The studio, more than the bench AMPS East September 24 & 25, 2011 Mike Del Vecchio AMPS East 2011 Who am i Mike Del Vecchio, Major, Field Artillery, Retired Currently working as the head of engineering for a water and wastewater

slide-1
SLIDE 1

AMPS East 2011

The studio, more than the bench

AMPS East September 24 & 25, 2011 Mike Del Vecchio

slide-2
SLIDE 2

AMPS East 2011

Who am i

  • Mike Del Vecchio, Major, Field Artillery, Retired
  • Currently working as the head of engineering for a

water and wastewater technology company

  • A passion for building models of artillery and artillery

support equipment!!

  • Known in many forums as Redleg12
slide-3
SLIDE 3

AMPS East 2011

Definitions

  • Studio (stū

'dē

  • ō

, styū '-) n., pl., -os.

– An artist's workroom

  • Work·bench

(wûrkbnch) n.

– A sturdy table or bench at which manual work is done, as by an machinist, jeweler or artist.

slide-4
SLIDE 4

AMPS East 2011

Definitions

  • Man cave

n.

– A dedicated area of a house, such as a basement, workshop, or garage, where a man can be alone or socialize with his friends

  • Thus, a “Man cave studio with a work bench”
slide-5
SLIDE 5

AMPS East 2011

What is your starting point

  • Who lives in a house they own?

– Are you looking to build….the studio?? – Where in the house?

  • Who rents or lives with someone?

– Many of the items to be discussed will apply and some will have to be more portable

slide-6
SLIDE 6

AMPS East 2011

The studio

  • Planning a Studio
  • The Room
  • The Bench
  • Storage
  • Paint Booth
  • Photo Area
  • Tools
  • Favorite Places
slide-7
SLIDE 7

AMPS East 2011

Planning Process

  • If you fail to plan…..you plan to fail
  • Every good plan is made to be changed
  • Start by drawing the room either on graph paper or on

Auto CAD!

  • Shop look and think at Home Depot/Lowes, Ikea, the

internet, etc. Get ideas

  • Make a budget $$$ or $$/yr
  • You can build all at once or over time with a good plan
  • There is no right or wrong, only what works for you!
slide-8
SLIDE 8

AMPS East 2011

Planning the studio

  • Planning items

–Ventilation –Lighting –Power –Communication –Compressed Air –Vacuum –Flooring –Cabinets Shelves & Furnishings –Safety

slide-9
SLIDE 9

AMPS East 2011

Ventilation

  • Plan for room ventilation.

–A/C and Heat feed and return

  • Ceiling Fans in the bench

area

  • Ducting to the outside for

paint booth

slide-10
SLIDE 10

AMPS East 2011

Lighting

  • If windows are available, maximize natural

lighting

  • Go with one style light, either fluorescent or

incandescent….do not mix

  • Plan for task lighting.
  • Lighted magnifiers, make sure to match light type
  • Think of lighting the paint booth.
slide-11
SLIDE 11

AMPS East 2011

Lighting

slide-12
SLIDE 12

AMPS East 2011

power

  • You can never have enough power or outlets.
  • Bench should have multiple outlet strips at either

end

  • Bench area wall should have quad wall outlets.
  • Also plan outlets for compressor, paint booth

fans, computer/desk

slide-13
SLIDE 13

AMPS East 2011

communication

  • The room should include a computer with CAT 6

wiring back to the router.

  • Wireless is easy but can be slower
  • Telephone, wired or wireless?
  • Cable/Satellite –for entertainment!!
slide-14
SLIDE 14

AMPS East 2011

Compressed air

  • Use an “industrial” compressor. Minimum 2 ½ gallon

pancake type

  • Look to mount compressor in a sound proof area if

possible.

  • Use copper ½ inch tubing or pipe for piping.
  • Pipe air to the paint booth & work bench
  • Use local quick disconnect fittings and pressure

regulators

  • Install a storage tank if possible to increase

compressed air storage

slide-15
SLIDE 15

AMPS East 2011

Compressed air

slide-16
SLIDE 16

AMPS East 2011

vacuum

  • Think about vacuum in

the bench area for clean up and for working with resin

  • Make a small “hood”

from flexible ducting connected to the vacuum hose

  • Vacuum should also be

accessible for wood working for bases!

slide-17
SLIDE 17

AMPS East 2011

flooring

  • Something easy to clean/paint resistant
  • Does not support the small part monster
  • Stay away from carpet
  • I like garage tiles
  • http://www.racedeck.com/
  • http://www.costco.com/Browse/Productgroup.aspx?

Prodid=11038308

slide-18
SLIDE 18

AMPS East 2011

Cabinets, shelves & Furnishings

  • Cabinets, THINK IKEA, Very nice lines of

inexpensive kitchen cabinets both wall and base cabinets

  • Shelves for storage, Home Depot/Lowes
  • Look in the shelving aisle but also in lumber for

pre-punched side panels and cut shelves

  • Display case/ shelves….again THINK IKEA
  • Work Bench for modeling & Bench/Desk or other

for paint booth

slide-19
SLIDE 19

AMPS East 2011

Cabinets, shelves & Furnishings

  • Desk for computer
  • Most important item….the chair. Look for a GOOD

comfortable, back supporting, well built chair. You will be spending a lot of time in it!

  • Visitor chair(s)
  • Clock….. So you know how long you have been

working!

  • I love me wall art!!
slide-20
SLIDE 20

AMPS East 2011

Cabinets, shelves & Furnishings

slide-21
SLIDE 21

AMPS East 2011

safety

  • Plug in emergency light
  • First Aid kit
  • Fire Extinguisher
  • Eye Shields
  • Respirator
slide-22
SLIDE 22

AMPS East 2011

The Room

  • Is the room and attic

room, spare bedroom, basement room, garage??

