Xing Pan, Frank Mueller North Carolina State University

The Colored Refresh Server for DRAM

1

North Carolina State University

Real-time system

Real-Time System requires:

— Logical Correctness: Produces correct outputs. — Temporal Correctness: Produces outputs at the right time.

Real-time task

2

Real-time task

— predict its worst-case execution time — schedule it to meet its deadline

= job release = job deadline WCET

0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15

NUMA Architecture

Modern NUMA (non-uniform memory access) architectures:

— CPU partitions sets of cores into “node”: 1 local + several remote controllers — Each memory controller (node) consists of multilevel resources (channel, rank and bank)

3

Core Isolation Hard Real-Time Composition

Challenge: shared resources

— One core execution affects other cores

Objective: Isolate cores

— Allows compositional timing analysis

Application: mission critical hard real-time

4

Application: mission critical hard real-time

— Automated driving…

DRAM Organization

DRAM bank array has: rows+columns of data cells Load the row which contains requested data into Row Buffer

— Row Buffer hit vs. Row Buffer miss

5

Memory Controller

DRAM banks can be accessed in parallel

6

Motivation

Apps on NUMA arch. experience varying execution times due to

— Remote memory node accesses — Conflict in memory banks/controllers

7

Past: Memory Predictability by Coloring

Local node policy under standard buddy allocation / numa library

— Not bank aware — numa library only works on heap memory

Previous Work

— Our Controller-Aware Memory Coloring (CAMC) @ SAC’18 — NUMA causes unpredictable

8

— NUMA causes unpredictable execution time — New memory allocator in kernel via mmap() syscall, no hardware modifications — Each task gets private memory (coloring)

• n local NUMA node

— Avoid remote refs, bank conflicts predictable exec., lower performance, lower utilization

Memory Frame Color Selection

Bank color (bc) of a physical page

• Physical Address

1516 17 18 19 20 31 channel rank bank

9

bc = ((nodeNN NC+channel)NR+rank)NB+bank —NN: # nodes (mem controllers) of a system —NC: # channels per controller —NR: # ranks per channel —NB: # banks per rank

Opteron 6128: NN=4, NC=2, NR=2, NB=8, Total of 128 colors Example: page in node 0, channel 1, rank 1 and bank 2

color is ((042+1)2+1)*8+2=26

Focus in this Paper: DRAM Refresh

Dynamic Random Access Memory (DRAM)

— data is stored in the capacitor as 1 or 0 (electrically charged/discharged) — capacitors slowly leak their charge over time — requires cells to be refreshed, otherwise data would be lost.

10

Unpredictability due to DRAM Refresh

Refresh commands to all DRAM cells periodically issued by DRAM

controller to maintain data validity. — row-buffer is closed — any memory access deferred until refresh completes

Distributed Refresh vs. Burst refresh

11

Unpredictability due to DRAM Refresh

Refresh commands to all DRAM cells periodically issued by DRAM

controller to maintain data validity — row-buffer is closed — any memory access deferred until refresh completes

Distributed Refresh vs. Burst refresh

Retention Time (tRET)

12

tRFC tREFI Retention Time (tRET)

DRAM Refresh Trends: It’s getting worse

tRET: 64 ms / 32 ms. determined by temperature (85 C) tRFC increases quickly with growing DRAM densities

Chip Density # banks #rows/bank #rows/bin tRFC 1Gb 8 16K 16 110 ns [1] 2Gb 8 32K 32 160 ns [1]

13

• [1] Standard, JEDEC, DDR3 SDRAM
• [2] Standard, JEDEC, DDR4 SDRAM
• [3] Jamie Liu, Onur Mutlu et al. "RAIDR: Retention-aware intelligent DRAM

refresh." ACM SIGARCH Computer Architecture News. 2012.

