TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET Iuri Frosio, GTC 2019 (San Jose, CA) THE IMPORTANCE OF NEGATIVE RESULTS I shall require that [the] logical form [of the theory] shall be such that it can be singled out, by

slide-1
SLIDE 1

Iuri Frosio, GTC 2019 (San Jose, CA)

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

slide-2
SLIDE 2

2

THE IMPORTANCE OF NEGATIVE RESULTS

“I shall require that [the] logical form [of the theory] shall be such that it can be singled

  • ut,

by means

  • f

empirical tests, in a negative sense: it must be possible for an empirical scientific system to be refuted by experience” (Karl Popper, The Logic

  • f

Scientific Discovery, 1959). In simple words, “negative results are fundamentals for the advancement

  • f

science”.

slide-3
SLIDE 3

3

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

  • Time Of Flight (TOF) cameras & artifacts
  • Naïve Machine Learning (ML) for TOF reconstruction
  • TOF cameras: working principles
  • Camera calibration
  • The FLAT dataset
  • Spoiler: our non-Naïve ML solution works*
  • Back to physics
  • DNN architecture
  • Results
  • Conclusion

Agenda

* See Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany),

  • Sept. 2018.
slide-4
SLIDE 4

4

TIME OF FLIGHT (TOF) CAMERAS & ARTIFACTS

E.g., Kinect 2

Image from https://stackoverflow.com/questions/22921390/how-to-scale-a-kinect- depth-image-for-applying-lbp-on-it-in-matlab?rq=1

slide-5
SLIDE 5

5

TIME OF FLIGHT (TOF) CAMERAS & ARTIFACTS

Applications

Image from https://www.physio- pedia.com/The_emerging_role_of_Microsoft_Kinect_in_physiotherapy_ rehab ilitation_for_stroke_patients Image from amazon.com Image from https://www.eenewsautomotive.com/news/3d-lidar-generates-e nviro nmental-model-time-flight- measurement

slide-6
SLIDE 6

6

TIME OF FLIGHT (TOF) CAMERAS & ARTIFACTS

Artifact #1: shot noise

Image from https://ptgrey.com

slide-7
SLIDE 7

7

TIME OF FLIGHT (TOF) CAMERAS & ARTIFACTS

Artifact #2: movement

Image from https://support.xbox.com

slide-8
SLIDE 8

8

TIME OF FLIGHT (TIF) CAMERAS & ARTIFACTS

Artifact #3: multiple reflections

Image from https://www.sciencedirect.com/science/article/pii/S0262885613001650

slide-9
SLIDE 9

9

TIME OF FLIGHT (TIF) CAMERAS & ARTIFACTS

Artifact #3: multiple reflections

slide-10
SLIDE 10

10

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

  • Time Of Flight (TOF) cameras & artifacts
  • Naïve Machine Learning (ML) for TOF reconstruction
  • TOF cameras: working principles
  • Camera calibration
  • The FLAT dataset
  • Spoiler: our non-Naïve ML solution works*
  • Back to physics
  • DNN architecture
  • Results
  • Conclusion

Agenda

* See Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany),

  • Sept. 2018.
slide-11
SLIDE 11

11

NAÏVE MACHINE LEARNING (ML) FOR TOF RECONSTRUCTION

What do we need?

(1) A large dataset of scenes… (2) … corrupted by: (1.1) photon noise, (1.2) motion, (1.3) multiple reflections… (3) … with clean output data… (4) … And a DNN.

slide-12
SLIDE 12

12

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

  • Time Of Flight (TOF) cameras & artifacts
  • Naïve Machine Learning (ML) for TOF reconstruction
  • TOF cameras: working principles
  • Camera calibration
  • The FLAT dataset
  • Spoiler: our non-Naïve ML solution works*
  • Back to physics
  • DNN architecture
  • Results
  • Conclusion

