Mixing in microfluidic structures Dr. Ing. Daniel Jussen B. Sc. David Lthy Dr. Ing. Peter Riedlberger Microprocess engineering and particulate systems Advantages: Challenges: Rapid mixing Macro to micro interface Defined

slide-1
SLIDE 1

Mixing in microfluidic structures

  • Dr. Ing. Daniel Jussen
  • B. Sc. David Lüthy
  • Dr. Ing. Peter Riedlberger
slide-2
SLIDE 2

Microprocess engineering and particulate systems

Advantages:

  • Rapid mixing
  • Defined temperature

control

  • Continuous processing
  • Ease of serial reactions
  • Favorable for hazardous

processes

  • Ease of Scale up
  • Flexible processes

Challenges:

  • Macro to micro interface
  • Backpressure
  • Fouling
  • Overhead
slide-3
SLIDE 3

Microfluidic mixing concepts

Kashid, M. N., Renken, A., & Kiwi-Minsker, L. (2015). Microstructured Devices for Cemical Processinf. Campos Domínguez, C., & Gamse, T. (2016). Process intensification by the use of micro devices for liquid fractionation with supercritical carbon dioxide. Chemical Engineering Research and Design, 108, 1–7. http://doi.org/10.1016/j.cherd.2016.01.011

Multilamelar mixer (Simm V2) High collision mixer

slide-4
SLIDE 4

Mixing efficiency – Test reaction

4

Competitive parallel reaction

𝑌𝑡 = 𝑍 𝑍

𝑇𝑈

𝑌𝑡= Segregation index 𝑍= Y is the ratio of acid mole number consumed by reaction (2) to the total acid mole number 𝑍

𝑇𝑈= Y in the total segregation case when the micromixing process is

infinitely slow

slide-5
SLIDE 5

Villermaux-Dushman Method

 I3

  • detectable 353 nm
slide-6
SLIDE 6

Villermaux-Dushman Method

SIMM-V2 (multilamellar mixer) R300 (SAR/caterpillar mixer) R600 (SAR/caterpillar mixer)

Segregation index (XS) depence on the mixer type and flow rate (Q)

slide-7
SLIDE 7

Precipitation of Bariumsulfate

7

Model reaction: Ba2+ SO4

2-  BaSO4

SIMM-V2 (multilamellar mixer) Batch process

left: particle size distribution for diferent mixers and batch reaction, right: dependence of the mean particle diameter for different mixers

Intensity /%

M4 (high collision mixer) R600 (SAR/caterpillar mixer) R300 (SAR/caterpillar mixer)

Particle Size d/ nm flow rate Q /mL min-1

slide-8
SLIDE 8

Summary and Outlook

  • Mixing has significant influence on reactions
  • Choice of mixer influences reaction and

performance

  • Utilization of microfluidic mixing setups for a

model process

– P/TiO2 process for exemplary process intensification – Fouling remidation studies for exemplary process

slide-9
SLIDE 9
slide-10
SLIDE 10

Villermaux-Dushman Method

𝑌𝑡 = 𝑍 𝑍

𝑇𝑈

𝑌𝑡 = Segregation index 𝑍 = Y is the ratio of acid mole number consumed by reaction (2) to the total acid mole number 𝑍

𝑇𝑈

= Y in the total segregation case when the micromixing process is infinitely slow
