April 15th, 2011

High Heat Materials: Trends and Challenges in Your Market PLUS Potential Solutions to Meet Performance Requirements while Reducing Costs!

 Part I:

Opportunities for Higher Heat Materials at Horizon 2012-2016

Raphaël Mestanza – SpecialChem's Chief Plastics Expert

 Part II:

Extreme Heat Solutions with TPI Blends From SABIC Innovative Plastics

Peter Catsman, Global PMM High Heat resins , SABIC Kapil Sheth, Global Product Technology Manager, SABIC

Agenda

2

Part I

Opportunities for Higher Heat Materials at Horizon 2012-2016

Raphaël Mestanza – SpecialChem's Chief Plastics Expert

3

Key questions we will try to answer today:

Q1: Main Market trends in the coming 2-3 years. Q2: Q4 : Type of material improvement needed to fullfill future requirements Q3 : How strong is the pressure to use higher heat materials in the coming 3- years? and main reasons. Q4 : What are the average levels of « heat » improvement expected? Q5 What materials will be considered for these Higher heat applications? Q6 : Type of materials considered for metal repals

Part I - Agenda

Trends in High Heat Materials

4

 Analysis of Omnexus.com members behavior  Interviews with key OEMs, Raw material suppliers and Experts  Market Surveys

Metal replacement Opportunities in the coming 3-5 Years (233 respondents, Jan 2011) Opportunities for Higher Heat plastics at the horizon 2014-2016 (225 respondents, Nov. 2011)

Where the answer are coming from

5

6

“Please rank the top 3 trends you see in your market in the 3 coming years.”

Scale from 0 to 5

Q1 : Main trends in the coming 3 years

Lower weight, Lower System Cost, More Compact design…

Source: Metal replacement opportunities Specialchem market survey, 235 respondants, 45% OEMs, 55% polymer suppliers, Jan 2010.

7

“Please rank the top 3 trends you see in your market in the 3 coming years.”

Q1 : Main trends in the coming 3 years

Lower weight, Lower System Cost, More Compact design…

Source: Metal replacement opportunities Specialchem market survey, 235 respondants, 45% OEMs, 55% polymer suppliers, Jan 2010.

Q2: Impact of trends on material requirements

8

“What are the 3 main improvements needed for plastics to fulfill these trends?”

Higher Stiffness/Impact, Dimensional Stability and Perf. at HT

Source: Metal replacement opportunities SpecialChem market survey, 235 respondants, 45% OEMs, 55% polymer suppliers, Jan 2010.

Q3a: Pressure to use higher Heat Material

9

73% of Total Respondents report Huge/Strong Pressure

No split 226 respondents

• 1. Dimensional Stability
• 2. Higher Max CST
• 3. Mechanical Perf.

Source: SpecialChem Market Survey based on 226 plastics professionals 50% Specifiers / 50% Material supplier, Nov 2010.

Q3b: Why do they have pressure?

Existing Application Demands, Product Reliability, metal replacement

10

No split 226 respondents

• 1. Existing Apps
• 2. Superior Reliability
• 3. Metal Replacement

Source: SpecialChem Market Survey based on 226 plastics professionals 50% Specifiers / 50% Material supplier, Nov 2010.

Q3: Pressure by market

Automotive and Industrial have the highest pressure

11

Market % Huge pressure % Huge + strong pressure Top 3 performances Top 3 Reasons Automotive Under the hood

42% 76% Dimensional Stab. Heat Aging Peak T° Resistance Stronger Heat Requirements Metal Replacement More part close to the engine

Automotive Lighting+other

19% 64% Peak T° Resistance

• Max. Continuous. Serv. T°

Dimensional Stab. Stronger Heat Requirements Metal Replacement Better product reliability

E&E

22% 69%

• Ret. Mechanical. Perf.
• Max. Continuous. Serv. T°

Dimensional Stab.

Industrial

23% 60%

Medical & Healthcare

12% 39% Peak T° Resistance

• Ret. Chemical Resist.
• Ret. Mechanical Perf.

Aerospace & Defense

21% 63%

• Max. Continuous. Serv. T°
• Ret. Electrical Perf.