Agenda

* See Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany),

  • Sept. 2018.
slide-13
SLIDE 13

13

TOF WORKING PRINCIPLES

Time of flight is not time of flight ☺

Image from https://www.semanticscholar.org/paper/Interference-mitigation-technique-for-(ToF)-camera-Islam-Hossain/

slide-14
SLIDE 14

14

TOF WORKING PRINCIPLES

Time of flight is not time of flight ☺

Images from https://www.semanticscholar.org/paper/Interference-mitigation-technique-for-(ToF)-camera-Islam-Hossain/

slide-15
SLIDE 15

15

TOF WORKING PRINCIPLES

Multiple measurements

Pulse method Continuous wave method

slide-16
SLIDE 16

16

TOF WORKING PRINCIPLES

Camera functions and scene response

slide-17
SLIDE 17

17

TOF WORKING PRINCIPLE

More on scene response

= න

−𝑈 2 𝑈 2 𝑔 𝑢 ⨂𝑕𝑗 𝑢

𝑠 𝑢 𝑒𝑢 = න

−𝑈 2 𝑈 2 𝑔 𝑢 ∗ 𝑠 𝑢

𝑕𝑗 𝑢 𝑒𝑢 Raw measurement: Emitted signal: 𝑔 𝑢 Returned signal: ℎ 𝑢 Demodulation signal: 𝑕𝑗 𝑢 Impulse response: 𝑠(𝑢) Camera Scene 𝑅𝑗(𝑢) = න

−𝑈 2 𝑈 2 ℎ 𝑢 𝑕𝑗 𝑢 𝑒𝑢

Depth: 𝑎 = 𝑈𝑑 4𝜌arctan σ𝑗 sin𝜄𝑗 𝑅𝑗 𝑢 σ𝑗 cos𝜄𝑗 𝑅𝑗 𝑢 t t t Demodulation: gi(𝑢)

slide-18
SLIDE 18

18

TOF WORKING PRINCIPLES

Multiple frequencies

  • Different max length (combine

them)

  • Different resolutions
  • Agreement between different

measurements

slide-19
SLIDE 19

19

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

  • Time Of Flight (TOF) cameras & artifacts
  • Naïve Machine Learning (ML) for TOF reconstruction
  • TOF cameras: working principles
  • Camera calibration
  • The FLAT dataset
  • Spoiler: our non-Naïve ML solution works*
  • Back to physics
  • DNN architecture
  • Results
  • Conclusion

Agenda

* See Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany),

  • Sept. 2018.
slide-20
SLIDE 20

20

CAMERA CALIBRATION

Camera response functions (flat scene)

Inside coated with black-out material

slide-21
SLIDE 21

21

CAMERA CALIBRATION

Camera response functions (flat scene)

  • Three “frequencies”
  • Three

measurements per frequency

slide-22
SLIDE 22

22

CAMERA CALIBRATION

Photon noise

Other calibration details (pixel delay, vignetting, … in Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany), Sept. 2018.

slide-23
SLIDE 23

23

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

  • Time Of Flight (TOF) cameras & artifacts
  • Naïve Machine Learning (ML) for TOF reconstruction
  • TOF cameras: working principles
  • Camera calibration
  • The FLAT dataset
  • Spoiler: our non-Naïve ML solution works*
  • Back to physics
  • DNN architecture
  • Results
  • Conclusion

Agenda

* See Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany),

  • Sept. 2018.
slide-24
SLIDE 24

24

THE FLAT DATASET

Flexible, Large, Augmentable, ToF (FLAT)

To disk (FLAT) https://github.com/NVlabs/FLAT

slide-25
SLIDE 25

25

THE FLAT DATASET

Flexible, Large, Augmentable, ToF (FLAT)

Transient rendering (scene response function) based on Jarabo, A., Marco, J., Muñoz, A., Buisan, R., Jarosz, W., Gutierrez, D.: A framework for transient rendering. In: ACM Transactions on Graphics (SIGGRAPH ASIA), (2014).

slide-26
SLIDE 26

26

THE FLAT DATASET

Flexible, Large, Augmentable, ToF (FLAT)

