SLIDE 1

Theory of Peer Data Management

Sebastian Skritek

Database and Artificial Intelligence Group Vienna University of Technology

DEIS 2010

S.Skritek – Theory of PDM 1/54

SLIDE 2

1.Motivation 1.1. Motivation

Motivation

From Data Integration to Peer Data Integration

DB1 DB2 DB3 G

S.Skritek – Theory of PDM 2/54

SLIDE 3

1.Motivation 1.1. Motivation

Motivation

From Data Integration to Peer Data Integration

DB1 DB2 DB3 G DB1 DB2 DB3

Extend semantics from data integration, BUT: query answering may become undecidable some tractable fragments are very restrictive further undesired properties ⇒ several suggestions made for semantics of mappings

S.Skritek – Theory of PDM 2/54

SLIDE 4

1.Motivation 1.1. Motivation

Motivation

⇒ use “tools” from data exchange and data integration (but they are not completely satisfactory) Additional problems (compared to DEI) Modularity of peers Inconsistencies, Updates Trust Peer Data Management covers a variety of scenarios ⇒ take a look on the theory behind some of these systems

(formal semantics, decidability, complexity, . . . )

S.Skritek – Theory of PDM 3/54

SLIDE 5

1.Motivation 1.1. Motivation

Talk Outline

1. Motivation
2. Query Answering in Peer Data Management
3. Materialization of Data in Peer Data Management
4. Optimization of Query Reformulation
5. Conclusion

S.Skritek – Theory of PDM 4/54

SLIDE 6

2.Query Answering in Peer Data Management 2.0.

Outline

1. Motivation
2. Query Answering in Peer Data Management

2.1 General Framework 2.2 PPL 2.3 An Epistemic Logic Approach

3. Materialization of Data in Peer Data Management
4. Optimization of Query Reformulation
5. Conclusion

S.Skritek – Theory of PDM 5/54

SLIDE 7

2.Query Answering in Peer Data Management 2.1. General Framework

A Framework for Peer Data Integration

P1 P2 P3 P4 P5 P6 P7 P8

Each peer P = (G, S, L, M) consists of

S.Skritek – Theory of PDM 6/54

SLIDE 8

2.Query Answering in Peer Data Management 2.1. General Framework

A Framework for Peer Data Integration

P1 P2 P3 P4 P5 P6 P7 P8 G1 G2 G3 G4 G5 G6 G7 G8

Each peer P = (G, S, L, M) consists of

a peer schema G

S.Skritek – Theory of PDM 6/54

SLIDE 9

2.Query Answering in Peer Data Management 2.1. General Framework

A Framework for Peer Data Integration

P1 P2 P3 P4 P5 P6 P7 P8 S1 G1 S2 G2 S3 G3 S4 G4 S5 G5 G6 G7 G8

Each peer P = (G, S, L, M) consists of

a peer schema G
a (possible empty) local/source schema S

S.Skritek – Theory of PDM 6/54

SLIDE 10

2.Query Answering in Peer Data Management 2.1. General Framework

A Framework for Peer Data Integration

P1 P2 P3 P4 P5 P6 P7 P8 S1 G1 S2 G2 S3 G3 S4 G4 S5 G5 G6 G7 G8

Each peer P = (G, S, L, M) consists of

a peer schema G
a (possible empty) local/source schema S
a (possible empty) set of local mappings L: {cqS cqG}

S.Skritek – Theory of PDM 6/54

SLIDE 11

2.Query Answering in Peer Data Management 2.1. General Framework

A Framework for Peer Data Integration

P1 P2 P3 P4 P5 P6 P7 P8 S1 G1 S2 G2 S3 G3 S4 G4 S5 G5 G6 G7 G8

Each peer P = (G, S, L, M) consists of

a peer schema G
a (possible empty) local/source schema S
a (possible empty) set of local mappings L: {cqS cqG}
a set of peer mappings M: {cqP′ cqP}

S.Skritek – Theory of PDM 6/54

SLIDE 12

2.Query Answering in Peer Data Management 2.1. General Framework

A Framework for Peer Data Integration

P1 P2 P3 P4 P5 P6 P7 P8 S1 G1 S2 G2 S3 G3 S4 G4 S5 G5 G6 G7 G8 q1 q2

Each peer P = (G, S, L, M) consists of

a peer schema G
a (possible empty) local/source schema S
a (possible empty) set of local mappings L: {cqS cqG}
a set of peer mappings M: {cqP′ cqP}

Queries q are posed over peer schema of a single peer

data remains in sources, queries (and results) are propagated

S.Skritek – Theory of PDM 6/54

SLIDE 13

2.Query Answering in Peer Data Management 2.2. PPL

PPL (Peer Programming Language)

[Halevy et al., VLDB J. 2005] P S G L M P = (G, S, L, M)

Definition

Local Mappings L:

P : r ⊆ cq (P : r = cq)

Peer Mappings M:

cq′

P′ ⊆ cqP (cq′ P′ = cqP)

inclusion/equality mappings

rP(

x) :- cqP′( x) definitional mappings

G, S:

relational schemas

(Note: mappings only between pairs of peers)

S.Skritek – Theory of PDM 7/54

SLIDE 14

2.Query Answering in Peer Data Management 2.2. PPL

PPL: Semantics

Definition (consistent data instance)

Let N be a PDMS, D an instance for S. Instance I for G is consistent with N and D if for every m ∈ L

r D ⊆ cqI

(resp. r D = cqI)

for every m ∈ M either

cq′I

P′ ⊆ cqI P

(resp. cq′I

P′ = cqI P)

r
r(

x)I = body(m1)I ∪ · · · ∪ body(mn)I where r = head(m), and {m ∈ M | head(m) = r} = {m1, . . . , mn}

certain answers to query q( x): tuples t s.t. t ∈ q( x)I for every consistent instance I

S.Skritek – Theory of PDM 8/54

SLIDE 15

2.Query Answering in Peer Data Management 2.2. PPL

PPL: First Order Interpretation

PDMS P = {P1, . . . , Pn}

(consider only inclusion storage descriptions)

→ Define semantics in terms of FO logic: ∀ x

r(

x) → ∃ zψG( x, z)

(for each m ∈ Li)

∀ x

∃

y(φPi( x, y)) → ∃ zψPj( x, z)

(for each m ∈ M)

allow only restricted inclusion peer mappings,
use disjunctive TGDs for definitional mappings

⇒ certain answers w.r.t. D: answer in every model I of P FO theory TPi for Pi, TP =

Pi∈P TPi for P

Models for theories (given instances Di for Si):

Model of TPi (TP) based on Di (D =

i Di):

interpretation I of TPi (TP) s.t. sI = sDi (for each s ∈ Si)

Model of P based on D:

model of TP based on D and of mappings M

S.Skritek – Theory of PDM 9/54

SLIDE 16

2.Query Answering in Peer Data Management 2.2. PPL

PPL: Complexity

Theorem (Halevy et al., 2005)

Let N be a PDMS specified in PPL

1 Finding all certain answers to CQ q is undecidable 2 If N contains only inclusion peer and storage descriptions and

the peer mappings are acyclic ⇒ CQ answering in polynomial time (data complexity)

Proof (sketch).

(2) Encode query and mappings in a nonrecursive datalog program with Skolem terms ⇒ evaluation PTIME (data complexity).

S.Skritek – Theory of PDM 10/54

SLIDE 17

2.Query Answering in Peer Data Management 2.2. PPL

PPL: Complexity (contd.)

Finding all certain answers to a CQ q is undecidable

Proof (sketch).

