Stress-Free Revit Project Setup Core Services Applied Matt Dillon Director Software Agenda Project Templates Linking Project Data Revit Models CAD Files Creating Levels with Copy Monitor Creating/Managing Views

SLIDE 1

Stress-Free Revit Project Setup

Matt Dillon

Core Services Director

Applied Software

SLIDE 2

Agenda

Project Templates
Linking Project Data
Revit Models
CAD Files
Creating Levels with Copy Monitor
Creating/Managing Views

SLIDE 3

Project setup steps

Start with a Template
Link CAD DWG or Revit Project – Use Origin to Origin
Acquire Coordinates
Establishes shared coordinate system
Subsequent Revit Links should be linked using “Shared Coordinates”
ption
Pin the CAD File/Revit Link
Create Levels and Grids (Copy/Monitor)
Create Views (Use View Templates and View Types)

SLIDE 4

Project Template

Repository for Standards
Line weights/Line styles
Annotation
View settings
Discipline-Specific Settings
Limit Pre-Loaded Content
Annotation Supporting Content
Load Component Families when

needed

SLIDE 5

Linking a revit project

Initial Link – Origin to Origin
Some detective work may be necessary…
Acquire Coordinates
Pin
Subsequent Links – By Shared Coordinates
You may need to have a conversation with other stakeholders…

SLIDE 6

For more in-depth coverage

Google Search: “Matt Dillon – Autodesk Knowledge Network

SLIDE 7

Creating Levels with Copy/Monitor

Copy Levels and Grids from linked projects into current project
Monitor provides notifications of changes in either file with
ptions for resolution.

SLIDE 8

Create and Manage Views

View Templates
Automate the application
f multitudes of view

settings.

Enable standards

management

View Types
Automate the application
f View Templates for new

views

Facilitate Project Browser

Organization

SLIDE 9

Consider Automation

Key to Automation - STANDARDS

SLIDE 10

Review – Project setup steps

Start with a Template
Link CAD DWG or Revit Project – Use Origin to Origin
Acquire Coordinates
Establishes shared coordinate system
Subsequent Revit Links should be linked using “Shared Coordinates”
ption
Pin the CAD File/Revit Link
Create Levels and Grids (Copy/Monitor)
Create Views (Use View Templates and View Types)

SLIDE 11

Thank you for attending our class!

Please fill out the survey for this session in the app. Go to “My Schedule” Select this session Scroll down to “Session Survey”
