RUB Chair of Communication Systems The DoF of the MIMO Y-channel Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin Chair of Digital Communication Systems RUB, Bochum Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 1

slide-1
SLIDE 1

RUB Chair of Communication Systems

The DoF of the MIMO Y-channel

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin

Chair of Digital Communication Systems RUB, Bochum

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 1

slide-2
SLIDE 2

RUB Chair of Communication Systems

Outline

1 Introduction and previous work 2 MIMO Y-channel 3 Transmission Strategy

An Example Generalization

4 Upper Bounds 5 Conclusion

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 2

slide-3
SLIDE 3

RUB Chair of Communication Systems

The Y-channel

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 3

slide-4
SLIDE 4

RUB Chair of Communication Systems

The Y-channel

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 3

slide-5
SLIDE 5

RUB Chair of Communication Systems

The Y-channel

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 3

slide-6
SLIDE 6

RUB Chair of Communication Systems

The Y-channel

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 3

slide-7
SLIDE 7

RUB Chair of Communication Systems

The Y-channel

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 3

slide-8
SLIDE 8

RUB Chair of Communication Systems

The Y-channel

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 3

slide-9
SLIDE 9

RUB Chair of Communication Systems

The Y-channel

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 3

slide-10
SLIDE 10

RUB Chair of Communication Systems

The Y-channel

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 3

slide-11
SLIDE 11

RUB Chair of Communication Systems

1 Introduction and previous work 2 MIMO Y-channel 3 Transmission Strategy

An Example Generalization

4 Upper Bounds 5 Conclusion

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 4

slide-12
SLIDE 12

RUB Chair of Communication Systems

Two-way Communications

  • Bi-directional channel (Two-way channel) [Shannon 61]

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 5

slide-13
SLIDE 13

RUB Chair of Communication Systems

Two-way Communications

  • Bi-directional channel (Two-way channel) [Shannon 61]
  • Bi-directional relay channel (BRC) [Rankov et al. 05]

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 5

slide-14
SLIDE 14

RUB Chair of Communication Systems

Two-way Communications

  • Bi-directional channel (Two-way channel) [Shannon 61]
  • Bi-directional relay channel (BRC) [Rankov et al. 05]
  • Capacity of the BRC within 1/2 bit [G¨

und¨ uz et al. 08]

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 5

slide-15
SLIDE 15

RUB Chair of Communication Systems

Two-way Communications

  • Bi-directional channel (Two-way channel) [Shannon 61]
  • Bi-directional relay channel (BRC) [Rankov et al. 05]
  • Capacity of the BRC within 1/2 bit [G¨

und¨ uz et al. 08]

  • Deterministic BRC [Avestimehr et al. 09]

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 5

slide-16
SLIDE 16

RUB Chair of Communication Systems

Multi-way Communications

  • Approximate capacity of the multi-pair BRC [Sezgin et al. 09]

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 6

slide-17
SLIDE 17

RUB Chair of Communication Systems

Multi-way Communications

  • Approximate capacity of the multi-pair BRC [Sezgin et al. 09]
  • Approximate capacity of the multi-way relay channel (multicast) [G¨

und¨ uz et al. 09], [Ong et al. 10]

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 6

slide-18
SLIDE 18

RUB Chair of Communication Systems

Multi-way Communications

  • Approximate capacity of the multi-pair BRC [Sezgin et al. 09]
  • Approximate capacity of the multi-way relay channel (multicast) [G¨

und¨ uz et al. 09], [Ong et al. 10]

  • Capacity region of the Y-channel within 7/6 bit [Chaaban et al. 12]

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 6

slide-19
SLIDE 19

RUB Chair of Communication Systems

1 Introduction and previous work 2 MIMO Y-channel 3 Transmission Strategy

An Example Generalization

4 Upper Bounds 5 Conclusion

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 7

slide-20
SLIDE 20

RUB Chair of Communication Systems

The MIMO Y-channel

Uplink:

  • Tx signals xj(i) ∈ RMj, power P

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 8

slide-21
SLIDE 21

RUB Chair of Communication Systems

The MIMO Y-channel

Uplink:

  • Tx signals xj(i) ∈ RMj, power P
  • Uplink channels Hj ∈ RN×Mj,

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 8

slide-22
SLIDE 22

RUB Chair of Communication Systems

The MIMO Y-channel

Uplink:

  • Tx signals xj(i) ∈ RMj, power P
  • Uplink channels Hj ∈ RN×Mj,

Downlink:

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 8

slide-23
SLIDE 23

RUB Chair of Communication Systems

The MIMO Y-channel

Uplink:

  • Tx signals xj(i) ∈ RMj, power P
  • Uplink channels Hj ∈ RN×Mj,

Downlink:

  • Relay signal xr(i) ∈ RN, power P

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 8

slide-24
SLIDE 24

RUB Chair of Communication Systems

The MIMO Y-channel

Uplink:

  • Tx signals xj(i) ∈ RMj, power P
  • Uplink channels Hj ∈ RN×Mj,

Downlink:

  • Relay signal xr(i) ∈ RN, power P
  • Downlink channels Dj ∈ RMj×N,

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 8

slide-25
SLIDE 25

RUB Chair of Communication Systems

The MIMO Y-channel

Uplink:

  • Tx signals xj(i) ∈ RMj, power P
  • Uplink channels Hj ∈ RN×Mj,

Downlink:

  • Relay signal xr(i) ∈ RN, power P
  • Downlink channels Dj ∈ RMj×N,

DoF The DoF per message is defined as djk = limP →∞

Rjk

1 2 log(P ), and the sum DoF

is d = djk.

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 8

slide-26
SLIDE 26

RUB Chair of Communication Systems

MIMO Y-channel

If the MIMO Y-channel has M1 = M2 = M3 = M and N ≥ ⌈3M/2⌉, then the cut-set bound is achievable, i.e., d = 3M [Lee et al. 10].

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 9

slide-27
SLIDE 27

RUB Chair of Communication Systems

MIMO Y-channel

If the MIMO Y-channel has M1 = M2 = M3 = M and N ≥ ⌈3M/2⌉, then the cut-set bound is achievable, i.e., d = 3M [Lee et al. 10]. Question 1: What is the DoF of the MIMO Y-channel in general?

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 9

slide-28
SLIDE 28

RUB Chair of Communication Systems

MIMO Y-channel

If the MIMO Y-channel has M1 = M2 = M3 = M and N ≥ ⌈3M/2⌉, then the cut-set bound is achievable, i.e., d = 3M [Lee et al. 10]. Question 1: What is the DoF of the MIMO Y-channel in general? Question 2: Is the DoF characterized by the cut-set bounds?

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 9

slide-29
SLIDE 29

RUB Chair of Communication Systems

MIMO Y-channel

If the MIMO Y-channel has M1 = M2 = M3 = M and N ≥ ⌈3M/2⌉, then the cut-set bound is achievable, i.e., d = 3M [Lee et al. 10]. Question 1: What is the DoF of the MIMO Y-channel in general? Question 2: Is the DoF characterized by the cut-set bounds? Theorem The DoF of the MIMO Y-channel with M1 ≥ M2 ≥ M3 (wlog) is given by d = min{M1 + M2 + M3

  • Cut-set bound

, }.

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 9

slide-30
SLIDE 30

RUB Chair of Communication Systems

MIMO Y-channel

If the MIMO Y-channel has M1 = M2 = M3 = M and N ≥ ⌈3M/2⌉, then the cut-set bound is achievable, i.e., d = 3M [Lee et al. 10]. Question 1: What is the DoF of the MIMO Y-channel in general? Question 2: Is the DoF characterized by the cut-set bounds? Theorem The DoF of the MIMO Y-channel with M1 ≥ M2 ≥ M3 (wlog) is given by d = min{M1 + M2 + M3

  • Cut-set bound

, 2M2 + 2M3, 2N

  • New bounds

}.