Transient rendering (scene response function) based on Jarabo, A., Marco, J., Muñoz, A., Buisan, R., Jarosz, W., Gutierrez, D.: A framework for transient rendering. In: ACM Transactions on Graphics (SIGGRAPH ASIA), (2014). Brightness, travel time

slide-27
SLIDE 27

27

Impulse response

slide-28
SLIDE 28

28

Impulse response

slide-29
SLIDE 29

29

Impulse response

slide-30
SLIDE 30

30

Impulse response

slide-31
SLIDE 31

31

Impulse response

slide-32
SLIDE 32

32

Impulse response

slide-33
SLIDE 33

33

Impulse response

slide-34
SLIDE 34

34

Impulse response

slide-35
SLIDE 35

35

Impulse response

slide-36
SLIDE 36

36

Impulse response

slide-37
SLIDE 37

37

Impulse response

slide-38
SLIDE 38

38

Impulse response

slide-39
SLIDE 39

39

Impulse response

slide-40
SLIDE 40

40

Impulse response

slide-41
SLIDE 41

41

Impulse response

slide-42
SLIDE 42

42

Impulse response

slide-43
SLIDE 43

43

Impulse response

slide-44
SLIDE 44

44

Impulse response

slide-45
SLIDE 45

45

Impulse response

slide-46
SLIDE 46

46

Impulse response

slide-47
SLIDE 47

47

Impulse response

slide-48
SLIDE 48

48

Impulse response

slide-49
SLIDE 49

49

Impulse response

slide-50
SLIDE 50

50

Impulse response

slide-51
SLIDE 51

51

Impulse response

slide-52
SLIDE 52

52

Impulse response

slide-53
SLIDE 53

53

Impulse response

slide-54
SLIDE 54

54

Impulse response

slide-55
SLIDE 55

55

Impulse response

slide-56
SLIDE 56

56

Impulse response

slide-57
SLIDE 57

57

Impulse response

slide-58
SLIDE 58

58

Impulse response

slide-59
SLIDE 59

59

Impulse response

slide-60
SLIDE 60

60

Impulse response

slide-61
SLIDE 61

61

Impulse response

slide-62
SLIDE 62

62

Impulse response

slide-63
SLIDE 63

63

Impulse response

slide-64
SLIDE 64

64

Impulse response

slide-65
SLIDE 65

65

Impulse response

slide-66
SLIDE 66

66

Impulse response

slide-67
SLIDE 67

67

Impulse response

slide-68
SLIDE 68

68

Impulse response

slide-69
SLIDE 69

69

Impulse response

slide-70
SLIDE 70

70

Impulse response

slide-71
SLIDE 71

71

Impulse response

slide-72
SLIDE 72

72

Impulse response

slide-73
SLIDE 73

73

Impulse response

slide-74
SLIDE 74

74

Impulse response

slide-75
SLIDE 75

75

Impulse response

slide-76
SLIDE 76

76

Impulse response

slide-77
SLIDE 77

77

Impulse response

slide-78
SLIDE 78

78

Impulse response

slide-79
SLIDE 79

79

Impulse response

slide-80
SLIDE 80

80

Impulse response

slide-81
SLIDE 81

81

Impulse response

slide-82
SLIDE 82

82

Impulse response

slide-83
SLIDE 83

83

Impulse response

slide-84
SLIDE 84

84

Impulse response

slide-85
SLIDE 85

85

Impulse response

slide-86
SLIDE 86

86

Impulse response

slide-87
SLIDE 87

87

Impulse response

slide-88
SLIDE 88

88

Impulse response

slide-89
SLIDE 89

89

Impulse response

slide-90
SLIDE 90

90

Impulse response

slide-91
SLIDE 91

91

Impulse response

slide-92
SLIDE 92

92

Impulse response

slide-93
SLIDE 93

93

Impulse response

slide-94
SLIDE 94

94

Impulse response

slide-95
SLIDE 95

95

Impulse response

slide-96
SLIDE 96

96

Impulse response

slide-97
SLIDE 97

97

Impulse response

slide-98
SLIDE 98

98

Impulse response

slide-99
SLIDE 99

99

Impulse response

slide-100
SLIDE 100

100

Impulse response

slide-101
SLIDE 101

101

Impulse response

slide-102
SLIDE 102

102

Impulse response

slide-103
SLIDE 103

103

Impulse response

slide-104
