations are key Importance of Queue! Snapshot needs only 15- 20 minutes Maximize efficient use of Gemini with small telescopes to trigger ToO’s and fill-in temporal record.

slide-21
SLIDE 21

Small angular size As Joe Jensen discussed on Monday: Flexibility of Gemini Operations are key Importance of Queue! Snapshot needs only 15- 20 minutes Maximize efficient use of Gemini with small telescopes to trigger ToO’s and fill-in temporal record.

slide-22
SLIDE 22

Results

slide-23
SLIDE 23

South polar clouds

Typical south polar clouds of early-to-mid southern summer. Can see more data on our poster at this meeting.

slide-24
SLIDE 24

Dissipation of south polar clouds

Schaller et al. 2006b Icarus

slide-25
SLIDE 25

Titan

North Pole South Pole

Southern Summer

slide-26
SLIDE 26

Titan

North Pole South Pole

Southern Summer Southern Fall

North Pole South Pole

slide-27
SLIDE 27

Roe et al. 2005 ApJL

Discovery of mid-latitude clouds at 40°S

slide-28
SLIDE 28

Geographic Control of mid-Latitude Clouds

Roe et al. 2005 Science

slide-29
SLIDE 29

Lake-effect clouds in the north polar region

lines of latitude are 5deg ISS in green, VIMS in red, gemini in blue

  • M. Brown et al. 2009 GRL
slide-30
SLIDE 30

Tropical storms & atmospheric waves Schaller et al. 2009 in press

accepted to Nature Event last spring Proves the value of our multi- telescope approach Wave activity GCM’s predict no/few clouds equatorially ever, AND no southern clouds in current season. This shows how Titan’s atmosphere can generate clouds & precip at time/places that ‘ should’ be dry

slide-31
SLIDE 31

3-color image constructed from K’, H210, & Brgamma amazing amount of color variation in the rings amazing amount of detail in dynamics of saturn atmosphere

slide-32
SLIDE 32

Mimas

Mimas is “ death-star moon” because of a large crater and its appearance 400 km across

slide-33
SLIDE 33
slide-34
SLIDE 34

F-ring & Pandora Janus

Janus is <200 km across F-ring discovered in 1979 by the Pioneer 11 imaging team. Constrained by 2 shepard moons (Pandora & Prometheus) Pandora <100km across

slide-35
SLIDE 35

F-ring & Pandora

Janus is <200 km across F-ring discovered in 1979 by the Pioneer 11 imaging team. Constrained by 2 shepard moons (Pandora & Prometheus) Pandora <100km across

slide-36
SLIDE 36

Thank you to all the Gemini staff who have helped with these observations!

slide-37
SLIDE 37

Summary

  • Titan has active methane meteorology
  • Ground-based observing required to provide necessary

temporal coverage

  • Gemini is key to ground-based observing
  • Discoveries in past 5 years include:
  • South polar cloud field in late southern spring
  • Seasonal shutdown of south polar cloud field

(monsoonal shift of winds)

  • Mid-southern latitude clouds that are geographically

controlled likely indicate region of geologic activity and methane resupply

  • Northern lake-effect clouds
  • Wave-activity can communicate globally and generate

clouds at latitudes/seasons not predicted by global circulation models

  • Have only observed a fraction of Titan’s 30-year seasonal

cycle Need to continue observing!