Peak T° Resistance

Wiring & Cable

5% 51% Better product reliability Stronger Heat Requirements Thermosets / Composites Replacement

Q4 Average Heat Improvements Required

12

Peak and Maximum Continuous Service temperature

No split 226 respondents

24% need +10 to +20°C 20% need +25 to +35°C 38% need more than 35°C 23% need +10 to +20°C 24% need +25 to +35°C 34% need more than 35°C

Source: SpecialChem Market Survey based on 226 plastics professionals 50% Specifiers / 50% Material supplier, Nov 2010.

Q5: Polymer considered for higher heat applications

Engineering plastics users

13

43% 30%

Amorphous Semi-crystalline

15% 12%

PA66 17% PPA 13% PBT/PET 11% PC 10% PPS 9% PEEK 8% Polysulfone 7% PEI 6% PA 4,6 5% POM 5% PI 4% PA12 2% PAI 2% LCP 1%

0% 15% of applications could switch to HH amorphous materials

Commodities

• Eng. Plastics

High perf. Plastics Specialties

Source: SpecialChem Market Survey based on 226 plastics professionals 50% Specifiers / 50% Material supplier, Nov 2010.

Q5: Polymer considered for higher heat applications

Amorphous High Heat Polymer users

14

18% 18%

Amorphous Semi-crystalline

38% 18% 0%

PC 8% HHPC 8% PA66 9% PEI 17% PET/PBT 9% PPS 9% PEEK 9% PI 9% PSU 13% PPA 9%

8%

Commodities

• Eng. Plastics

High perf. Plastics Specialties

Source: SpecialChem Market Survey based on 226 plastics professionals 50% Specifiers / 50% Material supplier, Nov 2010.

18% of applications could switch to HH amorphous materials

Q6: Material considered to replace metal

Many High Heat Plastics will be considered….

15

Source: Metal replacement opportunities Specialchem market survey, 235 respondants, 45% OEMs, 55% polymer suppliers, Jan 2010.

 Strong trends for weight saving, system cost reduction and more compact design will drive…  Demand for materials with Higher heat performances and higher stiffness/impact balance.  Stronger pressure in Automotive under-the-hood , E&E, Industrial and Aerospace seeking average improvements of 20 to 25°C (peak, RTI…)  These trends will also drive demand for extreme heat resistant materials  There is room for materials with intermediate performances between PEEK, PI and High Heat polymers.

Conclusion

16

Part II Extreme Heat Solutions From SABIC Innovative Plastics E-Seminar, April 15, 2011 In Special Cooperation with SpecialChem

Presenters: Peter Catsman, Global PMM High Heat resins Kapil Sheth, Global Product Technology Manager

18

1. Introduction 2. High Heat – What are you looking for.. 3. Case studies - Market and Value offerings 4. Wrap-up 5. Questions Today’s Agenda

19

High Heat… your challenges?

Short Term Heat Resistance? Long Term Heat Resistance? Additional Factors:

• dimension stability
• mechanical load
• chemical environment

EXTEM* TPI Resins:

• Melt Processable, Extreme

Environment Thermoplastics

• Based on proprietary amines

and anhydrides

• Proprietary blend technology

with e.g., PEEK resin

Heat

High Perf. Amorphous:

v Modulus at elevated

temperature

v Dimensional

stability

v Creep resistance

High Perf. Crystalline:

v Continuous use temp. v Chemical resistance v Wear resistance

Amorphous Crystalline

PBI PAI PI PPS LCP PTFE PEEK HH PC PSU PES ULTEM* PEI resin PPSU PA46 PPA Chemical Resistance

Ultra High Performance:

v High temp. load bearing v Low & stable CTE . vTypically must have

imidization step

The top of the Pyramid

XH UH UP

EXTEM

VH

Closing the Gap to the Top!

21

EXTEM* product families

Extem UH resins

• Glass transition > 300ºC
• Chemical resistance
• High continuous use Temp.
• RTI up to 260°C

Extem XH resins

• Glass transition ~ 267ºC
• High temperature creep
• High flow for thin wall
• Lead-free solderable

Extem UP – PEEK blends

• Strength/Stiffness/Creep at Temp.
• Outstanding Chemical Resistance
• High Flow
• RTI of 240ºC

Extem VH resins

• Glass transition ~ 247ºC
• Metalizable
• High flow for thin wall
• Cost/performance

LNP Specialty Compounds

for

• Lubrification
• Carbon Fibers

22

Performance offerings

23

• EXTEM XH/UH maintain stiffness up to Temp’s as High as ~280°C
• EXTEM UP blends offer 5-8x more stiffness vs. PEEK and PPS at high Temp’s

Looking for stiffness up to high Temperatures?

