Symbiotic EDA Suite

www.symbioticeda.com

Symbiotic EDA

• We build Open Source EDA Tools

– And offer commercial versions of those tools with additional

functionality and support → Symbiotic EDA Suite

• We specialize in

– Formal Verification Tools, with focus on Assertion Based Verification

(ABV) using SAT- and SMT-solvers

• Business model → SW Licenses and support

– Custom FPGA Implementation Tools (Synthesis, Place-and-route,

Timing analysis, Bit-stream generation)

• Business model → Custom tool development

Symbiotic EDA Suite Formal Verification Features

• HDL Support (Yosys++)

– Verilog Std. 1995, 2000, 2005 – SystemVerilog Std. 2005, 2009, 2012 – VHDL Std. 1987, 1993, 2000, 2008 – SystemVerilog Assertions (SVA)

• Immediate assert / assume / cover
• Concurrent assert / assume / cover
• Comprehensive SVA properties support
• Safety, liveness, and cover properties
• Types of Formal Methods (SymbiYosys)

– Bounded Model Check (BMC) – Complete proof with k-induction – Automatic complete proof with PDR/IC3 – Formal cover / reachability analysis – Verification of liveness properties – Formal Equivalence Check – Reactive Synthesis

• Supported Engines / Solvers

– SMT-based BMC and k-Induction Engine

• Z3
• Boolector
• Yices2
• CVC4
• Every SMT2 solver supported (BV recommended)

– AIGER-based model checkers

• ABC
• Super Prove
• Avy
• aigbmc

– Direct SAT solving

• Minisat
• Penelope
• (simple API for adding others)

– BTOR2 model checkers

• Boolector

Formal ABV Methodologies Traditional use vs. “Formal first”

• Traditional use of formal ABV

– Proof that the finished design is functionally correct – Exhaustive proofs at the end of the design process – Adds extra NRE cost at end of project – Only attractive for most critical designs

• “Formal first” methodology

– Exhaustive proofs only where it’s easy

• BMC and/or deep restricted BMC otherwise
• No need to cover entire functional spec for added value
• Reuse properties for common interfaces (AXI, Whishbone, etc.)

– Reduce development and verification time

• Formal methods find obscure corner-cases easily
• Formal ABV usually produces very short counter-example traces
• Ad-hoc cover statements can often replace simple ad-hoc test-benches during development

– Requires access to formal tools for design engineers and verification engineers – Attractive for all types of designs

Symbiotic EDA Suite is suitable for both methodologies!

Formal first

“Formal first” vs. traditional use of formal methods

Cost of (fixing) a bug Time Development Verification / Testing Production Traditional use-case for formal Number of new bugs found Most formal tools are priced and advertised for the traditional use case.

Hello World

module hello ( input wire clock, input wire reset,

• utput reg [3:0] dout

); initial dout = 0; always @(posedge clock) begin if (reset) dout <= 0; else dout <= dout + 1; end always @* begin assume (dout != 10); assert (dout != 15); end endmodule [options] mode prove depth 10 [engines] smtbmc z3 [script] read -sv hello.sv prep -top hello [files] hello.sv

hello.sv hello.sby

SBY 17:08:46 [hello] Removing direcory 'hello'. SBY 17:08:46 [hello] Copy 'hello.sv' to 'hello/src/hello.sv'. SBY 17:08:46 [hello] engine_0: smtbmc z3 SBY 17:08:46 [hello] base: starting process "cd hello/src; yosys -ql ../model/design.log ../model/design.ys" SBY 17:08:46 [hello] base: VERIFIC-WARNING [VERI-1209] hello.sv:12: expression size 5 truncated to fit in target size 4 SBY 17:08:46 [hello] base: finished (returncode=0) SBY 17:08:46 [hello] smt2: starting process "cd hello/model; yosys -ql design_smt2.log design_smt2.ys" SBY 17:08:46 [hello] smt2: finished (returncode=0) SBY 17:08:46 [hello] engine_0.basecase: starting process "cd hello; yosys-smtbmc -s z3 --presat --noprogress -t 10

