The Common Language Runtime (CLR)

Based on Mark Sapossnek Computer Science Department Metropolitan College Boston University

Agenda

What Is the CLR? Assemblies Execution Model

Web Form .NET Framework Windows Web Service CLR

What is the CLR?

The .NET Platform

.NET Foundation Web Services Your Internal Web Service Third-Party Web Services .NET Enterprise Servers Clients Applications Protocols: HTTP, HTML, XML, SOAP, UDDI Tools: Visual Studio.NET, Notepad

• A set of technologies for developing and using

components to create:

• Web Forms
• Web Services
• Windows applications
• Supports the software lifecycle
• Development
• Debugging
• Deployment
• Maintenance

What Is the CLR?

The .NET Framework

Common Language Specification Common Language Runtime VB C++ C# ASP.NET: Web Services and Web Forms JScript … Windows Forms Base Classes ADO.NET: Data and XML Visual Studio.NET

What Is the CLR?

The .NET Framework

What Is the CLR?

Overview

The CLR provides a run-time environment that manages the execution of code and provides services that improves development, deploy- ment, and run time. Code that targets the CLR is called managed code.

What Is the CLR?

Goals

Development services

Deep cross-language interoperability Increased productivity

Deployment services

Simple, reliable deployment Fewer versioning problems – NO MORE ‘DLL HELL’

Run-time services

Performance Scalability Availability

What Is the CLR?

Goal: Simpler Development

Plumbing disappears

Metadata Transparent proxies Memory management Consistent exception handling

Great WYSIWYG tool support

Designers and wizards Debuggers Profilers

Increased productivity

What Is the CLR?

Goal: Simpler, Safer Deployment

No registration, zero-impact install

XCOPY deployment, incremental download

Side-by-side versions of shared components

Capture version at compile time Administrative policy at run time

Evidence-based security policy

Based on code as well as user Code origin (location) Publisher (public key)

DLL Hell

What Is the CLR?

Goal: Scalability

Smart device to Web Farm Automatic memory management

Self-configuring Dynamically tuning

Thread pool Asynchronous messaging

Object remoting Events

Smart device version

Multiple RTOSes Same tools used for desktop

What Is the CLR?

Goal: Rich Web Clients, Safe Hosting

WinForms on the client ASP.NET Web Forms on the server Code is granted permissions

Evidence is used by policy to grant permissions

Application that starts runtime

Like Internet Explorer, IIS, SQL Server™, Shell Provides some evidence Controls code loading Maps applications to processes

• COM, ASP, VB, C++
• All services available
• Many services redesigned
• Ease of use
• Scalability
• Consistent API
• Consistent framework raises the abstraction layer
• Gradual transition from simplicity to full power
• Less training, greater productivity

What Is the CLR?

Goal: Converge Programming Models

What Is the CLR?

Goal: Multiple Languages

Common Type System

Object-oriented in flavor Procedural languages well supported Functional languages possible

CLS guides frameworks design

Rules for wide reach All .NET Framework functionality available

Over 15 languages investigated

Most are CLS consumers Many are CLS extenders

Choose the right language for a particular job

What Is the CLR?

Highlights

Common Type System

Mapping of data types: Programming language Framework

Just-in-time (JIT) compilers

JIT compiles intermediate language (MSIL) into native code Highly optimized for platform or device

Garbage collector Permission and policy-based security Exceptions Threading Reflection Diagnostics and profiling

What Is the CLR?

Services

Code management Memory management and isolation Verification of type safety Conversion of MSIL to native code Loading and execution of managed code Creation and management of metadata Insertion and execution of security checks Handling cross-language exceptions Interoperation between .NET Framework objects and COM objects and Win32 DLLs Automation of object layout for late binding Developer services (profiling, debugging, etc.)

What Is the CLR?

Architecture

Class Loader MSIL to Native Compilers (JIT) Code Manager Garbage Collector (GC) Security Engine Debug Engine Type Checker Exception Manager Thread Support COM Marshaler Base Class Library (.NET Framework) Support

What Is the CLR?

