The New Bearing Gard TM

Customer Presentation

2

Agenda

Welcome to the Bearing Gard

• Introduction
• Product overview
• Design qualification
• Same Day shipment
• Support materials

3

Why use a Bearing Gard?

Extend rotating equipment life and improve reliability with the Bearing Gard

• Prevent contamination ingress

– Extend oil and bearing life – Eliminate #1 cause of rotating equipment failure

• Provide long term oil retention

– Reduce bearing and lube operating temperature – Extend bearing and lubrication life – Improved housekeeping and safety

• Added protection at shutdown

– Shut-off O-ring blocks air transfer

• Create a positive return on investment

– An average investment of $400 per pump or motor can prevent maintenance or repair costs of $5,000 - $20,000 and more

4

Where do I use the Bearing Gard?

General bearing seal replacement (lip or labyrinth) in:

• All types of non-flooded bearing seals in rotating equipment
• Pumps: ANSI, ISO, API 610 and more
• Electric motors: IEEE-841, severe duty, washdown and more
• Gearboxes: non-flooded oil lubrication and grease

5

The Bearing Gard

Completely Redesigned for World Class Performance

• Technical Performance

– Superior contamination exclusion – Includes static ‘shut-off’ technology – Excellent oil retention – Easy installation

• Delivery Performance

– Automated design process – Built for industry-driven quick shipments – Including “Same-Day” shipment for unique sizes

6

Bearing Gard Qualification Testing

Performance validated from 22 to 150 mm (.875 to 6.000 inches)

• No contact, wear or heat generation from 0 - 3600 rpm
• Confirmed to hold static vacuum
• Oil retention for standard and overfill situations from 0 - 3600 rpm
• High velocity water spray performance

7

Bearing Gard Validation Testing

High velocity water spray test simulates extreme conditions

Low Velocity High Velocity

8

Bearing Gard General Design

Every aspect has been optimized

1. Pressfit in housing 2. Stator O-ring 3. Protected interface 4. Contamination channel 5. Contamination outlet 6. Unique dual drive O-ring 7. Innovative static shut-off barrier 8. Oil collection chamber 9. Protected oil outlet

• 10. Improved unitization

1 2 6 3 8 9 4 7 5 10

9

Key Features

Unitization with axial runout

• Improved unitization feature
• Prevents shut-off O-ring binding
• Axial runout up to 0.63 mm (0.025 in)
• Exceeds competition’s standard axial

runout of 0.13 mm (0.005 in)

10

Innovative shut-off design

• Improved static sealing
• Tapered shoulder creates positive side wall

sealing at all times

• Dynamically lifts off to prevent wear at
• perational speed
• Increased reliability by preventing O-

ring binding

Key Features

RPM

11

Bearing Gard

A more reliable solution

• Older design issues start at

axial runout of 0.17mm(.007 in)

• Minor binding with heat / wear
• Major binding causes

catastrophic drive o-ring failure

• Extreme binding causes shaft

damage and extreme heat

Rotor Stator

12

Unique double drive ring

• Superior shaft grip
• Improved rotor stability
• Compact size

Key Features

13

Key Features

Installation alignment notch

• Located at the 12 o’clock

position

• 180 degrees from outlet ports
• Customer requested feature
• Not present on Inpro designs
• Helps orientation for installation
• Easy check for proper

assembly

14

Key Features

Part Marking now standard

• “Flowserve”
• Part number
• Engraved on rotor OD (quick

shipment)

• Optional Laser on rotor face

(high volume)

15

Bearing Gard Core Design

Core Design = Quick ship / Lowest cost

• Core Design Parameters:

– Shaft Diameter: 23 – 203 mm (0.875 - 8.000 in) – Housing Bore: 20-50 mm (0.750-2.000 in) over shaft for shaft sizes up to 150 mm (6.000 in) – Housing Bore: 25-50 mm(1.000-2.000 in) over shaft for shaft size over 150 mm (6.000 in) – Length: see image to right – O-rings: FKM - up to 190 ° C(375 °F) – Rotor and Stator: Bronze

• Core Application Range:

– Oil splash, grease, oil mist, dry lube – Non-flooded conditions – Radial runout up to 0.13 mm (0.005 inch) – Axial runout up to 0.63 mm (.025 inch)

8.3 mm (0.325”)

Bore up to 5.375”

9.5 mm (0.375”) 9.5 mm (0.375”)

Bore over 5.375”

16

Bearing Gard Core Design

Core design easily retrofits where standard competitive designs were used

17

Bearing Gard Core Design

Ten questions to determine if the Bearing Gard ‘Core’ design is OK to use:

1. Is Shaft Diameter 0.875" - 8.000" (23 - 203 mm)? 2. Is Cross Section (Housing Bore - Shaft OD) 0.75" - 2.000" (20 - 50 mm) for shaft sizes up to 6.000 inch (152 mm) or 1.00”-2.00” (25 - 50 mm) for shaft sizes greater than 6.000 inch (152 mm)? 3. Is Insertion of 0.325" (8.3 mm) for Housing Bore up to 5.375” (136 mm) or 0.375" (9.5 mm) for Housing Bore over 5.375” (136 mm) OK? 4. Is Protrusion of 0.375" (9.6 mm) OK? 5. Is the axial movement 0.025 inch (0.63 mm) or less? 6. Is the radial shaft Movement 0.005 inch or less (0.13 mm)? 7. Is the Shaft Speed less than 100 ft/s (30m/s)? 8. Is the oil Lubrication not flooded (oil level below shaft)? 9. Is the shaft Temperature less than 375°F (190°C)?

• 10. Are the Materials bronze and Viton?
• If yes to all, the core design is OK to use
• If no to any, contact Flowserve for an “Engineered” solution

18

Bearing Gard “Engineered” Designs

Designs to fit various equipment types

Short insertion Large cross-section Narrow cross-section Vertical Up Stepped shaft

19

Bearing Gard Smart Part Code

New Smart Part Code streamlines the

• rder process
• BGVXXXXYYYYZZMO

– BG – Product family – V – design variation

• C = core design
• P = pump-specific design

– XXXX – shaft diameter

• 2000 = 2.000 inch
• M080 = 80 mm

– YYYY – housing bore

• 3000 = 3.000 inch
• M100 = 100 mm

– ZZ – equipment variation

• SD = Standard core design
• DX = Durco standard

– M – Metal

• B = Bronze

– O – O-ring

• V = FKM material (Viton)

Part code examples

• Core example 2.000 x 3.000

– BGC20003000SDBV (-SDBV for all core designs)

• Durco MKIIIGP3 radial end

– BGP26253677DXBV

20

Equipment-Specific Bearing Gard Designs

Popular pump-specific designs available in stock today

• Durco:

MK III, MK II, GP 1, 2, 3

• Goulds:

3196, 3175

• Sulzer:

APP/APT, CPT

• Many additional equipment specific solutions are available
• Contact Flowserve to determine which design is best for you

21

Equipment Specifications

Bearing Gard isolators satisfy industry standards and certifications

• API 610 compliant
• IEEE-841 compliant (Electric Motor)
• IP66 certified
• ATEX – contact product manager for details

– Ɛ II 2 GD c – Ɛ I M2 c

22

Bearing Gard Packaging

Bearing Gard isolators arrive ready for installation

• Installation instructions
• Shaft lubricant (Pac-Ease)

23

Easy quote and order process

Your local Flowserve Representative is your partner to:

• Identify equipment specific solutions
• Confirm smart part codes
• Confirm pricing
• Confirm same-day ship availability
• Coordinate application data for

engineered designs
