BEHCHOKǪ̀ WATER LICENCE

Surveillance Network Program (SNP)

Updated June 2017

SURVEILLANCE NETWORK PROGRAM

IMPORTANCE OF COMPLIANCE

▪Ensures the protection of the land and the water, which in-turn ensures the safety of wildlife and fish ▪Healthy environment = Healthy people ▪The Water Licence is a legally binding authorization

SURVEILLANCE NETWORK PROGRAM

TABLE OF CONTENTS

Step 1. Safety Step 2. Preparation Step 3. Sampling Procedure – Part 1 - 4 Step 4. Sampling Locations & Requirements Step 5. Sampling & Analysis Step 6. Storing and Reporting Sampling Data

STEP 1. SAFETY

BEFORE SAMPLING, MAKE SURE YOU ARE PREPARED WITH THE FOLLOWING:

Vaccinations

It is recommended that you get the vaccinations for:

• 1. Hepatitis A & B
• 2. Tetanus

Hand Sanitizer

Use hand sanitizer wipes after each sample

Gloves + Field Gear

Make sure you wear proper field gear such as boots Use gloves during sampling and discard afterwards inside cooler

STEP 2. PREPARATION

BEFORE SAMPLING, MAKE SURE THAT YOU PREPARE THE NECESSARY EQUIPMENT AND CONTACTS:

Pick a date!

Select a date each month to collect samples

Bottles and Cooler

Order bottles and a cooler from Taiga Lab 3 days advance of sampling date (use bottle order form, see Additional Attachments)

Ice packs

Community should have ice packs ready to keep samples cold (but not frozen)

Taiga Lab

Contact Taiga Lab and let them know you are planning to send them samples

Additional Bottles

TSS, Ammonia, Phosphate Faecal Coliforms Phenols Mercury & Total Metals BOD/ CBOD Oil & Grease pH/ Conductivity

STERILE PHENOL

BTEX: (2 vials per sample; NO AIR IN BOTTLES) TPH: Requires both the oil and grease and BTEX bottles

STEP 2. PREPARATION

BEFORE SAMPLING, PREPARE THE NECESSARY EQUIPMENT & CONTACTS:

Label Bottles

Label each bottle with:

• 1. Licence ‘#W2014L3-0002’ (Submission No.)
• 2. SNP # (Field Sample No.)
• 3. Date and Time
• 4. ‘Behchoko– SNP’ (Sample Description)

STEP 2. PREPARATION

BEFORE SAMPLING, PREPARE THE NECESSARY EQUIPMENT & CONTACTS:

Transport Bottles

• 1. Sample the same day (e.g. the morning) that they will be shipped
• 2. Complete Laboratory Order Form (See Additional Attachments)
• 3. Arrange with Air Tindi for delivery of samples to Yellowknife

4.Arrange with Taiga Lab to pick up samples from Air Tindi

• 5. Samples should be submitted within 24 hours of sampling

STEP 2. PREPARATION

BEFORE SAMPLING, MAKE SURE THAT YOU PREPARE THE NECESSARY EQUIPMENT AND CONTACTS:

STEP 3. SAMPLING PROCEDURE PART 1

• 1. Sample at the cleanest location first and as close to flight time as

possible (e.g. late morning if early afternoon flight, etc.)

• 2. AT EACH SNP LOCATION:

a) Wear gloves b) Ensure bottles are labeled before collecting samples c) Collect samples d) Place used bottles in cooler and keep unused bottles in separate bag e) Discard used gloves in cooler f) Use hand sanitizer wipes

STEP 3. SAMPLING PROCEDURE PART 3

Rinse Bottles 3 times, shake with lid on top, and dump away from sampling area before taking actual sample filled to the top “Fill, shake, and dump” x 3

FOR SAMPLING REQUIREMENTS:

pH/ Conductivity TSS, Ammonia, Phosphate Mercury & Total Metals BOD/ CBOD

STEP 3. SAMPLING PROCEDURE PART 4

DO NOT rinse bottle before taking actual sample. Instead, fill bottle to the top and record the time of day the sample was taken

FOR SAMPLING REQUIREMENTS:

Oil & Grease

STERILE

Faecal Coliforms

BTEX: (2 vials per sample; NO AIR IN BOTTLES) TPH: Requires both the oil and grease and BTEX bottles

Phenols

PHENOL

SAMPLING SUMMARY

Sampling Parameters Bottles Needed Frequency of Sampling

Cubic metres n/a Daily: E1 & R1

BOD5 , CBOD, Faecal Coliforms, pH, Suspended Solids, Ammonia-Nitrogen, and Total Phosphate

Monthly (June – October): E2, E3, E4, E5 10+ days prior to decant: R2 Weekly (see details): R3 Weekly (see details): R4

