Thyroid Storm in the Setting of Subacute Thyroiditis PGY-2 Case Conference Jordan Groubert, PGY-2 11/5/2019 1 Outline 1. Review Case 2. Discuss Disease Pathogenesis 3. Discuss Differential Diagnosis 4. Discuss Diagnostic Criteria 5.

slide-1
SLIDE 1

Thyroid Storm in the Setting of Subacute Thyroiditis

PGY-2 Case Conference Jordan Groubert, PGY-2 11/5/2019

1

slide-2
SLIDE 2
  • 1. Review Case
  • 2. Discuss Disease Pathogenesis
  • 3. Discuss Differential Diagnosis
  • 4. Discuss Diagnostic Criteria
  • 5. Discuss Treatment
  • 6. Patient Update

Outline

2

slide-3
SLIDE 3

History of Present Illness

3

slide-4
SLIDE 4

History of Present Illness

  • 19 y/o female presented with a 2-3 day history of generalized pain, confusion, nausea, emesis and right upper

extremity swelling. On presentation she was encephalopathic, intermittently crying out in pain and only able to answer some yes/no questions. The majority of the history was provided by the patient’s father.

4

slide-5
SLIDE 5

Medical History

5

slide-6
SLIDE 6

Past Medical History

  • IV drug abuse
  • Last admitted drug use was 6 months prior, but family was suspicious for active use
  • “Pink powder” found at home by her father
  • MRSA abscesses
  • No prior history of thyroid disorders

6

slide-7
SLIDE 7

Past Surgical History

  • No prior surgical history

7

slide-8
SLIDE 8

Family History

  • No pertinent family history
  • No known family history of thyroid disorders

8

slide-9
SLIDE 9

Social history

  • Current 1 ppd smoker, 5 pack-year history
  • Denied alcohol use
  • IV heroin/fentanyl use
  • Lives at home with her father

9

slide-10
SLIDE 10

Review of Systems

10

slide-11
SLIDE 11

Review of Systems

  • ROS positive for
  • Generalized pain
  • Nausea
  • Emesis
  • Right upper extremity swelling
  • Reliable ROS unable to be obtained upon admission due to encephalopathy

11

slide-12
SLIDE 12

Physical Exam

12

slide-13
SLIDE 13

Physical exam

  • Vitals: Temp 99.3 F, HR 143, RR 40, SpO2 97% RA, BP 93/57 (68)
  • General: Ill-appearing, moderate distress, diaphoretic
  • HEENT: NCAT, PERRL, EOMI, Poor dentition. No exophthalmos/ophthalmopathy.
  • Neck: Diffusely enlarged thyroid with tenderness to palpation, no bruit.
  • CV: Tachycardia, regular rhythm, no murmurs
  • Thorax: Tachypnea, bilateral crackles, labored respirations
  • Abdomen: Bowel sounds present, generalized tenderness, non-distended, no organomegaly, no rashes
  • Extremities: Track marks on bilateral upper/lower extremities, no peripheral edema, no pretibial myxedema
  • Neuro: Moves all extremities, sensation grossly intact, no focal deficits
  • Integument: Track marks
  • Psych: anxious and agitated, intermittently crying out in pain, AOx1

13

slide-14
SLIDE 14

Labs and Imaging

14

slide-15
SLIDE 15

Labs

134 3.6 96 32 0.77 162 22 12.5 36.4 23.3 83 Troponin: 1.530 TSH: 0.026 Free T3: 16.9 Free T4: > 6.99 Lactic Acid: 3.7 UDS: negative

15

slide-16
SLIDE 16

Imaging

16

  • CT Neck Soft Tissue
  • Generalized edema throughout the soft tissues of the neck with prominent swelling and edema involving

the thyroid gland. Findings concerning for thyroiditis.

