SLIDE 1

Simple SQL Queries (1)

SLIDE 2

CMPT 354: Database I -- Simple SQL (1) 2

Review

Collecting data
Storing data into databases

– Create relational tables in SQL Server 2005 – Insert tuples into tables – Specifying some integrity constraints

SLIDE 3

CMPT 354: Database I -- Simple SQL (1) 3

What the Next?

Collecting/storing data is not the ultimate

goal

– A database is useless if it can only store data, but cannot answer any queries

Query answering, the major functionality of

databases

– How to ask a query? A query can be arbitrarily complicated – What answer should I expect?

SLIDE 4

CMPT 354: Database I -- Simple SQL (1) 4

Outline

Data and queries
Introduction to SQL
Review: specifying database tables
Maintaining the structures of tables

SLIDE 5

CMPT 354: Database I -- Simple SQL (1) 5

Querying Unstructured Data

Natural language queries

– “I want jokes which are related to the topic of the class today, and can wake my students up” – Data: jokes, no matter where they are, could be come up by people – Hard to be answered by a computer

Keyword search

– Find web stuff related to “jokes, SQL, databases” – A search engine like Google can do it, but the results may not be accurate or even relevant

SLIDE 6

CMPT 354: Database I -- Simple SQL (1) 6

One Result

In meeting with DBA friends one of my friend suggested while searching for “MSSQL Client” Microsoft returns you suggestion as “MySQL Client“. I did not believe it so I tested it myself. He was correct. Here is the screen shot.

http://blog.sqlauthority.com/2007/08/01/sql-server-sql-joke-sql-humor-sql-laugh-search-sql/

SLIDE 7

CMPT 354: Database I -- Simple SQL (1) 7

One More …

www.edream.org/images/blog/117/no-clue.jpg

SLIDE 8

CMPT 354: Database I -- Simple SQL (1) 8

Querying Structured Data

List the students in class CMPT 354

– Student information is well organized in the student database – Each record contains student name, id, email, … – Each record has the same format

Answers should be more accurate than

keyword search

SLIDE 9

CMPT 354: Database I -- Simple SQL (1) 9

Data and Queries

Structured data (tables) Unstructured data (e.g., text) Structured queries SQL, relational databases XML Unstructured queries (e.g., keyword search) Keyword search in text-rich relational databases Information retrieval

SLIDE 10

CMPT 354: Database I -- Simple SQL (1) 10

History

IBM Sequel language

– Part of the System R project at the IBM San Jose Research Laboratory (http://www.mcjones.org/ System_R/SQL_Reunion_95/SRC-1997-018.pdf)

Renamed Structured Query Language (SQL)
ANSI and ISO standard SQL:

– SQL-86, 89, 92 – SQL:1999 (Y2K compliant language name), SQL:2003

Commercial systems offer most, if not all, SQL-92

features, plus varying feature sets from later standards and special proprietary features

SLIDE 11

CMPT 354: Database I -- Simple SQL (1) 11

What Can SQL Do?

Define databases

– What kinds of data? (e.g., names are character strings) – How to store them? (e.g., in alphabetical order) – Quality control (e.g., age cannot be negative)

Retrieve data from databases

– Which attributes are needed? – Which tuples should be retrieved?

Access control (e.g., only instructors can assign

final grades)

Interface to other language / development tools

(e.g., C/C++, Java, 4GL, etc.)

SLIDE 12

CMPT 354: Database I -- Simple SQL (1) 12

Parts in SQL

Data definition language (DDL)
Interactive data-manipulation language

(DML)

Integrity
View definition
Transaction control
Embedded SQL and dynamic SQL
Authorization

SLIDE 13

CMPT 354: Database I -- Simple SQL (1) 13

Data Definition Language (DDL)

Specification of tables

– A table is also called a relation

The schema for each table
The domain of values associated with each

attribute

Integrity constraints
The set of indices to be maintained for each

relations

Security and authorization information for each

relation

The physical storage structure of each relation on

disk

SLIDE 14

CMPT 354: Database I -- Simple SQL (1) 14

Tables (Relations)

Attributes (columns, dimensions)