SLIDE 104

104

Impulse response

slide-105
SLIDE 105

105

Impulse response

slide-106
SLIDE 106

106

Impulse response

slide-107
SLIDE 107

107

Impulse response

slide-108
SLIDE 108

108

Impulse response

slide-109
SLIDE 109

109

Impulse response

slide-110
SLIDE 110

110

Impulse response

slide-111
SLIDE 111

111

Impulse response

slide-112
SLIDE 112

112

Impulse response

slide-113
SLIDE 113

113

THE FLAT DATASET

Flexible, Large, Augmentable, ToF (FLAT)

Different cameras (beyond Kinect 2) can be simulated, after calibration.

slide-114
SLIDE 114

114

THE FLAT DATASET

Flexible, Large, Augmentable, ToF (FLAT)

Noise can be added…

slide-115
SLIDE 115

115

THE FLAT DATASET

Flexible, Large, Augmentable, ToF (FLAT)

… As well as motion (approximate model) and texture…

slide-116
SLIDE 116

116

THE FLAT DATASET

Flexible, Large, Augmentable, ToF (FLAT)

… and multiple reflections.

slide-117
SLIDE 117

117

THE FLAT DATASET

Samples

slide-118
SLIDE 118

118

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

  • Time Of Flight (TOF) cameras & artifacts
  • Naïve Machine Learning (ML) for TOF reconstruction
  • TOF cameras: working principles
  • Camera calibration
  • The FLAT dataset
  • Spoiler: our non-Naïve ML solution works*
  • Back to physics
  • DNN architecture
  • Results
  • Conclusion

Agenda

* See Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany),

  • Sept. 2018.
slide-119
SLIDE 119

119

NAÏVE MACHINE LEARNING (ML) FOR TOF RECONSTRUCTION

Supervised learning

Take it easy: supervised learning, from raw data to 3D map. Training input/output pairs from the FLAT dataset.

slide-120
SLIDE 120

120

NAÏVE MACHINE LEARNING (ML) FOR TOF RECONSTRUCTION

Supervised learning

slide-121
SLIDE 121

121

THE LESSON WE LEARNED*…

* To advance science.

That’s a nice negative result!

slide-122
SLIDE 122

122

… AND HOW WE IMPROVED

*1 Yes, it’s a fake picture… *2 … But the message is correct. *1 *2

slide-123
SLIDE 123

123

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

  • Time Of Flight (TOF) cameras & artifacts
  • Naïve Machine Learning (ML) for TOF reconstruction
  • TOF cameras: working principles
  • Camera calibration
  • The FLAT dataset
  • Spoiler: our non-Naïve ML solution works*
  • Back to physics
  • DNN architecture
  • Results
  • Conclusion

Agenda

* See Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany),

  • Sept. 2018.
slide-124
SLIDE 124

124

BACK TO PHYSICS

Cause: Sequential measurements Effect: Misaligned moving object Solution:Warping

And, more generally speaking, any a-priori knowledge.

time

slide-125
SLIDE 125

125

BACK TO PHYSICS

Cause: DNN architecture and learningmocks physics Effect: Sub-optimal results Solution:Include physics in the DNN architecture / reconstruction pipeline.

And, more generally speaking, any a-priori knowledge.

Naïve machine learning Physics

slide-126
SLIDE 126

126

DNN ARCHITECTURE

#1: Motion Correction Module

Trained to warp images to the central one

slide-127
SLIDE 127

127

DNN ARCHITECTURE

#2: Motion Reflection Module

Trained to reduce multiple reflection after re-alignment.

slide-128
SLIDE 128

128

DNN ARCHITECTURE

#3: Differential reconstruction pipeline

Non-trainable, but differentiable,physics- based reconstruction pipeline.

slide-129
SLIDE 129

129

DNN ARCHITECTURE

#3: Differential reconstruction pipeline

Can be refined with end-to-end training.

