Supercut A Mobile Board Processing Tool Product Presentation - - PowerPoint PPT Presentation
Supercut A Mobile Board Processing Tool Product Presentation Supercut | May 09 | 1 Supercut Brief Description A mobile cutting and working table for almost all board format materials Scope of application: dry mortarless construction,
Product Presentation Supercut | May 09 | 1
Product Presentation Supercut | May 09 | 2
Brief Description
Scope of application: dry mortarless construction, interior construction, acoustics construction, timber construction, facade construction, trade fair construction, set and scene construction etc. A mobile cutting and working table for almost all board format materials
Product Presentation Supercut | May 09 | 3
Advantages
polishing etc.
with high-quality units and tools
patented folding table fits through every door frame
zero training time and effort
elaborate and complex formed parts
with powerful and universal anti-dust system
quick yield starting with the first cut
Product Presentation Supercut | May 09 | 4
Control Panel with Digital Display
button
Product Presentation Supercut | May 09 | 5
Milling Unit
types like v-groove cutters, end milling cutters, flute, and form cutters
for the unit
Product Presentation Supercut | May 09 | 6
Cutting Unit
module
the unit
Product Presentation Supercut | May 09 | 7
Drilling Unit
Product Presentation Supercut | May 09 | 8
Brushing and Polishing Unit
calendering, and polishing
adapters
Product Presentation Supercut | May 09 | 9
unit for milling/ profiling fixture
Cutting with template up to a work piece size of: width: 1300 mm; length: 750 mm; board thickness: up to 45 mm
Milling/ Profiling Fixture
Product Presentation Supercut | May 09 | 10
Technical Data
Cutting Width - up to 1300 mm 51.2in Cutting Length - up to 2600 mm 102.4 in Cutting Depth - up to 62 mm 2.45 in Milling Depth - up to 51 mm 2.0 in Board Thickness - up to 80 mm 3.15 in Weight (total) – ca. 150 kg 330 lbs Power Requirement: 230 V/50 Hz
Power Consumption:
Dimensions – Folded Table: Length: 1950 mm 76.8 in Width: 650 mm 25.6 in Height: 1930 mm 76.0 in Dimensions – Unfolded Table: Length: 3000 mm 118.1 in Width: 1950 mm 76.8 in Height: 1360 mm 53.5 in Working Height: 800 mm 31.5 in
Product Presentation Supercut | May 09 | 11
Technical Data
Cutting Width - up to 1300 mm 51.2in Cutting Length - up to 2600 mm 102.4 in Cutting Depth - up to 62 mm 2.45 in Milling Depth - up to 51 mm 2.0 in Board Thickness - up to 80 mm 3.15 in Weight (total) – ca. 150 kg 330 lbs Power Requirement: 230 V/50 Hz
Power Consumption:
Dimensions – Unfolded Table: Length: 1500 mm 59.0 in Width: 1950 mm 76.8 in Height: 1360 mm 53.5 in Working Height: 800 mm 31.5 in
Product Presentation Supercut | May 09 | 12
Processible Materials
Title | Rev. | Division | Firstname Lastname | 20/11/2007 | 12
gypsum plasterboard (GKB, GKBI, GKF, GKFI) composite materials wooden boards GKF boards pattern plates multilayer boards Rigiform calcium silicate plates OSB boards wood composite boards MDF boards aluminium boards white fiber boards formwork boards Eternit boards Heraklith polystyrene boards insulating boards massive boards Alucobond Thermax boards aluminium composite boards facade boards Plexiglass plastic composite boards fireboards PU foam boards insulating materials fire protection boards spring groove press boards Fermacell boards Styrofoam laminate boards polystyrene carbon fiber boards building boards dry bottom-boards fiber composite boards perforated boards double bottom-boards counter tops/work surfaces tile cuts etc. Heraklith ceiling systems parquet floors
Product Presentation Supercut | May 09 | 13
