SLIDE 1

1

The Open IoT Stack: Architecture and Use Cases

James Kirkland – Chief IoT Architect, Red Hat Marco Carrer – CTO, Eurotech

SLIDE 2

2

Diverse set of technologies, features, standards, and point solutions, each

f which promises to be the panacea

Avoid being locked in by a single vendor and seek modular and standard solutions

Lack of Open Standards Vendor Lock-in

Must integrate operational technology with information technology to be able to derive insights at the edge and in the cloud

Fragmentation

TODAY’S IoT CHALLENGES

SLIDE 3

3

Open Source Cloud

PRINCIPLES of an OPEN IoT ARCHITECTURE

Open & Interoperable

Based on open source and open industry standards Accelerates innovation with no lock-in, enables eco-systems

Modular yet Integrated

Integration at the edge and in the data center Ready-to-use building blocks for a faster time to market

End-to-End Security

Enterprise- grade data security and compliance - from the edge, all the way through to storage and access

IT / OT Management

Manage field devices and the data center Improved operational efficiency with flexible deployments

SLIDE 4

4

Securely connect, authenticate and manage disparate connected devices that speak different protocols Apply analytics at the edge with machine learning and business rules to enable local, low-latency decision making Centralize IoT data processing, analytics and machine learning to enable deep business insights and actionable intelligence Enable integration with enterprise and business applications to bridge the gap between OT and IT and reduce complexity Tools to enable end-to-end data security, compliance, authorization and authentication

FEATURES of an OPEN IoT ARCHITECTURE

Device Management & Connectivity Intelligent Edge Processing & Analytics Advanced Analytics & Machine Learning Business & Application Integration End-to-End Security & Compliance

SLIDE 5

5

DATA MANAGEMENT & ANALYTICS PLATFORM

Integrating IoT operating technology, data management, analytics, and applications

IoT GATEWAYS CONNECTED “THINGS” IoT INTEGRATION HUB ENTERPRISE APPLICATIONS

OPEN END-TO-END IoT ARCHITECTURE

SLIDE 6

6

Connected “Things”

Sensors, Actuators, Data Sources

OPEN END-TO-END IoT ARCHITECTURE

Integrating IoT operating technology, data management, analytics, and applications

SLIDE 7

7

IOT Gateways Connected “Things”

Sensors, Actuators, Data Sources Edge Processing & Analytics

Device connectivity
Remote management
Data transformation
Intelligent routing
Business logic
Real-time decisions
Machine learning

execution

I/O services

OPEN END-TO-END IoT ARCHITECTURE

Integrating IoT operating technology, data management, analytics, and applications

SLIDE 8

8

IOT Gateways IOT Integration Hub Connected “Things”

Sensors, Actuators, Data Sources Data Integration, Routing, Device Command/Control Edge Processing & Analytics

Device connectivity
Remote management
Data transformation
Intelligent routing
Business logic
Real-time decisions
Machine learning

execution

I/O services
Device registry and

management

Device provisioning
Message routing
Data collection
Event management
Integration services
Access control

OPEN END-TO-END IoT ARCHITECTURE

Integrating IoT operating technology, data management, analytics, and applications

SLIDE 9

9

IOT Gateways Data Management & Analytics Platform IOT Integration Hub Connected “Things”

Sensors, Actuators, Data Sources Data Integration, Routing, Device Command/Control Edge Processing & Analytics Advanced Analytics & Machine Learning

Device connectivity
Remote management
Data transformation
Intelligent routing
Business logic
Real-time decisions
Machine learning

execution

I/O services
Device registry and

management

Device provisioning
Message routing
Data collection
Event management
Integration services
Access control
Data ingest
Real-time processing
Data storage
Machine learning
Real-time analytics
Data security

OPEN END-TO-END IoT ARCHITECTURE

Integrating IoT operating technology, data management, analytics, and applications

SLIDE 10

10

IOT Gateways Data Management & Analytics Platform IOT Integration Hub Enterprise Applications Connected “Things”

Sensors, Actuators, Data Sources Data Integration, Routing, Device Command/Control Edge Processing & Analytics Application Development, Deployment, Integration Advanced Analytics & Machine Learning

Device connectivity
Remote management
Data transformation
Intelligent routing
Business logic
Real-time decisions
Machine learning

execution

I/O services
Device registry and

management

Device provisioning
Message routing
Data collection
Event management
Integration services
Access control
Data ingest
Real-time processing
Data storage
Machine learning
Real-time analytics
Data security
Application development and

management

Self-service provisioning
Persistent storage
Polyglot, multi-language

support

Automation
Scalability
Container portability
Deployment flexibility

OPEN END-TO-END IoT ARCHITECTURE

Integrating IoT operating technology, data management, analytics, and applications

SLIDE 11

11

IoT GATEWAYS IoT INTEGRATION HUB ENTERPRISE APPLICATIONS CONNECTED “THINGS” DATA MANAGEMENT & ANALYTICS PLATFORM

Real-Time Analytics Data Ingest Real-Time Processing Data Storage Machine Learning Data Security

Telemetry Data

Application Integration Application Data Management

Telemetry Data

Integrating IoT operating technology, data management, analytics, and applications