Soon To Be a Standard

Microsoft, with HP and Intel, submitted proposal to ECMA to standardize:

C# Common Language Infrastructure Includes the Common Language Runtime and a subset of the

.NET Framework classes

http://msdn.microsoft.com/net/ecma/ http://www.ecma.ch

Agenda

What Is the CLR? Assemblies Execution Model Interoperability Security

Assemblies

Overview

Contains code and metadata Assemblies function as:

Unit of deployment Type boundary Security boundary Reference scope boundary Version boundary Unit of side-by-side execution

Assemblies

Overview

Assemblies can be:

Static: DLL, EXE Uses existing COFF binary format

Via existing extension mechanism

Dynamic

Create assemblies with

.NET Framework SDK Visual Studio.NET Your own code Dynamic assemblies

• Manifest
• Metadata about the assembly itself
• Type metadata
• Completely describes all types defined in

an assembly

• Managed code
• Microsoft Intermediate Language (MSIL)
• Resources
• For example, .bmp, .jpg

Assemblies

Components of an Assembly

Manifest MSIL Resources ParcelTracker.DLL

Assemblies

Components of an Assembly

Type Metadata

Assemblies

Components of an Assembly

An assembly is a logical unit, not physical

It can consist of multiple modules (.DLL, .JPG, etc.)

Assembly Module File Type

In this figure, containment implies a 1:M relationship

Assemblies

Components of an Assembly

A single-file assembly A multi-file assembly

Manifest Metadata MSIL

File1.dll

Metadata MSIL

File2.dll Graphic.jpg

Resource


Resource Manifest

File3.dll

Assemblies

Assembly Generation Tool: al.exe al.exe

Takes one or more files (containing either MSIL

• r resource files) and produces a file with an

assembly manifest. When compiling a C# file, you can specify that it create a module instead of an assembly by using /target:module.

Assemblies

Manifest

Manifest contains:

Identity information Name, version number, culture, strong name List of files in the assembly Map of assembly types to files Dependencies Other assemblies used by this assembly Exported types Security permissions needed to run

Type Descriptions Classes Base classes Implemented interfaces Data members Methods Assembly Description Name Version Culture Other assemblies Security Permissions Exported Types

Assemblies

Manifest and Metadata

Manifest Metadata

Assemblies

What’s In the Metadata

Description of types

Name, visibility, base class, interfaces implemented Members methods, fields, properties, events, nested types

Attributes

User-defined Compiler-defined Framework-defined

Assemblies

Demo: ILDASM.EXE

Allows you to inspect the metadata and disassembled IL code in an assembly Great way to see what’s really going on Use ildasm /? to see the various options

Assemblies

Metadata

Key to simpler programming model Generated automatically

Stored with code in executable file (.dll or .exe)

Assemblies

Metadata: Creation and Use

Assembly

(Manifest, metadata and code)

Debugger Schema Generator Profiler Other Compiler Proxy Generator Type Browser Compiler Source Code XML encoding

(WSDL)

Serialization

(e.g. SOAP)

Designers Reflection

Assemblies

Compilers Use Metadata

For cross-language data type import Emit metadata with output code

Describe types defined and used Record external assemblies referenced Record version information

Custom attributes can be used

Obsolete CLS compliance Compiled for debugging Language-specific markers

Assemblies

Other Tools Use Metadata

Designer behavior

Controlled by user-supplied attributes Category Description

Designer extensibility

User-supplied attributes specify code to use Type converters Editors

Web methods marked by custom attribute Type viewer

Assemblies

Global Assembly Cache

A set of assemblies that can be referenced by any application on a machine Should be used only when needed

Private assemblies are preferred

Located at %SystemRoot%\assembly

(c:\winnt\assembly)

Add assemblies by

Installer program gacutil.exe Windows Explorer

Assembly Cache Viewer (shfusion.dll) is a shell extension for

GAC that is installed with the .NET Framework SDK

.NET Framework Configuration Tool (mscorcfg.msc)

Assembly must have a strong name

Assemblies

Strong Names

Strong names identify an assembly

Contains text name, version, culture, public key, and

digital signature

Generated from an assembly using a private key Benefits

Guarantees name uniqueness Protect version lineage No one else can create a new version of your assembly Provides strong integrity check Guarantees that contents of an assembly didn’t change since it

was built

Assemblies

Strong Names

To sign an assembly with a strong name:

Use Assembly Generation tool: al.exe Use assembly attributes

(AssemblyKeyFileAttribute or AssemblyKeyNameAttribute)

Requires a key pair (private and public)

To generate a key pair use the Strong Name tool:

sn.exe

Assemblies

Demo: Installing an Assembly in GAC

Create assembly Sign assembly with key from sn.exe Install into GAC via gacutil.exe, Assembly Cache Viewer and .NET Framework Configuration Tool