– Attribute names are not stored explicitly in the table, they are stored in a meta-data table

Tuples (records, rows)

– Each tuple has a (internal) row-id, explained as the address of the tuple Attributes (columns, dimensions) Tuples (records, rows)

SLIDE 15

CMPT 354: Database I -- Simple SQL (1) 15

Tables and Spreadsheets

Tables are typed – each attribute has a pre-

defined data type

– Spreadsheet can be of undefined data type

Disadvantages of spreadsheets

– Lack of auditing and revision control – Lack of security – Lack of concurrency: unlike databases, spreadsheets typically allow only one user to be making changes at any given time – Prone to errors due to entering information incorrectly or in the wrong place

SLIDE 16

CMPT 354: Database I -- Simple SQL (1) 16

Do You Know? (from Wikipedia)

The concept of an electronic spreadsheet – "Budgeting

Models and System Simulation" (Richard Mattessich, 1961)

Rene K. Pardo and Remy Landau filed U.S. Patent

4,398,249 on some related algorithms in 1970

– While the patent was initially rejected by the patent office as being a purely mathematical invention, Pardo and Landau won a court case in 1983 establishing that "something does not cease to become patentable merely because the point of novelty is in an algorithm." This case helped establish the viability of software patents.

Dan Bricklin: the generally recognized inventor of

spreadsheets as a commercial product for the personal computer

VisiCalc, the first application turning the personal computer

from a hobby for computer enthusiasts into a business tool

SLIDE 17

CMPT 354: Database I -- Simple SQL (1) 17

Inventors of SpreadSheets

Richard Mattessich

SLIDE 18

CMPT 354: Database I -- Simple SQL (1) 18

Basic Types in SQL

char(n): Fixed length character string, with user-specified

length n

varchar(n): Variable length character strings, with user-

specified maximum length n

int: Integer (a finite subset of the integers that is machine-

dependent)

– smallint: Small integer (a machine-dependent subset of the integer domain type)

numeric(p,d): Fixed point number, with user-specified

precision of p digits, with n digits to the right of decimal point

– real, double precision: Floating point and double-precision floating point numbers, with machine-dependent precision – float(n): Floating point number, with user-specified precision of at least n digits.

SLIDE 19

CMPT 354: Database I -- Simple SQL (1) 19

Tables and User Data

Tables are holders of user data

– Only data fitting the type requirement can be held – A table can be empty

Data in applications are independent of

tables

– Tables can be defined properly to hold data – Data can be preprocessed properly to fit tables

Both tables and data can be modified

SLIDE 20

CMPT 354: Database I -- Simple SQL (1) 20

Review: Create a Table

The create table command:

create table r (A1 D1, A2 D2, ..., An Dn, (integrity-constraint1), ..., (integrity-constraintk))

Example:

create table branch (branch_name char(15) not null, branch_city char(30), assets integer)

SLIDE 21

CMPT 354: Database I -- Simple SQL (1) 21

Drop Table Construct

Delete all information about the dropped

relation from the database

– drop table r

Delete all tuples from a table

– delete from r

Tips: how to delete all tuples in a large table

efficiently?

– Drop the table and then recreate it – Why?

SLIDE 22

CMPT 354: Database I -- Simple SQL (1) 22

Alter Table Constructs

Add attributes to an existing relation

alter table r add A D

– A is the name of the attribute to be added to relation r, and D is the domain of A – All tuples in the relation are assigned null as the value for the new attribute.

Drop attributes of a relation:

alter table r drop column A

– A is the name of an attribute of relation r – Dropping attributes is not supported by many databases (why?)

SLIDE 23

CMPT 354: Database I -- Simple SQL (1) 23

Summary

Data and queries

– Different data allows different kinds of queries – Different queries may lead to different quality (e.g., accuracy)

SQL

– DDL: data definition language – DML: data manipulation language

Maintaining tables in relational databases

SLIDE 24

CMPT 354: Database I -- Simple SQL (1) 24

To Do List

Create a table in SQL Server, modify its

structure by adding new attributes, changing data types of attributes, and removing some attributes

Does SQL Server allow deleting an