(1) Shown by reduction from implication problem for FDs and IDs: Given R, Σ, ϕ = Ri[A] ⊆ Rj[B] ⇒ N = {P1}, with P1 = ( R, {S/1}, {S ⊆ Ri[A]}, M), and M: for FD Ri : A → B: {( A, B1, B2) | Ri( A, B1), Ri( A, B2)} ⊆ {( A, B, B) | Ri( A, B)} for ID Ri[ A] ⊆ Rj[ B]: Ri[ A] ⊆ Rj[ B] Then let I = {S(a)}, and q : {Rj[B]}. It holds that Σ | = ϕ iff q returns a.

S.Skritek – Theory of PDM 11/54

SLIDE 18

2.Query Answering in Peer Data Management 2.2. PPL

PPL: Complexity (contd.)

Consider the following restrictions:

1 equality storage or peer mappings do not contain projection 2 peer relations that appear in the head of a definitional

mapping do not appear on the rhs of any other mapping

Theorem (Halevy et al., VLDB J. 2005)

All inclusion peer mappings acyclic, but equality peer mappings ⇒ CQ answering is (data complexity) If (1) and (2) ⇒ in PTIME If (1) but not (2) ⇒ coNP complete If (2) but not (1) ⇒ coNP complete

S.Skritek – Theory of PDM 12/54

SLIDE 19

2.Query Answering in Peer Data Management 2.2. PPL

PPL: Query Answering

Consider again the mappings: Peer Mappings M:

cq′

P′ = cqP ⇒ cq′ P′ ⊆ cqP and cqP ⊆ cq′ P′

cq′

P′ ⊆ cqP ⇒ v(

x) ⊆ cqP and v( x) :- cq′

P′

rP(

x) :- cqP′( x)

⇒ pure LAV and GAV mappings

S.Skritek – Theory of PDM 13/54

SLIDE 20

2.Query Answering in Peer Data Management 2.2. PPL

PPL: Query Answering

Consider again the mappings: Peer Mappings M:

cq′

P′ = cqP ⇒ cq′ P′ ⊆ cqP and cqP ⊆ cq′ P′

cq′

P′ ⊆ cqP ⇒ v(

x) ⊆ cqP and v( x) :- cq′

P′

rP(

x) :- cqP′( x)

⇒ pure LAV and GAV mappings combine methods for answering queries in these settings:

unfolding
algorithms for answering queries using views

build a rule/goal tree derive UCQ over S from it ⇒ sound, and for polynomial cases also complete

S.Skritek – Theory of PDM 13/54

SLIDE 21

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Query Answering: First Order Reasoning

query answering: FO reasoning over P Citizen(P) Male(P) Female(P) TaxPayer(P) m1 m2 m3 m4

C(,) Female(alice) Male(alice) TaxPayer(alice)

m1 : Citizen(x) :- Male(x) m2 : Citizen(x) :- Female(x) m3 : Male(x) ⊆ TaxPayer(x) m4 : Female(x) ⊆ TaxPayer(x) m1, m2 : Citizen(x) → Male(x) ∨ Female(x) m3 : Male(x) → TaxPayer(x) m4 : Female(x) → TaxPayer(x)

S.Skritek – Theory of PDM 14/54

SLIDE 22

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Query Answering: First Order Reasoning

query answering: FO reasoning over P Citizen(P) Male(P) Female(P) TaxPayer(P) m1 m2 m3 m4

C(,) Citizen(alice) Female(alice) Male(alice) TaxPayer(alice)

m1 : Citizen(x) :- Male(x) m2 : Citizen(x) :- Female(x) m3 : Male(x) ⊆ TaxPayer(x) m4 : Female(x) ⊆ TaxPayer(x) m1, m2 : Citizen(x) → Male(x) ∨ Female(x) m3 : Male(x) → TaxPayer(x) m4 : Female(x) → TaxPayer(x)

Example

Consider Query {x | TaxPayer(x)}

S.Skritek – Theory of PDM 14/54

SLIDE 23

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Query Answering: First Order Reasoning

query answering: FO reasoning over P Citizen(P) Male(P) Female(P) TaxPayer(P) m1 m2 m3 m4

C(,) Citizen(alice) Female(alice) Female(alice) Male(alice) TaxPayer(alice) TaxPayer(alice)

m1 : Citizen(x) :- Male(x) m2 : Citizen(x) :- Female(x) m3 : Male(x) ⊆ TaxPayer(x) m4 : Female(x) ⊆ TaxPayer(x) m1, m2 : Citizen(x) → Male(x) ∨ Female(x) m3 : Male(x) → TaxPayer(x) m4 : Female(x) → TaxPayer(x)

Example

Consider Query {x | TaxPayer(x)}

S.Skritek – Theory of PDM 14/54

SLIDE 24

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Query Answering: First Order Reasoning

query answering: FO reasoning over P Citizen(P) Male(P) Female(P) TaxPayer(P) m1 m2 m3 m4

C(,) Citizen(alice) Female(alice) Male(alice) Male(alice) TaxPayer(alice) TaxPayer(alice)

m1 : Citizen(x) :- Male(x) m2 : Citizen(x) :- Female(x) m3 : Male(x) ⊆ TaxPayer(x) m4 : Female(x) ⊆ TaxPayer(x) m1, m2 : Citizen(x) → Male(x) ∨ Female(x) m3 : Male(x) → TaxPayer(x) m4 : Female(x) → TaxPayer(x)

Example

Consider Query {x | TaxPayer(x)}

S.Skritek – Theory of PDM 14/54

SLIDE 25

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Query Answering: First Order Reasoning

query answering: FO reasoning over P Citizen(P) Male(P) Female(P) TaxPayer(P) m1 m2 m3 m4

C(,) Citizen(alice) Female(alice) Male(alice) Female(alice) Male(alice) TaxPayer(alice) TaxPayer(alice)

m1 : Citizen(x) :- Male(x) m2 : Citizen(x) :- Female(x) m3 : Male(x) ⊆ TaxPayer(x) m4 : Female(x) ⊆ TaxPayer(x) m1, m2 : Citizen(x) → Male(x) ∨ Female(x) m3 : Male(x) → TaxPayer(x) m4 : Female(x) → TaxPayer(x)

Example

Consider Query {x | TaxPayer(x)}

S.Skritek – Theory of PDM 14/54

SLIDE 26

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Epistemic Logic

A modal logic used for modeling knowledge, certainty Modal logic is used e.g. in multi agent systems More precisely: KT45 (or S5)

S.Skritek – Theory of PDM 15/54

SLIDE 27

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Epistemic Logic

A modal logic used for modeling knowledge, certainty Modal logic is used e.g. in multi agent systems More precisely: KT45 (or S5)

I1 I2 I3 I4

Syntax: FOL, but also Kφ is an atom (if φ is a formula) Semantics:

Often defined using Kripke structures (W , R, V )
Here: every world is accessible from every world
epistemic interpretation ε = (I, W )

W . . . set of FO interpretations, I ∈ W

a( x) satisfied in ε: by t s.t. a( t) is true in I Kφ( x) satisfied in ε: by t s.t. φ( t) is satisfied in all ε′ = (J, W ) with J ∈ W epistemic model: φ is satisfied in every (J, W ) (J ∈ W )

S.Skritek – Theory of PDM 15/54

SLIDE 28

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Modeling PDM [Calvanese et al., 2004]

P1 P2 P3 P4 P5 P6 P7 P8 S1 G1 S2 G2 S3 G3 S4 G4 S5 G5 G6 G7 G8 q1 q2

Peer schema: G may contain function free FO formulas over AG

S.Skritek – Theory of PDM 16/54

SLIDE 29

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Modeling PDM [Calvanese et al., 2004]