• -append 0 --dump-vcd engine_0/trace.vcd --dump-vlogtb engine_0/trace_tb.v --dump-smtc engine_0/trace.smtc

model/design_smt2.smt2" SBY 17:08:46 [hello] engine_0.induction: starting process "cd hello; yosys-smtbmc -s z3 --presat -i --noprogress -t 10 --append 0 --dump-vcd engine_0/trace_induct.vcd --dump-vlogtb engine_0/trace_induct_tb.v --dump-smtc engine_0/trace_induct.smtc model/design_smt2.smt2" SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Solver: z3 SBY 17:08:46 [hello] engine_0.induction: ## 0:00:00 Solver: z3 SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assumptions in step 0.. SBY 17:08:46 [hello] engine_0.induction: ## 0:00:00 Trying induction in step 10.. ..... SBY 17:08:46 [hello] engine_0.induction: ## 0:00:00 Trying induction in step 5.. SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assumptions in step 1.. SBY 17:08:46 [hello] engine_0.induction: ## 0:00:00 Temporal induction successful. SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assertions in step 1.. SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assumptions in step 2.. SBY 17:08:46 [hello] engine_0.induction: ## 0:00:00 Status: PASSED SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assertions in step 2.. SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assumptions in step 3.. ..... SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assertions in step 7.. SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assumptions in step 8.. SBY 17:08:46 [hello] engine_0.induction: finished (returncode=0) SBY 17:08:46 [hello] engine_0: Status returned by engine for induction: PASS SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assertions in step 8.. SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assumptions in step 9.. SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Checking assertions in step 9.. SBY 17:08:46 [hello] engine_0.basecase: ## 0:00:00 Status: PASSED SBY 17:08:46 [hello] engine_0.basecase: finished (returncode=0) SBY 17:08:46 [hello] engine_0: Status returned by engine for basecase: PASS SBY 17:08:46 [hello] summary: Elapsed clock time [H:MM:SS (secs)]: 0:00:00 (0) SBY 17:08:46 [hello] summary: Elapsed process time [H:MM:SS (secs)]: 0:00:00 (0) SBY 17:08:46 [hello] summary: engine_0 (smtbmc z3) returned PASS for induction SBY 17:08:46 [hello] summary: engine_0 (smtbmc z3) returned PASS for basecase SBY 17:08:46 [hello] summary: successful proof by k-induction. SBY 17:08:46 [hello] DONE (PASS, rc=0)

sby -f hello.sby

Hello World (SVA)

module counter ( input clock, input reset, input up, input down,

• utput reg [7:0] cnt

); always @(posedge clock) begin if (reset) cnt <= 0; else if (up) cnt <= cnt + 8'd 1; else if (down) cnt <= cnt - 8'd 1; end endmodule [options] mode prove depth 10 [engines] smtbmc z3 [script] read -sv counter.sv read -sv counter_sva.sv prep -top counter [files] counter.sv counter_sva.sv

counter.sv counter.sby

module counter_sva ( input clock, input reset, input up, input down, input [7:0] cnt ); default clocking @(posedge clock); endclocking default disable iff (reset); // we have an outside guarantee that down and up can't be both active assume property (down |-> !up); // some simple properties assert property (up |=> cnt == $past(cnt) + 8'd 1); assert property (up [*2] |=> cnt == $past(cnt, 2) + 8'd 2); assert property (up ##1 up |=> cnt == $past(cnt, 2) + 8'd 2); // some more properties assert property (up ##1 down |=> cnt == $past(cnt, 2)); assert property (down |=> cnt == $past(cnt) - 8'd 1); property down_n(n); down [*n] |=> cnt == $past(cnt, n) - n; endproperty assert property (down_n(8'd 3)); assert property (down_n(8'd 5)); endmodule bind counter counter_sva sva_prop_inst (.*);

counter_sva.sv

memcheck.sv

module memory ( input clk, we, input [31:0] addr, input [7:0] wdata,

• utput reg [7:0] rdata

); reg [7:0] bank_0 [0:2**30-1]; reg [7:0] bank_1 [0:2**30-1]; reg [7:0] bank_2 [0:2**30-1]; reg [7:0] bank_3 [0:2**30-1]; always @(posedge clk) begin case (addr[1:0]) 2'b 00: begin rdata <= bank_0[addr >> 2]; if (we) bank_0[addr >> 2] <= wdata; end 2'b 01: begin rdata <= bank_1[addr >> 2]; if (we) bank_1[addr >> 2] <= wdata; end 2'b 10: begin rdata <= bank_2[addr >> 1]; // <- BUG if (we) bank_2[addr >> 2] <= wdata; end 2'b 11: begin rdata <= bank_3[addr >> 2]; if (we) bank_3[addr >> 2] <= wdata; end endcase end endmodule