  • Thyroid US
  • Large and heterogenous gland with no normal thyroid tissue appreciated. No focal nodules noted. No

evidence of increased vascularity on color doppler.

slide-17
SLIDE 17

Thyroid US

Summa Health Sample Preso 17

slide-18
SLIDE 18

Hospital Course

  • Admitted to the ICU for management of thyrotoxicosis and started on empiric antibiotics for sepsis
  • Blood cultures positive for MRSA; TTE showed tricuspid valve endocarditis
  • Endocrinology was consulted and started:
  • Methimazole
  • Propranolol
  • Hydrocortisone
  • Cholestyramine
  • Patient endorsed anterior neck pain, palpitations, diaphoresis and heat intolerance for 2-3 days before presentation
  • Thyroid receptor antibody (TRAb) was negative, ruling out Grave’s disease
  • Methimazole was stopped
  • TPO antibody was negative, ruling out Hashimoto’s thyroiditis
  • Repeat thyroid ultrasound continued to show evidence of thyroiditis
  • Thyroiditis attributed to septicemia/endocarditis/systemic inflammation
  • Patient’s condition gradually improved and steroids were tapered

18 11.05.19

slide-19
SLIDE 19

Thyroid Storm

19

slide-20
SLIDE 20

Thyroid Storm

  • Thyroid storm is a rare, life-threatening manifestation of thyrotoxicosis
  • 20-30% mortality rate
  • Affecting only 1% of thyrotoxic patients
  • Most common in patient’s with an underlying hyperthyroid state (Grave’s Disease, toxic multinodular goiter or

solitary toxic adenoma) who have an inciting event

  • Thyroid or non-thyroidal surgery
  • Infection
  • Trauma
  • Acute iodine load
  • Childbirth
  • Irregular use or discontinuation of anti-thyroid drugs (ex. methimazole, propylthiouracil)
  • Very few documented cases of thyroid storm in the setting of subacute thyroiditis

20

slide-21
SLIDE 21

Presentation

  • Patients present with severe signs/symptoms of thyrotoxicosis
  • Hyperpyrexia
  • Tachycardia
  • Heart failure
  • Hypotension
  • Diarrhea
  • Confusion/delirium
  • Anxiety/agitation
  • Physical exam
  • Goiter may or may not be present
  • Labs
  • Suppressed TSH, elevated Free T3/T4
  • Degree of Free T3/T4 elevation doesn’t necessarily correlate with severity of symptoms

Summa Health Sample Preso 21 06.06.2016

slide-22
SLIDE 22

Pathogenesis

  • Excess release of circulating thyroid hormones
  • Mechanism of hormone release differs depending on underlying hyperthyroid condition
  • Ex. Graves Disease, subacute thyroiditis, toxic multinodular goiter etc.

22

slide-23
SLIDE 23

Differential Diagnosis

  • Drug intoxication
  • Hypertensive emergency/hypertensive encephalopathy
  • Infection/sepsis
  • Neuroleptic malignant syndrome
  • Pheochromocytoma
  • Psychosis

Summa Health Sample Preso 23 06.06.2016

slide-24
SLIDE 24

24

  • Diagnosis is based on signs/symptoms of thyroid storm in

individuals with suppressed TSH and elevated Free T3/T4

  • The Burch-Wartofsky score is used to aid in the diagnosis
  • Scoring system:
  • < 25: thyroid storm unlikely
  • 25-44: impending thyroid storm
  • > 45: highly suggestive of thyroid storm
  • In this case, the Burch-Wartofsky score was 75

Diagnosis

slide-25
SLIDE 25

Workup

  • Labs
  • TSH, Free T3, Free T4
  • TSI or TRAb
  • Imaging
  • Thyroid ultrasound
  • CT neck soft tissue
  • Radioiodine uptake and scan

25

slide-26
SLIDE 26

Treatment

  • Patients require management in the ICU
  • Management includes:
  • Beta-blockers
  • Management of signs/symptoms related to increased adrenergic tone
  • Thionamides (methimazole or propylthiouracil)
  • Decrease synthesis and peripheral conversion of thyroid hormones
  • Glucocorticoids
  • Reduce peripheral conversion of T4 to T3 conversion
  • Promote vasomotor stability
  • Reduce inflammation (if present)
  • Bile acid sequestrants
  • Decrease enterohepatic recycling of thyroid hormones
  • Iodine (iodinated contrast or iodine tablets)
  • To be given after administration of anti-thyroid medications to prevent worsening of thyrotoxicosis
  • Decrease release of T3 and T4 from the thyroid

