Equipment and process systems Equipment and process systems for oil and gas industry for oil and gas industry td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE

Process facility for thermal disposal Process facility for thermal disposal of drilling waste of drilling waste ( (drilling mud drilling mud) ) Process stages I – Preparation and initial processing of drilling mud II – Feed of drilling mud into the line III – Preliminary drying of drilling mud IV – Grinding of material V – Kiln roasting of material Use of drilling mud after thermal treatment VI – Cool-down of material •At road constriction •Road enveloping VII – Flue gas treatment system •Slag blocks in low-rise construction •Sidewalk tiles VIII – Finished products warehouse •Curb stone •Binding mixes IX – Production management •Granulated filler in concretes td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE

Technical characteristics of the facility Technical characteristics of the facility Parameters STROM-ECO-10 STROM-ECO-20 Production capacity, processing*, t/h up to 10 up to 20 Receipt of processed raw materials*, t/h up to 5 up to 10 Fractional composition of initial raw materials, mm up to 50 up to 50 Moisture content in initial material, % up to 70 up to 70 Installed capacity*, kW up to 310 up to 430 Consumption of natural gas*, m 3 /h 1,840 2,880 Overall dimensions, without regard to mud 50×20×20 80×40×20 sumps, m (Length×Width×Height) Weight, t 75 125 *The facility characteristics shall be specified in each specific case on the basis of properties of the initial material and requirements for finished product td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE

STROM- -ECO ECO- -20 process facility 20 process facility STROM layout version layout version Depending upon the tasks determined by the customer and territorial conditions for placement of the production line, the complete set of delivery may vary, in particular, the length of transportation equipment shall be re-calculated. td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE

STROM- -Eco Eco- -MOBIL mobile process facility MOBIL mobile process facility STROM for thermal disposal of drilling mud for thermal disposal of drilling mud • The technology allows to use the mobile drilling mud processing module, both for cluster drilling and at drilling solitary prospecting, injection or operating wells. • The mobile facility for thermal treatment is designed for decontamination of solid drilling waste (drilling mud, drilling cuttings) accumulated and generating in the course of current operating activity of oil companies. •Thermal kiln roasting of drilling mud allows to change the class of hazard from Class 3 to Class 5. NEW TECHNOLOGY td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE

STROM- -Eco Eco- -MOBIL mobile process facility MOBIL mobile process facility STROM layout version layout version - Production capacity – 12,960 thousand tons a year, or up to 1.5 tons per hour - Total power consumption – up to 40 kW/h - Fuel being used – associated gas, natural gas or liquefied gas - Consumption of pipeline natural gas - 100 m 3 /h - Consumption of liquefied gas – 0.13 m 3 /h td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE

STROM- -Eco Eco- -MOBIL mobile process facility MOBIL mobile process facility STROM layout version layout version td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE

STROM- -Eco Eco- -MOBIL mobile process facility MOBIL mobile process facility STROM layout version layout version td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE

STROM- -Eco Eco- -MOBIL mobile process facility MOBIL mobile process facility STROM layout version layout version td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE

Possible product nomenclature after thermal treatment and grinding of drilling mud: At road construction, road enveloping Slag blocks in low-rise construction for enclosures and load-bearing structures Binding mixes, granulated filler in concretes Sidewalk tiles, curb stone td@strommash.ru www.strommash.ru ENGINEERING OF THE FUTURE