  • Every room has strengths
  • Is the room year round

and not affected by seasonal change

  • Is the space finished or

unfinished?

  • Walls are best with

paneling

  • Drop ceilings with inset

lights

slide-23
SLIDE 23

AMPS East 2011

The Bench

  • Give yourself as much

space as possible

  • Arms reach to each

side…5 –6’ for the modeling area

  • Additional area for paint

booth, resin or woodworking for bases.

slide-24
SLIDE 24

AMPS East 2011

Storage

  • Consider stash as well as

library.

  • For stash I used 16” deep

shelving and matching 12” for the books at the end

  • Note the small parts bin,

great for all those leftovers

  • Use binders with photo

insert pages for decals

slide-25
SLIDE 25

AMPS East 2011

storage

  • Small stackable drawers

are great.

  • These were from Staples

and fit perfect. On sale could get a nice big stack

  • You can organize PE,

styrene, tracks, etc.

slide-26
SLIDE 26

AMPS East 2011

Storage

  • All those little paint

bottles.

  • Long narrow shelved for

paint

  • Enough room to organize

base on type, finish colors, etc.

slide-27
SLIDE 27

AMPS East 2011

Paint Booth

  • Prefer a scratch built
  • Using 3/8 plywood,

essentially a 2’ x 2’ x 2’ box

  • If you use mostly acrylics,

min 100 cfm fan enamels at least 200 cfm

  • Use under cabinet hockey

puck lights

  • Interior shelves to hold

solvents

slide-28
SLIDE 28

AMPS East 2011

Paint booth

  • Outlet on the side for

shaker power

  • Paper towel rack

underneath

  • Regulator also underneath
  • Vent exhaust to outside
slide-29
SLIDE 29

AMPS East 2011

Photo area

  • Backdrop of light blue

polyester fabric $2/yd

  • Spring loaded curtain rod

$4

  • Side diffusers use a

transparent white fabric $2/yd

  • Wire frame bent from 1/16

rod $2

  • Lights after shopping well
  • n the internet $50
slide-30
SLIDE 30

AMPS East 2011

Photo area

  • You don’t need a store

bought photo booth!

  • Mine is built in using my

16” deep “stash” shelves

slide-31
SLIDE 31

AMPS East 2011

Tools

  • Peg board makes a great

bench back drop

  • A set of jewelers pliers

for PE and sprue cutters are a must.

  • Peg Board cups are good

for miscellaneous items

slide-32
SLIDE 32

AMPS East 2011

Tools

  • Custom brush holder
  • 1 ½” PVC conduit
  • 6 longer and 5 shorter
  • PVC or Epoxy
  • Sheet styrene cut to fit a

bottom

  • Sit on peg board hooks!
  • Note…a caliper is also

good to have

slide-33
SLIDE 33

AMPS East 2011

Tools

  • Bench top organizer for

frequently used tools.

  • Organizer was a sale

pickup at Staples.

slide-34
SLIDE 34

AMPS East 2011

Tools

  • A great holiday gift idea.
  • Could also be just a

“Sears” automotive box.

  • Small tool drawers

perfect to layout tools to find when you need them.

  • Note Dremel on extension
  • n the right
slide-35
SLIDE 35

AMPS East 2011

Tools

  • Small clamps for holding

a hull while glue sets.

  • Small hand saw
  • Dremel with cutting blade

for resin cutting and sanding

  • The old #11 E-xacto knife!
slide-36
SLIDE 36

AMPS East 2011

Tools

  • This is an acrylic

magazine holder. I use it to hold the kit directions and any printed research material.

  • Something like this keeps

paper off the work bench and out of the way.

slide-37
SLIDE 37

AMPS East 2011

Tools

  • Pegboard on the legs of

the bench keeps the larger items like the respirator or visor from clogging the main work area but are within reach.

slide-38
SLIDE 38

AMPS East 2011

Tools

  • List of other great tools

–Dremel with stand and flexible extension arm –Foot pedal for Dremel –Plastic Pottery wheel or lazy suzan –Soldering Iron for PE –Robart paint shaker –Punch set is a must.

  • Duh Tools

–Syringes 1 ml for glue & 5 ml for solvents. Use needle for glues to get into tight space. Do not mix use –Flint glass sample bottles for paint mixing/storage about 10 ml –20 ml disposable plastic measuring cups

slide-39
SLIDE 39

AMPS East 2011

Favorite Places

  • Stores

–Home Depot/ Lowes –Michaels –Any drug store chain –Ikea (cabinets) –Costco (flooring) –Staples. Office Max

  • Internet

– Ebay – Medical Supply – Laboratory Supply – Harbor Freight – Micromark

slide-40
SLIDE 40

AMPS East 2011

Looking, shopping, decisions

  • Be patient
  • Look hard
  • Measure twice, buy once
  • Rome was not built in a

day!

  • Most of all… do what

works and is right for you and your modeling!

slide-41
SLIDE 41

AMPS East 2011

Rounds complete!!

  • Thanks to all of you who

came to this session and to the staff of NMMA/ AMPS East

  • Thanks to all my fellow

redleg’s, past and present, The King’s of Battle

slide-42
SLIDE 42

AMPS East 2011

End of mission

  • Questions???
  • If after this seminar you

have further questions contact me at:

–redleg12@redleg2scale.com

  • Feel free to also check
  • ut my web site for a

copy of these slides

–www.redleg2scale.com