26

slide-27
SLIDE 27

Subacute Thyroiditis

  • Inflammation of the thyroid usually in the setting of viral illness or a post-viral inflammatory process
  • Pathogenesis: destruction of thyroid follicles and proteolysis of thyroglobulin causing release of T3 and T4
  • Presentation
  • Anterior neck pain
  • Diffuse goiter with tenderness to palpation
  • Signs/symptoms of hyperthyroidism/thyrotoxicosis with associated laboratory abnormalities
  • Thyrotoxicosis is usually mild
  • Severity of signs/symptoms don’t necessarily correlate with degree of lab abnormalities
  • Imaging
  • Ultrasound: hypoechoic appearance, may be normal or enlarged
  • Radioiodine uptake and scan: low uptake in the hyperthyroid phase
  • Treatment:
  • Pain control and beta blockers
  • Thionamides are not indicated
  • Clinical course
  • Hyperthyroid  Euthyroid  Hypothyroid  Recovery

Summa Health Sample Preso 27

slide-28
SLIDE 28

Patient update

  • Discharged to acute rehab following complicated ICU course
  • No outpatient follow-up to date

28

slide-29
SLIDE 29

Acknowledgements

  • Ahmad Al-Shoha, MD
  • Mansur Assaad, MD
  • Bisher Zuhdi, MD

29

slide-30
SLIDE 30

References

  • Salih AM, Kakamad FH, Rawezh QS, et al. Subacute thyroiditis causing thyrotoxic crisis; a case report with literature
  • review. Int J Surg Case Rep. 2017;33:112-114.
  • Swinburne JL, Kreisman SH. A rare case of subacute thyroiditis causing thyroid storm. Thyroid. 2007;17(1):73-6.
  • Fatourechi V, Aniszewski JP, Fatourechi GZ, Atkinson EJ, Jacobsen SJ. Clinical features and outcome of subacute

thyroiditis in an incidence cohort: Olmsted County, Minnesota, study. J Clin Endocrinol Metab. 2003;88(5):2100-5.

  • MKSAP
  • Uptodate

30

slide-31
SLIDE 31

Questions?

31

slide-32
SLIDE 32

Thank you

32

slide-33
SLIDE 33

Severe Cardio-Renal Syndrome Responding to Very High Dose Lasix Drip

Dan Redle MD, Bisher Zhudi MD, Chris Tanayan MD, Charina Gayomali MD

slide-34
SLIDE 34

Overview

 Review Case  Pathophysiology  Differentials  Treatment  Patient Update  References

slide-35
SLIDE 35

HPI

 61 yo M presented to ACH ED 4/3/19 with acute on chronic SOB with cough,

bilateral leg pain, chills, arthralgias, nausea. In ED, vital signs initially remarkable for increased work of breathing with RR of 22 and patient required BiPAP .

slide-36
SLIDE 36

Medical and Social History

 PMH: CAD, HFrEF (25%), Afib,CKD, Apical Thrombus, COPD, T2DM, OSA, DVT

, HTN, HPL, Gout, Back Pain

 PSH: CABG, Atrial Ablation, Embolectomy RLE  FMH: Father: Lung Cancer  Social: Single, known hoarder, denied tobacco/EtOH/illicit drug use

slide-37
SLIDE 37

Physical Exam

Constitutional: He is oriented to person, place, and time. In moderate respiratory distress

HENT:

Head: Normocephalic and atraumatic. Right Ear: External ear normal. Left Ear: External ear normal.

Nose: Nose normal.

Mouth/Throat: Oropharynx is clear and moist.

Eyes: Pupils are equal, round, and reactive to light. Conjunctivae and EOM are normal.

