The Search for Answers Myth busting lessons for those creating new fuels from oil shale Myth: Oil is becoming less important Fact: Countries continue to strive to grow their economies... 14,000 USA 12,000 GDP (USD Billion PPP) 10,000
SLIDE 2
SLIDE 3
Fact: Countries continue to strive to grow their economies...
Source: EnergyQuest 2009
2,000 4,000 6,000 8,000 10,000 12,000 14,000 1,000 2,000 3,000 4,000 5,000 6,000 7,000 8,000
GDP (USD Billion PPP)
Oil Consumption (Million Barrels)
ITALY INDIA FRANCE UK JAPAN CANADA AUSTRALIA GERMANY INDIA CHINA USA
SLIDE 4
...but myths continue to abound about fossil fuels...including oil shale!
SLIDE 5
Myth: Shale oil production generates 400% more GHG emissions than conventional oil
Source: Monica Richter, Australian Conservation Foundation, ABC TV 7.30 Report, 9 August 2010
SLIDE 6
Fact: CO2 emissions penalty 20% - 63%....
0.5 1 1.5 2 2.5 3 3.5 4 ULS Diesel, Current Australian Blend 100% Imported Crude Diesel Biodiesel, Canola CNG LNG LPG GTL CTL STL Base Case STL Modified Plant Case Source: RARE Consulting 2009
All ¡figures ¡indicate ¡kg ¡CO2e ¡per ¡km ¡travelled ¡in ¡43t ¡ar9culated ¡truck ¡
SLIDE 7
...and CO2 emissions levels can go lower
Cogeneration/ waste heat utilisation Solar thermal power Offsets, algal sequestration?
SLIDE 8
Myth: Processing shale oil uses vast amounts of water
SLIDE 9
Fact: 1:1 ratio of water used to oil produced
Source: HATCH Engineering and UniQuest 2009
SLIDE 10
Producing shale oil uses less water than other industrial processes....
Uniquest 2009
SLIDE 11
...and other fuel processes....
Uniquest 2009
SLIDE 12
Myth: It takes more energy to produce shale oil than the energy content of the shale oil produced...
Energy Out/Energy In < 1
Myth (?): ...and, energy return on energy invested (EROI) is a valid method for comparing the merits of alternative energy sources...
SLIDE 13
So many variables and so many boundary decisions render comparisons meaningless
Fact: ...there is no widely accepted protocol for calculating EROI.
SLIDE 14
Imperatives:
- “…if the cost of energy required to produce
shale oil is greater than the market value of the shale oil produced, it won’t get produced.”
- [ref: Shell’s M. King Hubbert]
- If left in the ground, the energy benefit of oil
shale to society is ZERO.
SLIDE 15
Myth: Oil shale “explodes” like popcorn when heated (i.e., retorted)
SLIDE 16
Facts:
In Situ 1650
Actual Bulk Density Measurements on Australian Shale (kg/tonne)
(+Voids) =
(- Weight) =
Crushed Shale 853 Retorted Shale 650
SLIDE 17
Fact: …sorry folks, there is no “popcorn effect”
SLIDE 18
Myth: Communities will not support
- il shale oil development
SLIDE 19
In Summary
- Myths and misconceptions continue to plague the
- il shale industry
- Proponents should:
- do good scientific work and subject it to peer
review
- be transparent – let the facts do the talking
- Shale oil is a legitimate option for our transport
fuel future
