Storing Data

CMPT 354: Database I -- Storing Data 2

Review

• Data collection is an important issue

– Dirty data – Multiple sources

• Data collection
• Data consolidation

– Data cleaning – Data integration

CMPT 354: Database I -- Storing Data 3

What Is the Next After We Get Data?

• Store data

– Holders: a paper notebook, a spreadsheet, a relational database, … – We focus on relational tables in this course

• Does a database need some structure? If

so, how to construct the structure?

• How can a user store data into a database?
• Can we prevent two students sharing a

same student-id from happening?

CMPT 354: Database I -- Storing Data 4

Outline

• How to create a relational table?
• How to insert data into a table?
• Integration constraints: making the data

correct

• Data first or schema first?

CMPT 354: Database I -- Storing Data 5

Storing Data in Tables

• For each web page, store the information

about

– URL, language, last update time, number of

• utgoing hyperlinks
• A spreadsheet works!

URL Language Last update # of out links www.sfu.ca HTML

• Sept. 5

45

CMPT 354: Database I -- Storing Data 6

Tables

• Relational databases store data in tables

– A database can have many tables

• Schema: WebPage(URL, language,

update_date, n_out_links)

CMPT 354: Database I -- Storing Data 7

Create a Table

• CREATE statement

CREATE TABLE WebPage ( URL CHAR(256), language CHAR(40), update_date DATETIME, n_out_links INT ) DATETIME is the DATE type in SQL Server

CMPT 354: Database I -- Storing Data 8

Data Types (1)

• Character strings

– Fixed length: CHAR(n) – Varying length, up to n characters: VARCHAR(n)

• Bit strings

– Fixed length: BIT(n) – Varying length, up to n bits: BIT VARYING(n)

• Boolean values BOOLEAN

– TRUE, FALSE, or UNKNOWN

CMPT 354: Database I -- Storing Data 9

Data Types (2)

• Integers INT or INTEGER

– SHORTINT is also supported in some systems

• Floating-point numbers

– FLOAT or REAL – DOUBLE PRECESION – Real numbers with a fixed decimal point: DECIMAL(n, d)

• 123.45 is a possible value of type DECIMAL(5, 2)
• Dates and times

– Exact time: DATE and TIME – Durations of time: INTERVAL

CMPT 354: Database I -- Storing Data 10

Table and Data

• Table itself is not user data!

– Is table data?

• Table is a container of data
• Data is represented as tuples in tables

– Tuple (‘www.sfu.ca’, ‘HTML’, 9/5/2006, 45)

CMPT 354: Database I -- Storing Data 11

Insert a Tuple into a Table

INSERT INTO WebPage(URL, language, update_date, n_out_links) VALUES (‘SFU’, ‘HTML’, ’9/5/2007’, 45)

• The attributes and the corresponding values

must be in the same order

CMPT 354: Database I -- Storing Data 12

Storing Complex Data

• Multimedia objects are often huge

– Music, video, e-books, …

• BLOB: binary large object block
• Complex data can be stored as BLOB’s

– Applications are in charge of handling and explanation

• Databases only store and retrieve BLOB’s

as whole

CMPT 354: Database I -- Storing Data 13

Example

• Extend the WebPage table to store web

page content

ALTER TABLE WebPage ADD content VARCHAR(MAX)

CMPT 354: Database I -- Storing Data 14

Storage in SQL Server – In Row

Figure from http://www.microsoft.com/technet/prodtechnol/sql/2000/reskit/part3/c1161.mspx?mfr=true

CMPT 354: Database I -- Storing Data 15

Storage in SQL Server – Out Row

Figure from http://www.microsoft.com/technet/prodtechnol/sql/2000/reskit/part3/c1161.mspx?mfr=true

CMPT 354: Database I -- Storing Data 16

Tips on Straightforward Design

• In many cases, we can start with one table

containing all attributes we want to store

– Universal table as will be explained later

• NULL value: value unknown, unavailable or

non-applicable

ALTER TABLE WebPage ADD title CHAR(256) INSERT INTO WebPage(URL, language, update_date, n_out_links, title) VALUES (‘www.my_page.net’, ‘HTML’, ‘9/5/2007’, 2, NULL)

CMPT 354: Database I -- Storing Data 17

Integrity Constraints – NOT NULL

• Each web page must have a unique URL

– NULL is not allowed in attribute URL CREATE TABLE WebPage ( URL CHAR(256) NOT NULL, language CHAR(40), update_date DATETIME NOT NULL, n_out_links INT NOT NULL )

CMPT 354: Database I -- Storing Data 18

Integrity Constraints – Primary Key

• Each web page must have a unique URL, an

update time, and the number of out links

– The language of an empty page can be undetermined CREATE TABLE WebPage ( URL CHAR(256) NOT NULL, language CHAR(40), update_date DATETIME NOT NULL, n_out_links INT NOT NULL, primary key (URL) )

CMPT 354: Database I -- Storing Data 19

Data Integrity and Constraints

• Integrity constraints: ensure accuracy and

consistency of data in a database

• Referential integrity: the properties that

should be satisfied when data entries are referenced

– Not NULL – Primary key – More will be discussed later

CMPT 354: Database I -- Storing Data 20

Schema-First or Data-First

• Schema first approaches

– Design a schema, collect data according to the schema – Traditional, well controlled applications: student information systems, library loan systems

• Data first approaches

– Data exists before a database is designed, or evolving data – More and more large applications: integrating data sources on the web (e.g., a database of blogs)

CMPT 354: Database I -- Storing Data 21

Summary

• Creating tables in relational databases
• Inserting tuples into a table
• Specifying integrity constraints

CMPT 354: Database I -- Storing Data 22

To-Do List

• Check the data types in SQL Sever

– Some data types in standard SQL may not be available in SQL Server. Please find their correspondences

• Create a table for web pages in SQL Server

– Record URL, language, update time, number of

• utgoing links, and title

– Use VARCHAR to store content

CMPT 354: Database I -- Storing Data 23

Advanced To-Do List

• How can you extend the web page table to

store the outgoing links?

– Each outgoing link is a URL

• SQL Server 2005 comes with a database
• AdventureWorks. Try to understand what

data is stored in the database