EXTEM UP

10 100 1000 10000

50 100 150 200 250 300 350 Temperature [°C]

Modulus [MPa]

ULTEM* resin PEEK PPS

Tailorable Tg Tailorable Modulus

EXTEM* UH resin EXTEM XH

DMA curves for unfilled resins

24

Extem UP Blends offer significantly higher strength at >150°C vs. PEEK

20 40 60 80 100 120 140 160 23ºC 150ºC 200ºC 250ºC Flex Strength [MPa] PEEK UP1004 UP1007 20 40 60 80 100 120 140 160 23ºC 150ºC 200ºC 250ºC Flex Strength [MPa] PEEK UP1004 UP1007

Looking for strength up to high Temperatures?

25

Looking for stiffness and strength up to high T’s? The Positive Effect May Stay With Reinforcements

40 50 60 70 80 90 100 5000 10000 15000 20000 25000 Tensile Modulus [MPa] Tensile Strength [MPa]

PPS PEEK PEI

Extem UP blend Extem UH resin 30% CF-Filled - Tensile Properties at 200°C

26

Specific Tensile strength of Extem XH1005 may

• utperform some Die Cast Aluminum’s at >170°C

Add Extem XH2315 data and new data

Looking for strength up to high Temperatures?

Aluminum/EXTEM* XH resin Comparison Specific Tensile Strength

10 20 30 40 50 60 70 80 50 100 150 200 250 300

Temp °C Specific Tensile Strength (MPa cm

3/g)

EXTEM XH1005 resin Aluminum 6063-T5 Aluminum 1100-H18

27

Looking for dimension control up to high T’s? Extem UH resin and UP blends may offer 30-50% lower dimension change at 200ºC versus PEEK resin

0.0 0.5 1.0 1.5 2.0 2.5 3.0 50 100 150 200 250

Temperature °C Dimension Change [%]

PEEK UP1004 UP1007 Extem

D 50% 0.0 0.5 1.0 1.5 2.0 2.5 3.0 50 100 150 200 250

Dimension Change [%]

PEEK UP1004 UP1007 EXTEM* resin

D 50%

28 0.1 0.2 0.3 0.4 0.5 0.6 0.7 1.E+01 1.E+02 1.E+03 1.E+04 1.E+05 1.E+06 Time [s] Strain [%] Extem* UP blend Extem UH resin PEEK PPS

30% Carbon Fiber Reinf. - Creep @ 150°C/25MPa

High Temperature Creep may be less for Amorphous materials Looking for low creep up to high T’s?

29

• RTI according UL746B is a long term temp. rating for electrical equipment.
• Temp at which 50% of tensile -, electrical strength are retained after 100khrs = 11 yrs exposure

Are you looking for High Continuous Use Temp.?

Relative Thermal Index (UL746B)

A method for continuous use temperature

• EXTEM UH1019 resin has an unparalleled RTI rating of 260°C
• At shorter exposure times higher heat exposures are possible

100 120 140 160 180 200 220 240 260 280 300 PEI TPI PES TPI/PEEK PEEK PPS PPA PA 4,6 PA 6,6 RTI [°C]

unfilled 30%GF

30

23°C, 7 day, Immersion Chemical Extem UH1006 Polyamideimide (PAI) Sulfuric Acid (10%) 95% 104% Hydrochloric Acid (20%) 91% 104% Sodium Hydroxide (10%) 93% 98% Methylethey ketone (MEK) 93% 103% Toluene 97% 106%

• -Dichlorobenzene

98% 107% % Strength Retention

Extem UH resins offer excellent chemical resistance Looking for chemical resistance?

31 Aircraft OSU heat FAR and OEM release Specs FAR 25.853 Extem UH1006 0/21 Extem EXEM0025 0/14 Extem UP1017 0/49 Extem XH1005 3/41 Extem VH1003 11/46 Ultem 1000 35/65 Ultem 9085 20/40

Looking for extreme flame retardancy?