P1 P2 P3 P4 P5 P6 P7 P8 S1 G1 S2 G2 S3 G3 S4 G4 S5 G5 G6 G7 G8 q1 q2

Peer schema: G may contain function free FO formulas over AG Epistemic Theory: TP:

formulas in G
∀

x

∃

y(φS( x, y)) → ∃ zψG( x, z)

(for each m ∈ L)

MP:

axioms ∀

x

K(∃

yφ( x, y)) → ∃ zψ( x, z)

(for each m ∈ M)

S.Skritek – Theory of PDM 16/54

SLIDE 30

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Modeling PDM [Calvanese et al., 2004]

P1 P2 P3 P4 P5 P6 P7 P8 S1 G1 S2 G2 S3 G3 S4 G4 S5 G5 G6 G7 G8 q1 q2

Peer schema: G may contain function free FO formulas over AG Epistemic Theory: TP:

formulas in G
∀

x

∃

y(φS( x, y)) → ∃ zψG( x, z)

(for each m ∈ L)

MP:

axioms ∀

x

K(∃

yφ( x, y)) → ∃ zψ( x, z)

(for each m ∈ M)

Semantics: Recall: FOL model of TP based on D Epistemic model of P based on D: (I, W )

W : set of models of TP based on D
(I, W ): epistemic model of MP

Certain answers w.r.t. D: qI for all epistemic models (I, W )

S.Skritek – Theory of PDM 16/54

SLIDE 31

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Properties of Epistemic Logic Based Semantics

(denote certain answers w.r.t. source instance D as ans(q, P, D)) sound approximation of FOL: ansK(q, P, D) ⊆ ansfol(q, P, D) Unique Maximal Epistemic Model for P (I, W ) s.t. there exists no model (J, W ′) with W ⊂ W ′

Unique, Independent of I

⇒ ansK(q, P, D) = { t | t ∈ qI for each I ∈ W }

S.Skritek – Theory of PDM 17/54

SLIDE 32

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Properties of Epistemic Logic Based Semantics

(denote certain answers w.r.t. source instance D as ans(q, P, D)) sound approximation of FOL: ansK(q, P, D) ⊆ ansfol(q, P, D) Unique Maximal Epistemic Model for P (I, W ) s.t. there exists no model (J, W ′) with W ⊂ W ′

Unique, Independent of I

⇒ ansK(q, P, D) = { t | t ∈ qI for each I ∈ W } FOE(P, D): minimal FO theory containing TP, D, and

for each cq′ cq, if FOE(P, D) |

= ∃ ybody cq′( t, y), then ∃ zbody cq( t, z) ∈ FOE(P, D)

Theorem (Calvanese et al., 2004)

The set of interpretations {I | I | = FOE(P, D)} is the unique maximal epistemic model W for P based on D.

S.Skritek – Theory of PDM 17/54

SLIDE 33

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Intuition: Only exchange certain answers

Definition (τ(P))

Given Pi = (G, S, L, M), define τ(Pi) = (G, S′, L′, M) where

1 S′ = S ∪ {r | cq′ cq ∈ M} 2 L′ = L ∪

{

x | r( x)} cq | cq′ cq ∈ M

G

S

cq′

1 cq1

cq′

2 cq2 S.Skritek – Theory of PDM 18/54

SLIDE 34

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Intuition: Only exchange certain answers

Definition (τ(P))

Given Pi = (G, S, L, M), define τ(Pi) = (G, S′, L′, M) where

1 S′ = S ∪ {r | cq′ cq ∈ M} 2 L′ = L ∪

{

x | r( x)} cq | cq′ cq ∈ M

G

S

cq′

1 cq1

cq′

2 cq2

r1 r2 r1 → cq1 r2 → cq2

S.Skritek – Theory of PDM 18/54

SLIDE 35

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Intuition: Only exchange certain answers (contd.)

G S

cq′

1 cq1

cq′

2 cq2

r1 r2 r1 → cq1 r2 → cq2

D q G S

cq′

1 cq1

cq′

2 cq2

r1 r2 r1 → cq1 r2 → cq2

D q

Given P, Pi = (G, S, L, M), D and query q over G: Let ¯ D be source instance for τ(Pi) s.t.

S ¯

D = SD and r ¯ D = ans(cq′, P, D)

We want ans(q, P, D) = ans(q, τ(P), ¯ D) provides: modularity and independence

S.Skritek – Theory of PDM 19/54

SLIDE 36

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Intuition: Only exchange certain answers (contd.)

Recall intuition: ans(q, P, D) = ans(q, τ(P), ¯ D) for cq′ cq ∈ M:

r ∈ S′, {

x | r( x)} cq ∈ L′

r ¯

D = ans(cq′, P, D)

S.Skritek – Theory of PDM 20/54

SLIDE 37

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Intuition: Only exchange certain answers (contd.)

Recall intuition: ans(q, P, D) = ans(q, τ(P), ¯ D) for cq′ cq ∈ M:

r ∈ S′, {

x | r( x)} cq ∈ L′

r ¯

D = ans(cq′, P, D)

Further recall: ansK(cq′, P, D) = { t | t ∈ cq′I for each I ∈ W }

for W : maximal epistemic model

axiom ∀ x

K(∃

ybodycq′( x, y)) → ∃ zbodycq( x, z)

S.Skritek – Theory of PDM

20/54

SLIDE 38

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Intuition: Only exchange certain answers (contd.)

Recall intuition: ans(q, P, D) = ans(q, τ(P), ¯ D) for cq′ cq ∈ M:

r ∈ S′, {

x | r( x)} cq ∈ L′

r ¯

D = ans(cq′, P, D)

Further recall: ansK(cq′, P, D) = { t | t ∈ cq′I for each I ∈ W }

for W : maximal epistemic model

axiom ∀ x

K(∃

ybodycq′( x, y)) → ∃ zbodycq( x, z)

Hence (informal)

ansK(cq′, P, D) = { t | for each I ∈ W : ∃ y: bodycq′( t, y) ∈ I} K(∃ ybodycq′( x, y)) satisfied by tuples { t | in each I ∈ W : ∃ y : bodycq′( t, y) ∈ I} ⇒ P “imports” the same tuples

S.Skritek – Theory of PDM 20/54

SLIDE 39

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Query Answering

use this idea for query answering ⇒ always consider τ(P)

perfect reformulation

Given query q over Gi ⇒ query q1 over S′

i s.t. for every instance

D1 for τ(P), qD1

1

= ans(q, τ(P), D1)

(assume settings where perfect reformulation always exists)

S.Skritek – Theory of PDM 21/54

SLIDE 40

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Query Answering

use this idea for query answering ⇒ always consider τ(P)

perfect reformulation

Given query q over Gi ⇒ query q1 over S′

i s.t. for every instance

D1 for τ(P), qD1

1

= ans(q, τ(P), D1)

(assume settings where perfect reformulation always exists)

Idea of the Algorithm Compute a datalog program DP, containing

facts from S
rules encoding perfect reformulations to S′

S.Skritek – Theory of PDM 21/54

SLIDE 41

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Query Answering

use this idea for query answering ⇒ always consider τ(P)

perfect reformulation

Given query q over Gi ⇒ query q1 over S′

i s.t. for every instance

D1 for τ(P), qD1

1

= ans(q, τ(P), D1)

(assume settings where perfect reformulation always exists)

Idea of the Algorithm Compute a datalog program DP, containing

facts from S
rules encoding perfect reformulations to S′

Theorem (Calvanese et al., 2004)