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 9

slide-31
SLIDE 31

RUB Chair of Communication Systems

1 Introduction and previous work 2 MIMO Y-channel 3 Transmission Strategy

An Example Generalization

4 Upper Bounds 5 Conclusion

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 10

slide-32
SLIDE 32

RUB Chair of Communication Systems

Transmission Strategy

Transmission strategy is signal-space alignment for network-coding [Lee et al. 10] with asymmetric DoF allocation

  • The signals H1x1, H2x2, and H3x3 fill the entire space at the relay

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 11

slide-33
SLIDE 33

RUB Chair of Communication Systems

Transmission Strategy

Transmission strategy is signal-space alignment for network-coding [Lee et al. 10] with asymmetric DoF allocation

  • The signals H1x1, H2x2, and H3x3 fill the entire space at the relay
  • Relay zero-forces H2x2 using N13 and H3x3 using N12

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 11

slide-34
SLIDE 34

RUB Chair of Communication Systems

Transmission Strategy

Transmission strategy is signal-space alignment for network-coding [Lee et al. 10] with asymmetric DoF allocation

  • The signals H1x1, H2x2, and H3x3 fill the entire space at the relay
  • Relay zero-forces H2x2 using N13 and H3x3 using N12
  • Result: N12H1x1 + N12H2x2 (2D) and N13H1x1 + N13H3x3 (1D)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 11

slide-35
SLIDE 35

RUB Chair of Communication Systems

Transmission Strategy

Transmission strategy is signal-space alignment for network-coding [Lee et al. 10] with asymmetric DoF allocation

  • The signals H1x1, H2x2, and H3x3 fill the entire space at the relay
  • Relay zero-forces H2x2 using N13 and H3x3 using N12
  • Result: N12H1x1 + N12H2x2 (2D) and N13H1x1 + N13H3x3 (1D)
  • Tx’s diagonalize their effective channels

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 11

slide-36
SLIDE 36

RUB Chair of Communication Systems

Transmission Strategy

Transmission strategy is signal-space alignment for network-coding [Lee et al. 10] with asymmetric DoF allocation

  • The signals H1x1, H2x2, and H3x3 fill the entire space at the relay
  • Relay zero-forces H2x2 using N13 and H3x3 using N12
  • Result: N12H1x1 + N12H2x2 (2D) and N13H1x1 + N13H3x3 (1D)
  • Tx’s diagonalize their effective channels ⇒ desired channel structure
  • Relay obtains net-coded signals: u12 + u21, u′

12 + u′ 21, and u13 + u31 Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 11

slide-37
SLIDE 37

RUB Chair of Communication Systems

Transmission strategy

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 12

slide-38
SLIDE 38

RUB Chair of Communication Systems

Transmission strategy

  • Relay uses a similar beam-forming strategy to deliver the net-coded

signals to their desired destinations

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 12

slide-39
SLIDE 39

RUB Chair of Communication Systems

Transmission strategy

  • Relay uses a similar beam-forming strategy to deliver the net-coded

signals to their desired destinations

  • User 1 gets u12 + u21, u′

12 + u′ 21, and u13 + u31, and extracts u21, u′ 21,

and u31

  • User 2 gets u12 + u21 and u′

12 + u′ 21 and extracts u12 and u′ 12

  • User 3 gets u13 + u31 and extracts u13

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 12

slide-40
SLIDE 40

RUB Chair of Communication Systems

Transmission strategy

  • Relay uses a similar beam-forming strategy to deliver the net-coded

signals to their desired destinations

  • User 1 gets u12 + u21, u′

12 + u′ 21, and u13 + u31, and extracts u21, u′ 21,

and u31

  • User 2 gets u12 + u21 and u′

12 + u′ 21 and extracts u12 and u′ 12

  • User 3 gets u13 + u31 and extracts u13
  • 6 symbols delivered successfully ⇒ 6 DoF (optimal)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 12

