APPENDIX B The impact of the weather Contents Rob Smiths Member Highway Service Update of 27 th January said.... Still busy dealing with the impact of the wet weather The exceptional weather over Christmas and early January is now

slide-1
SLIDE 1

The impact of the weather

APPENDIX B

slide-2
SLIDE 2

Contents

Rob Smith’s Member Highway Service Update of 27th January said.... “Still busy dealing with the impact of the wet weather

  • The exceptional weather over Christmas and early January is now behind

us, it has resulted in a higher number of highway faults than the seasonal average.

  • Teams that normally delivery Category 2 works and our minor HLB

schemes have had to focus their efforts on fixing the high number of highway faults, keeping our highways safe. Potholes - improving repair policy – You said, we did

  • Our recently launched Defect Management Approach means that more

potholes are now repaired permanently first time. This has shown a corresponding reduction in failures of temporary repairs.”

slide-3
SLIDE 3

The impact of the weather

slide-4
SLIDE 4

The impact of the weather

slide-5
SLIDE 5

How we have coped

  • Additional Staff providing cover Operations Hub at nights and

weekends

  • Additional Gangs have been working nights and weekends to

respond to the call outs

  • Teams that normally delivery Category 2 works and our minor

HLB schemes have been diverted to keeping our highways safe

  • Drainage crews focused on EA highlighted “areas of risk”
slide-6
SLIDE 6

Catching up post emergencies

  • The Emergency Protocol

– KPI suspension – Local Control

  • Recovery actions

– Four road sweeper vehicles are being utilised to clear debris where floods have dissipated – Permanent pothole repair catch up – Large scale resurfacing programmes (re-allocating crews)

slide-7
SLIDE 7

The new Defect Management Approach

Defect Types

  • ‘Emergency’ – is a Defect that requires very prompt attention

because they represent an immediate or imminent risk

  • ‘Category 1 Defects’ - are Defects that require prompt

attention because they represent an immediate or imminent risk

  • ‘Category 2 Defects’ are all Defects that are not categorised as

Category 1 Defects

slide-8
SLIDE 8

System categorisation - Potholes

Information requested Response Choice Where is the pot hole? (Mandatory) Road Cycle Lane What is the depth? Please provide your best estimate (Mandatory) Less than 40mm / 1 ½ inch 40mm / 1 ½ inch – 100mm / 3 inch More than 100mm / 3 inch What is the width? Please provide your best estimate (Mandatory) Less than 300mm / 12 inch / 1 foot More than 300mm / 12 inch / 1 foot

slide-9
SLIDE 9

System categorisation - Potholes

How deep is the fault? Less than 40mm Defect Risk Rating = 5 Classification

  • f road/cycle

lane A* Defect Risk Rating = 4 B, C* Defect Risk Rating = 3 Unclassified* Classification

  • f road/cycle

lane 40 - 100mm Defect Risk Rating = 10 A* Defect Risk Rating = 8 B, C* Defect Risk Rating = 6 Unclassified* Classification

  • f road/cycle

lane Defect Risk Rating = 16 A* Defect Risk Rating = 15 Defect Risk Rating = 15 Unclassified* Greater than 100mm B, C* Classification

  • f road/cycle

lane Defect Risk Rating = 20 A, B, C* Defect Risk Rating = 16 Unclassified* Classification

  • f road/cycle

lane Defect Risk Rating = 20 A, B, C* Defect Risk Rating = 15 Unclassified* Classification

  • f road/cycle

lane Defect Risk Rating = 20 Defect Risk Rating = 16 Unclassified* A, B, C* Width of pothole? Width of pothole? Width of pothole? Less than 300mm Less than 300mm Greater than 300mm Greater than 300mm Greater than 300mm Less than 300mm

Defect Risk Rating Potential Probability (P) Very Low (1) Low (2) Mediu m (3) High (4) Very High (5) Potential Impact (I) Very Low (1) 1 2 3 4 5 Low (2) 2 4 6 8 10 Mediu m (3) 3 6 9 12 15 High (4) 4 8 12 16 20 Very High (5) 5 10 15 20 25

slide-10
SLIDE 10

System prioritisation

Defect Category Defect Risk Rating Hazard Mitigation Response Time Permanent Remedy Time Enquiry Subject Code Emergency 25 2hr Assess & Decide Strategy Category 1 20 24 hr Assess & Decide Strategy CPH2 16 n/a 7 days CPH3 15 n/a 14 days CPH4 Category 2(H) 12 – 9 n/a Assess & Decide Strategy CPH5 Category 2(M) 8 – 5 n/a Assess & Decide Strategy CPH6 Category 2(L) 4 – 1 n/a Assess & Decide Strategy CPH7

slide-11
SLIDE 11

Fault reporting

slide-12
SLIDE 12

Fault resolution

CAT 1 (BR0101) Works Received Works Completed Average Received per Month Feb-14 Feb-14 Emergencies 833 833 557 24 Hour 3225 3190 1792 7 Day 1855 1846 1112 14 Day 1724 1507 739 Totals 7637 7376 4200

slide-13
SLIDE 13

Questions and answers

slide-14
SLIDE 14

Inspection categorisation

Impact

Very Low Low Medium High Very High 1 2 3 4 5 < 40mm deep How wide?

< 300 mm > 300 mm

40 – 100 mm deep How wide?

< 300 mm > 300 mm

> 100 mm deep How wide?

SELECT

Probability

Very Low Low Medium High Very High 1 2 3 4 5 < 40mm deep Road Classification

Unclassified B, C A

40 – 100 mm deep < 300 mm wide Road Classification

Unclassified, A, B, C

40 – 100 mm deep > 300 mm wide Road Classification

Unclassified A, B, C

> 100 mm deep Road Classification

Unclassified A, B, C

Defect Risk Rating Potential Probability (P) Very Low (1) Low (2) Mediu m (3) High (4) Very High (5) Potential Impact (I) Very Low (1) 1 2 3 4 5 Low (2) 2 4 6 8 10 Mediu m (3) 3 6 9 12 15 High (4) 4 8 12 16 20 Very High (5) 5 10 15 20 25
