Thermos Bottle Buildings Roy Swain, P.E. Lyme Inn Radiant Floor - - PowerPoint PPT Presentation

Sep 01, 2022 125 likes •666 views

Thermos Bottle Buildings Roy Swain, P.E. Lyme Inn Radiant Floor Thermos Bottle Building Design Heat Loss Thermos Bottle Building Design Heat Loss -10F outside, 70F Inside -10F outside, 70F Inside Building Element Heat

slide-1
SLIDE 1

Thermos Bottle Buildings

Roy Swain, P.E.

slide-2
SLIDE 2
slide-3
SLIDE 3
slide-4
SLIDE 4
slide-5
SLIDE 5
slide-6
SLIDE 6
slide-7
SLIDE 7

Lyme Inn

slide-8
SLIDE 8
slide-9
SLIDE 9
slide-10
SLIDE 10
slide-11
SLIDE 11
slide-12
SLIDE 12
slide-13
SLIDE 13
slide-14
SLIDE 14
slide-15
SLIDE 15
slide-16
SLIDE 16
slide-17
SLIDE 17

Radiant Floor

slide-18
SLIDE 18
slide-19
SLIDE 19
slide-20
SLIDE 20
slide-21
SLIDE 21
slide-22
SLIDE 22
slide-23
SLIDE 23
slide-24
SLIDE 24
slide-25
SLIDE 25

“Thermos Bottle” Building Design Heat Loss

  • 10°F outside, 70°F Inside

Building Element Heat Loss R-60 Roof 10% R-40 Walls (and Doors) 25% R-20 Basement/Foundation Walls 25% R-10 Basement Floor 5% R-5 Windows (10% of floor area) 35% Total 100% Approximate BTUH/ Sq. Ft. 5 For typical 150 Sq. Ft. Room: 750 BTUH (Hair Dryer on “Low”)

“Thermos Bottle” Building Design Heat Loss

  • 10°F outside, 70°F Inside

Note: Excludes infiltration/ventilation

slide-26
SLIDE 26

“Thermos Bottle” Building Design Internal Heat Gain Per Person 0-150 Sq. Ft./Person

Heat Source Btuh/Person Body Heat (Sensible) 250 Lights* 400 Plug Loads** 400 Total 1050

*0.75 Watts/Sq. Ft. x 150 Sq. Ft. x 3.412 Btuh/Watt (=384) ** Wilkins and Hosni, Plug Load Design Factors (ASHRAE Journal, May 2011, P. 30.

slide-27
SLIDE 27

Ventilation Air for One Person

15 cfm/ x 1.08 = 16 Btuh 300 Btuh net heat gain = ~20°F 16 Btuh/°F Therefore at -10°F outside air the 15 cfm of ventilation air needs to be at 55°F (!) to balance

  • ut the net heat gain assuming 75°F inside.

And assuming zero solar heat gain through the windows.

slide-28
SLIDE 28

Economizer Cooling

Per person, ignoring heat loss, at 150 Sq. Ft. / Person

Q = CFM x 1.08 x ΔT For 1050 Btuh/person heat gain:

  • For 20°F ΔT = 50 CFM

–

Or 1/3 CFM per Sq. Ft.

  • For 10°F ΔT = 100 CFM

–

Or 2/3 CFM per Sq. Ft.

  • For 5°F ΔT = 200 CFM

–

Or 1-1/3 CFM per Sq. Ft.

slide-29
SLIDE 29
slide-30
SLIDE 30
slide-31
SLIDE 31
slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34
slide-35
SLIDE 35
slide-36
SLIDE 36
slide-37
SLIDE 37
slide-38
SLIDE 38
slide-39
SLIDE 39
slide-40
SLIDE 40
slide-41
SLIDE 41
slide-42
SLIDE 42
slide-43
SLIDE 43
slide-44
SLIDE 44
slide-45
SLIDE 45
slide-46
SLIDE 46
slide-47
SLIDE 47
slide-48
SLIDE 48
slide-49
SLIDE 49
slide-50
SLIDE 50
slide-51
SLIDE 51
slide-52
SLIDE 52
slide-53
SLIDE 53