1 Eval(headq, DP) computes ansK(q, P, D) 2 Given P, q,

t, deciding t ∈ ansK(q, P, D) is PTIME-complete (data complexity)

S.Skritek – Theory of PDM 21/54

SLIDE 42

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Query Answering: Algorithm

query answering algorithm

at Pi: peerQueryHandler(q,rq) (1) DPI = computePerfectRef(q,rq,Pi); DPE = ∅ (2) for each r ∈ S′

i ∩ DPI:

(3) if r ∈ S (∗)

(3a) DPE = DPE ∪ {r( t) | r( t) ∈ D}

else (r ∈ S′ \ S)

(3b) DP′ = P′.peerQueryHandler(Q(r),r) DPI = DPI ∪ DP′

I ; DPE = DPE ∪ DP′ E

(4) return DP

(∗) loop detection omitted

G S

cq′

1 cq1

cq′

2 cq2

r1 r2 r1 → cq1 r2 → cq2

D q

S.Skritek – Theory of PDM 22/54

SLIDE 43

2.Query Answering in Peer Data Management 2.3. An Epistemic Logic Approach

Further nice properties

Decidability depends only on local properties under FOL: also constraints may be propagated by mappings Epistemic Logic: provides complete modularity for peers Mapping Composition Semantics allows for (reasonable) mapping composition Resulting systems are query equivalent Inconsistency Handling Consider two kinds of inconsistency:

local inconsistency, P2P inconsistency

Use nonmonotonic extension (K45A

n ), model cqi cqj:

∀

x

¬Ai⊥i ∧ Ki(∃

ybody cqi( x, y)) ∧ ¬Aj(¬∃ zbody cqj( x, z)) → Kj(∃ zbody cqj( x, z))

S.Skritek – Theory of PDM

23/54

SLIDE 44

3.Materialization of Data in Peer Data Management 3.0.

Outline

1. Motivation
2. Query Answering in Peer Data Management
3. Materialization of Data in Peer Data Management

3.1 Reconciling PDM and Data Exchange 3.2 Active XML 3.3 Orchestra

4. Optimization of Query Reformulation
5. Conclusion

S.Skritek – Theory of PDM 24/54

SLIDE 45

3.Materialization of Data in Peer Data Management 3.1. Reconciling PDM and Data Exchange

Idea

So far: Peer Data Integration data remains local at peers information needed for query answering are exchanged mappings can be considered as “virtual” Other possibility: Generalize Data Exchange copy data between different peers interpret mappings as constraints materialize data to satisfy these constraints → Look onto some approaches following this idea

S.Skritek – Theory of PDM 25/54

SLIDE 46

3.Materialization of Data in Peer Data Management 3.1. Reconciling PDM and Data Exchange

Reconciling Data Exchange and PDM

[De Giacomo et al., PODS 2007]

Si Gi

S.Skritek – Theory of PDM 26/54

SLIDE 47

3.Materialization of Data in Peer Data Management 3.1. Reconciling PDM and Data Exchange

Reconciling Data Exchange and PDM

[De Giacomo et al., PODS 2007]

P1

S.Skritek – Theory of PDM 26/54

SLIDE 48

3.Materialization of Data in Peer Data Management 3.1. Reconciling PDM and Data Exchange

Reconciling Data Exchange and PDM

[De Giacomo et al., PODS 2007]

P1 P2 P3 P4 P5 S = P, ,

S.Skritek – Theory of PDM

26/54

SLIDE 49

3.Materialization of Data in Peer Data Management 3.1. Reconciling PDM and Data Exchange

Reconciling Data Exchange and PDM

[De Giacomo et al., PODS 2007]

P1 P2 P3 P4 P5 S = P, , ME ME: TGDs between pairs

f peers

S.Skritek – Theory of PDM 26/54

SLIDE 50

3.Materialization of Data in Peer Data Management 3.1. Reconciling PDM and Data Exchange

Reconciling Data Exchange and PDM

[De Giacomo et al., PODS 2007]

P1 P2 P3 P4 P5 S = P, CE, ME ME: TGDs between pairs

f peers

CE: TGDs & EGDs over single peer

S.Skritek – Theory of PDM 26/54

SLIDE 51

3.Materialization of Data in Peer Data Management 3.1. Reconciling PDM and Data Exchange

Reconciling Data Exchange and PDM

[De Giacomo et al., PODS 2007]

P1 P2 P3 P4 P5 S = P, CE, ME ME: TGDs between pairs

f peers

CE: TGDs & EGDs over single peer Semantics: CE: FO semantics ME: exchanges only certain answers Universal S-solution

S.Skritek – Theory of PDM 26/54

SLIDE 52

3.Materialization of Data in Peer Data Management 3.1. Reconciling PDM and Data Exchange

Reconciling Data Exchange and PDM

[De Giacomo et al., PODS 2007]

P1 P2 P3 P4 P5 S = P, CE, ME, CI, MI ME, MI: TGDs between pairs of peers CE, CI: TGDs & EGDs over single peer

S.Skritek – Theory of PDM 26/54

SLIDE 53

3.Materialization of Data in Peer Data Management 3.1. Reconciling PDM and Data Exchange

Reconciling Data Exchange and PDM

[De Giacomo et al., PODS 2007]

P1 P2 P3 P4 P5 S = P, CE, ME, CI, MI ME, MI: TGDs between pairs of peers CE, CI: TGDs & EGDs over single peer Semantics: CE, CI: FO semantics ME, MI: certain answers CI, MI precedence Universal S-solution

S.Skritek – Theory of PDM 26/54

SLIDE 54

3.Materialization of Data in Peer Data Management 3.2. Active XML

Active XML

S.Skritek – Theory of PDM 27/54

SLIDE 55

3.Materialization of Data in Peer Data Management 3.2. Active XML

Active XML

Recall: Active XML

xml x x x

Not considered yet Formal semantics

service call
query answering

Complexity [Abiteboul et al., PODS 2004] → consider only monotone Web Services

S.Skritek – Theory of PDM 28/54

SLIDE 56

3.Materialization of Data in Peer Data Management 3.2. Active XML

AXML Document

Definition (AXML document)

AXML document: pair (T, λ) where T = (N, E): finite, unordered tree

N ⊂ N: finite set of nodes
E ⊂ N × N: directed edges

λ: N → L ∪ F ∪ V: function s.t.

λ(n) ∈ V only if n is a leaf node
for root n, λ(n) ∈ V ∪ L

D: document names, N: nodes, L: labels, V: atomic values, F: function names

S.Skritek – Theory of PDM 29/54

SLIDE 57

3.Materialization of Data in Peer Data Management 3.2. Active XML

AXML Document

data nodes, function nodes

Definition (AXML document)

AXML document: pair (T, λ) where T = (N, E): finite, unordered tree

N ⊂ N: finite set of nodes
E ⊂ N × N: directed edges

λ: N → L ∪ F ∪ V: function s.t.

λ(n) ∈ V only if n is a leaf node
for root n, λ(n) ∈ V ∪ L

D: document names, N: nodes, L: labels, V: atomic values, F: function names

S.Skritek – Theory of PDM 29/54

SLIDE 58

3.Materialization of Data in Peer Data Management 3.2. Active XML

AXML Document

data nodes, function nodes

Definition (AXML document)

AXML document: pair (T, λ) where T = (N, E): finite, unordered tree

N ⊂ N: finite set of nodes
E ⊂ N × N: directed edges

λ: N → L ∪ F ∪ V: function s.t.

