THUNDER BAY STORMWATER MASTER PLAN

PA C R E M E D I A L A C T I O N P L A N M E E T I N G - J a n . 7 2 0 1 5

Presented by Cecilio Olivier, MSc., PEng. - Emmons & Olivier Resources, Inc. (EOR)

THUNDER BAY STORMWATER MASTER PLAN

PA C R E M E D I A L A C T I O N P L A N M E E T I N G - J a n . 7 2 0 1 5

Directed by the City of Thunder Bay with support from the Government of Ontario & with the financial support of the Government of Canada through the federal Department of the Environment

Project Introduction

City of Thunder Bay committed to the development of a Stormwater Master Plan in:

• 2008
• City of Thunder

Bay EarthWise Community Action Plan

• 2011
• City of Thunder Bay

2011-2014 Strategic Plan 2014 - Thunder Bay SMP to be developed funded by Environment Canada with the help of Emmons & Olivier Resources, Inc. (EOR)

Project Consultant: profile

Emmons & Olivier Resources, Inc.

A collaborative group of environmental and design professionals passionate about protecting our waters, restoring healthy ecosystems, and enhancing our community's unique sense of place.

A water resource-based consulting & engineering firm specializing in:

• Water resources engineering,

watershed planning, and modeling

• environmental compliance, biological

surveying, and eco-restoration

• sustainable site design, planning,

and landscape architecture

Project Consultant: experience

Watershed Management:

Produced over 70 Watershed Management and Stormwater Management Plans for Cities, CAs, & WDs throughout North America.

Examples of Work in Ontario:

• Credit Valley Conservation Authority - Inspector’s

Guide to LID & Bioretention Protocols

• City of Thunder Bay - McVicar Creek Protection &

Rehabilitation Plan & Bioretention Design

• City of Nipigon – Outfalls Stabilization & Clear

Creek Management Plan

• Southeast Lake Huron - Rural Stormwater

Management Model

• Lake Simcoe Protection Strategies Plan

Stormwater Master Plan: Area

Thunder Bay’s watershed

Lake Superior

Stormwater Master Plan: elements

• physical conditions
• drainage boundaries
• natural features
• water quality rating
• map infrastructure

WATERSHED CHARACTERIZATION:

• issues identification
• evaluation of

existing infrastructure

• climate change

NEEDS ASSESSMENT:

• strategy for

stormwater mgmt.

• policy changes
• standards for design

and development

ESTABLISHING GOALS & POLICIES:

• retrofit opportunities
• ordinances & by-laws
• CIP and O&M
• monitoring
• education/outreach
• partnership/financing

PROGRAM IMPLEMENTATION:

1 2 3 4

Stormwater Master Plan: functions

WATERSHED CITY HOME

• facilitates protection &

restoration of natural watershed functions

• preserves ecological

quality and function

• protects surface water

/groundwater connections

• maximizes network
• f stakeholders
• facilitates maintenance of

stormwater infrastructure

• implements stormwater

regulations for new- and re-development

• provides stormwater

management assistance & education to community

• anticipates future needs &

builds system resiliency

• promotes runoff reduction

by e.g. harvesting rainwater

• improves water quality

by e.g. practicing healthier lawn care, picking up pet waste or using a car wash

• promotes stewardship ethic

resulting in healthier streams, rivers and lakes

Stormwater Master Plan: action items

20 Year Approach:

programs, policies and projects

programs:

• operations and maintenance
• combined sewer overflow
• conservation initiatives
• monitoring and analysis

policies:

• stormwater regulations
• design standards
• engineering and site plan review

process

Stormwater Master Plan: action items

projects: hard-to-soft range of options

typical pipe conveyance underground infiltration urban tree trenches typical culverts

• pen infiltration trenches

green roofs & raingardens

Traditional Stormwater Management

Collect Concentrate

Convey

Centralize

BMP Stormwater Management

Use Collect

Convey

Infiltrate

Project Timeline

Task Descriptions:

• 1. Review and Characterize the Study Area
• 2. Evaluate the Effectiveness of Existing Infrastructure
• 3. Identify New Stormwater Measures and Retrofit Opportunities
• 4. Identify Recommended Strategy for Stormwater Management
• 5. Identify Framework for a Stormwater Asset Management Plan
• 6. Develop Implementation Plan and Final SMMP Report
• 7. Consultation Plan & Ongoing Public Engagement

Summary of Work Performed to Date

Watershed Assessment

• Data collection from all sources
• Determination of Existing

Drainage

• Assessment of Water Quality &

Pollutant Sources

• Natural Resources and Land Use

Issues Identification Matrix

• Gathering of Issues/Concerns

through Public Engagement and Data Collection

• Development of Issues

Statements to Inform Action Items

Summary of Work Performed to Date

New SWM and Retrofit Opportunities

• Public Lands Retrofit Investigation
• Best Management Practices

Suitability

• Over 400 Opportunities Identified

Summary of Work Performed to Date

Hydrologic & Hydraulic Modeling

• Base Models of the 7 Watersheds
• NW Arterial Golf Links Feasibility-

Level Model (plus 2 more initiated)

IDF Curve Development

• Collected Latest Precipitation Data

from Environment Canada Airport Monitoring Station

• Developed new IDF curves based on

full record using statistical model R

Stakeholders/Participants:

• Project Steering Committee
• City Council
• First Nations
• Special Interest Groups
• Members of the Public
• City staff

Public Engagement: community

Options for Public Engagement:

• Project Website at

www.thunderbay.ca/stormwaterplan

• Community Postings at

Facebook.com/ thunderbaystormwaterplan

• Participation and

Public Awareness Survey

• Public Open House
• On-going stormwater management

programs implemented with the help of community groups and stakeholders

Public Engagement: outreach

Meetings & Community Engagement