2Gb 8 32K 32 160 ns [1] 4Gb 8 64K 64 260 ns [1] 8Gb 8 128K 128 350 ns [1] 16Gb 8 256K 256 550 ns [2] 32Gb 8 512K 512 > 1 us [3] 64Gb 8 1M 1K > 2 us [3]

Challenge: Refresh Delay

Auto-refresh : recharges all the memory cells within the

“retention time” — a rank during refresh becomes unavailable to memory requests until the refresh completes (tRFC). — all bank row buffers of this rank closed (tRP) and need to be re-opened (tRAS)

14

re-opened (tRAS) — More bank row buffer misses around refreshes.

Challenge: Refresh Delay

Auto-refresh : recharges all the memory cells within the

“retention time” — a rank during refresh becomes unavailable to memory requests until the refresh completes (tRFC). — all bank row buffers of this rank closed (tRP) and need to be re-opened (tRAS)

15

re-opened (tRAS) — More bank row buffer misses around refreshes.

• 1. Increase in memory latency
• 2. Significant fluctuation of memory reference latency.

Challenge: Refresh Delay

As density and size of DRAM grow:

— more rows required per DRAM chip — longer tRFC — higher probability for refresh interference

16

Challenge: Refresh Delay

As density and size of DRAM grow:

— more rows required per DRAM chip — longer tRFC — higher probability for refresh interference

17

• 1. Increases length a refresh operation
• 2. Reduces memory throughput

Solution: Colored Refresh Server (CRS)

Partition DRAM memory at rank granularity

— Refreshes rotate round-robin from rank to rank — Assign real-time tasks to different ranks via colored memory allocation (say: green,blue) — Schedule 2 server tasks to refresh green/blue memory — Ensure that no blue task runs when green server active and vice versa: no green task runs when blue server active

18

— Ensure that no blue task runs when green server active and vice versa: no green task runs when blue server active

Cooperative scheduling real-time tasks and refresh operations

memory requests no longer suffer from refresh interference

Architecture of Colored Refresh Server

Hierarchical model

— System Level − Refresh tasks w/ static priority: Refresh Tasks > S1 > S2 tasks — Server Level (inside the servers) − User tasks scheduled inside servers − w/ memory colored diametric to server

19

− w/ memory colored diametric to server − with any real-time scheduling policy: EDF, RM, … − Refresh Lock/unlock tasks: no memory blocking during refresh

Refresh Lock/Unlock Tasks

… …

Refresh Lock and Unlock Tasks

partition entire DRAM space into two “colors”

— e.g., c1(k0, k1 ... ki), and c2(ki+1, ki+2 ... kK-1).

refresh lock tasks, and

— period of tRET(64ms) — trigger refresh for c1 (green) and c2 (blue), respectively

refresh unlock tasks, and

20

refresh unlock tasks, and

— update corresponding color to be available once refresh finishes

Server Model

Server model, S(W,A, c, ps , es)

— with CPU time as resource — Where: − W is the workload model (applications) − A is the scheduling algorithm, e.g., EDF or RM − c denotes the memory color assigned to this server, i.e., a

21

− c denotes the memory color assigned to this server, i.e., a set of memory ranks available for allocation − ps is the server period − es is the server budget

Server Model

Set execution budget to es at time instants k* ps, where k > 0. Any unused execution budget cannot be carried over to next period The refresh server can execute when

— (i) its budget is not zero;

22

— (i) its budget is not zero; — (ii) its available task queue is not empty; and — (iii) its memory color is not locked by a “refresh task” (introduced above). — Otherwise, it remains suspended.

Example of CRS

T1(16ms, 4ms)

T2(16ms, 2ms) T3(32ms, 8ms) T4(64ms, 8ms) S ((T , T ), RM, c (k ,k ,k ,k ), 16ms , 6ms )

23

S1((T1, T2), RM, c1(k0,k1,k2,k3), 16ms , 6ms )

S2((T3, T4), RM, c2(k4,k5,k6,k7), 16ms , 6ms)

Phases φ of S1 and S2 are tRET/2 and 0, respectively

— i.e., S2 (colors c2) refreshed first

Example of CRS

24

Schedulability Analysis within a Server

Given a server S(W,A, c , ps , es) [SL03],

— Periodic Capacity Bound (PCB): − bound period (ps ) and deadline (es) − with workload (W) and algorithm (A) — Utilization Bound (UB) − Bound utilization of workload

25

− Bound utilization of workload − with ps, es , and A

[SL03] Shin, I. & Lee, I. “Periodic resource model for

compositional real-time guarantees”. RTSS. 2003.