Assemblies

Signcode

A strong name identifies an assembly but it does not authenticate an assembly

Strong names do NOT imply a level of trust

Signcode allows the embedding of a certificate in an assembly

Now your assembly can be authenticated

Assemblies

Signcode

To use signcode:

Obtain a Software Publisher Certificate (.spc) Use signcode.exe to sign the assembly

Signcode can only sign one file at a time

For an assembly, you sign the file containing the

manifest

Purchase one from a well known Certificate Authority (such as Verisign) Create your own

For testing purposes only Use Makecert.exe to create a X.509 certificate Use cert2spc.exe to generate an SPC from a

X.509 certificate

Assemblies

How Do You Obtain a Certificate?

Assemblies

Strong Names and Signcode

Strong names and signcode provide different, complimentary levels of protection You can assign a strong name or assign a signcode signature to an assembly, or both When using both, the strong name must be assigned first

Assemblies

Signcode

Specify what permissions your assembly needs

Only specify required permissions Handle optional permissions dynamically

Set security policy on run-time machine

Unit of deployment

One or more files, independent of packaging Self-describing via manifest and metadata

Versioning

Captured by compiler Policy per-application as well as per-machine

Security boundary

Assemblies are granted permissions Methods can demand proof that a permission

has been granted to entire call chain

Mediate type import and export

Types named relative to assembly

Assemblies

Deployment

Assemblies

Deployment

Applications are configurable units

One or more assemblies Application-specific files or data

Assemblies are located based on:

Their logical name and the application that loads

them

Applications can have private versions of assemblies

Private version preferred to shared version Version policy can be per application

Assemblies

MSIL

Microsoft Intermediate Language

.assembly hello {} .assembly hello {} .assembly extern mscorlib .assembly extern mscorlib {} {} .method static public .method static public void main() il void main() il managed { managed { .entrypoint .entrypoint .maxstack .maxstack 1 ldstr ldstr "Hello World from IL!" "Hello World from IL!" call call void [mscorlib]S void [mscorlib]System.Console::WriteLine(class ystem.Console::WriteLine(class System.String) System.String) ret ret }

Assemblies

MSIL

Compiled with ilasm.exe MSIL was designed for the CLR

Object-oriented (primitives are not special) Designed for the Common Type System Does not embed type information

See documentation in

\FrameworkSDK\Tool Developers Guide\docs

Agenda

What Is the CLR? Assemblies Execution Model Interoperability Security

Source Code

C++, C#, VB or any .NET language

csc.exe csc.exe or vbc.exe vbc.exe

Compiler

Assembly

DLL or EXE

Execution Model

Create Assembly

CLR

Execution Model

VB

Source Code

Compiler C++ C# Assembly Assembly Assembly Operating System Services

MSIL

Common Language Runtime JIT Compiler Compiler Compiler

Native Code

Managed Code Managed Code Managed Code Unmanaged Code CLR Services Ngen

Execution Model

Compiling IL to Native Code

JIT compiler

Generates optimized native code Compiled when a method is first called Includes verification of IL code

Ngen.exe

Install-time native code generation Used when assembly is installed on machine Reduces start-up time Native code has version checks and reverts

to run-time JIT if they fail

Execution Model

Run-Time Hosts

ASP.NET Internet Explorer Shell executables More in future

For example: SQL Server (Yukon)

Can create your own run-time hosts

Execution Model

Binding to Assemblies

An application consists of one or more assemblies. How does one assembly bind to another?

Based upon metadata and policy Local (preferred) Assembly Global Cache

Multiple versions of an assembly may exist on the same machine.

Easier software deployment, updates and removal Multiple versions of an assembly can even be used

by the same application

Execution Model

Application Domains

Traditionally, processes were used to isolate applications running on the same computer

Isolates failure of one application Isolates memory

Problems

Uses more resources If needed, inter-process calls can be expensive

Execution Model

Application Domains

.NET introduces Application Domains, which allow you to run multiple applications within the same process Enabled by code verification

No code will crash the process

Managed by the System.AppDomain class Common assemblies can be shared across domains or can be specific to a domain

Execution Model

Application Domains

Benefits:

Application domains are isolated Faults are isolated Individual applications can be stopped without

stopping the process

Can configure each application domain independently Can configure security for each domain Cross-domain calls can be done through proxies More efficient than cross-process calls

Execution Model

Application Domains

Process Shared class data and native code App. Domain

(class data and native code)

App. Domain Thread
