Thinking Beyond RDBMS : OPEN SHIFT Building Polyglot Persistence - - PowerPoint PPT Presentation

OPENSHIFT

Workshop

PRESENTED

BY

Shekhar Gulati

Thinking Beyond RDBMS : Building Polyglot Persistence Java Applications

WHO AM I?

• Shekhar Gulati -- OpenShift Developer Evangelist
• Java / JavaScript /Python / NoSQL / Cloud Guy
• Twitter Handle : shekhargulati
• Github https://github.com/shekhargulati
• Slides http://www.slideshare.net/shekhargulati

AGENDA

WHO ARE YOU?

There are no stupid questions only stupid

• answers. So ask questions

ASK QUESTIONS

http://nosql-database.org/ lists 150 databases

NOW WE HAVE CHOICES ...

• Widely used and understood
• Tested in real environments
• Efficient use of storage space if data normalized properly
• Great tools support
• ACID semantics
• Incredibly flexible and powerful query language
• Great framework support

WHY RDBMS?

• Complex object graphs does not map very well with flat

tables.

• Difficult to evolve Schema with time.
• Data constraints and JOINs can be expensive at runtime.
• Difficult to scale horizontally.

RDBMS LIMITATIONS

NoSQL Databases to rescue

• Schema-less
• Eventual consistent
• Scales writes and reads
• Easy to scale horizontally to add processing power and

storage

• Tries to solve few practical use-cases

NoSQL TO RESCUE

NoSQL CLASSIFICATION NOSQL CLASSIFICATION

Source http://www.slideshare.net/bscofield/nosql-codemash-2010

Using multiple data storage technologies, chosen based upon the way data is being used by individual applications or components of single application. Martin Fowler http://martinfowler.com/articles/nosql-intro.pdf

POLYGLOT PERSISTENCE

http://martinfowler.com/articles/nosql-intro.pdf HYPOTHETICAL EXAMPLE

GET MORE INFO AT

APPLICATION

http://localjobs-t20.rhcloud.com/

• MongoDB – Storing Jobs data
• PostgreSQL – Storing Users data
• Redis – Cache for Users
• Java 7

– Spring framework , Spring Social, Spring MongoDB,

Spring Security , Spring Redis , etc.

• OpenShift
• Git
• Twitter Bootstrap
• jQuery
• Searchify : Full-text Search as a Service

TECHNOLOGY CHOICES

• Document Oriented database

–

JSON-style documents

• Schema-less

–

Each document is heterogeneous, and may have completely unique structure compared to other documents.

• Fast and horizontally scalable
• Rich query language

MONGODB

Database → Database Table → Collection Row → Document Index → Index

MONGODB TERMINOLOGY MONGODB TERMINOLOGY

• Easy to get running
• Open Source
• Active community
• Rich documents
• Geospatial indexing
• Writes are very fast. You can customize it using

WriteConcern

WHY MONGODB?

RICH DOCUMENT

21

 What is it for?



Find all the MongoDB jobs near me – Proximity Queries



Find all the MongoDB jobs within Colombo – Bounded Queries



Find all the MongoDB job at this location – Exact Queries

• Supports only two dimensional indexes.

 You can only have one geospatial index per collection.  By default, 2d geospatial indexes assume longitude

and latitude have boundaries of -180 inclusive and 180 non-inclusive (i.e. [-180, 180))

GEOSPATIAL INDEXING BASICS

22

1) Put your coordinates into an array { loc : [ 50 , 30 ] } //SUGGESTED OPTION { loc : { x : 50 , y : 30 } } { loc : { foo : 50 , y : 30 } } 1) { loc : { lon : 40.739037, lat: 73.992964 } } 2) Make a 2d index db.places.ensureIndex( { loc : "2d" } ) 3) If you use latitude and longitude as your coordinate system, always store longitude first. MongoDB’s 2d spherical index

• perators only recognize [ longitude, latitude] ordering.

HOW TO MAKE IT WORK

OpenShift

is

PaaS by Red Hat

Multi-language, Auto-Scaling, Self-service, Elastic, Cloud Application Platform

• Supports MongoDB , PostgreSQL ,and MySQL
• Multi-language support. Supports Java, Node.js, Perl,

Python, PHP and Ruby

• Extensible via DIY and cartridges
• No need to learn anything new
• Open source – OpenShift Origin
• Scalable
• FREE!

WHY OPENSHIFT?

• rigin

Public Cloud Service On- premise

• r Private

Cloud Software Open Source Project FLAVORS OF OPENSHIFT

26

OUR STACK

27

Let's build the application

28

OPENSHIFT – GETTING STARTED

• Go to

https://openshift.redhat.com/app/account/new

Promo code is LINUXCON2013

• Create namespace
• Install rhc command line

utility

• Run rhc setup command

29

$ rhc create-app localjobs jbosseap mongodb-2.2 postgresql-9.2 -s $ rhc add-cartridge http://cartreflect-claytondev.rhcloud.com/reflect? github=smarterclayton/openshift-redis-cart --app localjobs $ rhc env set SPRING_PROFILES_ACTIVE=openshift Lot of other tasks you can do with rhc – tail log, app management, cartridge management , ssh management , namespace management, etc. Run rhc -h for details

DEMO : LOCALJOBS APP

30

$ git rm -rf src pom.xml $ git commit -am “delete template app” $ git remote add upstream -m master https://github.com/shekhargulati/localjobs- demo.git $ git pull -s recursive -X theirs upstream master

ITS All GIT

Source code https://github.com/shekhargulati/localjobs-demo

31

git push

32

Code Walkthrough

QUESTIONS?

DONE!