slide-41
SLIDE 41

RUB Chair of Communication Systems

1 Introduction and previous work 2 MIMO Y-channel 3 Transmission Strategy

An Example Generalization

4 Upper Bounds 5 Conclusion

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 13

slide-42
SLIDE 42

RUB Chair of Communication Systems

General Transmission Strategy

Case 1: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = 2M2 + 2M3

  • Use only M2 + M3 antennas at the relay

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 14

slide-43
SLIDE 43

RUB Chair of Communication Systems

General Transmission Strategy

Case 1: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = 2M2 + 2M3

  • Use only M2 + M3 antennas at the relay
  • Users send u12 and u21 (M2-dim), and u13 and u31 (M3-dim)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 14

slide-44
SLIDE 44

RUB Chair of Communication Systems

General Transmission Strategy

Case 1: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = 2M2 + 2M3

  • Use only M2 + M3 antennas at the relay
  • Users send u12 and u21 (M2-dim), and u13 and u31 (M3-dim)
  • Align u12 and u21, and align u13 and u31 @ relay

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 14

slide-45
SLIDE 45

RUB Chair of Communication Systems

General Transmission Strategy

Case 1: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = 2M2 + 2M3

  • Use only M2 + M3 antennas at the relay
  • Users send u12 and u21 (M2-dim), and u13 and u31 (M3-dim)
  • Align u12 and u21, and align u13 and u31 @ relay
  • Relay decodes L(u12, u21) and L(u13, u31)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 14

slide-46
SLIDE 46

RUB Chair of Communication Systems

General Transmission Strategy

Case 1: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = 2M2 + 2M3

  • Use only M2 + M3 antennas at the relay
  • Users send u12 and u21 (M2-dim), and u13 and u31 (M3-dim)
  • Align u12 and u21, and align u13 and u31 @ relay
  • Relay decodes L(u12, u21) and L(u13, u31)
  • Beam-form L(u12, u21) and L(u13, u31) orthogonal to users 3 and 2,

respectively

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 14

slide-47
SLIDE 47

RUB Chair of Communication Systems

General Transmission Strategy

Case 1: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = 2M2 + 2M3

  • Use only M2 + M3 antennas at the relay
  • Users send u12 and u21 (M2-dim), and u13 and u31 (M3-dim)
  • Align u12 and u21, and align u13 and u31 @ relay
  • Relay decodes L(u12, u21) and L(u13, u31)
  • Beam-form L(u12, u21) and L(u13, u31) orthogonal to users 3 and 2,

respectively

  • Each user decodes the desired linear combinations, and extracts the

desired signals ⇒ 2M2 + 2M3 DoF

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 14

slide-48
SLIDE 48

RUB Chair of Communication Systems

General Transmission Strategy

Case 2: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = M1 + M2 + M3

  • Similar to [Lee et al. 10] but with an asymmetric DoF allocation

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 15

slide-49
SLIDE 49

RUB Chair of Communication Systems

General Transmission Strategy

Case 2: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = M1 + M2 + M3

  • Similar to [Lee et al. 10] but with an asymmetric DoF allocation
  • Use only M1+M2+M3

2

antennas at the relay

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 15

slide-50
SLIDE 50

RUB Chair of Communication Systems

General Transmission Strategy

Case 2: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = M1 + M2 + M3

  • Similar to [Lee et al. 10] but with an asymmetric DoF allocation
  • Use only M1+M2+M3

2

antennas at the relay

  • Align u12 and u21 in a d12-dim subspace

(d12 = dim(span(H1) ∩ span(H2)) = M1+M2−M3

2

)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 15

slide-51
SLIDE 51

RUB Chair of Communication Systems

General Transmission Strategy

Case 2: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = M1 + M2 + M3

  • Similar to [Lee et al. 10] but with an asymmetric DoF allocation
  • Use only M1+M2+M3

2

antennas at the relay

  • Align u12 and u21 in a d12-dim subspace

(d12 = dim(span(H1) ∩ span(H2)) = M1+M2−M3

2

)