memcheck.sv

module memcheck ( input clk, we, input [31:0] addr, input [7:0] wdata,

• utput [7:0] rdata

); memory uut ( .clk (clk ), .we (we ), .addr (addr ), .wdata(wdata), .rdata(rdata) ); checker monitor; rand const reg [31:0] monitor_addr; rand const reg [7:0] monitor_data; assert property ( @(posedge clk) (we && addr == monitor_addr && wdata == monitor_data) ##1 (!we || addr != monitor_addr) [*] ##1 (addr == monitor_addr) |=> rdata == monitor_data ); endchecker endmodule

[options] mode bmc expect fail depth 10 ...

memcheck.sby

sby -f memcheck.sby SBY 18:22:58 [memcheck] Removing direcory 'memcheck'. SBY 18:22:58 [memcheck] Copy 'memcheck.sv' to 'memcheck/src/memcheck.sv'. SBY 18:22:58 [memcheck] Copy 'memcheck_mem.sv' to 'memcheck/src/memcheck_mem.sv'. SBY 18:22:58 [memcheck] engine_0: smtbmc z3 SBY 18:22:58 [memcheck] base: starting process "cd memcheck/src; yosys -ql … SBY 18:22:58 [memcheck] base: finished (returncode=0) SBY 18:22:58 [memcheck] smt2: starting process "cd memcheck/model; yosys -ql … SBY 18:22:58 [memcheck] smt2: finished (returncode=0) SBY 18:22:58 [memcheck] engine_0: starting process "cd memcheck; yosys-smtbmc … SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Solver: z3 SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Checking assumptions in step 0.. SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Checking assertions in step 0.. SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Checking assumptions in step 1.. SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Checking assertions in step 1.. SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Checking assumptions in step 2.. SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Checking assertions in step 2.. SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Checking assumptions in step 3.. SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Checking assertions in step 3.. SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 BMC failed! SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Assert failed in memcheck: memcheck.sv:25 SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Writing trace to VCD file: engine_0/trace.vcd SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Writing trace to Verilog testbench: engine_0/trace_tb.v SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Writing trace to constraints file: engine_0/trace.smtc SBY 18:22:58 [memcheck] engine_0: ## 0:00:00 Status: FAILED (!) SBY 18:22:58 [memcheck] engine_0: finished (returncode=1) SBY 18:22:58 [memcheck] engine_0: Status returned by engine: FAIL SBY 18:22:58 [memcheck] summary: Elapsed clock time [H:MM:SS (secs)]: 0:00:00 (0) SBY 18:22:58 [memcheck] summary: Elapsed process time [H:MM:SS (secs)]: 0:00:00 (0) SBY 18:22:58 [memcheck] summary: engine_0 (smtbmc z3) returned FAIL SBY 18:22:58 [memcheck] summary: counterexample trace: memcheck/engine_0/trace.vcd SBY 18:22:58 [memcheck] DONE (FAIL, rc=0)

multiclk.sv

module multiclk(input clk, output [3:0] counter_a, counter_b); reg [3:0] counter_a = 0; reg [3:0] counter_b = 0; always @(posedge clk) counter_a <= counter_a + 1; always @(posedge clk) counter_b[0] <= !counter_b[0]; always @(negedge counter_b[0]) counter_b[1] <= !counter_b[1]; always @(negedge counter_b[1]) counter_b[2] <= !counter_b[2]; always @(negedge counter_b[2]) counter_b[3] <= !counter_b[3]; always @* assert (counter_a == counter_b); endmodule

... [options] ... multiclock on ... ...

multiclk.sby

setreset.sv

module setreset(input clk, input set, rst, d, output q1, q2); reg q1 = 0; always @(posedge clk, posedge set, posedge rst) if (rst) q1 <= 0; else if (set) q1 <= 1; else q1 <= d; reg q2_s = 0, q2_r = 0, q2_l; wire q2 = q2_l ? q2_s : q2_r; always @(posedge clk, posedge set) if (set) q2_s <= 1; else q2_s <= d; always @(posedge clk, posedge rst) if (rst) q2_r <= 0; else q2_r <= d; always @* begin if (rst) q2_l <= 0; else if (set) q2_l <= 1; always @* assert (q1 == q2); endmodule