λ(n) ∈ V only if n is a leaf node
for root n, λ(n) ∈ V ∪ L

D: document names, N: nodes, L: labels, V: atomic values, F: function names

function call: pass subtree as parameter; get forest as return value ⇒ append as siblings to call node

S.Skritek – Theory of PDM 29/54

SLIDE 59

3.Materialization of Data in Peer Data Management 3.2. Active XML

Reduced Documents

Definition

(T1, λ1) is subsumed by (T2, λ2) ((T1, λ1) ⊆ (T2, λ2)) if there exists mapping h: N1 → N2 s.t:

h(root(T1)) = root(T2)
n1 child of n2 ⇒ h(n1) child of h(n2) (for all n1, n2 ∈ N1)
λ1(n) = λ2(h(n)) (for all n ∈ N1)

d1 ⊆ d2 and d2 ⊆ d1 ⇒ d1 ≡ d2 → Document d is reduced if for no subtree d′ of d, d ≡ d′

S.Skritek – Theory of PDM 30/54

SLIDE 60

3.Materialization of Data in Peer Data Management 3.2. Active XML

Reduced Documents

Definition

(T1, λ1) is subsumed by (T2, λ2) ((T1, λ1) ⊆ (T2, λ2)) if there exists mapping h: N1 → N2 s.t:

h(root(T1)) = root(T2)
n1 child of n2 ⇒ h(n1) child of h(n2) (for all n1, n2 ∈ N1)
λ1(n) = λ2(h(n)) (for all n ∈ N1)

d1 ⊆ d2 and d2 ⊆ d1 ⇒ d1 ≡ d2 → Document d is reduced if for no subtree d′ of d, d ≡ d′ Properties:

Each document has a unique reduced version
Decision and Function problem solvable in PTIME

S.Skritek – Theory of PDM 30/54

SLIDE 61

3.Materialization of Data in Peer Data Management 3.2. Active XML

Monotone AXML Systems

Definition (monotone AXML system)

monotone AXML system: S = (D, F, I)

finite sets D ⊂ D , F ⊂ F
mapping I: for d ∈ D, I(d) returns a document,

for f ∈ F, I(f ) returns a monotone service

S.Skritek – Theory of PDM 31/54

SLIDE 62

3.Materialization of Data in Peer Data Management 3.2. Active XML

Monotone AXML Systems

Definition (monotone AXML system)

monotone AXML system: S = (D, F, I)

finite sets D ⊂ D , F ⊂ F
mapping I: for d ∈ D, I(d) returns a document,

for f ∈ F, I(f ) returns a monotone service

(web) service s

defined w.r.t. set {d1, . . . , dn} of document names
given assignment θ of AXML documents to {d1, . . . , dn},

return forest of AXML documents

consider s as black box

monotone service

for all θ, θ′: for all i: θ(di) ⊆ θ′(di) ⇒ s(θ) ⊆ s(θ′)

S.Skritek – Theory of PDM 31/54

SLIDE 63

3.Materialization of Data in Peer Data Management 3.2. Active XML

Invocations of Services

Service invocation

given S, d ∈ D, v ∈ I(d), λ(v) = f
invoking f : call I(f ) on θ: θ(di) = I(di), θ(input), θ(context)
append I(f )(θ) to parent of v, normalize afterward

S.Skritek – Theory of PDM 32/54

SLIDE 64

3.Materialization of Data in Peer Data Management 3.2. Active XML

Invocations of Services

Service invocation

given S, d ∈ D, v ∈ I(d), λ(v) = f
invoking f : call I(f ) on θ: θ(di) = I(di), θ(input), θ(context)
append I(f )(θ) to parent of v, normalize afterward

Sequences of Invocations

S

v

− → S′: S′ ≡ S; S′ obtained from S by invoking function at node v

rewriting (possible infinite): S

v1

− → S1

v2

− → S2 → . . .

vn

− → Sn . . . (S

∗

− → Sn)

system terminates in Sn: no vn+1, Sn+1 s.t. Sn

vn+1

− − → Sn+1

S.Skritek – Theory of PDM 32/54

SLIDE 65

3.Materialization of Data in Peer Data Management 3.2. Active XML

Invocations of Services

Service invocation

given S, d ∈ D, v ∈ I(d), λ(v) = f
invoking f : call I(f ) on θ: θ(di) = I(di), θ(input), θ(context)
append I(f )(θ) to parent of v, normalize afterward

Sequences of Invocations

S

v

− → S′: S′ ≡ S; S′ obtained from S by invoking function at node v

rewriting (possible infinite): S

v1

− → S1

v2

− → S2 → . . .

vn

− → Sn . . . (S

∗

− → Sn)

system terminates in Sn: no vn+1, Sn+1 s.t. Sn

vn+1

− − → Sn+1

fair (infinite) sequence

for every vi ∈ Si: there exists a j > i s.t. either Sj

vi

− → Sj+1 or invoking vi has no effect on Sj

S.Skritek – Theory of PDM 32/54

SLIDE 66

3.Materialization of Data in Peer Data Management 3.2. Active XML

Semantics of monotone AXML systems

Definition (semantics of monotone AXML systems)

For a monotone AXML system S, its semantics [S] is defined as: [S] = J if S

∗

− → J and system terminates at J (J finite) [S] = Si for infinite fair rewriting S . . . → . . . vi − → Si . . .

S.Skritek – Theory of PDM 33/54

SLIDE 67

3.Materialization of Data in Peer Data Management 3.2. Active XML

Semantics of monotone AXML systems

Definition (semantics of monotone AXML systems)

For a monotone AXML system S, its semantics [S] is defined as: [S] = J if S

∗

− → J and system terminates at J (J finite) [S] = Si for infinite fair rewriting S . . . → . . . vi − → Si . . . Semantics is well defined (order of invocations does not matter)

S

∗

− → ˆ S and S

∗

− → ¯ S: either ¯ S ⊆ S′ ( ˆ S terminates at S′),

r ¯

S ⊆ Si for some i ( ˆ S not terminating)

one rewriting terminates at J ⇒ any rewriting terminates at J
one fair rewriting does not terminate ⇒ no rewriting

terminates; any fair rewriting results in same infinite system

S.Skritek – Theory of PDM 33/54

SLIDE 68

3.Materialization of Data in Peer Data Management 3.2. Active XML

Positive Active XML

Also consider service implementations, defined as queries

S.Skritek – Theory of PDM 34/54

SLIDE 69

3.Materialization of Data in Peer Data Management 3.2. Active XML

Positive Active XML

Also consider service implementations, defined as queries

Definition (Positive Query)

positive query q: r :- d1/p1, . . . , dn/pn, e1, . . . , em where di: document names, r, pi: positive AXML tree patterns each variable occurring in r also occurs in some pi ej: inequalities x = y between label, function, or value variables or constants (no tree variables). No tree variable occurs twice in the body simple query: no tree variables AXML tree pattern: subtree of AXML document some labels replaced by label variables

S.Skritek – Theory of PDM 34/54

SLIDE 70

3.Materialization of Data in Peer Data Management 3.2. Active XML

Query Semantics

Recall:

query q = r :- d1/p1, . . . , dn/pn, e1, . . . , em
monotone AXML system S = (D, F, I)

S.Skritek – Theory of PDM 35/54

SLIDE 71

3.Materialization of Data in Peer Data Management 3.2. Active XML

Query Semantics

Recall:

query q = r :- d1/p1, . . . , dn/pn, e1, . . . , em
monotone AXML system S = (D, F, I)

Snapshot Result q(S)

consider variable assignments µ (respect typing) s.t.

for each di/pi ∈ q: µ(pi) ⊆ I(di)

q(S): forest of all documents µ(r)