Limiting Oxygen Index (LOI) & UL94

Aircraft Flammability:

 FAR25.853, vertical burn a(60s) - PASS  Smoke Density ABD0031/BSS7238 – PASS  Smoke Toxicity ABD0031/BSS7239 – PASS  OSU Heat release 55/55 - PASS

Extreme Flame-Smoke-Tox Performance

 Halogen Free, RoHS compliant  UL94 V0 at extreme thin gauge  Pushing the LOI envelope LOI (%) UL94 V0 (mm) Ultem* PEI resin 45 1.6 PEEK 35 1.6 PAI 45 1.2 Extem* XH1005 resin 45 0.4 Extem UH1006 47 0.4 Extem EXEM0025 53 0.4

32

Are you looking for simple thermoplastic processing?

Molded Parts Part Inspection Load Ovens Part Inspection Part Inspection Low Yield Overall (40-60%) ~95% Yield Overall PAI* EXTEM* resins

several days

Unusable Losses Reusable Loss Unload Ovens CURE Parts

Processing simplicity

 May provide easy processing  May provide as molded properties  Potential High yields

* Customer feedback

Reusable Loss

33 Molding # 2 Sprue/Runner Regrind Virgin Resin Molding # 1 Molding # 4 Sprue/Runner Regrind Sprue/Runner Regrind Molding # 3

75% 75% 75% 100% 25% 25% 25%

Extem resins may offer: Sustainable Solutions – Maximized Yield and Re-use Rework Study Extem* UH1016 resin

Izod Impact 100% 77% 103% 104% Viscosity 100% 104% 105% 101% 100% Virgin Resin 25% Regrind, 1 Pass 25% Regrind, 2 Pass 25% Regrind, 3 Pass Flexural Strength 100% 101% 101% 100% Tensile Strength 100% 94% 104% 103% Heat Distortion Temp 100% 100% 100% 100%

34

Processing techniques



Extem* resins can be processed with different techniques

35

Looking for Ultrafine Powders?

Volume % Particle Size mm)

<45mm

Viable grades: Ultem* 1000 resins Siltem* resins Extem* VH1003, XH1005 resins Expanding the portfolio with Ultrafine Powders Ultrafine Powder Development:

• new technology to create micronised powders
• particle size < 45micron
• larger sample availability as of 5/2011

36  Upfront application/process assessment  Prepare a trial plan  Involve SABIC personnel  Perform the trial  Involve SABIC personnel  Analyze the results  Involve SABIC personnel  Celebrate success (Involve SABIC personnel..)

EXTEM* Resin Processing Trials, recommendations

37

High Temperature Performance

(Strength, Creep, Dimensional Stability)

Thermoplastic Benefits

(Melt Processing, Regrind, Recycle, Molding)

Thermoset-like Thermoplastic PI PAI

TPI Resins & Blends

PEI PEEK

Summary

Extem* resins may offer:

 Thermoplastic, as molded properties  Short and Long term Heat performance  Maintained mechanical and dimension stability at high Temp’s  Extreme, halogen free FR performance

Desired

38

Case Studies - Market look and value offering

39

Potential Applications

• Chip Trays
• Pick up systems
• Vacuum chamber components
• Test Sockets

Potential features:

• Cleanliness (low out gassing and - ionic content)
• UL746C RTI listings up to 260°C
• Dimension stability
• Strength/Creep resistance at high T’s
• High LOI’s up to 53%

Semiconductor Market

Portfolio:

Extem UH, Tg up to 300°C+ Extem UP, Tg = 145/300°C, TM = 345°C

• Std. Flow

UH1016 Unfilled UP1004 Easy Flow UH1026

Highest Heat

EXEM0025 30% GF Dvlpmntl

Portfolio:

PEEK rich Unfilled UP1017 30% GF Dvlpmntl UH rich

40

Potential features:

• Dimension Stability
• Strength at high temperatures
• Direct metallization
• Transparency
• visible
• near IR light
• Lead-free soldering
• System Cost

Potential Applications

• Defense, Aerospace Connectors
• LED Substrates
• Wire insulation
• Film
• Industrial/Domestic lighting

E&E + Lighting

Extem XH, Tg = 267°C Extem VH, Tg = 247°C

• Std. Flow

XH1005

• Std. Flow

VH1003 Easy Flow XH1015 30% GF XH2315 30% GF developm ent

Portfolio:

41

Automotive

Portfolio:

Potential features:

• Direct Metallization
• Haze Onset ~250oC
• Transparency for near IR light
• Dimension stability
• System Cost

Potential Applications

• Main Beam Reflectors
• Fog light reflectors
• Brackets/housings
• Turbo Chargers

Extem VH, Tg = 247°C

• Std. Flow

VH1003(F) 30% GF development

Extem XH, Tg = 267°C

• Std. Flow

XH1005 Easy Flow XH1015 30% GF XH2315

42

Potential features:

• Strength/Creep resistance at high temp
• Dimension stability at high temp
• High Continuous Use Temperature
• Chemical resistance
• Thin wall

Potential Applications

• Pump/valve linings/seats
• Seals
• Bearings
• Gears
• Bushings
• Composites
• Coatings

Industrial

Portfolio:

Extem UP, Tg = 145/300°C, TM = 345°C Extem UH, Tg up to 300°C+

Lubricated

Crystalline Extem Blend CF/Graphite/PTFE

• r CF/PTFE

Graphite/PTFE

Structural/ Conductive

30% CF ESD Crystalline Extem Blend Amorphous Extem Blend 30% CF

LNP portfolio:

43

Potential features:

• Baking temps up to 250°C/482°F
• Food Contact Approvals
• Excellent Stain resistance
• Scratch Resistance
• Metal Adhesion
• Durability
• Thin Wall
• (Limited) color availability

Potential Applications

• Bread Baking Trays
• Oven ware
• Oven components
• Binder for PTFE coatings

Extem XH, Tg = 267°C Extem VH, Tg = 247°C

• Std. Flow

XH1005F

• Std. Flow

VH1003F Easy Flow XH1015F 30% GF XH2315F 30% GF Dvlmnt

Portfolio:

Food Service

*

44

High Temperature Performance

(Strength, Creep, Dimensional Stability)

Thermoplastic Benefits

(Melt Processing, Regrind, Recycle, Molding)

Thermoset-like Thermoplastic PI PAI

TPI Resins & Blends

PEI PEEK

Summary page

Extem* resins may offer:

 Expanded Range of properties  Opportunities for improvements over current solutions  New opportunities for metal, thermoset or ceramic replacement  Provide lower system cost solutions

Desired

45

Disclaimer:

THE MATERIALS, PRODUCTS AND SERVICES OF SABIC INNOVATIVE PLASTICS HOLDING BV, ITS SUBSIDIARIES AND AFFILIATES (“SELLER”), ARE SOLD SUBJECT TO SELLER’S STANDARD CONDITIONS OF SALE, WHICH CAN BE FOUND AT http://www.sabic-ip.com. AND ARE AVAILABLE UPON REQUEST. ALTHOUGH ANY INFORMATION OR RECOMMENDATION CONTAINED HEREIN IS GIVEN IN GOOD FAITH, SELLER MAKES NO WARRANTY OR GUARANTEE, EXPRESS OR IMPLIED, (i) THAT THE RESULTS DESCRIBED HEREIN WILL BE OBTAINED UNDER END-USE CONDITIONS, OR (ii) AS TO THE EFFECTIVENESS OR SAFETY OF ANY DESIGN INCORPORATING SELLER’S PRODUCTS, SERVICES OR RECOMMENDATIONS. EXCEPT AS PROVIDED IN SELLER’S STANDARD CONDITIONS OF SALE, SELLER SHALL NOT BE RESPONSIBLE FOR ANY LOSS RESULTING FROM ANY USE OF ITS PRODUCTS OR SERVICES DESCRIBED HEREIN. Each user is responsible for making its own determination as to the suitability of Seller’s products, services or recommendations for the user’s particular use through appropriate end-use testing and analysis. Nothing in any document or oral statement shall be deemed to alter or waive any provision of Seller’s Standard Conditions of Sale or this Disclaimer, unless it is specifically agreed to in a writing signed by Seller. No statement by Seller concerning a possible use of any product, service or design is intended, or should be construed, to grant any license under any patent or other intellectual property right of Seller or as a recommendation for the use of such product, service or design in a manner that infringes any patent or other intellectual property right. SABIC Innovative Plastics is a trademark of SABIC Holding Europe BV * Trademark of SABIC Innovative Plastics IP BV