... [options] ... multiclock on ... ...

setreset.sby

SymbiYosys example flow with Yosys-SMTBMC

Verilog Design Verilog Asserts Yosys SMT-LIB2 Code Constraints File Yosys-SMTBMC PASS / FAIL VCD File Verilog Testbench Constraints File

Trace / counterexample formats

SMT-LIB2 Solver

SymbiYosys example flow with AIGER model checker

Verilog Design Verilog Asserts Yosys AIGER Model Checker (e.g. pdr, avy) AIGER witness SMT-LIB code Yosys-SMTBMC Counter Example SMT-LIB2 Solver

unoptimized word-level representation, good for creating human readable counter examples

• ptimized bit-level model

Yosys-SMTBMC is only used here as a post- processor, turning the AIGER witness into a useful human readable counter example (e.g. VCD). PASS/FAIL

Non-trivial use case: riscv-formal

• riscv-formal is a verification IP for formal “black-box” verification of

RISC-V Processor Cores against the RISC-V ISA spec.

• riscv-formal is verifying real-world RISC-V processors cores (Rocket,

VexRiscv, PicoRV32) using SymbiYosys.

• Processors must implement RVFI (RISC-V Formal Interface) to be

verifiable using riscv-formal.

• riscv-formal spec is formally verified for equivalence against riscv-

isa-sim (aka Spike), the official C++ reference simulator.

• It is also formally verified against riscv-semantics, aka “the RISC-V

MIT Model” and upcoming official RISC-V formal spec written in Haskell.

• Currently supported ISAs: User-Mode RV32IMC, RV64IMC
• Currently in development: M-Mode, S-Mode, F/D/Q-Extension

Additional Features of Symbiotic EDA Suite

• We continuously improve Symbiotic EDA Suite

– All new features go into Symbiotic EDA Suite – Instantly available to all existing customers – No “optional features” with extra license cost

• Verification IPs (under development)

– Standard bus interfaces (AXI, Wishbone, Avalon, …) – Library of example projects to use as starting point for verification tasks

• Additional Tools (under development)

– QMC-Fuzzer: A tool to produce a universal quality metrics for test

methodologies, utilizing formal method and fuzzing techniques.

• Various advantages over functional coverage and code coverage metrics

Symbiotic EDA Suite Licensing Options

• Symbiotic-CE – Cloud Edition

Dedicated cloud instances with Symbiotic EDA Suite pre-installed, rent by the hour

• Symbiotic-FL – Floating Licenses

Run on any machine, pay license fees by the hour (100 hours per month included in base package), premium user support, needs Internet access

• Symbiotic-WE – Workgroup Edition

Unlimited runtime on up to 20 nodes (nodes can be changed at any time), plus 200 hours floating licenses per month, premium user support

• Symbiotic-OS – Open Source

Premium and developer support for the open source stack. Includes support for Yosys C++ API, Yosys Python API, and Yosys-SMTIO Python API.

• Symbiotic-EE – Enterprise Edition

Unlimited number of nodes and premium and developer support.

Symbiotic-WE Workgroup Edition

• Contains

– 20 node locked licenses – 200 hours floating (use on any node) – Premium Support

• Access to Symbiotic License Portal

– Self-service for managing node locked licenses

• create node-locked licenses as needed
• max 20 active licenses at each point in time
• contact business support if more licenses are needed for a short period of time

(for example during switch-over periods when making changes to infrastructure)

– Monitoring and management of floating licenses

• Create and manage floating licenses and quotas
• Monitor the use of floating licenses

Price: € 50.000,- / year € 4.800,- / month

Symbiotic EDA Suite

www.symbioticeda.com

fib.sv

module fib ( input clk, pause, start, input [3:0] n,

• utput reg busy, done,
• utput reg [9:0] f

); reg [3:0] count; reg [9:0] q; initial begin done = 0; busy = 0; end always @(posedge clk) begin done <= 0; if (!pause) begin if (!busy) begin if (start) busy <= 1; count <= 0; q <= 1; f <= 0; end else begin q <= f; f <= f + q; count <= count + 1; if (count == n) begin busy <= 0; done <= 1; end end end end `ifdef FORMAL always @(posedge clk) begin if (busy) begin assume (!start); assume ($stable(n)); end if (done) begin case ($past(n)) 0: assert (f == 1); 1: assert (f == 1); 2: assert (f == 2); 3: assert (f == 3); 4: assert (f == 5); 5: assert (f == 8); endcase cover (f == 13); cover (f == 144); cover ($past(n) == 15); end assume property (s_eventually !pause); if (start && !pause) assert property (s_eventually done); end `endif endmodule