Sodium, Potassium, Magnesium, Sulphate, Total Phenols, Oil and Grease, Conductivity, Calcium, Total Lead, Total Chromium, Total Nickel, Total Iron, Total Cadmium, Total Copper, Total Mercury, and Total Zinc

Once (June – October): E2, E3, E4, E5, R3, and R4

pH, Total Zinc, Sodium, Suspended Solids, Magnesium,Total Phosphate, Potassium, Sulphate, Total Phenols, Oil and Grease, Conductivity, Calcium, Total Lead, Total Chromium, Total Nickel, Total Iron, Total Cadmium, Total Copper, Total Mercury, Faecal Coliforms, BTEX, and TPH

Twice per year during the months of June and September: R5, R6, R7, R8, R9, and R10

h h h h h h h h h h h h h h see insert 2 Water Supply Facilities Great Slave Lake see insert 1 see insert 1 F r a n k C h a n n e l E1 R4 R1

Rae Edzo Behchokǫ̀ Rae Point Smith Island Old Fort Rae Mosquito Lake Bedford Point Peter Baker Bay Russell Channel 115°40'0"W 115°45'0"W 115°45'0"W 115°50'0"W 115°50'0"W 115°55'0"W 115°55'0"W 116°0'0"W 116°0'0"W 116°5'0"W 116°5'0"W 116°10'0"W 116°10'0"W 116°15'0"W 116°15'0"W 62°58'0"N 62°56'0"N 62°56'0"N 62°54'0"N 62°54'0"N 62°52'0"N 62°52'0"N 62°50'0"N 62°50'0"N 62°48'0"N 62°48'0"N 62°46'0"N 62°46'0"N 62°44'0"N 62°44'0"N 62°42'0"N 62°42'0"N 62°40'0"N 62°40'0"N

h h h h Great Slave Lake Insert 2 E1 E2 E4 E3 h h h h h h h h h Insert 1

• ld solid

waste facility proposed new solid waste facility R a e A cces s Roa d R6 R7 R8 R9 R2 R3 R5 R4 R10

1:24,000

1:125,000

SNP Stations of Water Licence W2014L3-0002 Tlicho Community of Behchoko

Ü

Legend h

SNP Stations Road Stream Structures Community Boundary Water

This map demonstrates the Surveillance Network Program (SNP) sampling stations of the Tlicho Community of Behchoko’s Water Licence WL2014L3-0002. The accuracy of the SNP locations cannot be guaranteed. This map is for illustrative purposes only. This is not a legal document, and should not be treated as such. Map Description: Coordinate System: NAD 1983 UTM Zone 11N Projection: Transverse Mercator Datum: North American 1983 False Easting: 500,000.0000 False Northing: 0.0000 Central Meridian: -117.0000 Scale Factor: 0.9996 Latitude Of Origin: 0.0000 Units: Meter Map Information: SNP Stations (GPS unit, June, 2017) Road, Stream, Structure, Boundary, Water (GNWT, Accessed Jun 8, 2017) Map Produced: Jun 9, 2017 Data Source: This map is created for the Wek'èezhìi Land and Water Board. For regulatory related questions, please contact the WLWB or visit www.wlwb.ca. For mapping related questions, please contact: Jacqueline Ho Regulatory Technician Sahtu Land and Water Board 867 766 7465 jacqueline.ho@slwb.com www.slwb.com 1 2 3 4 5 0.5 Kilometers www.wlwb.ca

SNP 2014-E1 - Active

Where: N62 46 45.1 W116 01 36.9

Raw water intake line at the Water Supply Facilities serving Edzo

Sampling Requirements: Quantity and Frequency

Measured & recorded in cubic metres (m3) 1 volume reading daily

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

SNP 2014-E2 – Active

Where: N62 46 16.1 W116 01 35.6

In the Sewage Disposal Facilities serving Edzo, immediately prior to flowing towards the

• verflow ditches

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

Sampling Requirements:

1 sample monthly from June – October 1 sample between June – October

Sampling Requirements:

SNP 2014-E3 – Active

Where: N62 46 16.1 W116 01 30.0

Point of junction at the outflow ditches from the Sewage Disposal Facilities serving Edzo

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

1 sample monthly from June – October 1 sample between June – October

P

SNP 2014-E4 – Active

Where: N62 46 09.9 W116 01 13.4

In natural wetland system, immediately prior to entering Great Slave Lake If unable to sample at this location, please see 2014-E5

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

Sampling Requirements:

1 sample monthly from June – October 1 sample between June – October

P

Sampling Requirements:

SNP 2014-E5 – Inactive

Where:

Great Slave Lake downstream from Sewage Disposal Facilities serving Edzo

ONLY SAMPLE HERE IF 2014-E4 IS UNABLE TO BE SAMPLED

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

Sampling Requirements:

1 sample monthly from June – October 1 sample between June – October

P

SNP 2014-R1 - Active

Where: N62 49 36.5 W116 03 14.8

Raw water intake line at the Water Supply Facilities serving Rae

Sampling Requirements: Quantity and Frequency

Measured & recorded in cubic metres (m3) 1 volume reading daily

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

Sampling Requirements: Quantity and Frequency

1 sample at least 10 days prior to decant

SNP 2014-R2 – Active

Where: N62 49 53.9 W116 00 33.9

Sewage Disposal Facilities Serving Rae near decant structure Send results to an Inspector prior to decant

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

Sampling Requirements:

SNP 2014-R3 – Active

Where: N62 49 43.9 W116 00 02.9

Point of outflow from the Sewage Disposal Facilities Serving Rae at the culvert crossing the Rae Access road

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

Sampling Requirements:

1. Weekly, beginning two weeks before decant

• 2. every three days during decant flow
• 3. 1 sample one week after the end of decant flow

1 sample between June – October

P

Sampling Requirements:

SNP 2014-R4 – Active

Where: N62 49 27.5 W116 59 10.6

At the end of Rae Wetland prior to entering Frank’s Channel

*During decant flow, this sample should be collected one day following collection of the sample at 2014-R3, or as determined by the retention time of the wetlands, to ensure that the effluent has reached this location

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

Sampling Requirements:

1. Weekly, beginning two weeks before decant

• 2. every three days during decant flow*
• 3. 1 sample one week after the end of decant flow

1 sample between June – October

P

Sampling Requirements: Quantity and Frequency

2 samples per year during the months of June and September

SNP 2014-R5 – Active

Where: N62 49 40.3 W117 13 50.2

Run-off from old Solid Waste Disposal Facilities (north-west of Landfarm)

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

P

Sampling Requirements: Quantity and Frequency

2 samples per year during the months of June and September

SNP 2014-R6 – Active

Where:

New Solid Waste Disposal Facilities (north of waste footprint)

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

P

Sampling Requirements: Quantity and Frequency

2 samples per year during the months of June and September

SNP 2014-R7 – Active

Where:

New Solid Waste Disposal Facilities (north-east

• f waste footprint, south-east of SNP station

2014-R6)

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

P

Sampling Requirements: Quantity and Frequency

2 samples per year during the months of June and September

SNP 2014-R8 – Active

Where:

New Solid Waste Disposal Facilities (south of waste footprint, north of waterbody)

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

P

Sampling Requirements: Quantity and Frequency

2 samples per year during the months of June and September

SNP 2014-R9 – Active

Where:

New Solid Waste Disposal Facilities (south of waste footprint, east of waterbody, south-east

• f SNP station 2014-R8)

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

P

Sampling Requirements: Quantity and Frequency

2 samples per year during the months of June and September

SNP 2014-R10 – Active

Where:

New Solid Waste Disposal Facilities (south of waste footprint, west of waterbody, south-west

• f SNP station 2014-R9)

STEP 4. SAMPLING LOCATIONS & REQUIREMENTS

P

STEP 5. SAMPLING & ANALYSIS

Send samples to the Taiga Environmental Laboratory in Yellowknife for analysis along with the laboratory order form Taiga will send you your results back in 14 days

When results come back from Taiga:

Record results and Fill out template for annual reporting (DUE MARCH 31 EACH YEAR), including reporting of all SNP results (ELECTRONIC TEMPLATE PROVIDED IN THE WLWB’s ONLINE REGISTRY AT WWW.WLWB.CA)

STEP 6. STORING AND REPORTING DATA

STEP 6. STORING AND REPORTING DATA

ANNUAL REPORT TEMPLATE SNP RESULTS LICENCE REQUIREMENTS

STEP 6. STORING AND REPORTING DATA

ANNUAL REPORT TEMPLATE SNP RESULTS

19 mg/l 6.48 mg/l

LICENCE REQUIREMENTS

 Sample bottles (pre-labelled) and cooler Ice Packs  Heavy duty garbage bags (to carry bottles)  Rubber gloves - at least one clean pair per SNP site (dispose of used gloves into garbage bag with the sample bottles)  Hand sanitizer  Rubber boots  Permanent markers

SAMPLING CHECKLIST

CONTACTS

4601 - 52nd Avenue Yellowknife, NT X1A 3Z4 Phone: (867) 767-9325 ext. 53151 Fax: (867) 920-8740 Email: taiga@gov.nt.ca *To order Bottles and Cooler: Fax or email the form to Taiga Lab Airport Location 101 Berry Street P.O. Box 1693 Yellowknife, NT X1A 3Z4 Phone: (867) 669-8200 Toll-Free: 1-888-545-6794 #1-4905 48th St Yellowknife, NT X1A 3S3 Telephone: (867) 765-4592 Fax: (867) 765-4593 Water Resource Officer Heather Beck and Nahum Lee Phone: (867) 767-9238 ext. 53243/53244 Email: Heather_Beck@gov.nt.ca and Nahum_Lee@gov.nt.ca