slide-130
SLIDE 130

130

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

  • Time Of Flight (TOF) cameras & artifacts
  • Naïve Machine Learning (ML) for TOF reconstruction
  • TOF cameras: working principles
  • Camera calibration
  • The FLAT dataset
  • Spoiler: our non-Naïve ML solution works*
  • Back to physics
  • DNN architecture
  • Results
  • Conclusion

Agenda

* See Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany),

  • Sept. 2018.
slide-131
SLIDE 131

131 NVIDIA CONFIDENTIAL. DO NOT DISTRIBUTE.

RESULTS

Compare against LF2 [1] [Kinect, non DL] DToF [3] [DL, Raw to 3D, no motion] Phasor [2] [High frequencies reduce MPI]

[1] Xiang, et al. libfreenect2: Release 0.2 [2] Marco, et al. DeepToF: Off-the-shelf real -time correction of multipath interference in time-of-flight imaging. In: ACM Transactions on Graphics (SIGGRAPH ASIA). [3] Gupta, et al. Phasor imaging: A generalization of correlation-based time-of- flight imaging. ACM Transactions on Graphics.

Competitors & ablation study

Ablation study MOM [motion only] MRM [multiple reflection and noise only] MOM-MRM [motion, multiple reflection and noise ]

slide-132
SLIDE 132

132

RESULTS

Ablation study: none, MRM, MOM+MRM [simulation]

Median [Med] and Inter Quartile Range [IQR] of the error decreased by MRM / MOM-MRM, in cm.

slide-133
SLIDE 133

133

RESULTS

Ablation study: none, MRM, MOM+MRM [simulation]

slide-134
SLIDE 134

134

RESULTS

Compare against: DTOF, Phasor imaging [simulation]

Smaller error when compared to DToF or Phasor.

slide-135
SLIDE 135

135

RESULTS

Compare against: DTOF, Phasor imaging on multi-reflection and shot noise [simulation]

Field of view

Multiple reflection removed through local reflection / a-priori information, no bias.

slide-136
SLIDE 136

136

RESULTS

Compare against: LF2, on multi-reflection and shot noise [real data]

Multiple reflection removed through local reflection / coherence / a-priori information, no bias.

slide-137
SLIDE 137

137

RESULTS

Compare against: LF2, on movement [real data]

Realignment of raw data reduce motion artifacts, specular reflections (red box) generate errors.

slide-138
SLIDE 138

138

TACKLING 3D TOF ARTIFACTS THROUGH LEARNING AND THE FLAT DATASET

  • Time Of Flight (TOF) cameras & artifacts
  • Naïve Machine Learning (ML) for TOF reconstruction
  • TOF cameras: working principles
  • Camera calibration
  • The FLAT dataset
  • Spoiler: our non-Naïve ML solution works*
  • Back to physics
  • DNN architecture
  • Results
  • Conclusion

Agenda

* See Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz, Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, ECCV 2018, Munich (Germany),

  • Sept. 2018.
slide-139
SLIDE 139

139

CONCLUSION

  • 1. Naïve ML does not always work…
slide-140
SLIDE 140

140

CONCLUSION

  • 1. Naïve ML does not always work…
  • 2. ….But going back to a priori knowledge may help.
slide-141
SLIDE 141

141

CONCLUSION

The physics of ToF cameras: acquisition, reconstruction, artifacts Photon shot noise, motion artifacts, multiple reflection A large dataset of simulated data Design the DNN architecture accordingly to a-priori knowledge Effective reduction of reconstruction artifacts

slide-142
SLIDE 142

142

RESOURCES

Tackling 3D ToF Artifacts Through Learning and the FLAT Dataset, Qi Guo, Iuri Frosio, Orazio Gallo, Todd Zickler, Jan Kautz; The European Conference on Computer Vision (ECCV), 2018,

  • pp. 368-383,

http://openaccess.thecvf.com/content_ECCV_2018/html/Qi_Guo_Tackling_3D_ToF_ECCV_20 18_paper.html The FLAT dataset (code and data): https://github.com/NVlabs/FLAT Contact: {ifrosio, ogallo}@nvidia.com, qiguo@g.harvard.edu

Online