S.Skritek – Theory of PDM 35/54

SLIDE 72

3.Materialization of Data in Peer Data Management 3.2. Active XML

Query Semantics

Recall:

query q = r :- d1/p1, . . . , dn/pn, e1, . . . , em
monotone AXML system S = (D, F, I)

Snapshot Result q(S)

consider variable assignments µ (respect typing) s.t.

for each di/pi ∈ q: µ(pi) ⊆ I(di)

q(S): forest of all documents µ(r)
Properties:

monotone (i.e. S ⊆ S′ ⇒ q(S) ⊆ q(S′)) for positive queries (no inequalities of tree variables) for positive queries: PTIME

S.Skritek – Theory of PDM 35/54

SLIDE 73

3.Materialization of Data in Peer Data Management 3.2. Active XML

Query Semantics

Recall:

query q = r :- d1/p1, . . . , dn/pn, e1, . . . , em
monotone AXML system S = (D, F, I)

Snapshot Result q(S)

consider variable assignments µ (respect typing) s.t.

for each di/pi ∈ q: µ(pi) ⊆ I(di)

q(S): forest of all documents µ(r)
Properties:

monotone (i.e. S ⊆ S′ ⇒ q(S) ⊆ q(S′)) for positive queries (no inequalities of tree variables) for positive queries: PTIME

Query Result [q](S)

[q](S) = q([S]) if S converges to finite system [S]
[q](S) = q(Si) for infinite fair rewriting S . . . Si . . .
therwise
for positive queries: result is independent of rewriting sequence

S.Skritek – Theory of PDM 35/54

SLIDE 74

3.Materialization of Data in Peer Data Management 3.2. Active XML

Positive Systems

service descriptions I(f ) defined as positive queries if all queries are simple → simple positive system

S.Skritek – Theory of PDM 36/54

SLIDE 75

3.Materialization of Data in Peer Data Management 3.2. Active XML

Positive Systems

service descriptions I(f ) defined as positive queries if all queries are simple → simple positive system Semantics of positive systems positive system S, function node v, λ(v) = f , I(f ) = q invoking f : evaluate q under θ snapshot result of q(S) is added as sibling of v

S.Skritek – Theory of PDM 36/54

SLIDE 76

3.Materialization of Data in Peer Data Management 3.2. Active XML

Positive Systems

service descriptions I(f ) defined as positive queries if all queries are simple → simple positive system Semantics of positive systems positive system S, function node v, λ(v) = f , I(f ) = q invoking f : evaluate q under θ snapshot result of q(S) is added as sibling of v Complexity

Theorem (Abiteboul et al., PODS 2004)

Any Turing Machine can be simulated by a positive AXML system, with the input tape represented by an AXML tree. ⇒ it is undecidable whether a positive system terminates

S.Skritek – Theory of PDM 36/54

SLIDE 77

3.Materialization of Data in Peer Data Management 3.2. Active XML

Restricted Systems

Try to find decidable systems Acyclic Systems dependency graph (V , E) of S = (D, F, I):

V : D ∪ F (document and function names)
E: edge (d, f ) if f occurs in I(d),

edge (f , d) (resp. (f , g)) if d (resp. g) occurs in I(f )

AXML system acyclic if dependency graph is acyclic acyclic systems always terminate

S.Skritek – Theory of PDM 37/54

SLIDE 78

3.Materialization of Data in Peer Data Management 3.2. Active XML

Restricted Systems

Try to find decidable systems Acyclic Systems dependency graph (V , E) of S = (D, F, I):

V : D ∪ F (document and function names)
E: edge (d, f ) if f occurs in I(d),

edge (f , d) (resp. (f , g)) if d (resp. g) occurs in I(f )

AXML system acyclic if dependency graph is acyclic acyclic systems always terminate Simple Positive Systems Recall: simple queries: no tree variables For every simple positive system S:

[S] is regular
compute finite graph representation of [S] in EXPTIME
termination: decidable in EXPTIME, coNP hard

S.Skritek – Theory of PDM 37/54

SLIDE 79

3.Materialization of Data in Peer Data Management 3.2. Active XML

Querying Positive Systems

Instead of materialization: just consider query answering

Definition (q-finite)

AXML system S is q-finite if [q](S) is finite

S.Skritek – Theory of PDM 38/54

SLIDE 80

3.Materialization of Data in Peer Data Management 3.2. Active XML

Querying Positive Systems

Instead of materialization: just consider query answering

Definition (q-finite)

AXML system S is q-finite if [q](S) is finite q: non-simple query undecidable whether positive system S is q-finite acyclic systems are q-finite simple positive systems: deciding q-finiteness is coNP hard and in EXPTIME

S.Skritek – Theory of PDM 38/54

SLIDE 81

3.Materialization of Data in Peer Data Management 3.2. Active XML

Querying Positive Systems

Instead of materialization: just consider query answering

Definition (q-finite)

AXML system S is q-finite if [q](S) is finite q: non-simple query undecidable whether positive system S is q-finite acyclic systems are q-finite simple positive systems: deciding q-finiteness is coNP hard and in EXPTIME q: simple query result is always finite BUT: for non-simple positive systems S: testing if [q](S) is nonempty is undecidable

S.Skritek – Theory of PDM 38/54

SLIDE 82

3.Materialization of Data in Peer Data Management 3.2. Active XML

Lazy Query Evaluation

It might not be necessary to invoke a service answering a query irrelevant for answer just return call to service in answer (lazy evaluation)

S.Skritek – Theory of PDM 39/54

SLIDE 83

3.Materialization of Data in Peer Data Management 3.2. Active XML

Lazy Query Evaluation

It might not be necessary to invoke a service answering a query irrelevant for answer just return call to service in answer (lazy evaluation)

Definition (possible answer)

AXML document α is a possible answer if [α] = [[q](I)]

S.Skritek – Theory of PDM 39/54

SLIDE 84

3.Materialization of Data in Peer Data Management 3.2. Active XML

Lazy Query Evaluation

It might not be necessary to invoke a service answering a query irrelevant for answer just return call to service in answer (lazy evaluation)

Definition (possible answer)

AXML document α is a possible answer if [α] = [[q](I)] ⇒ not expanding function nodes N still gives a possible answer? (q–unneeded)

S.Skritek – Theory of PDM 39/54

SLIDE 85

3.Materialization of Data in Peer Data Management 3.2. Active XML

Lazy Query Evaluation

It might not be necessary to invoke a service answering a query irrelevant for answer just return call to service in answer (lazy evaluation)

Definition (possible answer)

AXML document α is a possible answer if [α] = [[q](I)] ⇒ not expanding function nodes N still gives a possible answer? (q–unneeded) Given positive AXML system S, q, N in S, t:

undecidable if: d is possible answer to q; function nodes in N

need not be expanded; no more function needs to be expanded

For simple systems: in NEXPTIME, coNP hard

S.Skritek – Theory of PDM 39/54

SLIDE 86

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Updates in PDM

Updates in Peer Data Management

S.Skritek – Theory of PDM 40/54

SLIDE 87

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Updates in PDM

Updates in Peer Data Management Updates in PDI: no problem in PDM: may lead to inconsistencies ⇒ problem

S.Skritek – Theory of PDM 40/54

SLIDE 88

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Updates in PDM

Updates in Peer Data Management Updates in PDI: no problem in PDM: may lead to inconsistencies ⇒ problem Other concerns so far: “global” systems Trust Provenance information

S.Skritek – Theory of PDM 40/54

SLIDE 89

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Updates in PDM

Updates in Peer Data Management Updates in PDI: no problem in PDM: may lead to inconsistencies ⇒ problem Other concerns so far: “global” systems Trust Provenance information Take a look onto the Orchestra system