Neck: Normal range of motion. No JVD present. No tracheal deviation present.

Cardiovascular: Normal rate, Irregularly Irregular Rate, normal heart sounds and intact distal pulses.

Pulmonary/Chest: He is in respiratory distress. He has wheezes.

Abdominal: Soft. Bowel sounds are normal. He exhibits no distension. There is tenderness (mild generalized). There is no rebound. Musculoskeletal: Normal range of motion. He exhibits no tenderness. Positive lower extremity edema Neurological: He is alert and oriented to person, place, and time.

Skin: Skin is warm and dry. No erythema.

Nursing note and vitals reviewed.

slide-38
SLIDE 38

Vitals/Labs

 Vitals: T 97.5, HR 82, RR 24, O2 95  Lactic Acid: 1.7

4/3/2019 19:58 Hemoglobin, Art, Extended: 10.0 pH, Arterial: 7.205 (L) pCO2, Arterial: 52.9 (H) pO2, Arterial: 471.3 (H) HCO3, Arterial: 20.4 (L) TCO2 (calc), Art: 22.1 (L) Base Excess, Arterial: -7.4 (L) O2 Sat, Arterial: 99.7 FIO2 Arterial: 100%

slide-39
SLIDE 39

Hospital Course

  • Admitted 4/3/19-5/1/19
  • AHRF 2/2 Influenza, CXR congested -> ICU, BiPAP

, BiPaP -> Resp status worsened/CXR worsened then intubated, Increased diuretic dosages/frequency. Initial wt 281 lbs.

  • Diuresis fairly well at first with boluses, then UOP dropped, CXR still well -> Lasix gtt

10 mg/hr ->20 mg/hr-> UOP improved, net negative, CXR Improved, extubated to NIV , -7.8 L net, On NC, Lasix boluses -> UOP worsening/Cr climbing, Na 160s, required Free H2O-> Afib RVR overnight-> amio gtt -> resp status worse req BiPAP , UOP dropped/net positive, CXR more wet, Cr climbing, still had edema -> Lasix gtt 10 mg/hr with bolus Lasix 120 mg, no response

  • Consulted Nephrology-> UF vs High dose Lasix gtt? -> already net -8 L, JVD?,

Hypernatremic and less edema but CXR very wet -> 4/13/19 IV Lasix drip 100 mg/hr, (CVP just before 24 mmHg), Consulted Cardiology

  • Patient responded VERY WELL, Over the next 2 days net of -7 L UOP for a total. Able

to wean off Lasix drip and start Bumex 3 mg BID

  • by April 18th Net -21 L, off BiPAP

, to Floors, did not develop tinnitus, wt now 244 lbs.

slide-40
SLIDE 40

Hospital Course

 On Floor, patient continued to be net negative with wt decreasing. 

4/19: Cr increased, 2.8->3.2, Bumex held

 TTE: LVEF 23% with global dysfunction/RV severely dilated with moderate

dysfunction/2 + PVR/PASP 45 mmHG

 Cr climbed and peaked at 3.59 4/21, diuretics held up till this time. Bumex 2 mg PO

BID started after.

 Decision was made to hold off on LHC/RHC due to severe renal dysfunction  Not deemed a good candidate for dialysis by Nephrology  Palliative Care consulted, patient made a limited code  DC’d to SNF  Patient net – 23.5 L, wt 221 lbs (from 281 lbs)

slide-41
SLIDE 41

Creatinine, Weight, and Urine Output Course

Initiation of increased bolus diuresis, wt 281 UOP dropped 4/7/19, started Lasix Drip at 10/hr, still net neg, total Decision to start Lasix at 100/hr

  • n 4/13 in

afternoon, CVP 24, started making urine 4/13/19 morning CXR wet, no UOP Cr climbing, Lasix at 10/hr no response, bolus of 120, no response, wt 257 lbs 4/12: night Afib RVR

  • 7 L over next

two days, total net negative - 13.8 L since admission, wt 244

  • 23.5 L by end of

admission, wt 221 Patient either Euvolemic v.

