Thermal Equipment Corporation Manufacturer of the Highest Quality Autoclave Systems THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS IT S WHAT WE DO TEC Over the Past 50 Years Pioneered all modern Autoclave Innovations

slide-1
SLIDE 1

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Thermal Equipment Corporation

Manufacturer of the Highest Quality Autoclave Systems

slide-2
SLIDE 2

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Over the Past 50 Years

  • Pioneered all modern Autoclave Innovations & Safety Concepts
  • Supplied more than 1,000 Autoclave Systems Worldwide
slide-3
SLIDE 3

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

The Beginning…

Founded in the 1950s as Fuel Engineering

slide-4
SLIDE 4

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Innovations of the 1950s

Laboratory Autoclave Extremely valuable in the development of new composite bonding materials and techniques due to its accurate control of both heating and cooling cycles.

slide-5
SLIDE 5

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Innovations of the 1960s

Control Consoles for Multiple Autoclaves Control systems developed using new technology and instrumentation to

  • ffer accurate control of Cooling, Heating, Pressure & Vacuum systems
slide-6
SLIDE 6

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Innovations of the 1970s

Large Autoclave Systems Largest autoclave systems in the industry built since the early years. (20 ft. Diameter Autoclave shown on photo)

slide-7
SLIDE 7

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC in the 1980s

TEC Expands & Acquires Baron Autoclaves in 1987

slide-8
SLIDE 8

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Innovations of the 1980s

Autoclave Computerized Control Systems (ACCS)

  • Introduction of computers. Hardware included IBM systems and 7-color dot matrix

printers.

  • Computerized control system that is both “user-friendly” and technically advanced.
  • Development of easy-to-follow software allowing customer to operate the system with

ease and still satisfy all quality control requirements.

slide-9
SLIDE 9

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Innovations of the 1980s

TEC 715-2000 Vacuum Valves

  • Vacuum valves system offering unparalleled Vacuum Control and Performance that

guarantees the compliance to the most stringent industry standards and requirements.

slide-10
SLIDE 10

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC in the 1990s

  • Advanced Microprocessor Controls
  • Dual Fuel Gas or Propane Fired Combustion Systems
slide-11
SLIDE 11

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Innovations of the 2000s

Innovative Circumferential Airflow Autoclave System

  • Development of new circumferential airflow system to meet extremely stringent

Heating, Cooling, and Uniformity requirements on Large 7M Diameter Autoclave system.

slide-12
SLIDE 12

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Innovations of the 2000s

First ever 30 foot Diameter Autoclave System in Production Worldwide

slide-13
SLIDE 13

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC in 2008

TEC expands and moves to its new “State of the Art” facility in Rancho Dominguez, California in 2008

slide-14
SLIDE 14

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Today…

Employing “State of the Art” Technology for the Design and Engineering of Autoclave Systems

Finite Element Analysis (FEA) Software Computational Fluid Dynamics (CFD) Software

Door Deformation Analysis for Reliability, Safety, and long-term cyclic life CFD Analysis to ensure Autoclave is designed to meet Heating, Cooling, and Uniformity requirements to customer satisfaction

slide-15
SLIDE 15

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Today…

  • TEC has built more Autoclave Systems than all other Autoclave

suppliers combined.

  • TEC is number one for Autoclaves larger than 13 feet Diameter.
slide-16
SLIDE 16

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Completed Systems: 30 feet Diameter x 70 feet Long Autoclave

slide-17
SLIDE 17

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Completed Systems: 23 feet Diameter x 120 feet Long Autoclave

slide-18
SLIDE 18

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Completed Systems: 23 feet Diameter x 120 feet Long Autoclave

slide-19
SLIDE 19

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Completed Systems: 20 feet Diameter x 50 feet Long Autoclave

slide-20
SLIDE 20

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Completed Systems: 20 feet Diameter x 70 feet Long Autoclave

slide-21
SLIDE 21

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Completed Systems: (3) Identical Systems 15 feet Diameter x 60 feet Long Autoclaves

slide-22
SLIDE 22

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Completed Systems: 12 feet Diameter x 33 feet Long Autoclave

slide-23
SLIDE 23

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Completed Systems: 22 feet Diameter x 80 feet Long Autoclave

slide-24
SLIDE 24

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC SHOP BUILT SUB-COMPONENTS

slide-25
SLIDE 25

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Shop Fabrication of Combustion Chamber For 30 foot Diameter Autoclave

COMBUSTION CHAMBER FINISHING WORK 4.4 m. 8.4 m. COMBUSTION CHAMBER READY FOR SHIPPING TO JOBSITE

slide-26
SLIDE 26

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Shop Fabrication of Cooling Coil for 30 foot Diameter Autoclave

COOLING COIL HYDROSTATIC PRESSURE TESTING COOLING COIL READY FOR SHIPPING TO JOBSITE 6.1 m. 5.2 m

slide-27
SLIDE 27

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Shop Fabrication of Heating Coil for 30 foot Diameter Autoclave