fib_{prove,live,cover}.sby

[options] mode prove [engines] abc pdr [script] read_verilog -formal fib.sv prep -top fib [files] fib.sv fib_prove.sby [options] mode live [engines] aiger suprove [script] read_verilog -formal fib.sv prep -top fib [files] fib.sv fib_live.sby [options] mode cover append 10 [engines] smtbmc yices [script] read_verilog -formal fib.sv prep -top fib [files] fib.sv fib_cover.sby

Prove safety properties in fib.v using IC3 (pdr). Prove liveness properties in fib.v. This assumes that safety properties are already proven. Create a trace for each cover statement in the design (and check asserts for that trace). Add 10 additional time steps after the cover statement has been reached.

parcase.sv

module parcase (input clk, A, B, C, D, E, BUG, output reg Y); always @(posedge clk) begin Y <= 0; if (A != B || BUG) begin (* parallel_case *) case (C) A: Y <= D; B: Y <= E; endcase end end endmodule

[script] read_verilog -formal parcase.v prep -top parcase assertpmux $ sby -f parcase.sby … … Assert failed in parcase: parcase.v:6 … SBY [parcase] DONE (FAIL)

Safety Properties: Are the bad states reachable from the initial states ?

reachable states (implicit) assertions (explicit) unreachable non- bad states. many of those usually implies a difficult proof.

Bounded Model Check (BMC)

In steps 1 .. k-1: UNSAT → next step SAT → FAIL In step k: UNSAT → PASS SAT → FAIL

1 2 3 k-1 1 1 1 2 2 3

Step 1: Step 2: Step 3: Step 4: Step k: BMC proves that no bad state is reachable within k cycles.

k-Induction

k-1 k k-2 k-3 k-1 k k-2 k-3 k-1 k k-2 k-1 k k

Step 1: Step 2: Step 3: Step 4: Step k+1: In steps 1 .. k: SAT → next step UNSAT → PASS In step k+1: SAT → UNKNOWN UNSAT → PASS k-induction proves that a sequence of k non-bad states is always followed by another non-bad state. The k used for induction must be ≤ the k used in BMC for a valid complete proof.

Free Variables

• (* anyseq *) wire [7:0] cmd;

– Behaves like an additional primary input

• (* anyconst *) wire [7:0] cmd;

– Behaves like an additional primary input that is latched in the

first cycle.

• rand reg [7:0] cmd;
• rand const reg [7:0] cmd;

– For improved SV compatibility (only valid SV in checker …

endchecker block, Yosys supports it everywhere)

Special “forall” Variables

• (* allseq *) wire [7:0] cmd;

– Find a trace so that assumptions are satisfied for all possible

sequences of values in cmd. Only one of those values needs to violate an assertion for a CEX.

• (* allconst *) wire [7:0] cmd;

– Find a trace so that assumptions are satisfied for all possible

constant values in cmd. Only one of those values needs to violate an assertion for a CEX.

• This features can be used to construct exists-forall (

) SMT2 ∃∀ problems using Verilog code. (Requires SMT solver with quantifier support, such as Z3.)

∃∀ Example: Find a prime

module primegen; (* anyconst *) wire [31:0] prime; (* allconst *) wire [15:0] factor; always @* begin if (1 < factor && factor < prime) assume((prime % factor) != 0); assume(prime > 1000000000); cover(1); end endmodule Z3 after 35 seconds: 2359012091

∃∀ Example: Find two primes with a prime gap of 500

module primes; parameter [8:0] gap = 500; (* anyconst *) wire [8:0] prime1; wire [9:0] prime2 = prime1 + gap; (* allconst *) wire [4:0] factor; always @* begin if (1 < factor && factor < prime1) assume((prime1 % factor) != 0); if (1 < factor && factor < prime2) assume((prime2 % factor) != 0); assume(1 < prime1); cover(1); end endmodule Z3 after 2 seconds: 173 and 673