OPEN END-TO-END IoT ARCHITECTURE

SLIDE 12

12

WHY OPEN SOURCE FOR IoT

SLIDE 13

13

IOT Gateways IOT Integration Hub CONNECTED “THINGS” Enterprise Applications

AN END-TO-END OPEN SOURCE ARCHITECTURE FOR IoT: Products

Sensors, Actuators, Data Sources Data Integration, Routing, Device Command/Control Edge Processing & Analytics Application Development, Deployment, Integration Advanced Analytics & Machine Learning

Data Management & Analytics Platform

Community Data Hub

Mobile and Web Business Applications

SLIDE 14

14

SLIDE 15

15

Develop IoT Edge Computing Apps

Wires Data Flow SQL Database Full Java APIs

Connect to Field Devices

Industrial Protocols Modular Drivers

Connect to IoT Cloud Services

Multiple Connections Message Routing Digital Twins

RS 232/485 Bluetooth Low Energy USB CAN bus GPS/GNSS GPIO/I2C/PWM

Everyware Cloud AWS IoT Azure IoT Eclipse Kapua Other

SLIDE 16

16

SLIDE 17

17

Application Integration Security Device Management Data Management Device Connectivity (A-MQ)

Mobile & Enterprise Application s

@

Alerts & Notifications JBOSS BRMS

Message Routing (Fuse)

Enterprise Integration Patterns JBOSS Fuse

Administration Real-Time Analytics

Data Dashboard s Business Intelligence ETL Hooks

Device Registry MQTT Storage Account Management Access Control REST API Device Mgmt Console Device Management Protocols Device Provisioning Device Batch Operations IoT Devices and Gateways

Cellular Connectivity / SIM Management Platforms

SLIDE 18

18

SLIDE 19

19

Device Provisioning
Application Life-cycle Management
Service Configuration Management
Security / Certificate Management
Device Batch Operations & Groups
Remote Access and Maintenance
Remote Log Retrieval
Digital Twin for Gateway and Field Devices

MQTT

n

Security Administration Data Management Device Connectivity Application Integration Device Management

Field Devices, PLC’s

SLIDE 20

20

IOT Gateways IOT Integration Hub CONNECTED “THINGS” Enterprise Applications

AN END-TO-END OPEN SOURCE ARCHITECTURE FOR IoT: Products

Sensors, Actuators, Data Sources Data Integration, Routing, Device Command/Control Edge Processing & Analytics Application Development, Deployment, Integration Advanced Analytics & Machine Learning

Data Management & Analytics Platform

Enterprise Data Hub

Mobile and Web Business Applications

SLIDE 21

21

IoT Use Cases

SLIDE 22

22

Connected Clinics

Application:

Connect machines to the internet in a

nonintrusive way

Provide nurses with access to machine status
Provide manufacturers access to machine logs
Enable remote maintenance with less field visits

Key Success Factors:

Open Standard Connectivity
Device Provisioning
Remote Access VPN
Onboarding and Data Acquisition App
Port/IP Forwarding
Cellular Connectivity

powered by powered by

SLIDE 23

23

BOILER GATEWAY IOT APPLICATION IOT PLATFORM CONSUMER SERVICE CENTER

Application:

End users to remote control their own thermo-

devices

For technical assistance operators to perform

remote diagnostics

Valuable data for R&D, Service, Marketing

departments to develop & sell new products and services Key Success Factors:

Service-oriented business model
Open and industry standards based
ESF hardware abstraction, Java/OSGi
Remote device & embedded app. mgmt.
Real time data
M2M / IoT know how in Eurotech
Eurotech worldwide footprint

Connected Product

powered by powered by

SLIDE 24

24

Connected Plant

Computationally intensive algorithms for data manipulation and analysis

Application:

Failure Monitoring and Predictive Maintenance
Smart sensor and analytics capabilities at the

edge

Powerful analytics and visualization solutions

at the enterprise IT level Key Success Factors:

Flexibility of the platform
Advanced Analytics and Pattern Matching at the

gateway (Fog/Edge Computing)

Multiple Cloud connections

powered by powered by

SLIDE 25

25

Application:

Cloud based automatic passenger

counting (APC) system

Equip trams with Eurotech’s passenger

counters and a gateway

Real time planning of route, optimizing use
f the fleet
Application for Data Statistics, combining

passenger counts, GPS positioning, door

pen/close events and other route

information Key Success Factors:

Complete end-to-end solution
Advanced PCN technology
High accuracy
Short development time
Easily integration with web app
Cost effective
Scalable for future requirements

DynaCOR PCN-1000

Connected Public Transporation

powered by powered by

SLIDE 26

26

Business Requirements:

Active remote monitoring and control of

various systems in a building

End-to-end solution with bi-directional

communication to all kind of sensors and actuators

data and process hub for energy-related

services and operative asset management.

Value-added services around buildings for

energy suppliers and facility service providers Benefits from:

Pay-per-use business model
Comprehensive tool for service and asset

management

Maintenance cost reduction
Increase availability and reliability for

costumers

Improve quality assurance of existing SLA

CUSTOM MULTISERVICE GATEWAY IOT CLOUD PLATFORM

Portal Operator B2B Customers

Flexible Energy Appliance

Field Service

Energy Management

powered by powered by

SLIDE 27

27

Connected Trains

Application:

On board diagnostics
Data collection for optimization and predictive

maintenance

Remote access and maintenance
Railway certified hardware with MVB interface
On premise device management and data

integration Key Success Factors:

Open Standard Connectivity
Modular Field Access Drivers
Data Flow Programming
Portable IoT Edge Middleware
On-premise IoT Cloud Platform

powered by powered by

SLIDE 28

28