  • similarly, align u13 and u31 in d13 = M1+M3−M2

2

dimensions, and align u23 and u32 in d23 = M2+M3−M1

2

dimensions

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 15

slide-52
SLIDE 52

RUB Chair of Communication Systems

General Transmission Strategy

Case 2: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = M1 + M2 + M3

  • Similar to [Lee et al. 10] but with an asymmetric DoF allocation
  • Use only M1+M2+M3

2

antennas at the relay

  • Align u12 and u21 in a d12-dim subspace

(d12 = dim(span(H1) ∩ span(H2)) = M1+M2−M3

2

)

  • similarly, align u13 and u31 in d13 = M1+M3−M2

2

dimensions, and align u23 and u32 in d23 = M2+M3−M1

2

dimensions

  • Achieve d = 2d12 + 2d13 + 2d23 = M1 + M2 + M3 DoF

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 15

slide-53
SLIDE 53

RUB Chair of Communication Systems

General Transmission Strategy

Case 3: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = 2N

  • Reduce the number of antennas at the users so that

N = min{2M2 + 2M3, M1 + M2 + M3}

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 16

slide-54
SLIDE 54

RUB Chair of Communication Systems

General Transmission Strategy

Case 3: d = min{2M2 + 2M3, M1 + M2 + M3, 2N} = 2N

  • Reduce the number of antennas at the users so that

N = min{2M2 + 2M3, M1 + M2 + M3}

  • Use same scheme as case 1 and case 2

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 16

slide-55
SLIDE 55

RUB Chair of Communication Systems

1 Introduction and previous work 2 MIMO Y-channel 3 Transmission Strategy

An Example Generalization

4 Upper Bounds 5 Conclusion

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 17

slide-56
SLIDE 56

RUB Chair of Communication Systems

Upper Bounds: Cut-set

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 18

slide-57
SLIDE 57

RUB Chair of Communication Systems

Upper Bounds: Cut-set

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 18

slide-58
SLIDE 58

RUB Chair of Communication Systems

Upper Bounds: Cut-set

  • ⇒ Cut-set bounds: djk + djl ≤ min{N, Mj, Mk + Ml}

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 18

slide-59
SLIDE 59

RUB Chair of Communication Systems

Upper Bounds: Cut-set

  • ⇒ Cut-set bounds: djk + djl ≤ min{N, Mj, Mk + Ml}
  • ⇒ d ≤ M1 + M2 + M3

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 18

slide-60
SLIDE 60

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 2 decodes (m12, m32) from (y2, m21, m23),

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 19

slide-61
SLIDE 61

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 2 decodes (m12, m32) from (y2, m21, m23),
  • give (y3, m31) to user 2 as side information

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 19

slide-62
SLIDE 62

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 2 decodes (m12, m32) from (y2, m21, m23),
  • give (y3, m31) to user 2 as side information
  • now user 2 knows (y3, m31, m32) and can decode m13

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 19

slide-63
SLIDE 63

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 2 decodes (m12, m32) from (y2, m21, m23),
  • give (y3, m31) to user 2 as side information
  • now user 2 knows (y3, m31, m32) and can decode m13
  • ⇒ R12 + R32 + R13 ≤ I(m12, m32, m13; y2, y3, m21, m23, m31)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 19

slide-64
SLIDE 64

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 2 decodes (m12, m32) from (y2, m21, m23),
  • give (y3, m31) to user 2 as side information
  • now user 2 knows (y3, m31, m32) and can decode m13
  • ⇒ R12 + R32 + R13 ≤ I(m12, m32, m13; y2, y3, m21, m23, m31)
  • ⇒ d12 + d32 + d13 ≤ min{N, M2 + M3} (bound 1)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 19

slide-65
SLIDE 65

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 1 decodes (m21, m31) from (y1, m12, m13),

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 20

slide-66
SLIDE 66

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 1 decodes (m21, m31) from (y1, m12, m13),
  • give (yr, m32) to user 1 as side information