  • Hypovolemic. Likely due

diuresis with lagging fluid

  • shifts. Bumetanide held for a

couple days Bolus Lasix

slide-42
SLIDE 42

Cardio-Renal Syndrome Pathophysiology

 Complex interaction between Hemodynamics, RAAS, Sympathetic, HPA Axis,

Vasopressin, and Inflammation

 Cardiac output is reduced, resulting in venous systemic pressure elevation

which is transmitted to the kidneys/other organs, which have impaired perfusion and are so damaged. Reduced cardiac output also reduces perfusion to organs

 RASS, Vasopressin, HPA and local/systemic inflammation result, and continue

in a downward spiral perpetuating volume overload and end organ damage

 These patients have a narrow volume status, BP status and so diuretic window  Diuresis can is needed and may result in improvement, maintenance, or

worsening of creatinine initially (but is still needed regardless)

 These patients are often diuretic resistant

slide-43
SLIDE 43

Diagnostic Criteria

slide-44
SLIDE 44

Cardio-Renal Syndrome

slide-45
SLIDE 45

Cardio-Renal Syndrome

slide-46
SLIDE 46

Cardio-Renal Syndrome

slide-47
SLIDE 47

Diuretic Resistance

 RAAS Activation  Low Albumin/Protein  Nephron Remodeling  Decreased GFR

slide-48
SLIDE 48

Differentials

 Pure Heart Failure  Pure AKI  MI/Cardiogenic Shock  ARDS  Sepsis/Pneumonia  PE  HRS

slide-49
SLIDE 49

Treatment/Management of Acute CRS

 Loop Diuretics 1st line  Augment with Thiazides (metolazone, chlorthalidone, HCTZ)  Ultrafiltration (HD/CRRT) if patient cannot make urine after diuretic

challenge

 Tolvaptan (when hyponatremic, infrequently used)  Vasodilators (i.e. isordil/hydralazine, nipride drip, avoid ACEi 2/2 AKI)  Inotropes (i.e. dobutamine, avoid milrinone 2/2 AKI)  Swan-Ganz (idk why we didn’t do this…)  CVP (at least we did this)  Echo

slide-50
SLIDE 50

Patient Update

 Patient appears to be doing OK per chart review  Has had several hospital admissions/ED visits since this past April for HF

, gout flare, and dehydration. He is living at home; family is bringing him to appointments.

 Is seeing Cardiology, Nephrology and Pulmonology

slide-51
SLIDE 51

References

Ellison, D. and Felker, M. (2018). Diuretic Treatment in Heart Failure. New England Journal of Medicine, 378(7), pp.683-685.

Rangaswami J, Bhalla V, Blair J E.A., Chang T I., Costa S, Lentine K L., Lerma E V., Mezue K, Molitch M, Mullens W, Ronco C, Tang W Wilson, McCullough, P A. Cardiorenal Syndrome: Classification, Pathophysiology, Diagnosis, and Treatment Strategies: A Scientific Statement From the American Heart Association. Circulation. March 2019;139:840-878. https://www.ahajournals.org/doi/10.1161/CIR.0000000000000664.

Ronco C, Cicoira M, McCullough PA. Cardiorenal Syndrome Type 1 Pathophysiological Crosstalk Leading to Combined Heart and Kidney Dysfunction in the Setting of Acutely Decompensated Heart

  • Failure. Journal of the American College of Cardiology. September 18, 2012;60(12):1031-1042.

http://www.onlinejacc.org/content/60/12/1031. Accessed November 11, 2019.

https://www.uptodate.com/contents/cardiorenal-syndrome-definition-prevalence-diagnosis-and- pathophysiology?search=cardiorenal%20syndrome&source=search_result&selectedTitle=1~16&usage_ type=default&display_rank=1

https://www.uptodate.com/contents/cardiorenal-syndrome-prognosis-and- treatment?search=cardiorenal%20syndrome&source=search_result&selectedTitle=2~16&usage_type= default&display_rank=2#H17931522

slide-52
SLIDE 52