HEATING COIL FABRICATION HEATING COIL READY FOR SHIPMENT TO JOBSITE 3.7 m 5.2 m Dia. HEATING COIL & OTHER COMPONENTS SHIPMENT TO JOB SITE

slide-28
SLIDE 28

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Shop Fabrication of Miscellaneous Autoclave Components

MOTOR HOUSING WITH INTERNAL COOLING COIL (1) MOTOR HOUSING WITH INTERNAL COOLING COIL (2) COMBUSTION AND VENT EXHAUST DUCTS PROTECTION

slide-29
SLIDE 29

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Shop Fabrication of Miscellaneous Autoclave Components

COOLING FILTRATION SYSTEM VACUUM SYSTEM (READY TO CONNECT) AUTOCLAVE TRANSITION PIECE (TOP SECTION)

slide-30
SLIDE 30

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC FIELD SUPERVISION

slide-31
SLIDE 31

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC FIELD SUPERVISION

Unparalleled Field Supervision:

  • Efficient and optimized installation procedures

developed over the last 50 years

  • Procedures & Guidance ensure
  • Safety is number one priority
  • Regulatory measures & Codes are always met
  • Final Installed Autoclave system has No Flaws &

is built as intended per design

slide-32
SLIDE 32

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC FIELD SUPERVISION

TEC Field Supervision Services Include:

  • Schedule and deadlines are number key priority
  • Optimize installation supervision efficiency through broad

knowledge & experience

  • Minimize your labor costs
  • Reduce your installation space and materials costs
  • TEC does not use third-party supervisor
  • TEC support and direct communication with home office

from start to finish

slide-33
SLIDE 33

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Aerojet Government of Korea Pratt & Whitney Alliant TechSystems Government of Spain Raytheon Company American Airlines Government of Taiwan Sikorsky Aircraft Beech Aircraft Hercules, Inc. Singapore Aerospace Bell Helicopters Hexcel Corporation Spirit AeroSystems Boeing Company Hitco Carbon Composites Texas Instruments Bombardier Israeli Aircraft Industries Thiokol Brunswick Corp. Israeli Military Industries Turkish Aerospace Ciba-Geigy Korean Aerospace Industries United Technologies Dow Chemical Korean Airlines US Air Force DuPont Lockheed Martin Corp. US Army General Electric Mitsubishi Heavy Industries US Marines Goodrich Aerospace NASA US Navy Goodrich Industries Nordam Group Vought Government of Australia Northrop Grumman Westinghouse

Partial List of Our Major Customers

slide-34
SLIDE 34

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

  • Engineering - 15 Years
  • Management – 25 Years
  • Shop Fabrication Crew – 20+ Years
  • Field Crew – 18+ Years
  • Field/Service Technicians – 30 years
  • Administrative Support – 14 years

Experience

slide-35
SLIDE 35

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

TEC Works in Concert with the Customer to Ensure On Time Delivery as Follows:

  • Routine MPP Schedule updates including: Detailed Critical

Path Designation, Fabrication, & Installation Schedules

  • Project Acceptance, Buyoff, Training & As-Built Drawings Plan
  • Design/Fabrication Progress Meetings
  • Dedicated project manager available 24/7
  • Onsite supervision throughout the field installation until

project completion and customer acceptance

Project Management

slide-36
SLIDE 36

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Why Buy a TEC Autoclave?

  • TEC is the worldwide leader
  • Pioneered the modern Aerospace Autoclave System
  • Competition may imitate, but cannot duplicate a TEC Autoclave
  • TEC is here to stay
  • New Corporate Management committed to long term Customer satisfaction
  • Field Crews, Engineers and Service Technicians with vast experience and
  • n payroll
  • Ongoing investment in R&D (energy efficient Controls)
  • Proven long-term production quality systems with many in service
  • ver 30 years
  • Unparalleled & Superior Customer Support
  • TEC builds relationships with its customers for continued success
  • Specializes in Custom Autoclave Systems
  • All site work supervised directly by TEC personnel
  • TEC prides itself for developing its autoclave systems on Budget and on

Schedule

slide-37
SLIDE 37

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Sample Autoclave Layout

slide-38
SLIDE 38

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Sample Autoclave Front View

slide-39
SLIDE 39

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Sample Motor Housing

Designed to Reduce Maintenance Costs, such as with Motor Housing:

slide-40
SLIDE 40

THERMAL EQUIPMENT CORPORATION CUSTOM AUTOCLAVE SYSTEMS – “IT’S WHAT WE DO”

Thank you for your time and interest in Thermal Equipment Corporation (TEC). TEC looks forward to working closely with you for all of your important Autoclave projects with a desire to meet your requirements, needs and expectations. We believe our vast experience will ensure you will receive the best Autoclave money can

  • buy. We can provide a not only all of your new Autoclave equipment,

but complete Autoclave service, upgrades and spare parts. Being your Autoclave supplier is not just about selling you an Autoclave, but being your supplier Partner to help you keep your production equipment at its optimum performance for many, many years to come. Your success is our success and TEC wants to be there every step of the way. We take this role very seriously. No one else has more satisfied customers than TEC.