S.Skritek – Theory of PDM 40/54

SLIDE 90

3.Materialization of Data in Peer Data Management 3.3. Orchestra

General Setting

P1 P2 P3 schema mappings:

(weakly acyclic) sets of TGDs

users work on their local copies from time to time, they

publish their updates and
retrieve updates of other users

trust conditions on the mappings ⇒ need for provenance information

S.Skritek – Theory of PDM 41/54

SLIDE 91

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Update Propagation

R( x) ∆R(d, x) User Actions:

Insert, Delete, Publish/Import

Maintain local edit log Answers over local database

consistent with local edit log
for imported updates:

certain answers

S.Skritek – Theory of PDM 42/54

SLIDE 92

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Update Propagation

R( x) ∆R(d, x) ∆G(d, y) User Actions:

Insert, Delete, Publish/Import

Maintain local edit log Answers over local database

consistent with local edit log
for imported updates:

certain answers

S.Skritek – Theory of PDM 42/54

SLIDE 93

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Update Propagation

R( x) ∆R(d, x) ∆G(d, y) User Actions:

Insert, Delete, Publish/Import

Maintain local edit log Answers over local database

consistent with local edit log
for imported updates:

certain answers

⇒ what data to materialize inconsistent updates: reconciliation algorithm (Taylor, Ives; Sigmod 2006)

resolve conflicts using priority mappings
user interaction if merging not possible

here: assume consistent updates

concentrate on what data to materialize

S.Skritek – Theory of PDM 42/54

SLIDE 94

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Semantics of Update Exchange

R( x) ∆R(d, x)

S.Skritek – Theory of PDM 43/54

SLIDE 95

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Semantics of Update Exchange

R( x) ∆R(d, x) Ro Ri Rr Rℓ Split every relation R:

Rℓ: local contributions

table

Rr: rejections table
Ri: input table
Ro: output table

S.Skritek – Theory of PDM 43/54

SLIDE 96

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Semantics of Update Exchange

R( x) ∆R(d, x) Ro Ri Rr Rℓ Split every relation R:

Rℓ: local contributions

table

Rr: rejections table
Ri: input table
Ro: output table

Translate mappings Σ → Σ′:

for each m ∈ M: replace R

in lhs by Ro and in rhs by Ri

Ri(

x) ∧ ¬Rr( x) → Ro( x)

Rℓ(

x) → Ro( x)

S.Skritek – Theory of PDM 43/54

SLIDE 97

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Semantics of Update Exchange (contd.)

Recall Σ′:

Ri(

x) ∧ ¬Rr( x) → Ro( x)

Rℓ(

x) → Ro( x)

M′: weakly acyclic TGDs

S.Skritek – Theory of PDM 44/54

SLIDE 98

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Semantics of Update Exchange (contd.)

Recall Σ′:

Ri(

x) ∧ ¬Rr( x) → Ro( x)

Rℓ(

x) → Ro( x)

M′: weakly acyclic TGDs

Publish:

create new instance of Rr, Rℓ

Import:

recompute Ri, Ro (chase)

S.Skritek – Theory of PDM 44/54

SLIDE 99

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Semantics of Update Exchange (contd.)

Recall Σ′:

Ri(

x) ∧ ¬Rr( x) → Ro( x)

Rℓ(

x) → Ro( x)

M′: weakly acyclic TGDs

Publish:

create new instance of Rr, Rℓ

Import:

recompute Ri, Ro (chase)

Definition (consistent system state)

Instance I, J over schema Rℓ ∪ Rr, Ro ∪ Ri is consistent if J = chaseΣ ′(I) computable in polynomial time (data complexity)

S.Skritek – Theory of PDM 44/54

SLIDE 100

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Provenance

Need to track from where tuples are derived, and how Provenance Token base tuple: tuple id derived tuple: polynomial

binary operators +,·
unary function for each

mapping

S.Skritek – Theory of PDM 45/54

SLIDE 101

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Provenance

Need to track from where tuples are derived, and how Provenance Token base tuple: tuple id derived tuple: polynomial

binary operators +,·
unary function for each

mapping

Example (Provenance Tokens)

Relations R1, R2, Mappings m1 : R1(A, B) → R2(A, B), m2 : R2(A, B) ∧ R1(B, C) → R2(A, C)

S.Skritek – Theory of PDM 45/54

SLIDE 102

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Provenance

Need to track from where tuples are derived, and how Provenance Token base tuple: tuple id derived tuple: polynomial

binary operators +,·
unary function for each

mapping

Example (Provenance Tokens)

Relations R1, R2, Mappings m1 : R1(A, B) → R2(A, B), m2 : R2(A, B) ∧ R1(B, C) → R2(A, C) r1 : R1(a, b), r2 : R1(b, c), r3 : R1(a, c) r4 : R1(c, d)

S.Skritek – Theory of PDM 45/54

SLIDE 103

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Provenance

Need to track from where tuples are derived, and how Provenance Token base tuple: tuple id derived tuple: polynomial

binary operators +,·
unary function for each

mapping

Example (Provenance Tokens)

Relations R1, R2, Mappings m1 : R1(A, B) → R2(A, B), m2 : R2(A, B) ∧ R1(B, C) → R2(A, C) r1 : R1(a, b), r2 : R1(b, c), r3 : R1(a, c) r4 : R1(c, d) Pv(R2(a, b)): m1(r1)

S.Skritek – Theory of PDM 45/54

SLIDE 104

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Provenance

Need to track from where tuples are derived, and how Provenance Token base tuple: tuple id derived tuple: polynomial

binary operators +,·
unary function for each

mapping

Example (Provenance Tokens)

Relations R1, R2, Mappings m1 : R1(A, B) → R2(A, B), m2 : R2(A, B) ∧ R1(B, C) → R2(A, C) r1 : R1(a, b), r2 : R1(b, c), r3 : R1(a, c) r4 : R1(c, d) Pv(R2(a, b)): m1(r1) Pv(R2(a, c)): m1(r3)+m2(r2·m1(r1))

S.Skritek – Theory of PDM 45/54

SLIDE 105

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Provenance

Need to track from where tuples are derived, and how Provenance Token base tuple: tuple id derived tuple: polynomial

binary operators +,·
unary function for each

mapping

Example (Provenance Tokens)

Relations R1, R2, Mappings m1 : R1(A, B) → R2(A, B), m2 : R2(A, B) ∧ R1(B, C) → R2(A, C) r1 : R1(a, b), r2 : R1(b, c), r3 : R1(a, c) r4 : R1(c, d) Pv(R2(a, b)): m1(r1) Pv(R2(a, c)): m1(r3)+m2(r2·m1(r1)) Pv(R2(a, d)): m2(r4 · (m1(r3) + m2(r2 · m1(r1)))

S.Skritek – Theory of PDM 45/54

SLIDE 106

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Provenance

Need to track from where tuples are derived, and how Provenance Token base tuple: tuple id derived tuple: polynomial

binary operators +,·
unary function for each

mapping

Also possible: define provenance via provenance graph (omitted)

Example (Provenance Tokens)

Relations R1, R2, Mappings m1 : R1(A, B) → R2(A, B), m2 : R2(A, B) ∧ R1(B, C) → R2(A, C) r1 : R1(a, b), r2 : R1(b, c), r3 : R1(a, c) r4 : R1(c, d) Pv(R2(a, b)): m1(r1) Pv(R2(a, c)): m1(r3)+m2(r2·m1(r1)) Pv(R2(a, d)): m2(r4 · (m1(r3) + m2(r2 · m1(r1))) Infinitely many or arbitrarily large derivations ⇒ finitely representable

