Surveillance & Home Automation for the Smart Home AllJoyn and Kalay Integration Yuping Tseng Chief Technology Officer ThroughTek Co., Ltd. 10/15/2015 AllSeen Alliance 1 Agenda 1. Introduction About ThroughTek 2. Kalay Platform &
10/15/2015 AllSeen Alliance 2
- 1. Introduction About ThroughTek
- 2. Kalay Platform & Cloud Modules
- 3. Use Applications:
Surveillance & Home Automation
- 4. Future Possibilities:
Smart Home and Beyond
Agenda
3
Introduction About ThroughTek
10/15/2015 AllSeen Alliance 4
About ThroughTek
- Established in July 2008
- Employees: 170+
- Headquarters: Taipei, Taiwan
- Branches:
– Shenzhen – Shanghai – Yilan – London
15 October 2015 AllSeen Alliance 5
Objectives
- Develop strategic services to optimize product experiences across
company lines and industries Services include:
- Multimedia Streaming Interface – to enable data transmission of
multimedia between AllJoyn devices
- Kalay Cloud Platform – provide cloud services:
Video streaming, cloud recording, push notification service, device/account management, data analytics
6
Kalay Platform
Platform Structure
10/15/2015 AllSeen Alliance 7
“Handshake” in the language of the aboriginal Tao people of Taiwan
7,000,000
Connected Devices
100,000,000
Connections per Month
What Does Kalay Mean?
10/15/2015 AllSeen Alliance 8
SDK & RESTful APIs
Consumer
Device Layer
Enterprise
Retail Industry Agriculture Home Storage Wearables
3rd Party Modules 3rd Party Modules
Data Analytics VSaaS Cloud Storage Push Notification Concurrent Relay/P2P
Kalay Connect
Device/Account Management
IoT Ecosystem Simplified
10/15/2015 AllSeen Alliance 9
Rapid Solution for SOC Integration
Support over 150 SOCs from 40+ chipset vendors Easy integration and cross-platform connectivity Time-to-market with cost effective solution
10/15/2015 AllSeen Alliance 10
Applied over 7 million devices
Kalay Ecosystem Partners
10/15/2015 AllSeen Alliance 11
- Protocol Agnostic
- SOC Support, 150+ Integration
- Generic Applications & Portal
- Customization Service
Windows Mac OS Android iOS
Kalay Cloud Kalay Connect Kalay Apps
Platform Overview
150+ SOC
12
Surveillance and Home Automation
Sample applications with AllJoyn and Kalay Integration
10/15/2015 AllSeen Alliance 13
What Each Framework Offers
AllJoyn and Kalay Integration Cloud services for connectivity
- ver internet:
- Video Streaming (two-way)
- Cloud Recording
- Push Notification
- Device Management
- Data Analytics
Service runs on local network and enables:
- Discovery
- Advertisement
- Notification
- Gateway Agent
Kalay AllJoyn
10/15/2015 AllSeen Alliance 14
Powertech – Smart Plug: Control turn on/off lighting, device management LG - Smart TV: Receive push notification of live feed of what’s happening Raspberry Pi – Gateway Agent: Connect over internet PESI – Set-Top Box: Gateway, storage of multimedia Haier – Air Conditioner: Remote control and adjust temperature EasyN – IP Camera: Recorded videos stored to the cloud and accessed remotely
Outdoor Environment
Doorphone: Deliver real-time video feed to mobile and TV
10/15/2015 AllSeen Alliance 15
- Combine AllJoyn notification framework and Kalay Multimedia SDK
- App developed to integrate Kalay and Gateway Agent Framework
- Kalay Cloud Service used for remote access
Kalay
Cloud Service
IP Camera
Notification Service Framework Kalay Multimedia SDK
Raspberry Pi
(Gateway Agent)
Gateway Agent Framework Kalay BOX SDK
LG TV
Notification Service Framework
PESI Set Top Box with Storage
Notification Service Framework Kalay Multimedia SDK
Mobile Device
Gateway Agent Framework Kalay Multimedia SDK
AllJoyn Kalay
Use Case: Smart Home Surveillance
(IoT Security)
16
Kalay Platform
Cloud Service Modules
10/15/2015 AllSeen Alliance 17
Kalay P2P / Relay Server
- P2P delivers live feed with two-way communication for
reduced data costs & greater privacy
- P2P and Relay means always connected
UID Verify Access with UID & Password Connection Established Kalay P2P / Relay Server
Device
Device Firmware UID Kalay API Modules Host OS
Client
Browser or App Kalay API Modules Host OS
10/15/2015 AllSeen Alliance 18
Kalay Platform
- P2P real time live streaming
- Flexible cloud recording securely stored on cloud storage
- APIs to integrate 3rd party value-added applications & services
Video Surveillance as a Service
10/15/2015 AllSeen Alliance 19
- Supports push for text, image or video
- Push scheduling
TPNS Server Push Networks
Baidu Google Cloud Message Apple Push Notification
Push Notification System
10/15/2015 AllSeen Alliance 20
Monitor, search and manage all
devices by group or individually
Collect and record device data for
further analysis
Device Management
Define multiple user types Manage user account with full
permission control and visibility
Account Management
Kalay Management
Secure Identity of Things Service by TrendMicro
Authentication
Management
Access
Enforcement
Access
Analysis
10/15/2015 AllSeen Alliance 21
Business intelligence reports Define the data type and
contents to be collected Data Analytics
See location of devices as they log in See distribution of actions (p2p, relay, login, banned)
Real Time Insights
See data collected from various sensors
22
Future Possibilities: Smart Home and Beyond
10/15/2015 AllSeen Alliance 23
Smart Cities
10/15/2015 AllSeen Alliance 24 24
Visit our website:
- Our latest white paper with Machina Research
“Combining the four pillars of innovation within the Internet of Things in one platform”
Our open SDK Kalay Kit:
- http://www.throughtek.com
Learn More About ThroughTek
10/15/2015 AllSeen Alliance 25
- r visit www.throughtek.com