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 20

slide-67
SLIDE 67

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 1 decodes (m21, m31) from (y1, m12, m13),
  • give (yr, m32) to user 1 as side information
  • now user 1 knows (yr, m31, m32) which is a better observation than

(y3, m31, m32)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 20

slide-68
SLIDE 68

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 1 decodes (m21, m31) from (y1, m12, m13),
  • give (yr, m32) to user 1 as side information
  • now user 1 knows (yr, m31, m32) which is a better observation than

(y3, m31, m32)

  • then, user 1 can decode m23,

⇒ R21 + R31 + R23 ≤ I(m21, m31, m23; y1, yr, m12, m13, m32)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 20

slide-69
SLIDE 69

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 1 decodes (m21, m31) from (y1, m12, m13),
  • give (yr, m32) to user 1 as side information
  • now user 1 knows (yr, m31, m32) which is a better observation than

(y3, m31, m32)

  • then, user 1 can decode m23,

⇒ R21 + R31 + R23 ≤ I(m21, m31, m23; y1, yr, m12, m13, m32)

  • ⇒ d21 + d31 + d23 ≤ min{N, M2 + M3} (bound 2)

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 20

slide-70
SLIDE 70

RUB Chair of Communication Systems

Upper Bounds: Genie-aided

  • User 1 decodes (m21, m31) from (y1, m12, m13),
  • give (yr, m32) to user 1 as side information
  • now user 1 knows (yr, m31, m32) which is a better observation than

(y3, m31, m32)

  • then, user 1 can decode m23,

⇒ R21 + R31 + R23 ≤ I(m21, m31, m23; y1, yr, m12, m13, m32)

  • ⇒ d21 + d31 + d23 ≤ min{N, M2 + M3} (bound 2)

Adding bound 1 and bound 2 ⇒ d ≤ min{2N, 2M2 + 2M3}

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 20

slide-71
SLIDE 71

RUB Chair of Communication Systems

1 Introduction and previous work 2 MIMO Y-channel 3 Transmission Strategy

An Example Generalization

4 Upper Bounds 5 Conclusion

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 21

slide-72
SLIDE 72

RUB Chair of Communication Systems

Conclusion

  • We derived new upper bounds for the MIMO Y-channel

Thank

u!

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 22

slide-73
SLIDE 73

RUB Chair of Communication Systems

Conclusion

  • We derived new upper bounds for the MIMO Y-channel
  • We generalized the scheme of signal-space alignment for net-coding to

the MIMO Y-channel with asymmetric DoF allocation

Thank

u!

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 22

slide-74
SLIDE 74

RUB Chair of Communication Systems

Conclusion

  • We derived new upper bounds for the MIMO Y-channel
  • We generalized the scheme of signal-space alignment for net-coding to

the MIMO Y-channel with asymmetric DoF allocation

  • As a result, we characterized the DoF of the MIMO Y-channel with

arbitrary number of antennas

Thank

u!

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 22

slide-75
SLIDE 75

RUB Chair of Communication Systems

Conclusion

  • We derived new upper bounds for the MIMO Y-channel
  • We generalized the scheme of signal-space alignment for net-coding to

the MIMO Y-channel with asymmetric DoF allocation

  • As a result, we characterized the DoF of the MIMO Y-channel with

arbitrary number of antennas Future work:

  • Extension to networks with more users

Thank

u!

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 22

slide-76
SLIDE 76

RUB Chair of Communication Systems

Conclusion

  • We derived new upper bounds for the MIMO Y-channel
  • We generalized the scheme of signal-space alignment for net-coding to

the MIMO Y-channel with asymmetric DoF allocation

  • As a result, we characterized the DoF of the MIMO Y-channel with

arbitrary number of antennas Future work:

  • Extension to networks with more users

2 3 R 1

Thank

u!

Anas Chaaban, Karlheinz Ochs, and Aydin Sezgin DoF of the MIMO Y-Channel 22