S.Skritek – Theory of PDM 45/54

SLIDE 107

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Trust

Trust annotations T and D – Reject D

S.Skritek – Theory of PDM 46/54

SLIDE 108

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Trust

Trust annotations T and D – Reject D Trust Conditions Define trust conditions ρi for mappings mi

e.g. trivial conditions T, D
more elaborate conditions like T if xi > 4, D otherwise

Assume every base tuple to be annotated with T, D Import data if ρi is satisfied and tuples are trusted

S.Skritek – Theory of PDM 46/54

SLIDE 109

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Trust

Trust annotations T and D – Reject D Trust Conditions Define trust conditions ρi for mappings mi

e.g. trivial conditions T, D
more elaborate conditions like T if xi > 4, D otherwise

Assume every base tuple to be annotated with T, D Import data if ρi is satisfied and tuples are trusted Evaluate (finite) provenance expressions Identify T, D with boolean true, false, and +, · with ∨, ∧ Combine trust conditions on mappings by ∧ with arguments ⇒ Consider finite provenance expression as boolean equation

S.Skritek – Theory of PDM 46/54

SLIDE 110

3.Materialization of Data in Peer Data Management 3.3. Orchestra

Trust

Trust annotations T and D – Reject D Trust Conditions Define trust conditions ρi for mappings mi

e.g. trivial conditions T, D
more elaborate conditions like T if xi > 4, D otherwise

Assume every base tuple to be annotated with T, D Import data if ρi is satisfied and tuples are trusted Evaluate (finite) provenance expressions Identify T, D with boolean true, false, and +, · with ∨, ∧ Combine trust conditions on mappings by ∧ with arguments ⇒ Consider finite provenance expression as boolean equation Encode trust in Σ′ add table Rt; change intern mappings to

Rt(

x) = trusted(Ri( x))

Rt(

x) ∧ ¬Rr( x) → Ro( x)

S.Skritek – Theory of PDM 46/54

SLIDE 111

4.Optimization of Query Reformulation 4.0.

Outline

1. Motivation
2. Query Answering in Peer Data Management
3. Materialization of Data in Peer Data Management
4. Optimization of Query Reformulation
5. Conclusion

S.Skritek – Theory of PDM 47/54

SLIDE 112

4.Optimization of Query Reformulation 4.0.

Query Reformulation in Peer Data Integration

consider again query answering for PPL Query Reformulation Algorithm combination of LAV and GAV mappings for a query goal

unfolding if part of a GAV mapping
rewriting if part of a LAV mapping

follow semantic paths through the system create (special) rule-goal tree

S.Skritek – Theory of PDM 48/54

SLIDE 113

4.Optimization of Query Reformulation 4.0.

Query Reformulation in Peer Data Integration

consider again query answering for PPL Query Reformulation Algorithm combination of LAV and GAV mappings for a query goal

unfolding if part of a GAV mapping
rewriting if part of a LAV mapping

follow semantic paths through the system create (special) rule-goal tree ⇒ prune the search tree

S.Skritek – Theory of PDM 48/54

SLIDE 114

4.Optimization of Query Reformulation 4.0.

Query Reformulation in Peer Data Integration

consider again query answering for PPL Query Reformulation Algorithm combination of LAV and GAV mappings for a query goal

unfolding if part of a GAV mapping
rewriting if part of a LAV mapping

follow semantic paths through the system create (special) rule-goal tree ⇒ prune the search tree peers described by XML schemas mappings described as queries in a subset of XQuery

S.Skritek – Theory of PDM 48/54

SLIDE 115

4.Optimization of Query Reformulation 4.0.

Pruning the Search Tree

possibilities for optimization Pruning reformulation goals

identify dead ends, redundancies

Minimizing reformulations

identify redundant subexpressions

Pre-computation of semantic paths

a priori optimization

Order of expansions (search strategy) Memorization Find first reformulations quickly

S.Skritek – Theory of PDM 49/54

SLIDE 116

4.Optimization of Query Reformulation 4.0.

Pruning the Search Tree

possibilities for optimization Pruning reformulation goals ⇒ XML query containment

identify dead ends, redundancies

Minimizing reformulations

identify redundant subexpressions

Pre-computation of semantic paths

a priori optimization

Order of expansions (search strategy) Memorization Find first reformulations quickly

S.Skritek – Theory of PDM 49/54

SLIDE 117

4.Optimization of Query Reformulation 4.0.

Pruning the Search Tree

possibilities for optimization Pruning reformulation goals ⇒ XML query containment

identify dead ends, redundancies

Minimizing reformulations ⇒ minimization of XML queries

identify redundant subexpressions

Pre-computation of semantic paths

a priori optimization

Order of expansions (search strategy) Memorization Find first reformulations quickly

S.Skritek – Theory of PDM 49/54

SLIDE 118

4.Optimization of Query Reformulation 4.0.

Pruning the Search Tree

possibilities for optimization Pruning reformulation goals ⇒ XML query containment

identify dead ends, redundancies

Minimizing reformulations ⇒ minimization of XML queries

identify redundant subexpressions

Pre-computation of semantic paths ⇒ mapping composition

a priori optimization

Order of expansions (search strategy) Memorization Find first reformulations quickly

S.Skritek – Theory of PDM 49/54

SLIDE 119

5.Conclusion 5.0.

Outline

1. Motivation
2. Query Answering in Peer Data Management
3. Materialization of Data in Peer Data Management
4. Optimization of Query Reformulation
5. Conclusion

S.Skritek – Theory of PDM 50/54

SLIDE 120

5.Conclusion 5.1. Conclusion

Conclusion

Theory of Peer Data Management considering PDM: interesting questions and results Summary

Peer Data Integration

global FO theory or “modular” semantics

Data Exchange in Peer Data Management

exchange certain answers AXML (service invocations, rewritings, query answering) update exchange (including trust, provenance)

Further Results

Trust, Priorities, Preferences
(In)consistency handling
Updates
. . .

S.Skritek – Theory of PDM 51/54

SLIDE 121

5.Conclusion 5.2. References

References I

S. Abiteboul, O. Benjelloun, and T. Milo.

Positive active xml. In PODS, pages 35–45, 2004.

D. Calvanese, G. D. Giacomo, D. Lembo, M. Lenzerini, and R. Rosati.

Inconsistency tolerance in p2p data integration: An epistemic logic approach.

Inf. Syst., 33(4-5):360–384, 2008.
D. Calvanese, G. D. Giacomo, M. Lenzerini, and R. Rosati.

Logical foundations of peer-to-peer data integration. In PODS, pages 241–251, 2004.

G. D. Giacomo, D. Lembo, M. Lenzerini, and R. Rosati.

On reconciling data exchange, data integration, and peer data management. In PODS, pages 133–142, 2007.

T. J. Green, G. Karvounarakis, Z. G. Ives, and V. Tannen.

Update exchange with mappings and provenance. In VLDB, pages 675–686, 2007.

T. J. Green, G. Karvounarakis, and V. Tannen.

Provenance semirings. In PODS, pages 31–40, 2007.

S.Skritek – Theory of PDM 52/54

SLIDE 122

5.Conclusion 5.2. References

References II

A. Y. Halevy, Z. G. Ives, D. Suciu, and I. Tatarinov.

Schema mediation for large-scale semantic data sharing. VLDB J., 14(1):68–83, 2005.

I. Tatarinov and A. Y. Halevy.

Efficient query reformulation in peer-data management systems. In SIGMOD Conference, pages 539–550. ACM, 2004.

S.Skritek – Theory of PDM 53/54

SLIDE 123

5.Conclusion 5.3. Thanks!

Thank you!

S.Skritek – Theory of PDM 54/54