Refresh Lock/Unlock Tasks

… …

Schedulability Analysis

Servers + refresh lock/unlock tasks at system level

26

Time Demand Analysis

— Refresh tasks w/ static priority: Lock/Unlock Tasks > S1 > S2

Refresh Lock/Unlock Tasks

… …

Colored Refresh Server Design

Off-line algorithm

— Searches entire range of available configurations — Find minimum refresh overhead & budgets for servers — Short tasks: create copy tasks — See dissertation [Pan’18]

27

Colored Refresh Server

— Guarantees schedulability (if task set was schedulable w/o CRS) — Cost much lower overhead than auto-refresh (removes entire refresh overhead in most cases)

Colored Refresh Server Implementation

SimpleScalar

— simulates execution of application — generates memory tracefile

Scheduler & Coloring Tool (from CAMC [SAC’18] work) RTMemController (only to obtain timings, no Ethereal support)

28

RTMemController (only to obtain timings, no Ethereal support) — schedule memory transactions, determine access latency

Experimental Setup

Single core processor

— split 16KB data and instruction caches, — unified 128KB L2 cache — cache line size is 64B.

JEDEC-compliant DDR3/DDR4 SDRAM

29

JEDEC-compliant DDR3/DDR4 SDRAM — varied memory density: 1/2/4/8/16/32/64Gb)

The DRAM retention time: tRET=64ms

— 8 ranks (K=8) & 1 memory controller. — Issue refresh by memory controllers at rank granularity.

Real-Time Tasks

Malardalen benchmark task set S1( (cnt, lms, st),

EDF, c1(k0,k1,k2,k3), 4ms, 2.4ms ) S2( (compress, matmult), EDF, c2(k4,k5,k6,k7), 4ms, 1.6ms)

Execution Time Period

30

Execution Time Period cnt 3 ms 20 ms compress 1.2 ms 10 ms lms 1.6 ms 10 ms matmult 10 ms 40 ms st 2 ms 9 ms

Evaluation

CRS hides memory latency penalty of auto-refresh,

which increases with memory density under autorefresh.

31

AutoRefresh Latency Normalized to CRS

Evaluation

Auto-refresh has increasing probability (more accesses) of

memory references to interfere with each other with higher DRAM density (depends on memory access patterns in benchmarks) while CRS eliminates this variability

32

Normalized to CRS

Evaluation

Compared to auto-refresh,

— CRS reduces execution time of tasks and system utilization — performance of CRS remains stable and predictable irrespective of DRAM density. CRS as good as it gets same as hypothetical “no refresh”

33

Deadline missed

Evaluation

DDR4 Fine Granularity Refresh (FGR)

— Create a range of refresh options — Provide a trade-off between refresh latency and frequency.

CRS exhibits better performance and higher task predictability

than DDR4’s FGR.

34

Evaluation

CRS obtains better performance and higher task predictability

than burst refresh of the closest prior work. [BM10]

35

[BM10] Bhat, Balasubramanya & Mueller, Frank

“Making DRAM refresh predictable”, ECRTS 2010

Conclusion

Make memory references more predictable w/ coloring

— Controller-Aware Memory Coloring (CAMC) [SAC’18] − reduce varied memory access latency − provide single core equivalence but subject to refresh delay

Colored Refresh Server:

− hide refresh delays & reduce DRAM access latencies

36

− hide refresh delays & reduce DRAM access latencies − exhibit better performance & higher task predictability than auto-refresh & [BM’10] − hierarchical server task scheduling, apps inside servers − supports any real-time scheduling policy in server (EDF, RM) − realized in software, applicable to commercial off-the-shelf (COTS) systems.

Supports Core Isolation real-time composability

• supported in part by NSF grants 1239246,1329780,1525609 and 1813004.
